Spear & Jackson SCM32C User manual

IN THE BOX QUICK START
GUIDE
Important - Please read these instructions
fully before starting assembly
These instructions contain important information that will help
you get the best from your mower, ensuring it is assembled correctly
and safely. If you need help or have damaged or missing parts,
call the Customer Helpline on 0345 605 2067
AFTER SALES SUPPORT
0345 605 2067
32cm 400W
Electric Cylinder
Lawnmower
SCM32C
S4032EC
2
3
11
14
5
1
10
4
6
7
8
9
12
13
15 16
Switch box
Power cable
Locking knob x4pcs
Cable hooks
Upper handle
Middle handle
Lower handle
Carry handle
Motor housing
Height adjustment handle
Rear roller
Blade
Front roller
Cable clip x 2pcs
Cable retainer
1
2
8
3
4
5
6
7
9
10
11
12
13
14
15
16

ASSEMBLE PREPARE OPERATE
1
2
10
1 2
4
3
Locate the lower handle to the slot on deck,
and tighten the lower handle fixing knobs(14)
on both sides.
Slide the cord retainer onto the middle handle,
sliding it around to the top of the handle
so it does not fall off during the following
assembly steps.
1
7 8
9
Double the extension cord, about a
foot from the end. Hook the loop over
the cord strain.
Connect the plug to the main socket.
6
5
10 11
Press the button (1). Pull the switch
bar (2) towards the handle and hold in
position.
When you begin to mow please follow
the arrow, avoiding twisting the power
cord or the risk of cutting the cord.
1
2
Secure the upper handle to the middle
handle frame with the locking knob and
bolts provided.
Attach the grass bag to the frame by fixing
all plastic hooks. The grass bag front plate
(A) is at the original position, need
assemble.
A
Lift & rotate the front plate until the locking
tab clips (B) over the frame.
B
When assembling the grass bag onto the
machine, lift the front plate(A) cross strap
and locate the 2pins into the slot holes on
the deck.
1
2
Pull the lever outwards from the machine
and then select your required cutting
height position 1-2-3. Release the lever
and then make sure that it is fully secured
into the selected cutting position.
12
Release the switch bar to switch t
he mower off.
O
