Speco Sp6pb User manual

6” Pendant Mount Speaker with Optional Ground or Wall Mount

Thank you for your choice of Speco Technologies’ SP6P combination speaker. This unit is designed and manufactured to

provide an extremely versatile solution for background music and paging. Out of the box, the SP6P is a pendant speaker. With

the optional mounting kits, the speaker can also be mounted on a wall or in the ground as a landscape speaker.

SPEAKER FEATURES:

1) Transformer Dial to determine speaker power (Only on SP6PTB and SP6PTW). Use a flat-edged screwdriver and turn until the left

end of the groove points towards the power value you desire. Options are 32W, 16W, 8W, 4W, and 8 Ohms. For all settings but 8

Ohms use a 70 or 25V amplifier (depending on what you set #3 to). For 8 Ohms, use an 8 Ohms amplifier.

2) Socket for pendant mount eye-bolt. Eye-bolt should be inserted through Speaker Top A described below.

3) Transformer selection switch (Only on SP6PTB and SP6PTW). Alternate between 70V and 25V. This switch should never be used

while speaker is live on an amplifier. Connecting the speaker to the wrong amplifier could damage your speaker or amplifier.

4) Speaker terminal (phoenix connector). Use this to connect to your amplifier and to another speaker. Please consult an expert if you

are not familiar with proper wiring practices.

5) Landscape/Wall-mount wire channel. Insert speaker wire under metal bar to fortify installation.

INSTALLATION INSTRUCTIONS:

1) All speaker adjustments must be made either before connection to amplifier or while amplifier is off to avoid potential damage to

equipment.

2) If you have the SP6PTB or SP6PTW, select first which voltage you are using via the switch described in #3 above. Then, select the

speaker wattage you want via the dial described in #1 above.

3) If you have the SP6PB or SP6PW, no adjustments are necessary.

4) There are two speaker tops that come in your package. The

difference is easily identifiable as one will have a built-in screw

(B), and one has two openings (A). (Pictured right)

5) Top A is the top you will use if you did not purchase the

optional mounting kit and wish to pendant mount the speaker.

To install with top A, you will need to run your speaker wire

through the top prior to connecting to the phoenix connector.

Connect the positive wire running from your amp or adjacent

speaker to one of the (+) terminals on the connector. Connect

the negative wire running from your amp or adjacent speaker

to one of the (-) terminals on the connector. If you are daisy-

chaining 70V/25V speakers, use the second (+) and (-) terminals

to connect to that speaker and repeat. (Pictured following

page)

6) Place the phoenix connector into the cradle on the top of the speaker. Make sure it’s firmly connected.

7) Line up top A so that the notch on the top meets the cutout on the speaker. (Pictured below)

8) The pendant mount eye-bolt will come with a nut and locking washer (Pictured below). Tighten the nut to the top and place the

washer underneath.

9) Place the eye-bolt in the hole in the center of top A and screw all the way until you meet resistance. Tighten carefully at that point

until you can no longer tighten the bolt. (Pictured below) Your speaker is ready to hang. Be sure the chain running to the building

structure is strong enough to support the speaker and securely fastened.

10) If you purchased SP6PMNT (Black Ground Mount/White Wall Mount) or SP6PMNTB (Black Ground Mount/Black Wall Mount), you

will use top B. This time, you want to mount the speaker wire under the metal bar in #5 pictured above and run it through the

speaker wire channel. (Pictured Below)

11) Top B is very easy to attach. Just insert the built-in screw into the hole in the center of the top of the speaker and spin until tight.

(Pictured Below) Specific instructions for connecting the mounting accessories are included with the mounting kits.

SPECIFICATIONS:

 Power: 32W RMS, 64W Max

 Frequency Response: 98Hz ~20kHz

 Transformer (SP6PTW and SP6PTB only): Selectable 70/25V transformer with settings of 32W, 16W, 8W, 4W & 8 Ohms

 Sensitivity: 88dB (1W/1M)

 Termination Type: Phoenix connector

 Dimensions: 8.1" (Diameter) x 12.6" (H)

 Weight: 7 pounds

 Optional ground and wall mount kits:

o SP6PMNT – Black ground mount with white wall mount

o SP6PMNTB – Black ground mount with black wall mount

WARRANTY INFORMATION:

We warranty this product to be free from any manufacturing or material defects for 5 years from date of purchase.

This warranty will not extend to any products which have been subjected to misuse, neglect, accident, or improper installation, used in violation of instructions furnished by us; or to units

which have been repaired or altered outside of the factory. This limited warranty does not apply to broken cases, batteries, or other physically damaged parts. If a Speco Technologies product

is purchased from an unauthorized distributor or other source, including RETAILERS, MAIL ORDER SELLERS and ONLINE SELLERS, it will not be honored or serviced under existing Speco

Technologies warranty policy. Any sale of products by an unauthorized source or other manner not authorized by Speco Technologies will void the warranty on the applicable product.

Upon request by customer, Speco Technologies (“The Company”) will, at customer's expense, repackage merchandise in new cartons, replace missing accessories, and return in resalable

condition. Unless requested, the company will replace and return all merchandise in the packaging in which it was received. This warranty is in lieu of all expressed warranties, expressed or

implied, and of all obligations or liability on our part, and we neither assume nor authorize any representative or other person to assume for us any obligation or liability. In no event shall we

be liable for incidental or consequential damages arising from the use of the product, or for any delay in the use of this product due to causes beyond our control. Some states do not allow

limitations of how long an implied warranty lasts and/or do not allow the exclusion or limitation of consequential damages. The above limitations on implied warranty and consequential

damages may not apply to you. This warranty gives you specific legal rights. You may have other rights which vary from state to state. This limited warranty extends to products listed in the

company's current price schedule.

Speco Technologies is constantly developing and improving products.

We reserve the right to modify product design and specifications without notice and without incurring any obligation.

Speco Technologies . 200 New Highway . Amityville . NY . 11701 . www.specotech.com

Rev. 05/24/16
