Speco P16S18 User manual

!
!
P16
P16S S18 18&–&18-Port&Switch,&16-Ports&802.3at/af&PoE&
!
Thank!you!for!your!choice!of!Speco!Technologies’!P16S18!IP!camera!accessory.!!This!unit!is!designed!and!
manufactured!to!provide!an!economical!solution!for!powering!IP!cameras!via!Power!over!Ethernet.!!The!sturdy!
construction!of!these!units!ensures!a!long!&!productive!life.!
!
IN&THIS&BOX&
1!x!PoE!Switch!
1!x!AC!Power!Cable!
1!x!Mounting!Accessories!
!
DESCRIPTION&
The!P16S18!consists!of!a!single!chassis!with!18!RJ-45!connectors.!These!units!are!designed!to!provide!PoE!power!
for!up!to!16!PoE!ready!IP!cameras.!
!
&
INSTALLATION&INSTRUCTIONS:&
1) Turn!off!power!to!the!units!and!sources.!!Installing!the!P16S18!while!power!is!live!may!damage!the!units.!
2) Use!an!RJ45!network!cable!to!connect!a!POE!capable!IP!camera!with!any!or!all!of!the!P16SW18!ports!1-16.!
3) Use!an!RJ45!network!cable!to!connect!your!recording!device!(NVR,!Hybrid!DVR,!etc.)!with!the!P16S18!
uplink!ports.!
4) Connect!the!power!adapter.!
5) Confirm!all!cables!are!connected!securely!and!properly!and!power!on!all!units.!
&
NOTE:&CCTV&Isolate/Default&switch&function:&Activation&of&this&switch&will&isolate&downlink&ports&and&thus&prevent&ports&from&
sharing&data.&&This,&in&turn,&could&improve&data&forwarding&efficiency,&port&bandwidth&utilization&and&system&security.&
IMPORTANT:&Using&this&feature&will&slow&ports&to&10MBPS&speed,&so&it&is&recommended&to&keep&switch&on&default&unless&you&
have&a&specific&application.&
!
& &

SPECIFICATIONS:&
•Downlink!Ethernet!Ports:!! ! 16×10/!100Base-TX!PoE+!
•Uplink!Ethernet!Ports:!! ! 2×10/100/1000Base-T+1×1000Base-X(combo)!
•Power!Input:! ! ! !1×AC!Female!Terminal!
•Grounding!Terminal:!!!!1×Grounding!Terminal!
•Power!Input:!!!!Mains!on!load,!100～240VAC!50/!60Hz!
•PoE!Power!Supply:!!!!!Endspan!(1/2,!3/6),!IEEE802.3!af/!at!
•PoE!Max.!Power!Output:! ! !180W!
•Single!Port!Power!Output!&!Voltage:!! ≤30W,!Voltage!54VDC!
•CCTV!Mode:!!!!!1.!Downlink!ports!only!communicate!with!uplink!ports;!
2.!Restrain!network!storm!under!2Mbps;!
3.!Extend!transmission!distance!to!250m;!
4.!Rate:!10Mbps!(Downlink!Ports)!
•Network!Standards:! ! ! !IEEE!802.3,IEEE!802.3u,IEEE!802.3ab,IEEE!802.3z!
•Maximum!Transmission!Distance:!!328’!(100m)!
•Exchange!Capacity:!! ! ! 7.2Gbps!
•Packet!Transfer!Rate:!!!!5.36Mpps!
•MAC!Address:!!!!4K!
•Packet!Data!Cache:! ! ! 2.75Mb!
•Indicator!Status:!!!!1.!!Power!Input:!1x!Red!LED!
2. Downlink!Ethernet!Ports:!16x!Green!LED!
3. PoE:!16x!Yellow!LED!
4. Uplink!Ethernet!Port:!2x!Green!LED!
5. PoE!Power!Output!Percent:!5x!LED(Including!3x!Green,!1x!Yellow,!1x!
Red!-!!separately!indicates!30%、60%、90%、95%～100%)!
•ESD:!!!!!6KV/8KV,!Per:IEC61000-4-2!
•Surge!Protection:!!!6KV,!Per:!IEC61000-!4-!5!
•Operation!Temperature:!! ! 14F!to!114F!(-10!to!45C)!
•Storage!Temperature:!! ! -40F!to!185F!(-40C-85C)!
•Humidity!(Non-!condensing):!! ! 0～95%!
•Dimensions!(LxWxH):!!!!17.4”!x!11.2”!x!1.8”!(442mmx285mmx44.5mm)!
•Weight:!!!!!2.2!Lbs!
•Warranty:!2!Years!(please!visit!Specotech.com!for!full!warranty!terms!and!conditions)!
!
TROUBLESHOOTING!TIPS!
•Please!make!sure!you!have!carefully!followed!instructions!
•Please!confirm!the!RJ45!cable!being!used!is!in!accordance!with!the!EIA/TIA568A!or!568B!industry!standards!
•Please!make!sure!no!more!than!30W!of!power!is!being!put!onto!any!one!port!and!that!the!total!combined!power!of!
all!cameras!or!accessories!does!not!exceed!180W!
•If!possible,!try!the!same!equipment!with!another!PoE!switch!to!confirm!if!your!switch!might!be!at!fault!
!
!
!
!
!
!
!
Speco!Technologies!is!constantly!developing!and!improving!products.!!
We!reserve!the!right!to!modify!product!design!and!specifications!without!notice!and!without!incurring!any!obligation.!
Speco Technologies . 200 New Highway . Amityville . NY . 11701 . www.specotech.com
Rev. 04/17/18.
