Speed Queen ST025 User manual

On-Premises
Sin le Pocket Dryin Tumblers
A Passion to Lead
25 lb (11.3 kg) DryingTumbler
30 lb (13.9 kg) DryingTumbler
35 lb (15.9 kg) DryingTumbler
55 lb (24.9 kg) DryingTumbler

Dual Di ital
Dual digital timer
control models
enable operators
to set drying time
(0-60 minutes),
cool down time
(1-15 minutes) and temperature (High, Medium,
Low, No Heat). Features include one-touch cycle
repeat, automatic extended tumble, and large digital
time countdown display.
Classic Durability
For more than 100 years, the Speed Queen name
has been synonymous with quality construction.That
reputation continues today. All our commercial tumblers
are built on heavy-duty frames and utilize extremely
durable internal components. Our commitment to
quality ensures your laundry receives years of service
from Speed Queen products.
Efficiency = Profitability
The faster and more efficient your tumblers are, the
more profitable your business is. Speed Queen’s
single pocket tumbler models in 25, 30, 35 and the
recently added 55 lb unit feature an axial airflow process.
This pattern ensures heated air comes in contact with
the load at the optimum time in the tumble process.
Bottom line? t’s the fastest, most efficient drying process
to save your operation in utility costs.
Speed Queen On-Premises
Sin le Pocket Dryin Tumblers
The on-premises laundry business is changing. Managers
today must be flexible in adapting quickly to changes to
linen processing formulas, while keeping operating costs
within budget. Features that a few years ago were
considered luxuries are now essential components to
doing business.
Speed Queen is dedicated to giving managers the
power to respond instantly to changes in order to
produce superior wash quality. Programming ease
and user-friendly operation ensure our technology
makes your life easier, not more complicated.
MicroMaster2
The MicroMaster2
dryers feature an
automatic drying
cycle, or time dry.
As the automatic
cycle reaches the
appropriate dryness level, the dryer begins the cool
down process. Automatic dry cycles have factory-set
dryness levels; other settings can be created. Operators
can save frequently used settings as custom cycles.
Fabric type also can be a cycle selection. Preset
temperatures for various fabrics simplify drying.
ndicator lights inform users of cycle status. Special
Cycle specifies the number and temperature of
heating cycles and allows users to select cycle
frequency from heat-on to heat-off.

An Easy Open-and-Shut Case
Extra-large stainless steel doors and heavy-duty hinges
ensure they can stand up to the repeated use of high-
volume commercial laundries.
Belt-drive Simplicity
Speed Queen commercial dryers feature an all-belt
drive system, which means they’re less noisy than others
in the market. And because the units utilize self-adjusting
belts, maintenance costs are reduced.
Fast Heatin
Our high-performance burners ignite instantly, providing
the desired temperature quickly and efficiently distrib-
uting even heat.This means reduced drying times and
energy savings.
C.A.R.E.®System
For laundries desiring an additional layer of security in
when it comes to the threat of laundry combustion
within the tumbler cylinder, Speed Queen offers its
Combustion Auto Response Equipped (C.A.R.E.)
system as an option on 50 lb and 75 lb tumblers.
C.A.R.E. monitors for excessive cylinder temperatures
and sprays water on the load should it register an
abnormally high reading.A “system active” signal also
can be sent to a property’s alarm system or
another device.
Less Lint Clean-Up
A fine mesh lint screen cleans itself automatically, depositing
lint into a large storage area for easy removal.The size
of the compartment translates into emptying it once a
day versus three times a day — saving time.
Warranty
Speed Queen’s commitment to customers comes with
an industry-leading warranty, which starts with a three-
year* limited parts warranty. To us, building the best
machines on the market doesn’t mean much if we’re
not willing to also take the lead in standing behind them.
As a Speed Queen customer, you’ll never have to worry
about our bond.
* Parts only, labor not included. See Speed Queen Warranty Bond for specifics.

www.speedqueen.com
AO09-201
Tumb er mode s are made to suit a variety of e ectrica service characteristics. See your Speed Queen distributor for specifications. For further detai s on insta ation, refer
to Insta ation, Operation and Maintenance instructions supp ied with the tumb er. Amperage ratings avai ab e in Insta ation Manua .
For the most accurate information, the insta ation guide shou d be used for a design and construction purposes. Due to continuous product improvements, design and
specifications subject to change without notice. The qua ity management system of A iance Laundry Systems’ Ripon faci ity has been registered to ISO 9001:2000.
©Copyright 2009 Alliance Laundry Systems LLC
OPL Single Pocket Drying Tumblers Specifications
ST025 ST030 ST035 ST055
Control Option MicroMaster2, Dual Digital MicroMaster2, Dual Digital MicroMaster2, Dual Digital MicroMaster2, Dual Digital
Dry Capacity - lb (kg) 25 (11.3) 30 (13.6) 35 (15.9) 55 (24.9)
Filling Ratio 20:1 = 10.9 kg 20:1 = 13.6 kg 20:1 = 17. 4 kg 20:1 = 24. 6 kg
Width - in (mm) 28" (711) 28" (711) 31 1/2" (800) 34 1/2" (876)
Depth - in (mm) 40 7/8" (1038) 46 7/8" (1191) 46 7/8" (1191) 53 5/8" (1362)
Height - in (mm) 63 7/8" (1622) 63 7/8" (1622) 63 7/8" (1622) 66 3/4" (1695)
Cylinder Depth - in (mm) 24" (610) 30" (762) 30" (762) 35" (889)
Cylinder Diameter - in (mm) 26 1/2" (673) 26 1/2" (673) 30" (762) 33" (838)
Cylinder Volume - cu. ft. (liters) 7.7 (217) 9.6 (271) 12.3 (347) 17.3 (491)
Door Opening Size - in (mm) 22 11/16" (576) 22 11/16" (576) 22 11/16" (576) 26 7/8" (683)
Airflow - cfm (liter/sec) 60 Hz: 500 (236) 60 Hz: 500 (236) 60 Hz: 650 (307) 60 Hz: 700 (330)
50 Hz: 430 (203) 50 Hz: 430 (203) 50 Hz: 550 (260) 50 Hz: 600 (283)
Air Outlet Diameter - in (mm) 6" (152) 6" (152) 8" (203) 8" (203)
Energy Data Gas 60Hz - 64,000 Btu/hr (18.8 kW) 60Hz - 73,000 Btu/hr (21.4 kW) 60Hz - 90,000 Btu/hr (26.4 kW) 60Hz - 112,000 Btu/hr (32.8 kW)
50Hz - 64,000 Btu/hr (18.8 kW) 50Hz - 73,000 Btu/hr (21.4 kW) 50Hz - 90,000 Btu/hr (26.4 kW) 50Hz - 102,000 Btu/hr (29.9 kW)
Steam At 100 psi (6.9 bar): 3.9 BHP, At 100 psi (6.9 bar): 3.9 BHP, At 100 psi (6.9 bar): 4.8 BHP, –
135,000 Btu/hr (39.6 kW) 135,000 Btu/hr (39.6 kW) 166,000 Btu/hr (48.6 kW) –
At 15 psi (1.0 bar): 2.6 BHP, At 15 psi (1.0 bar): 2.6 BHP, At 15 psi (1.0 bar): 3.7 BHP, –
90,000 Btu/hr (26.4 kW) 90,000 Btu/hr (26.4 kW) 129,000 Btu/hr (37.8 kW) –
Electric 12 kW 21 kW 24 kW 27 kW
Electrical Specifications Gas and Steam Amps Amps Amps Amps
100/200–220/60/1; 2W+G 11.0/5.8 11.0/5.8 11.0/5.8 9.8/4.9
120/208-240/60/1; 2W/3W+G 12.0/6.7 12.0/6.7 12.0/6.7 9.2/6.5
200-208/240/60/3; 3W+G 3.2/3.2 3.2/3.2 3.2/3.2 4.0/3.9
380/60/3; 3W+G 1.5 1.5 1.5 –
460-480/60/3; 3W+G 1.6 1.6 1.6 –
100/200/50/1; 2W+G 12.1/7.5 12.1/7.5 12.1/7.5 10.0/6.2
230–240/50/1; 2W+G 7.5 7.5 7.5 5.5
200/50/3; 3W+G 2.9 2.9 2.9 –
230–240/50/3; 3W+G 3.5 3.5 3.5 –
380/50/3; 3W+G –––2.0
400-415/50/3;3W+G –––2.0
380/400–415/50/3; 3W+G 1.5/1.6 1.5/1.6 1.5/1.6 –
Electric
208/60/1; 3W+G 64 108 122 129
240/60/1; 3W+G 57 94 107 115
200/60/1; 2W+G 64 108 122 125
200-208/60/3; 3W+G 37 62 71 79
240/60/3; 3W+G 33 54 62 65
380/60/3; 3W+G 20 33 38 –
460–480/60/3; 3W+G 16 27 31 –
200/50/1; 2W+G 63 105 119 131
230–240/50/1; 2W+G 58 95 108 119
200/50/3; 3W+G 36 60 65 –
230-240/50/3; 3W+G 33 55 62 –
380/50/3; 3W+G 20 33 38 43
400–415/50/3; 3W+G 18 31 35 38
Motor Size - HP (W) Fan 1/4 (187) 1/4 (187) 1/4 (187) 1/2 (375)
Cylinder 1/4 (187) 1/4 (187) 1/4 (187) 1/2 (375)
Plumbing Connections Gas 1/2" - PT 1/2" - PT 1/2" - PT 1/2" - PT
Steam 3/4" - PT 3/4" - PT 3/4" - PT –
Width 30" (762) 30" (762) 33" (838) 35 1/2" (902)
Depth 43" (1092) 49" (1245) 49" (1245) 59" (1499)
Height 69" (1753) 69" (1753) 69" (1753) 72" (1829)
et Weight - lb (kg) 299 (135) 331 (150) 361 (164) 435 (197)
Shipping Weight - lb (kg) 332 (151) 364 (165) 394 (179) 476 (216)
Agency Approvals Gas CSA Star, CSA Flame, cCSAus, CE, CSA Star, CSA Flame, cCSAus, CE, CSA Star, CSA Flame, cCSAus, CE, CSA Star, CSA Flame, cCSAus, CE,
Australia Gas Australia Gas Australia Gas Australia Gas
Electrical & Steam cCSAus, CE cCSAus, CE cCSAus, CE cCSAus, CE
Shipping Dimensions
Approx. - in (mm)
