Vended
Coin/Card-Op rat d Singl Pock t Drying Tumbl rs
A Passion to Lead
50 lb (22.7 kg) Drying Tumbler
75 lb (34.0 kg) Drying Tumbler

Micro-Display (MDC)
This control’s
digital display
can give your
laundry a
high-tech look.
Our icro-
Display Control
( DC) shows vend price, while customers stay informed
during operation with its digital cycle countdown. Like
Quantum™ Gold, the DC can interface with the
store owner’s card manufacturer of choice.
Classic Durability
For more than 100 years, the Speed Queen name
has been synonymous with quality construction.That
reputation continues today. All our commercial tumblers
are built on heavy-duty frames and utilize extremely
durable internal components. Our commitment to
quality ensures your laundry receives years of service
from Speed Queen products.
Effici ncy = Profitability
The faster and more efficient your dryers are, the more
more profitable your store will be. Speed Queen’s
Quantum™Syst m
Coin or Card-Op rat d
The vended laundry business is changing. Owners today
need the versatility to adapt quickly to fluctuations in
operating expenses and customers’ needs. Features that a
few years ago were considered luxuries are now essential
components to doing business.
Speed Queen’s cutting-edge Quantum™ System,
gives owners the power to respond instantly to
changes in order to maximize their store’s profitability.
A Quantum™ Gold networked store is the ultimate
in management ease, enabling owners to modify vend
prices or cycles from the comfort of their own home
or anywhere they have access to a computer. Operations
reports and machine data further assist with manage-
ment and identifying any potential service problems.
With Speed Queen’s advanced network technology
and efficient equipment in your store, you’ll be assured
you’re ready to do business in the Quantum™ world.
Quantum™Gold
Quantum™
Gold keeps
owners on
top of their
business with
advanced
functions such
as special and time-of-day pricing. Operations reports
are easily downloaded to PC or PDA. However, for the
greatest ease, networking your Quantum™ Gold store
enables you to make changes from your computer any-
where in the world … that’s life in the Quantum™World.

50 and 75 lb dryers feature large cylinders and a design
that emphasizes speed and efficiency. These commercial
dryers are perfect for drying oversized items such as
quilts and your customers’ largest loads.
An Easy Op n-and-Shut Cas
An extra-large stainless steel door and heavy-duty hinge
ensure both can stand up to the repeated use of high-
traffic vended laundries.The door also is reversible
enabling owners to install it to open to the left or right,
for greater customer satisfaction.
B lt-driv Simplicity
Speed Queen commercial dryers feature an all-belt
drive system, which means they’re less noisy than others
in the market. And because the units utilize self-adjusting
belts, maintenance costs are reduced.
Th Hol Story
Vended laundry owners know all too well that drywall
screws, left behind in clothes, can cause extensive damage
to the metal surrounding the cylinder. Our patented
cylinder design allows drywall screws to pass through
oval perforations and saves store owners from the
annoyances of reduced efficiency and expensive
replacement parts.
Fast H ating
Our high-performance burners ignite instantly, providing
the desired temperature quickly and efficiently distribut-
ing even heat.This means reduced drying times and
energy savings.
L ss Lint Cl an-Up
A fine mesh lint screen cleans itself automatically, depositing
lint into a large storage area for easy removal.The size of
the compartment translates into emptying it once a day
versus three times a day — saving time.
Warranty
Speed Queen’s commitment to customers comes with
an industry-leading warranty, which starts with a three-
year* limited parts warranty. To us, building the best
machines on the market doesn’t mean much if we’re
not willing to also take the lead in standing behind them.
As a Speed Queen customer, you’ll never have to worry
about our bond.
* Parts only, labor not included. See Speed Queen Warranty Bond for specifics.
Activation F atur s
Coin Mod ls
Speed Queen’s drying tumblers are factory equipped
with high security coin drops.
Five checks are used to validate the coin and invalid coins
are returned through a reject slot.
Card R ady Mod ls
Speed Queen’s drying tumblers are card-ready for
interfacing with a card reader supplier of choice.

www.speedqueen.com
AC09-203
Vended Single Pocket Drying Tumblers Specifications
Tumb er mode s are made to suit a variety of e ectrica service characteristics. See your Speed Queen distributor for specifications. For further detai s on insta ation, refer
to Insta ation, Operation and Maintenance instructions supp ied with the tumb er. Amperage ratings avai ab e in Insta ation Manua .
For the most accurate information, the insta ation guide shou d be used for a design and construction purposes. Due to continuous product improvements, design and
specifications subject to change without notice. The qua ity management system of A iance Laundry Systems’ Ripon faci ity has been registered to ISO 9001:2000.
©Copyright 2009 Alliance Laundry Systems LLC
ST050 ST075
Control Option Gold, DC Gold, DC
Dry Capacity - lb (kg) 50 (22.7) 70 (34.0)
Filling Ratio 20:1 = 26.4 kg 20:1 = 31.7 kg
Width - in (mm) 38 5/8" (981) 38 5/8" (981)
Depth - in (mm) 47" (1194) 53" (1346)
Height - in (mm) 76 5/8" (1946) 76 5/8" (1946)
Cylinder Depth - in (mm) 30" (762) 36" (914)
Cylinder Diameter - in (mm) 37" (939) 37" (939)
Cylinder Volume - cu. ft. (liters) 18.6 (528) 22.4 (634)
Door Opening Size - in (mm) 26 7/8" (683) 26 7/8" (683)
Airflow - cfm (liter/sec) 60 Hz: 750 (354) 60 Hz: 920 (434)
50 Hz: 750 (354) 50 Hz: 750 (354)
Air Outlet Diameter - in (mm) 8" (203) 8" (203)
Energy Data Gas 60Hz - 130,000 Btu/hr (38.1 kW) 60Hz - 165,000 Btu/hr (48.3 kW)
50Hz - 130,000 Btu/hr (38.1 kW) 50Hz - 165,000 Btu/hr (48.3 kW)
Steam At 100 psi (6.9 bar): 5.1 BHP, At 100 psi (6.9 bar): 6.1 BHP,
178,000 Btu/hr (52.0 kW) 210,000 Btu/hr (61.6 kW)
At 15 psi (1.0 bar): 3.4 BHP, At 15 psi (1.0 bar): 4.1 BHP,
119,000 Btu/hr (34.8 kW) 141,000 Btu/hr (41.2 kW)
Electric 30 kW 30 kW
Electrical Specifications Gas and Steam Amps Amps
120/60/1; 2W+G 9.3 13.8
200-208/240/60/1; 2W+G 5.1/5.1 7.6/7.6
200-208/240/60/3; 3W+G 2.8/2.8 (4.0/4.0) 3.8/3.8 (4.3/4.3)
380/60/3; 3W+G 1.6 (2.0) 1.8 (2.1)
(Steam Only) 440/60/3; 3W+G 1.4 (1.9) 1.9 (2.1)
460–480/60/3; 3W+G 1.4 (1.9) 1.9 (2.1)
230–240/50/1; 2W+G 6.3 (6.9) 6.7 (7.0)
200/50/3; 3W+G 3.3 (4.2) 3.5 (4.5)
230–240/50/3; 3W+G 3.1 (4.3) 3.5 (4.9)
380/400–415/50/3; 3W+G 1.6/1.6 (2.0/2.0) 1.8/1.8 (2.1/2.1)
Electric
200–208/60/3; 3W+G 89 (88) 89 (88)
240/60/3; 3W+G 79 (78) 79 (78)
380/60/3; 3W+G 47 (48) 47 (48)
440/60/3; 3W+G 41 (41) 41 (41)
480/60/3; 3W+G 38 (38) 38 (38)
(21kW heater only) 240/50/1; 2W+G 93 (95) –
200/50/3; 3W+G 84 (85) 84 (85)
230/50/3; 3W+G 73 (75) 73 (75)
240/50/3; 3W+G 79 (78) 79 (78)
380/50/3; 3W+G 47 (48) 47 (48)
400–415/50/3; 3W+G 43 (44) 43 (44)
Motor Size - HP (W) Fan 1/2 (375) 3/4 (559)
Cylinder 1/2 (375) 3/4 (559)
Plumbing Connections Gas 1/2" - PT 1/2" - PT
Steam 3/4" - PT 3/4" - PT
Width 41 1/2" (1054) 41 1/2" (1054)
Depth 52 1/8" (1323) 56 13/32" (1433)
Height 81" (2057) 81" (2057)
et Weight - lb (kg) 545 (247) 615 (279)
Shipping Weight - lb (kg) 602 (273) 677 (307)
Agency Approvals Gas CSA Star, CSA Flame, cCSAus, CE, CSA Star, CSA Flame,cCSAus, CE,
Australia Gas Australia Gas
Electrical & Steam cCSAus, CE cCSAus, CE
Shipping Dimensions
Approx. - in (mm)
