Speed Queen AWS17NW User manual

Topload Washers
AWS17
AWS44
AWS51
AWS76
Laundry — it’s all we do.
Mode AWS17 AWS44 AWS51 AWS76
Appearance
Color: White ✔✔✔✔
3.3 cu.ft. Stainless ✔✔✔✔
Steel Washtub
Galvanized Metal ✔✔✔✔
Washer Cabinet
Flex Vane Agitator ✔✔✔✔
Technica Information
Tub Volume - cu. ft. 3.3 3.3 3.3 3.3
verall Dimensions - 43" x 25 5/8" x 28" 43" x 25 5/8" x 28" 43" x 25 5/8" x 28" 43" x 25 5/8" x 28"
H x W x D
Work Surface Height - in 36" 36" 36" 36"
Approximate Shipping 195 195 195 195
Weight - lb
Electrical Requirements 120V/60 HzAC 120V/60 HzAC 120V/60 HzAC 120V/60 HzAC
- Breaker Size 15 Amp 15 Amp 15 Amp 15 Amp
Motor HP 1/2 1/2 1/2 1/2
Performance/Features
Water Temperature 3333
Selections
Spin Speeds - RPM 710 710/473 710/473 710/473
Motor Speeds 1222
Automatic Balancing ✔✔✔✔
System
Rear Self-Leveling Legs ✔✔✔✔
Porcelain Steel uter ✔✔✔✔
Draintub
Tuff Guard Protected Top ✔✔✔✔
Variable Water Level ✔✔✔✔
Selector
Hush Pak ✔✔✔
Extra Rinse ption ✔✔
Bleach Dispenser ✔✔✔✔
Fabric Softener ✔✔✔✔
Dispenser
Wash Cyc es
Cycles 7817 20
Average Water 36.7 36.7 36.7 36.7
Consumption - Gallons
Agency Approvals UL UL UL UL
®
www.speedqueen.com
AR07-211
Speed Queen Warranty
Speed Queen brings to you the industry’s best
warranty on all of our washers and dryers.
3 years on parts and labor.
5 years on the motor.*
5 years on the cabinet.*
5 years on bearings and seal assembly.*
10 years on transmission.
Lifetime on all stainless steel washtubs and outer
draintubs.*
* Limited. See Speed Queen warranty bond for details.
28"
53"
26"
3/8"
29"
43"
36"
25 5/8"
AWS17 -1-Speed Motor, 7 Cycles, 3 Water Temperatures AWS44 -2-Speed Motor, 8 Cycles, 3 Water Temperatures
AWS51 -2-Speed Motor, 17 Cycles, 3 Water Temperatures,
Extra Rinse ption
AWS76 (Shown on front) -2-Speed Motor, 20 Cycles, 3 Water Temperatures,
Extra Rinse ption, Fabric Selector Switch
Since 1908, Speed Queen laundry equipment has set the standard for commercial durability, a record
exemplified daily in coin laundries worldwide. ur products for the home deliver the same American-built
reliability and unparalleled performance that have made us an industry leader. Laundry — it’s all we do.
For the most accurate information the installation guide should be used for all design and construction purposes.
Due to continuous product improvements, design and specifications are subject to change without notice.
The quality management systems at all Alliance Laundry Systems’ Ripon facilities are registered to IS 9001:2000.
©Copyright 2007 Alliance Laundry Systems LLC
Printed in the U.S.A.
Printed on paper manufactured with virgin pulp from certified sources and a minimum of 10%
post-consumer recovered fiber.
