Speed Queen SCN020GF Installation instructions

QUANTUM STANDARD OPL CONTROL
For laundry managers requiring basic management options,Quantum
Standard comes with four cycle selections, two water levels and manual
programming. It also offers a maximum extraction speed of 100 G-force.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements,design and specifications subject to change without notice.The
quality management system of Alliance Laundry Systems’Ripon facility has been registered to ISO#9001:2000.
Printed in the U.S.A.
speedqueen.com
© 2012 Alliance Laundry Systems LLC AO11-0670R1
PRODUCT SPECIFICATIONS
SCN020GF
Capacity 20 lb
Width 26”
Depth 30 1/4”
Height 42”
Cylinder Diameter 21”
Cylinder Depth 13 3/4”
Cylinder Volume 2.76 cu. ft.
Door Opening Size 11 5/8”
Door Bottom to Floor 14 3/8”
Wash Speeds 51 RPM
Extract Speed 580 RPM
Distribution Speed 92 RPM
Extract G-Force 100
Water Inlet 2 @ 3/4”
Drain Diameter 1 @ 2”
Drain Height To Floor 4 1/2”
Motor Size 1 HP
Electrical Specs
Voltage/Hz/Phase
B 110-120/60/1
X 200-208/220-240/50/60/1/3
Q 200-208/220-240/50/60/3 (electric heat)
P 380-415/50/60-3
N 440-480/50/60/3
Net Weight 362 lb
Shipping Weight 402 lb
Shipping Width 29 1/2”
Shipping Depth 34 5/8”
Shipping Height 51 1/2”
Agency Approvals cETLus, CE
ON-PREMISES LAUNDRY HARDMOUNT SCN020GF
FEATURES & BENEFITS
• Advancedwaterprotectionalertsownersifthewasher
hasastuckdrain,slowdrainconditionorleakinginlet
valve,whichhelpsconservewater.
• Ruggeddoorhandleandnewlockmechanismensure
easyopeningandclosingandreliablelocking—no
moredoorlockerrorcodes.
• Newdualtriple-lipsealsandastainlesssteelsleeve
aroundthetrunnion,deliverthestrongestlineof
defenseinprotectingthebearingsagainstthe
damagingeffectsofmoisture.
• Four-compartmentchemicaldispenseradds
chemicalsattherighttime,automaticallysaving
stafftime.Thenewdispenserdesigneliminates
over-sudsingconditions.
