Speed Queen SCN020G2 Installation instructions

©Copyright 2011 Alliance Laundry Systems LLC AO11-0670
FEATURES & BENEFITS
• Advancedwaterprotection
alertsownersifthewasher
hasastuckdrainorslow
draincondition,whichhelps
conservewater.
• Ruggeddoorhandleand
newlockmechanismensure
easyopeningandclosing
andreliablelocking—no
moredoorlockerrorcodes.
• Newtriple-lipsealanda
stainlesssteelsleevearound
thetrunnion,deliverthe
strongestlineofdefense
inprotectingthebearings
againstthedamagingeffects
ofmoisture.
• Newfour-compartment
chemicaldispenseradds
chemicalsattherighttime,automaticallysavingstafftime.Thenewdispenser
designeliminatesover-sudsingconditions.
AVAILABLE CONTROLS
Control Description
Quantum Standard Washer Extractor OPL For laundry managers requiring basic manage-
ment options, Quantum Standard comes with four
cycle selections, two water levels and manual
programming. It also offers a maximum extraction
speed of 80 G-force.
Forthemostaccurateinformation,theinstallationguideshouldbeusedforalldesignandconstructionpurposes.
Duetocontinuousproductimprovements,designandspecificationssubjecttochangewithoutnotice.
ThequalitymanagementsystemofAllianceLaundrySystems’Riponfacilityhasbeenregisteredto
ISO#9001:2000.
PRODUCT SPECIFICATIONS
Cabinet Dimensions
Capacity 20 lb
Width 26”
Depth 30 1/4”
Height 42”
Cylinder Diameter 21”
Cylinder Depth 13 3/4”
Cylinder Volume 2.76 cu. ft.
Door Opening Size 11 5/8”
Door Bottom to Floor 14 3/8”
Speed
Wash Speeds 57 RPM
Extract Speed 528 RPM
Distribution Speed N/A
Extract G-Force 80
Connections
Water Inlet 2 @ 3/4”
Drain Diameter 1 @ 2”
Drain Height To Floor 4 1/2”
Motor
Motor Size 0.74 HP
Electrical Specifications
B 110-120/60/1
Voltage/Hz/Phase
F 440-480/60/3
Voltage/Hz/Phase
O 208-240/60/3
Voltage/Hz/Phase
Y 208-240/60/1
Voltage/Hz/Phase
Shipping
Net Weight 387 lb
Shipping Weight 420 lb
Shipping Width 29 1/2”
Shipping Depth 34 5/8”
Shipping Height 51 1/2”
Agency Approvals
Agency Approvals cETLus, CE
ON-PREMISES LAUNDRY HARDMOUNT SCN020G2
