Speed Queen SCN080GF Installation instructions

QUANTUM STANDARD OPL CONTROL
For laundry managers requiring basic management options,Quantum
Standard comes with four cycle selections, two water levels and manual
programming. It also offers a maximum extraction speed of 100 G-force.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product improvements,design and specifications subject to change without notice.The
quality management system of Alliance Laundry Systems’Ripon facility has been registered to ISO#9001:2000.
Printed in the U.S.A.
speedqueen.com
© 2012 Alliance Laundry Systems LLC AO11-0682R1
ON-PREMISES LAUNDRY HARDMOUNT SCN080GF
FEATURES & BENEFITS
• Advancedwaterprotectionalertsownersifthe
washerhasastuckdrain,slowdrainconditionor
leakinginletvalve,whichhelpsconservewater.
• Ruggeddoorhandleandnewlockmechanism
ensureeasyopeningandclosingandreliablelocking
—nomoredoorlockerrorcodes.
• Newdualtriple-lipsealsandastainlesssteelsleeve
aroundthetrunnion,deliverthestrongestlineof
defenseinprotectingthebearingsagainstthe
damagingeffectsofmoisture.
• Four-compartmentchemicaldispenseradds
chemicalsattherighttime,automaticallysaving
stafftime.Thenewdispenserdesigneliminates
over-sudsingconditions.
PRODUCT SPECIFICATIONS
SCN080GF
Capacity 80 lb
Width 41 1/2”
Depth 51 1/2”
Height 56 3/16”
Cylinder Diameter 36”
Cylinder Depth 22”
Cylinder Volume 12.4 cu. ft.
Door Opening Size 18 1/2”
Door Bottom to Floor 17 3/4”
Wash Speeds 39 RPM
Extract Speed 443 RPM
Distribution Speed 70 RPM
Extract G-Force 100
Water Inlet 2 @ 3/4”
Drain Diameter 1 @ 3”
Drain Height To Floor 5 3/4”
Motor Size 5 HP
Electrical Specs
Voltage/Hz/Phase
X 200-208/220-240/50/60/1/3
Q 200-208/220-240/50/60/3 (electric heat)
P 380-415/50/60-3
N 440-480/50/60/3
Net Weight 1262 lb
Shipping Weight 1275 lb
Shipping Width 48”
Shipping Depth 56”
Shipping Height 65 3/4”
Agency Approvals cETLus, CE
