42" SNOW THROWER
the fastest way to purchase parts
www.speedepart.com
youtube.com/c/agrifab
Video
Instruction
Guide
Want more information or assembly tips?

2
TABLE OF CONTENTS
SAFETY RULES................................................................................................................................................................... 3
FULL SIZE HARDWARE CHART......................................................................................................................................... 4
CARTON CONTENTS.......................................................................................................................................................... 6
ASSEMBLY........................................................................................................................................................................... 7
OPERATION....................................................................................................................................................................... 25
MAINTENANCE ................................................................................................................................................................. 26
SERVICE AND ADJUSTMENTS ........................................................................................................................................ 27
STORAGE .......................................................................................................................................................................... 28
TROUBLESHOOTING........................................................................................................................................................ 29
REPAIR PARTS ILLUSTRATION............................................................................................................................. 30,32,34
REPAIR PARTS LIST................................................................................................................................................ 31,33,34
SLOPE GUIDE ................................................................................................................................................................... 35
PARTS ORDERING/SERVICE ........................................................................................................................BACK COVER
IMPORTANT:
Rear wheel weights and tire chains are required to
provide extra traction and stability when using this snow
thrower attachment. These items are available where
you purchased your tractor.
WHEEL WEIGHTS TIRE CHAINS

3
SAFETY
Read and understand the operating instructions before using.
Keep the area of operation clear of all persons, especially small children and pets.
Thoroughly inspect the area to be cleared and remove all door mats, sleds, boards,
wires and other foreign objects. Use extreme caution when operating on or crossing
gravel surfaces. Never direct discharge at bystanders or allow anyone in front of the
snow thrower.
Do not place hands near rotating parts. Keep clear of the
discharge opening at all times.
Do not place feet near rotating parts.
• Never allow children to operate the equipment.
• Never allow adults to operate the equipment without
proper instruction.
• Disengage all clutches and shift into neutral before
starting engine.
• Do not operate equipment without wearing adequate
winter outer garments.
• Wear substantial footwear which will protect feet and
improve footing on slippery surfaces.
• Check fuel before starting the engine. Do not remove
the fuel cap or ll the fuel tank while the engine
is running or hot. Do not ll the fuel tank indoors.
Gasoline is an extremely ammable fuel.
• Make sure the snow thrower height is adjusted to
clear the type surface it will be used on.
• Do not use the snow thrower without wheel weights
attached to the tractor.
• Never make any adjustments while the engine is
running.
• Always wear safety glasses or eye shield during
operation or while performing adjustment or repair.
• Do not place hands or feet near rotating parts. Keep
clear of the discharge opening at all times.
• Do not carry passengers.
• After striking a foreign object, stop the engine, remove
the wire from the spark plug and then thoroughly
inspect the snow thrower for damage. Repair any
damage before restarting and operating the snow
thrower.
• If the snow thrower starts to vibrate abnormally, stop
the engine immediately and check for the cause.
Vibration is generally a warning of trouble.
• Stop the engine whenever you leave the operating
position, before unclogging the snow thrower or
making any adjustments or inspections.
• Take all possible precautions when leaving the unit
unattended. Disengage the attachment clutch lever or
switch, lower the snow thrower, shift into neutral, set
the parking brake, stop the engine and remove the key.
• When cleaning, repairing or inspecting, make certain
all moving parts have stopped. Disconnect the spark
plug wire and keep it away from the plug to prevent
accidental starting.
• Do not run engine indoors except when transporting
the snow thrower in or out of the building. Open the
outside doors. Exhaust fumes are dangerous.
• Do not clear snow across the face of slopes. Exercise
extreme caution when changing direction on slopes.
Do not attempt to clear steep slopes. Refer to the
slope guide on page 35 of this manual.
• Never operate the snow thrower without guards,
plates or other safety protection devices in place.
• Never operate the snow thrower near glass
enclosures, automobiles, window wells, drop offs
etc. without proper adjustment of the snow thrower
discharge angle.
• Never run the snow thrower into snow at high speeds.
• Do not overload the snow thrower capacity by
attempting to clear snow at too fast a rate.
• Never operate the snow thrower at high transport
speed on slippery surfaces. Look behind and use care
when backing up.
• Watch for traffic and stay alert when crossing or
operating near roadways.
• Disengage power to the snow thrower when
transporting or when not in use.
• Use only attachments and accessories approved by
the manufacturer of the snow thrower (such as wheel
weights, counter weights, cabs etc.)
• Never operate the snow thrower without good visibility.
184045
199683199682

4
HARDWARE PACKAGE CONTENTS
J
x2
H
x6
L
x2
P
x7
X
x10
V
x6
Y
x22
W
x1
R
x8
S
x1
U
x2
Z
x2
O
x7
NOT SHOWN ACTUAL SIZE
NOT SHOWN ACTUAL SIZE
N
x2
Q
x7
A
x1
46938
43084
43182
43661
47631
43350 44215
43682
44326
43080
42849
43003 43088 43081
R19172410
47605 44695
43082
47810
47572
46584
47598
43063
AA
x1
GG
x2
EE
x2
DD
x1
CC
x3
BB
x3
FF
x6
LL
HH
x2
II
x1 JJ
x2
KK
x2
46959 27809 27810 42848 HA3090
43343 43055 43038
46963
726-0178
47788 HA9822 42991 44044 42842
R19131316
23727
MM
x1
NN
x1
QQ
x2
OO
x2
PP
x6
B
x2
C
x4
D
x4
E
x6
F
x6
M
x4
47630
48106
G
x2
I
x2
K
x4
T
x3
43070

5
REF. QTY. DESCRIPTION
A 1 Hex Bolt, 3/8" x 3-1/4"
B 2 Hex Bolt, 5/16" x 1-3/4"
C 4 Hex Bolt, 5/16" x 1"
D 4 Hex Bolt, 5/16" x 3/4"
E 6 Hex Bolt, 1/4" x 1"
F 6 Hex Bolt, 3/8" x 1" (Thread Forming)
G 2 Hex Bolt, 5/16" x 3/4" (Thread Forming)
H 6 Carriage Bolt, 3/8" x 1"
I 2 Carriage Bolt, 5/16" x 1-3/4"
J 2 Carriage Bolt , 5/16" x 1-1/4"
K 4 Carriage Bolt, 5/16" x 1"
L 2 Carriage Bolt, 5/16" x 3/4"
M 4 Shoulder Bolt
N 2 Shear Bolt (spare parts)
O 7 Lock Washer, 3/8"
P 7 Washer, 1/4"
Q 22 Washer, 5/16" (Extra washers included)
R 8 Washer, 1/2"
S 1 Washer, 3/8" (Thin)
T 3 Washer, 3/8"
U 2 Bowed Washer
V 6 Flanged Nut, 1/4"
REF. QTY. DESCRIPTION
W 1 Flanged Nut, 5/16"
X10 Flanged Nut, 3/8"
Y 22 Nylock Nut, 5/16" (2 spare parts)
Z 2 Hex Lock Nut, 3/8"
AA 1 Spring
BB 3 Chute Keeper
CC 3 Chute Spacer
DD 1 Trunnion
EE 2 Hairpin Cotter, 5/64"
FF 6 Hairpin Cotter, 1/8"
GG 2 Hairpin Cotter, 3/32"
HH 2 Lock Pin
II 1 Small Spacer
JJ 2 Chain, Tensioning
KK 2 Tail Reector
LL 2 Nylon Tie
MM 1 Grip
NN 1 Plug
OO 2 Clevis Pin, 3/8" x 3/4"
PP 6 Washer
QQ 2 Clevis Pin, 1/2" x 7/8"

6
CARTON CONTENTS
1. Housing Assembly
2. Lift Handle and Cable
3. Crank Rod Support Tube
4. Chute Crank Rod Assembly
5. Engagement Rod (Not used on some models)
6. Cable Bracket
7. Engine Pulley Keeper (Not used on some models)
8. Chute and Control Cable Assembly
9. Clutch Idler Assembly
10. Rear Pulley Frame Bracket (2)
11. Anti-rotation Bracket.
12. Front Pulley Frame Bracket (2)
13. V-Belt, Drive 56" (#48138)
14. V-Belt, Drive 55" (#46989)
15. V-Belt, Auger (Attached to Housing Assembly)
16. L.H. Hanger Bracket (Outside Mounting)
17. R.H. Hanger Bracket (Outside Mounting)
18. L.H. Hanger Bracket (Inside Mounting)
19. R.H. Hanger Bracket (Inside Mounting)
20. Left Hand Side Plate
21. Right Hand Side Plate
22. Pulley
23. Large Spacer, 3/8"
46989
48138
42992
11
5
7
17
2
4
6
19
18
16
8
15
13
1
9
3
20 21
14
25678BL1
25679BL1
27509BL1
64452BL1
64451BL1
25774BL1
6-162BL1
47043
46948
25728BL1
24558BL1
10
12
27016BL1
48883 25780
22 23

7
• Remove all parts and hardware packages from the
carton. Lay out parts and hardware and identify using
the illustrations on pages 4 and 6.
NOTE: Not all of the supplied parts and hardware will
be needed for your particular tractor. Unneeded items
may be discarded after you have completed assembly
and checked operation of unit. DO NOT DISCARD the
two spare shear bolts and 5/16" nylock nuts. Refer to the
Service and Adjustments section on page 27.
REMOVAL OF PARTS FROM CARTON
TOOLS REQUIRED FOR ASSEMBLY
(2) 7/16" Wrenches
(2) 1/2" Wrenches
(2) 9/16" Wrenches
(2) 3/4" Wrenches
(1) Knife
ADDITIONAL ITEMS REQUIRED
General Purpose Grease
TRACTOR PREPARATION
Before performing these instructions, refer to the Service
and Adjustments section of your tractor owner's manual
for specic safety instructions.
• Allow engine, muffler and exhaust deector to cool
before beginning.
• Remove any front or rear attachment which is
mounted to your tractor.
•Remove the mower deck. Refer to your tractor owner's
manual for removal instructions. Mark all loose parts
and save for reassembly.
• Remove the tractor hood. Refer to your tractor owner's
manual for removal instructions.
FIGURE 2 RIGHT SIDE VIEW
IMPORTANT: Right hand (R.H.) and left hand (L.H.) side
of the tractor are determined from the operators position
while seated on the tractor.
REMOVE
BROWNING SHIELD
REMOVE
FRONT SCREWS
MOWER DECK
SUSPENSION
BRACKET
FIGURE 1
INSTRUCTIONS FOR TRACTORS WITH
SINGLE FRONT DECK SUSPENSION
BRACKET
STEP 2: (SEE FIGURE 2)
• Remove the browning shield from the front of the
tractor as shown. Hold onto the shield as you remove
the second screw to prevent it from falling.
• Be sure to reinstall the browning shield when so
instructed in step 3.
IDENTIFY YOU TRACTOR
STEP 1: (SEE FIGURE 1)
• Look under the front of your tractor. If there is a single
mower deck suspension bracket located underneath
the middle of the front axle, continue on to step
2. If your tractor does not have a mower deck
suspension bracket underneath the middle of the
front axle, skip to step 21 on page 13 for tractors
with dual suspension brackets.
ASSEMBLY
CAUTION: Before starting to assemble the
snow thrower, remove the spark plug wire(s),
set the parking brake and remove the key from
the tractor ignition.
CAUTION: Do not begin assembling until
the tractor engine, muffler and exhaust
deector have been allowed to cool off.

8
STEP 4: (SEE FIGURE 4)
•Install a shoulder bolt (M), a 3/8" washer (T) and a
3/8" anged lock nut (X) in the R.H. (21) and L.H. (20)
Side Plates.
FIGURE 4 RIGHT SIDE VIEW
FIGURE 3 RIGHT SIDE VIEW
5/16"
NYLOCK
NUT
5/16" x 1"
CARRIAGE BOLT (K) ENGINE MOUNTING
PLATE
(4) 1/2" WASHERS (R)
(3) 3/8" FLANGE NUTS (X)
(3) 3/8" x 1"
CARRIAGE
BOLTS (H)
SEE NOTE
INSTALL SIDE PLATES
STEP 3: (SEE FIGURE 3)
• Fasten the R.H. Side Plate (bend facing out) to the
front three holes in the tractor frame using three 3/8"
x 1" carriage bolts (H), three 1/2" washers (R) (see
note) and three 3/8" ange nuts (X). For the rear hole,
use a 5/16" x 1" carriage bolt (K), a 1/2" washer (R)
and a 5/16" nylock nut (Y). Place the 1/2" washers
between the tractor frame and the side plate. Repeat
for L.H. side plate.
• Reinstall the browning shield onto the tractor frame
using the original screws.
NOTE: If there is an engine mounting plate (shown with
dotted lines) leave the 1/2 washer off the bolt that goes
through the plate.
INSTALL HANGER BRACKETS AND SHOULDER
BOLTS TO OUTSIDE OF FRAME
STEP 5: (SEE FIGURE 5)
•Remove the bolt, if present, in the hole directly behind
the brake rod on the left side of the tractor frame.
• Attach the L.H. Hanger Bracket (16) to the hole using
a 5/16" x 3/4" self threading bolt (G).
• Install a shoulder bolt (M) into the hole that is 9-1/2" to
the rear of the bolt you just installed. Secure it with a
3/8" ange nut (X) on the inside of the frame.
FIGURE 5 LEFT SIDE VIEW
5/16" x 3/4" SELF
THREADING BOLT (G)
L.H. HANGER
BRACKET (16)
BRAKE ROD
3/8" FLANGED NUT (X)
SHOULDER
BOLT (M)
5/16" x 3/4" SELF
THREADING BOLT (G)
R.H. HANGER
BRACKET (17)
RIGHT END OF
BRAKE ROD
3/8" FLANGED
NUT (X)
SHOULDER
BOLT (M)
STEP 6: (SEE FIGURE 6)
•Remove the bracket, if present, from the hole directly
behind the end of the brake rod on the right side of
the tractor frame. Store the bracket and bolt.
• Attach the R.H. Hanger Bracket (17) to the hole using
a 5/16" x 3/4" self threading bolt (G).
• Install a shoulder bolt (M) into the hole that is 9-1/2" to
the rear of the bolt you just installed. Secure it with a
3/8" ange nut (X) on the inside of the frame.
FIGURE 6 RIGHT SIDE VIEW
3/8" WASHER (T)
SHOULDER
BOLT (M)
3/8" FLANGED
NUT (X)

9
STEP 7: (SEE FIGURE 7)
• Attach the cable bracket (6) to the double hole in the
clutch frame as shown, using a 5/16" x 3/4" carriage
bolt (D) and a 5/16" nylock nut (Y). Place the bolt in
the front hole of the bracket and in the end of the hole
closest to the pulley. Do not tighten yet.
FIGURE 7
FIGURE 9
STEP 9: (SEE FIGURE 9)
• Using lower set of holes attach each rear pulley frame
bracket to the inside of the clutch frame using two
5/16" x 3/4" hex bolts (D), 5/16" washers (Q), and
5/16" nylock nuts (Y). Use upper set of holes for
Husqvarna TS200 with dual pedals.
• Using lower set of holes attach each front pulley frame
bracket to the inside of the clutch frame using two
5/16" x 1" hex bolts (C), four 5/16" washers (Q), and
two 5/16" nylock nuts (Y). Use upper set of holes for
Husqvarna TS200 with dual pedals.
THIS SECTION IS FOR TRACTORS WITH A
MANUAL ATTACHMENT CLUTCH
If your tractor has an electric attachment clutch go to
step 14 on page 11.
FIGURE 10
STOP
Did you select the correct drive belt for your
tractor? Using the wrong length belt may
cause premature bearing or belt failure.
STEP 10: (SEE FIGURE 10)
• Two different length drive belts are included with your
snow thrower. Use the longer, 56" drive belt (#48138)
on tractors with manual attachment clutches.
• Slightly loosen the hex bolt next to the at idler pulley.
Install the drive belt down between the hex bolt and the
at idler pulley with the at side of the belt against the
pulley. Retighten the hex bolt.
• Loop the belt around the large v-pulley, placing it
between the v-pulley and the hex bolt next to the pulley.
Place the belt to the inside of the other at idler pulley.
FIGURE 8
STEP 8: (SEE FIGURE 8)
• Attach the pulley (22) (long end of hub facing down)
and the large 3/8" spacer (23) to the clutch frame. Use
a 3/8" x 3-1/4" hex bolt (A), a 3/8" washer (T), a 3/8"
lock washer (O), and a 3/8" hex lock nut (Z).
• Install a tensioning chain (JJ) through the hole shown
and then insert a 3/32" hairpin cotter (GG) into the 4th
link.
• Attach the chain to the spring on the lower idler arm.
CABLE
BRACKET (6)
5/16" x 3/4"
CARRIAGE BOLT (D)
5/16" NYLOCK
NUT (Y)
5/16" x 1"
HEX BOLT (C)
5/16" x 3/4"
HEX BOLT (D) 5/16"
NYLOCK
NUT (Y)
5/16" WASHER (Q)
(2) 5/16"
WASHERS (Q)
HEX BOLTS
(#48138)
DRIVE BELT
FLAT IDLER
PULLEYS
LARGE 3/8" SPACER (23)
3/8" LOCKWASHER (O)
3/8" HEX LOCK NUT (Z)
3/8" WASHER (T)
3/8" x 3-1/4"
HEX BOLT(A)
TENSIONING
CHAIN (JJ)
PULLEY (22)
(long end of
hub down)
3/32" HAIRPIN COTTER
IN 4TH LINK (GG)
STOP Using the wrong holes will cause belt
misalignment!

10
FIGURE 12 VIEWED FROM LEFT SIDE
STEP 13: (SEE FIGURE 13)
• Assemble the drive belt onto the engine pulley rst
and then onto the large pulley on top of the clutch/idler
assembly. The belt must be placed inside the engine
pulley belt keeper(s) and between the large pulley and
the keeper bolt next to it.
IMPORTANT: Do Not assemble the "V" belt outside of
the engine pulley keepers or outside of the keeper bolt
next to the large pulley.
• Go to step 48 on page 21.
FIGURE 13 VIEWED FROM UNDERNEATH
CLUTCH/IDLER ASSEMBLY
FIGURE 11
ATTACH CLUTCH IDLER ASSEMBLY TO TRACTOR
STEP 12: (SEE FIGURE 12)
• Hook the rear of the clutch/idler assembly onto the
two shoulder bolts assembled to the tractor frame. Lift
the front of the assembly and attach it to the R.H. and
L.H. hanger brackets using two clevis pins (OO), six
washers (PP), and two 1/8" hairpin cotters (FF).
• Loosely attach the mower clutch cable to the left side
of the tractor frame with a nylon tie (LL). Do not pull
the nylon tie completely tight. The cable may need to
be removed from the nylon tie when using the mower
deck.
STEP 11: (SEE FIGURE 11)
• Find the cable clip that is attached to the left side
of the tractor frame underneath the footrest. Open
the clip and remove the mower clutch cable. Do not
remove the clip from the tractor frame. The cable
reattaches to the clip when using the mower deck.
• Move the attachment clutch lever on the dash panel to
the disengaged position.
• Place the clutch/idler assembly on the oor on the left
side of the tractor.
• Attach the tractor's mower clutch cable to the cable
bracket on the clutch/idler assembly. Secure the cable
housing guide (groove down) to the cable bracket
using the original collar and a 5/64" hair cotter pin (EE).
• Place the small spacer (II)on the welded pin on the
idler arm. Hook the end of the clutch cable spring
over the pin and secure it with a 1/4" washer (P)and a
5/64" hair cotter pin (EE).
• Align cable bracket with welded pin and tighten the
nut assembled in step 7.
L.H.
HANGER
BRACKET
1/8" HAIRPIN
COTTER (FF)
NYLON TIE (LL)
WASHERS (PP) 44044
SHOULDER
BOLT
MOWER
CLUTCH
CABLE
1/4" SPACER (II)
5/64" HAIR
COTTER PIN (EE)
CABLE
BRACKET
TRACTOR'S
CLUTCH CABLE
5/64" HAIR
COTTER PIN (EE)
1/4" WASHER (P)
ENGINE
PULLEY
ENGINE
PULLEY
Left Side
of Tractor
ENGINE
PULLEY
KEEPER
KEEPER BOLT
IDLER
PULLEY

11
THIS SECTION IS FOR TRACTORS WITH AN
ELECTRIC ATTACHMENT CLUTCH
STEP 14: (SEE FIGURE 14)
• Turn the clutch idler assembly upside down.
• Hook the long end of the spring (AA) onto the end of
the bolt that extends through the nut on the bottom of
the upper idler arm. Install a 3/8" hex lock nut (Z) onto
the bolt, leaving enough space for the spring to pivot.
FIGURE 14
FIGURE 16
STEP 16: (SEE FIGURE 16)
• Using the lower set of holes attach each rear pulley
frame bracket to the inside of the clutch/idler assembly
using two 5/16" x 3/4" hex bolts (D), 5/16" washers
(Q), and 5/16" nylock nuts (Y). Use upper set of
holes for Husqvarna TS200 with dual pedals.
• Using the lower set of holes attach each front pulley
frame bracket to the inside of the clutch/idler assembly
using two 5/16" x 1" hex bolts (C), four 5/16" washers
(Q), and two 5/16" nylock nuts (Y). Use upper set of
holes for Husqvarna TS200 with dual pedals.
STEP 15: (SEE FIGURE 15)
• Insert tensioning chains (JJ) through the holes shown
and attach to the springs on the upper and lower idler
arms.
• Install a 3/32" hairpin cotter (GG) in the 5th link of the
chain attached to the upper idler arm.
• Install a 3/32" hairpin cotter (GG) in the 4th link of the
chain attached to the lower idler arm.
FIGURE 15
STEP 17: (SEE TABLE 1)
•Two different length drive belts are included with
your snow thrower. Use the table below to select
the correct drive belt for your type tractor. The part
number is printed on the outside of the belt.
• Set aside the belt that is not for your tractor to avoid
accidentally using it.
SELECT THE CORRECT DRIVE BELT
(Electric clutch tractors with a single front deck
suspension bracket)
55" BELT (PART #46989)
TRACTOR TYPE DECK SIZE CLUTCH TYPE
(LT) Lawn Tractor 38", 42" Electric
56" BELT (PART #48138)
TRACTOR TYPE DECK SIZE CLUTCH TYPE
(LT) Lawn Tractor 48" Electric
(GT) Garden Tractor 48", 54" Electric
TABLE 1
3/8" HEX
LOCK NUT (Z)
SPRING (AA)
ATTACH
LONG
END OF
SPRING
HERE
TENSIONING CHAIN (JJ)
(lower idler arm)
TENSIONING CHAIN (JJ)
(upper idler arm)
3/32" HAIRPIN
COTTER (GG)
IN 5th LINK
3/32" HAIRPIN COTTER (GG)
IN 4th LINK
5/16" x 1" HEX BOLT (C)
5/16" x 3/4"
HEX BOLT (D)
5/16" NYLOCK NUT (Y)
5/16" WASHER (Q)
5/16"
NYLOCK NUT (Y)
(2) 5/16" WASHERS (Q)
STOP Using the wrong holes will cause belt
misalignment!

12
STEP 19: (SEE FIGURE 18)
• Hook the rear of the clutch/idler assembly onto the
two shoulder bolts assembled to the outside of the
tractor frame. Lift the front of the assembly and attach
it to the R.H. and L.H. hanger brackets using two
clevis pins (OO), six washers (PP), and two 1/8"
hairpin cotters (FF).
FIGURE 18 VIEWED FROM LEFT SIDE
FIGURE 19 VIEWED FROM UNDERNEATH
FIGURE 17
STEP 18: (SEE FIGURE 17)
• Turn the clutch/idler assembly right side up.
• Slightly loosen the hex bolt next to the at idler pulley.
Install the drive belt down between the hex bolt and the
at idler pulley with the at side of the belt against the
pulley. Retighten the hex bolt.
• Loop the belt around the large v-pulley, placing it
between the v-pulley and the hex bolt next to the pulley.
STOP
Did you choose the correct drive belt for
your tractor? Using the wrong length belt
may cause premature bearing or belt failure.
DRIVE BELT
FLAT IDLER
PULLEY
HEX BOLTS
1/8" HAIRPIN
COTTER (FF)
L.H. HANGER
BRACKET
PP
CLEVIS PIN (OO)
SHOULDER
BOLT
1/8"
HAIRPIN
COTTER (FF)
ENGINE
PULLEY
HEX BOLTS
FLAT IDLER
PULLEY
TENSIONING
CHAIN
LEFT SIDE
OF TRACTOR
STEP 20: (SEE FIGURE 19)
• Assemble the drive belt onto the engine pulley. You
may need to remove the belt from the large pulley on
the clutch/idler assembly in order to assemble it onto
the engine pulley. When re-assembling the belt onto
the large pulley, be sure the belt is between the large
pulley and the hex bolt next to it.
• Place tension on the belt by pulling the left side
tensioning chain out as far as the 3/32" hairpin cotter
(GG) that was installed in the chain in step 15 will
allow. Secure the chain in this position by inserting a
1/8" hairpin cotter (FF) through the chain.
• Go to step 48 on page 21.

13
STEP 22: (SEE FIGURE 21)
• Fasten the R.H. Side Plate (21) (bend facing out) to
the front three holes shown in the tractor frame using
three 3/8" x 1" thread forming bolts (F), three 3/8"
lock washers (O), and one 1/2" washer (R). Place the
washer on the third bolt as a shim between the side
plate and the frame. Tighten all bolts. Repeat for the
L.H. side.
NOTE: If you installed a bolt in the fourth hole in step 21,
assemble a 5/16" ange nut (W) onto the bolt after the
side plate is installed.
• Go to step 25 on this page.
(3) 3/8" x 1"
THREAD FORMING
BOLTS (F)
5/16" FLANGED
NUT (W)
(SEE NOTE) (3) 3/8" LOCK
WASHERS (O)
1/2" WASHER (R)
5/16" x 1"
CARRIAGE BOLT
(SEE NOTE)
FIGURE 21 RIGHT SIDE VIEW
FRONT SUSPENSION
BRACKET
REMOVE BOLTS
IF PRESENT
FIGURE 22 RIGHT SIDE VIEW
STEP 23: (SEE FIGURE 22)
•Remove any bolts found in the holes shown.
STEP 21: (SEE FIGURE 20)
•Remove bolts from front three holes shown.
• If a bolt is present in the fourth hole, replace it with a
5/16" x 1" carriage bolt (K) without a nut. The bracket
fastened to inside of frame must remain in place.
FRONT
SUSPENSION
BRACKET
REPLACE BOLT
(IF PRESENT)
REMOVE BOLTS
(IF PRESENT)
FIGURE 20 RIGHT SIDE VIEW
INSTRUCTIONS FOR TRACTORS WITH DUAL
FRONT DECK SUSPENSION BRACKETS
FASTEN SIDE PLATES TO TRACTOR
If your tractor resembles gure 20, start with step 21.
If your tractor resembles gure 22, start with step 23.
STEP 25: (SEE FIGURE 24)
•Install a hex head shoulder bolt (M), a 3/8" washer (T)
and a 3/8" anged lock nut (X) in the R.H. and L.H.
Side Plates.
FIGURE 24 RIGHT SIDE VIEW
3/8" WASHER (T)
SHOULDER
BOLT (M) 3/8" FLANGED
NUT (X)
STEP 24: (SEE FIGURE 23)
•Fasten the R.H. Side Plate (21) (bend facing out) to the
three holes shown in the tractor frame. Use three 3/8"
x 1" thread forming bolts (F), 3/8" lock washers (O),
and 1/2" washers (R). Use the 1/2" washers as shims
between the Side Plate and the tractor frame. Tighten
all bolts and repeat for the L.H. side.
NOTE: If the bolt inserts freely into the front hole, assemble
a 3/8" anged nut (X) onto the bolt.
(3) 3/8" x 1"
THREAD FORMING
BOLTS (F)
(3) 3/8" LOCK
WASHERS (O)
3/8" FLANGED NUT (X)
(SEE NOTE)
(3) 1/2" WASHERS (R)
FIGURE 23 RIGHT SIDE VIEW

14
FIGURE 28 RIGHT SIDE VIEW
INSTALLING HANGER BRACKETS
For better clearance, lower the tractor's suspension arms
using the attachment lift lever.
STEP 26: (SEE FIGURE 25 or 26)
On Tractors With Foot Rest Brackets
•Remove the bolt and nut that fasten the L.H. and R.H.
foot rest brackets to the frame.
• Attach the L.H. Hanger Bracket (18) (marked "L")
to the inside of the tractor frame using two 3/8" x
1" carriage bolts (H) and 3/8" anged nuts (X). Bolt
heads go on inside of tractor frame. Repeat for the
R.H. side.
FIGURE 26 LEFT SIDE VIEW
FIGURE 25 LEFT SIDE VIEW
On Tractors Without Foot Rest Brackets
• Find the empty hole beneath the foot rest. Attach the
L.H. Hanger Bracket (marked "L") to the inside of
the frame using a 3/8" x 1" carriage bolt and a 3/8"
anged nut. Bolt head goes on inside of tractor frame.
Repeat for the R.H. side.
STEP 28: (SEE FIGURE 28)
• Assemble a shoulder bolt (M)and 3/8" anged nut (X)
to the R.H. side of the tractor frame, using the rst
empty hole to the rear of the R.H. hanger bracket (19).
Bolt goes on inside of frame.
FIGURE 27 LEFT SIDE VIEW
INSTALLING SHOULDER BOLTS
STEP 27: (SEE FIGURE 27)
• Remove the bolt, washer and nut which fasten the
sway bar bracket to the L.H. side of the tractor frame.
Replace with a shoulder bolt (M) and a 3/8" anged
nut (X). Bolt goes on inside of frame.
BOLT REMOVED
FROM THIS HOLE
SWAY BAR
BRACKET
SHOULDER BOLT (M)
3/8"
FLANGED
NUT (X)
3/8" x 1"
CARRIAGE
BOLT (H)
3/8" FLANGED
NUT (X)
L.H. HANGER
BRACKET (18)
SUSPENSION ARM
SHOULDER BOLT (M)
3/8"
FLANGED
NUT (X)
R.H. HANGER BRACKET (19)
BOLT REMOVED
FROM THIS HOLE
3/8" x 1"
CARRIAGE
BOLT (H)
3/8" FLANGED
NUT (X)
L.H. HANGER
BRACKET (18)
SUSPENSION ARM

15
INSTALLING CLUTCH/IDLER ASSEMBLY
This section covers the installation of the Clutch/Idler
assembly to tractors with attachment clutches that are
either rod operated (p. 15), cable operated (p. 17) or
electric (p. 19). Use the appropriate instructions for your
tractor.
ROD OPERATED MANUAL ATTACHMENT CLUTCH
STEP 29: (SEE FIGURE 29)
• Move the attachment clutch lever on the dash panel to
the disengaged (down) position.
• Screw the trunnion (DD) onto the end of the snow
thrower engagement rod (5).
• Locate the clutch arm (where the mower clutch rod
was connected) underneath the right hand side the
tractor, just to the inside of the suspension arm. If
there is an extension attached to the clutch lever, the
extension, bolt and nut must be removed and stored
with the mower deck.
IMPORTANT: Re-attach the extension to the clutch
lever before reinstalling the mower deck.
• Position the engagement rod (5) to the inside of
the clutch arm and insert the drilled end of the rod
through the arm. Secure with a 5/64" hairpin cotter
(EE).
FIGURE 29 RIGHT SIDE VIEW
ENGAGEMENT ROD (5)
5/64" HAIRPIN
COTTER (EE)
TRACTOR'S CLUTCH ARM
SUSPENSION ARM
TRUNNION (DD)
REMOVE EXTENSION,
BOLT AND NUT
(IF PRESENT)
STEP 30: (SEE FIGURE 30)
• Attach the two rear pulley frame brackets (10) to the
inside of the clutch/idler assembly using two 5/16" x 1"
hex bolts (C), eight 5/16" washers (Q), and two 5/16"
nylock nuts (Y) for each bracket.
• Attach the two front pulley frame brackets to the inside
of the clutch/idler assembly using two 5/16" x 3/4" hex
bolts (D), 5/16" washers (Q), and 5/16" nylock nuts (Y)
for each bracket. Add extra washers if needed.
FIGURE 30
FIGURE 31
STOP
Did you choose the correct drive belt for
your tractor? Using the wrong length belt
may cause premature bearing or belt failure.
STEP 31: (SEE FIGURE 31)
• Two different length drive belts are included with
your snow thrower. Tractors with manual attachment
clutches and dual front deck suspension brackets use
the 55" drive belt with #46989 printed on the outside
of the belt. DO NOT USE the other belt.
• Slightly loosen the hex bolt next to the at idler pulley.
Install the drive belt down between the hex bolt and the
at idler pulley with the at side of the belt against the
pulley. Retighten the hex bolt.
• Loop the belt around the large v-pulley, placing it
between the v-pulley and the hex bolt next to the pulley.
TENSIONING CHAIN (JJ)
(lower idler arm)
5/16" x 3/4"
HEX BOLT (D)
5/16" x 1"
HEX BOLT (C)
5/16" NYLOCK NUT (Y)
5/16"
WASHER (Q)
(4) 5/16" WASHERS (Q)
3/32" HAIRPIN
COTTER (GG)
IN 4th LINK
#46989
DRIVE BELT
FLAT IDLER
PULLEY
HEX BOLTS
• Insert a tensioning chain through the hole shown and
attach it to the spring on the lower idler arm.
• Install a 3/32" hairpin cotter (GG) in the 4th link of the
chain.

16
FIGURE 33 RIGHT SIDE VIEW
FIGURE 32 RIGHT SIDE VIEW
STEP 33: (SEE FIGURE 33)
• Make sure the attachment clutch lever on the dash
panel is in the disengaged (down) position.
• Pivot the upper idler arm so that it rests against the
stop bolt and is pointing toward the front as shown.
Screw the trunnion (DD) along the threads of the
engagement rod until it is aligned at the front end of
the idler arm slot. Attach the trunnion to the slot using
the 3/8" thin washer (S) and a 5/64" hairpin cotter
(EE).
• Remove the engine pulley keeper from the side of the
tractor frame by removing the washer and nut that
secure the keeper. Attach the new pulley keeper (7)
supplied with the snow thrower, reusing the original
bolt, washer and nut.
NOTE: Some tractors may already be equipped with a
pulley keeper that is identical to the new one supplied.
IDLER ARM
5/64" HAIRPIN
COTTER (EE)
STOP BOLT
3/8" THIN
WASHER (S)
NEW ENGINE PULLEY KEEPER (4)
WITH ORIGINAL BOLT, NUT, AND WASHER
TRUNNION (DD)
STEP 34: (SEE FIGURE 34)
• Assemble the short "V" belt onto the engine pulley
and then onto the large pulley on top of the clutch/idler
assembly. The belt must be placed to the inside of the
engine pulley keeper, the idler pulley and the keeper
bolt located beside the large pulley.
IMPORTANT: Do Not assemble the "V" belt around the
outside of the engine pulley keeper or the keeper bolt.
• Go to step 48 on page 21.
FIGURE 34 VIEWED FROM UNDERNEATH
CLUTCH/IDLER ASSEMBLY
STEP 32: (SEE FIGURE 32)
• Be sure to lift up the front end of the engagement rod
(5) as shown when performing the next operation. You
can temporarily support the rod using a rubber band
tied to the engine pulley keeper.
• Attach the clutch/idler assembly to the tractor frame
as follows. Hook the assembly's notched rear pulley
frame brackets onto the two shoulder bolts you
assembled to the inside of the tractor frame. Lift the
front of the assembly and attach it to the R.H. and L.H.
hanger brackets using two pivot lock pins (HH) and
1/8" hairpin cotters (FF).
PIVOT LOCK PIN (HH)
(use second hole)
1/8" HAIRPIN COTTER (FF)
ENGAGEMENT
ROD (5)
ENGINE
PULLEY
KEEPER BOLT
IDLER
PULLEY
ENGINE
PULLEY
KEEPER
Left Side
of Tractor

17
FIGURE 36
STEP 35: (SEE FIGURE 35)
• Assemble the cable bracket (6) to inner part of the
double holes in the clutch/idler assembly using two
5/16" x 3/4" carriage bolts (L) and 5/16" nylock nuts
(Y). Use the two front holes in the cable bracket for
42" mower decks. Use the two rear holes for 46"
mower decks.
STEP 36: (SEE FIGURE 36)
• Attach the two rear pulley frame brackets (10) to the
inside of the clutch/idler assembly using two 5/16" x 1"
hex bolts (C), eight 5/16" washers (Q), and two 5/16"
nylock nuts (Y) for each bracket.
• Attach the two front pulley frame brackets (12) to the
inside of the clutch/idler assembly using two 5/16" x
3/4" hex bolts (D), 5/16" washers (Q), and 5/16" nylock
nuts (Y) for each bracket. Add extra washers if needed
in step 39.
• Insert a tensioning chain (U) through the hole shown
and attach the end link to the spring on the lower idler
arm.
• Install a 3/32" hairpin cotter (GG) in the 4th link of the
chain.
FIGURE 35
CABLE OPERATED MANUAL ATTACHMENT CLUTCH
FIGURE 37
STEP 37: (SEE FIGURE 37)
• Two different length drive belts are included with
your snow thrower. Tractors with manual attachment
clutches and dual front deck suspension brackets use
the 55" drive belt with #46989 printed on the outside
of the belt. DO NOT USE the other belt.
• Slightly loosen the hex bolt next to the at idler pulley.
Install the drive belt down between the hex bolt and the
at idler pulley with the at side of the belt against the
pulley. Retighten the hex bolt.
• Loop the belt around the large v-pulley, placing it
between the v-pulley and the hex bolt next to the pulley.
STOP
Did you choose the correct drive belt for
your tractor? Using the wrong length belt
may cause premature bearing or belt failure.
CABLE
BRACKET (6)
5/16" x 3/4"
CARRIAGE BOLT (L)
5/16" NYLOCK
NUT (Y)
42"
DECKS
46"
DECKS
TENSIONING CHAIN (JJ)
(lower idler arm)
5/16" x 3/4"
HEX BOLT (D)
5/16" x 1"
HEX BOLT (C)
5/16" NYLOCK NUT (Y)
5/16"
WASHER (Q)
(4) 5/16" WASHERS (Q)
3/32" HAIRPIN
COTTER (GG)
IN 4th LINK
#46989
DRIVE BELT
FLAT IDLER
PULLEY
HEX BOLTS

18
FIGURE 40 VIEWED FROM UNDERNEATH
FIGURE 39
STEP 40: (SEE FIGURE 40)
• Assemble the short "V" belt onto the engine pulley
and then onto the large pulley on top of the clutch/idler
assembly. The belt must be placed to the inside of the
engine pulley keeper, the idler pulley and the keeper
bolt located beside the large pulley.
IMPORTANT: Do Not assemble the "V" belt around the
outside of the engine pulley keeper or the keeper bolt.
• Go to step 48 on page 21.
STEP 39: (SEE FIGURE 39)
• Remove the engine pulley keeper from the side of
the tractor frame by removing the washer and nut
that secure the keeper. Attach the new pulley keeper
supplied with the snow thrower, reusing the original
bolt, washer and nut.
NOTE: Some tractors may already be equipped with a
pulley keeper that is identical to the new one supplied.
• Attach the clutch/idler assembly to the tractor frame
as follows. Hook the rear of the assembly onto the two
shoulder bolts you installed on the tractor frame. Lift
the front of the assembly and attach it to the hanger
brackets you installed using two pivot lock pins (HH)
and 1/8" hairpin cotters (FF).
FIGURE 38
STEP 38: (SEE FIGURE 38)
• Move the attachment clutch lever on the dash panel to
the disengaged (down) position.
• Place the clutch/idler assembly on the oor on the right
side of the tractor.
• Attach the tractor's clutch cable to the cable bracket.
Secure the cable housing guide (groove down) to the
cable bracket using the original collar and a 5/64" hair
cotter pin (EE).
• Place a spacer (II) on the welded pin on the idler arm.
Hook the end of the clutch spring over the pin and
secure it with a 1/4" washer (P) and a 5/64" hair cotter
pin (EE).
5/64" HAIR
COTTER PIN (EE)
1/4" WASHER (P)
TRACTOR'S
CLUTCH CABLE
5/64" HAIR
COTTER PIN (EE)
SPACER (II)
NEW ENGINE PULLEY KEEPER WITH
ORIGINAL BOLT, NUT AND WASHER
PIVOT LOCK PIN (HH)
(use second hole)
1/8" HAIRPIN COTTER (FF)
ENGINE
PULLEY
KEEPER BOLT
IDLER
PULLEY
ENGINE
PULLEY
KEEPER
Left Side
of Tractor

19
ELECTRIC ATTACHMENT CLUTCHES
FIGURE 42
FIGURE 43 VIEW OF BOTTOM
STEP 43: (SEE FIGURE 43)
• Attach the two rear pulley frame brackets (10) to the
inside of the clutch/idler assembly using two 5/16" x 1"
hex bolts (C), eight 5/16" washers (Q) and two 5/16"
nylock nuts (Y) for each bracket.
• Attach the two front pulley frame brackets (12) to the
inside of the clutch/idler assembly using two 5/16" x
3/4" hex bolts (D), 5/16" washers (Q), and 5/16" nylock
nuts (Y) for each bracket.
STEP 44: (SEE TABLE 2)
•Two different length drive belts are included with
your snow thrower. Use the table below to select
the correct drive belt for your type tractor. The part
number is printed on the outside of the belt .
• Set aside the belt that is not for your tractor to avoid
accidentally using it.
55" BELT (PART #46989)
TRACTOR TYPE DECK SIZE CLUTCH TYPE
56" BELT (PART #48138)
TRACTOR TYPE DECK SIZE CLUTCH TYPE
(LT) Lawn Tractor 48" Electric
(LT) Lawn Tractor 38", 42", 46" Electric
TABLE 2
STEP 41: (SEE FIGURE 41)
• Turn the clutch idler assembly upside down.
• Hook the long end of the spring (AA) onto the end of
the bolt that extends through the nut on the bottom of
the upper idler arm. Install a 3/8" hex lock nut (Z) onto
the bolt, leaving enough space for the spring to pivot.
FIGURE 41
STEP 42: (SEE FIGURE 42)
• Insert tensioning chains (JJ) through the holes shown
and attach to the springs on the upper and lower idler
arms.
• Install a 3/32" hairpin cotter (GG) in the 5th link of the
chain attached to the upper idler arm.
• Install a 3/32" hairpin cotter (GG) in the 4th link of the
chain attached to the lower idler arm.
3/8" HEX
LOCK NUT (Z)
SPRING (AA)
ATTACH
LONG
END OF
SPRING
HERE
TENSIONING CHAIN (JJ)
(lower idler arm)
TENSIONING CHAIN (JJ)
(upper idler arm)
3/32" HAIRPIN
COTTER (GG)
IN 5th LINK
3/32" HAIRPIN COTTER (GG)
IN 4th LINK
5/16" x 3/4" HEX BOLT (D)
5/16" x 1"
HEX BOLT (C)
5/16" NYLOCK NUT (Y)
5/16"
WASHER (Q)
(4) 5/16" WASHERS (Q)

20
FIGURE 46 VIEWED FROM UNDERNEATH
STEP 47: (SEE FIGURE 46)
• Assemble the drive belt onto the engine pulley and
then onto the large pulley on top of the clutch/idler
assembly. The belt must be placed to the inside of
the idler pulley and the keeper bolt located beside the
large pulley.
• Place tension on the belt by pulling the left side
tensioning chain out as far as the 3/32" hairpin cotter
will allow. Secure the chain in this position by inserting
a 1/8" hairpin cotter (FF) through the chain.
IMPORTANT: Do Not assemble the "V" belt around the
outside of the engine pulley keeper or the keeper bolt.
STEP 46: (SEE FIGURE 45)
• Attach the clutch/idler assembly to the tractor frame as
follows. Hook the assembly's notched arms onto the
two shoulder bolts you assembled to the inside of the
tractor frame. Lift the front of the assembly and attach
it to the R.H. and L.H. hanger brackets using two pivot
lock pins (HH) and 1/8" hairpin cotters (FF).
FIGURE 45 RIGHT SIDE VIEW
CLUTCH/IDLER ASSEMBLY
FIGURE 44
STOP
Did you choose the correct drive belt for
your tractor? Using the wrong length belt
may cause premature bearing or belt failure.
STEP 45: (SEE FIGURE 44)
• Turn the clutch/idler assembly right side up.
• Slightly loosen the hex bolt next to the at idler pulley.
Install the drive belt down between the hex bolt and the
at idler pulley with the at side of the belt against the
pulley. Retighten the hex bolt.
• Loop the belt around the large v-pulley, placing it
between the v-pulley and the hex bolt next to the pulley.
DRIVE BELT
FLAT IDLER
PULLEY
HEX BOLTS
PIVOT LOCK PIN (HH)
(use second hole)
1/8" HAIRPIN COTTER (FF)
1/8" HAIRPIN
COTTER (FF)
ENGINE
PULLEY
ENGINE
PULLEY
Left Side
of Tractor
KEEPER
BOLT
IDLER
PULLEY
