Spinner A77137 User manual

Data subject to change without notice –June.09.2021 (F)
SPINNER GmbH │ Erzgiessereistr. 33 │ 80335 München │ Germany │ www.spinner-group.com │ [e-mail]
Installation guide for
In-Building omni antennas
1 Introduction and safety advice
This instruction shall provide information how to install the antenna with mounting kits.
The installation of Thin Omni Chip antennas is not recommended for metal ceilings or nearby any
metallic materials. Additional Isolation/Absorbing accessories can be applied for improving the
Antenna VSWR value.
Omni antennas must not be rotated after connecting the feeder cables.
All shown tasks are intended to be carried out by qualified personnel only. Safety rules apply (e.g.
for working with heavy loads, radio frequency power signals or tools). In order to prevent damage
to equipment and humans, make sure that no RF power is present at the combiner during
installation.
Please note that satisfactory performance of the system (especially in terms of intermodulation)
can only be achieved if all jumper cables and connectors are handled properly. Please make sure
that all connectors are clean and free from metal dust or dirt. Avoid sharp bending of the
connecting jumper cables.
After carrying out all described steps, the antenna is ready for use. Make sure that the specified
environmental conditions for operation are not exceeded.
SPINNER does not guarantee for any faults or damage resulting from improper installation.

Data subject to change without notice –June.09.2021 (F)
SPINNER GmbH │ Erzgiessereistr. 33 │ 80335 München │ Germany │ www.spinner-group.com │ [e-mail]
2 Installation
2.1 Install the antenna
Method 1: Through hole mounting
Step 1: Drill a hole with ≥ 22 mm resp. ≥ 28 mm diameter into suspended ceiling.
- 22 mm hole diameter is applicable for antennas A77137, A77137C0001, A77141, A77142,
A77142C0001, A77143, A77144, A77145, A77146, A77146C0003 and A77148.
- 28 mm hole diameter is applicable for antennas A77147, A77670 and A77684.
Step 2: Pass the antenna connectors through the hole.
Step 3: Secure the antenna with supplied plastic lock nut.

Data subject to change without notice –June.09.2021 (F)
SPINNER GmbH │ Erzgiessereistr. 33 │ 80335 München │ Germany │ www.spinner-group.com │ [e-mail]
Method 2: Tightening screw mounting
Drill a hole with ≥ 22 mm diameter into the suspended ceiling to pass the connectors of the
antenna. Then drill 2 resp. 4 holes with 6 mm diameter into suspended ceiling and put the plastic
dowels into the holes. Lock the antenna with tightening screws (M4*25 mm), then cover lids.
The method is applicable for antennas A77137, A77137C0001, A77142, A77142C0001, A77143,
A77146, A77146C0003, A77147 and A77148.
2.2 Warning:
Please respect the cable bending radius of minimum 40 mm.

Data subject to change without notice –June.09.2021 (F)
SPINNER GmbH │ Erzgiessereistr. 33 │ 80335 München │ Germany │ www.spinner-group.com │ [e-mail]
2.3 Install the Interference Absorber
Interference absorbers are not available for antennas A77148, A77670 and A77684.
Step 1: Drill a hole with ≥ 29 mm diameter and three holes with 6 mm diameter in the ceiling using
the provided drilling jig.
Step 2: Fix the Interference Absorber to the ceiling with three plastic dowels and M4*25 screws.
Step 3: Secure the antenna to the Interference Absorber with two M4*25 screws.
