MFJ-1623 Instruction Manual Window/Balcony Mount Antenna
1
MFJ-1623 Window/Balcony Mount Antenna
Introduction
The MFJ-1623 Window/Balcony Mount Antenna was designed to provide portable or permanent HF
communications on 30 through 10 meters and VHF on 6 meters. The universal mount design allows the
user to install the antenna in many ways. The mount will easily attach to window frames, balconies, and
railings. The MFJ-1623 works well indoors mounted to a desk or table as well.
The antenna consists of a whip tuner designed for tuning short whips as well as virtually any random
length wire antenna, collapsible whip, universal mount, and counterpoise wire. The operating frequency
is found by turning the knobs on the whip tuner and setting them for maximum RF current. The
counterpoise wire length can also be adjusted for maximum RF current. The MFJ-1623
Window/Balcony Mount Antenna will allow the operator to get on the air from locations where antenna
size is limited.
The whip tuner section uses a reversible "L" network. The advantage of the “L” network is that it has
only two tuning controls, and only one tuning solution for given impedance match. The MFJ-1623 has
rear panel connectors for coaxial input and a “Hi-Z/Lo-Z” switch for reversing the “L” network. An
internal input-isolating current balun provides isolation of DC and RF grounds for optimum tuning of the
RF counterpoise.
An RF Current Meter indicates the summed antenna and counterpoise antenna currents, making tuning
particularly easy. Simply tune for maximum RF current.
Choosing a Mounting Position
WARNING: ALWAYS ATTACH THE SAFETY ROPE TO A STABLE SUPPORT
BEFORE ATTEMPTING TO ATTACH THE UNIVERSAL MOUNT TO A
WINDOW FRAME OR RAIL. INJURY AND DAMAGE COULD OCCUR
IF THE ANTENNA WERE TO FALL.
1. Locate the MFJ-1623 in a convenient location. The best performance will be obtained by
placing the antenna outside, however the antenna may be used indoors if necessary. Avoid
placing the tuner near microphones, speech processors, computers, TNC's or other RF
sensitive devices.
2. The design of the antenna allows it to be installed in many ways. It can be easily attached to a
window frame, window box or balcony railing. A Wooden fence is another common mounting
location. The counterpoise is simply placed on the floor. Some installations may require the use
of a C-clamp or vice-grips to secure the base plate.

MFJ-1623 Instruction Manual Window/Balcony Mount Antenna
2
WARNING: High RF voltages exist at the antenna and counterpoise terminals. Avoid
touching these terminals while transmitting!
Important: Always remember to keep the antenna away from metal objects and out of
reach to prevent injury.
WARNING: SERIOUS RF BURNS AND INJURY CAN OCCUR IF CONTACT IS MADE
WITH THE ANTENNA.
Installation
IMPORTANT: WHILE INSTALLING THE ANTENNA TO A WINDOW OR BALCONY
CONNECT THE SAFETY ROPE OF THE BASE PLATE TO A
SUPPORT.
1. Choose a location to mount the antenna.
WARNING: NEVER MOUNT THE ANTENNA IN A LOCATION CLOSE TO POWER
LINES. SERIOUS INJURY OR DEATH MAY OCCUR.
2. Connect the safety rope to a good support.
3. Attach the mounting bracket in position by placing the bracket over or around the surface of the
support.
NOTE:THE ANTENNA SHOULD BE ORIENTED AWAY FROM WINDOWS AND OTHER
OBJECTS THAT ARE WITHIN CLOSE RANGE IF POSSIBLE.
4. Tighten the screws on the rear of the base plate against the surface of the support. The screws
should be tightened in equal increments to keep the force on the spacer plate proportioned.
5. Loosen the Counterpoise Attachment.
6. Insert the end of the counterpoise wire
7. Tighten to secure the counterpoise.
8. Connect your transceiver’s output to the SO-239 (UHF female) connector labeled
TRANSMITTER on the back of the tuner.
9. Decide which mount hole will be used on the mounting bracket according to your situation.
There are five holes available.
10. Connect the MFJ-1956 12 ft. telescopic whip antenna to the 3/8x24 stud on the top of the
mounting bracket and extend to its full length.

MFJ-1623 Instruction Manual Window/Balcony Mount Antenna
3
Using the MFJ-1623
CAUTION:Never Change The Antenna or Inductor Selector Switch Position While
Transmitting! Never Apply More Than 200 Watts To The MFJ-1623.
Preset the controls on the MFJ-1623 as follows:
•ANTENNA to maximum inductance -Position "A".
•MATCHING to minimum capacitance –Position “10”
•NORM/+C switch to NORM
•COUNTERPOISE to minimum inductance –Position “L”
•Hi-Z/Lo-Z switch (back of unit) to Lo-Z.
•SENSITIVITY control fully clockwise (maximum sensitivity)
Most modern solid state transceivers do not require tuning and loading adjustments. If the transceiver
has a built in antenna tuner, be sure it is turned off or disabled. If your transmitter has an adjustable
output circuit, it must be properly tuned to a 50 ohm load at the operating frequency before adjusting
the tuner. This should be done with a dummy load.
Tuning Procedure
WARNING: Never transmit while changing the INDUCTOR SELECTOR.
1) First, tune for maximum receiver noise as follows:
•While listening to your desired receive frequency, adjust the ANTENNA control for
maximum receiver noise.
•Adjust the MATCHING control for maximum receiver noise.
•Adjust the COUNTERPOISE control for maximum receiver noise.
Note: If no noise peak is evident, try adding extra capacitance with the NORM/+C
switch. Then reverse the HI-Z/LO-Z switch and re-try with both positions of the
NORM/+C switch.
2) Apply just enough power on CW (or AM/FM/RTTY) to obtain a noticeable deflection on the RF
CURRENT meter.
3) Carefully adjust the ANTENNA, MATCHING and COUNTERPOISE controls for maximum RF
current as follows.
•Adjust the MATCHING capacitor for maximum RF current.
•Adjust the COUNTERPOISE inductor for maximum RF current.
•Try plus or minus a position or two on the ANTENNA inductor, along with tuning the
MATCHING capacitor to see if higher RF current is achievable.

MFJ-1623 Instruction Manual Window/Balcony Mount Antenna
4
Note: These controls interact. Go back and forth between these adjustments as required until
maximum RF current is obtained.
4) The transmitter power may now be increased up to a maximum of 200 watts. Make sure you
reduce the RF SENSITIVITY control as necessary to keep from pinning the RF Current meter.
Note: The MFJ-1623 will reduce the SWR of most antenna systems to below 1.5:1. Maximum RF
current also corresponds to minimum SWR. This can be verified with an external SWR meter if
desired.
In Case of Difficulty
If this tuner fails to tune, please double check all connections and follow the tuning procedure again.
The power rating of this tuner is 200 watts on 30-10 meters. If this tuner arcs at the rated power
levels, please double-check all connections and follow the tuning procedure again.
If you are still unsuccessful, please read the following ANTENNA HINTS text.
Grounding Hints
To minimize RFI, antennas should be kept away from other wiring as much as possible. Also, the
antenna should be adequately insulated to prevent arcing or accidental contact if placed near other
objects.
For safety, it is always best to use both dc and RF grounds. A DC ground may not be practical in
some portable locations, however.
It is always important to have a good RF ground, provided by the counterpoise, when using any whip or
long-wire antenna. This is because the MFJ-1623 tuner needs something to "push" against in order to
force current into the antenna. If a good RF ground is not available, RF will usually find its way back
into the power line (RFI), transmitter audio circuits (RF feedback), or the operator (RF burns).
Water pipes provide good dc and ac safety grounds, but they are often inadequate for RF grounding
because they are long single conductors. RF grounds require large "spread out" surfaces with direct
multiple connections to the equipment ground point. Water pipes, heating ducts, or multiple ground
rods may work (especially if they are all connected together with jumper wires), but the best RF
grounds are radial systems or multi-wire counterpoises.

MFJ-1623 Instruction Manual Window/Balcony Mount Antenna
5
Antenna Hints
WARNING: For operator safety, a good earth ground should be installed and connected to
the case of the MFJ-1623. Make certain the safety ground connects to the
same terminal that connects to the transmitter and other station accessories.
A binding post labeled "COUNTERPOISE" is provided for counterpoise or
other RF ground connection(s). This post will not provide a safety ground.
Matching Problems
Most matching problems occur when the antenna system presents extremely high impedance to the
tuner. This occurs when the antenna is approximately a half-wavelength long at the frequency at which
you are trying to tune.
MFJ-1623 Artificial Ground
The MFJ-1623 contains a series L-circuit that is used to tune the RF ground system (either a
counterpoise or a ground wire). Maximum ground current will flow through the MFJ-1623 RF current
meter when the COUNTERPOISE switch is properly set.
Installation of a Suitable Counterpoise / Artificial Ground
The MFJ-1623 includes a counterpoise set of wires that will work well from 80-10 meters. It is
important to keep the last few feet of the counterpoise wires as far as possible (two feet minimum) from
each other and other near-by conductors.
You can also build your own counterpoise system if you desire. A RF counterpoise system can be as
simple as a single wire a quarter wave long or less, or as complicated as several wires cut for different
bands. Always insulate counterpoise wires and keep them from accidentally contacting animals, people,
RF sensitive devices and wiring. For best performance, try to position the counterpoise wires in a
straight line if possible.
A counterpoise wire must be well insulated. For best performance, several wires a quarter-
wavelength long on different frequencies should be connected together at the COUNTERPOISE post
of the MFJ-1623.
When counterpoise wires are located indoors, they can be laid on a floor under a carpet, placed in an
attic, or stapled to a basement ceiling. If you place the counterpoise under the carpet or where

MFJ-1623 Instruction Manual Window/Balcony Mount Antenna
6
someone may contact it, be sure to use well insulated wire and multiple counterpoise wires. Insulate the
far end of the counterpoise wire(s) with electrical tape to prevent accidental contact.
When counterpoise wires are used outdoors, only place them high enough to walk under. Use multiple
wires spaced a few feet apart (at minimum).
DANGER: Touching counterpoise and/or antenna wires while transmitting can cause an RF
burn. The wire must be well insulated and the end properly insulated.
There are cases very little deflection of the RF current meter can be seen. However, even though the
meter may not indicate much RF current change while adjusting the COUNTERPOISE control, even
the slightest RF current peak indicates that the artificial ground is helping.
Tuning Out Reactance of Long Ground Leads
If the station ground has a long lead, you can connect it to the COUNTERPOISE binding post of the
MFJ-1623. Connect the station ground bus and accessories to the GROUND post. Do not reverse
these wires. Follow the same procedure for maximizing RF Current described in the tuning procedure.
WARNING: This unit does NOT provide a dc or ac safety ground through the
COUNTERPOISE terminal. A separate wire from the station ground bus to
an electrical or earth ground must be used.
TVI and RFI Hints
It is possible for RF to flow down power cables into the house wiring. This may cause TVI, Stereo,
VCR or other RFI problems. As a precaution, a ferrite core can be clamped around power leads. The
MFJ-701 RFI-FREE CHOKE KIT makes it easy to eliminate common RFI problems.
Technical Assistance:
If you have any problem with this unit first check the appropriate section of this manual. If the manual
does not reference your problem or your problem is not solved by reading the manual, you may call
MFJ Technical Service at 662-323-0549 or the MFJ Factory at 662-323-5869. You will be best
helped if you have your unit, manual and all information on your station handy so you can answer any
questions the technicians may ask.
You can also send questions by mail to MFJ Enterprises, Inc., 300 Industrial Park Road, Starkville,
MS 39759; by Facsimile (FAX) to 662-323-6551; or by email to [email protected]. Send
a complete description of your problem, an explanation of exactly how you are using your unit, and a
complete description of your station.

MFJ-1623 Instruction Manual Window/Balcony Mount Antenna
7
Schematic

MFJ-1623 Instruction Manual Window/Balcony Mount Antenna
8
Tuning Chart
You may wish to remove or make a copy of this page and place it near the tuner. Insert your own
values for each frequency according to your station.
Freq MHz Counterpoise Matching Antenna Hi/Lo Z switch Extra cap switch
1.8
1.8
2.0
2.0
3.5
3.5
3.5
3.75
3.75
3.75
4.0
4.0
4.0
7.15
7.15
10.1
10.1
14.2
18.1
18.1
21.2
21.2
24.9
28.5
