Splash SLPLRND9 User manual

RoundMetalFramePoolSet
SLPLRND9-SLPLRND12-SLPORND15-SLPORND18
Above Ground Swimming Pool, Fast Setup and Durable,
Garden Backyard Lawn and Courtyard
IMPORTANTSAFETYRULES
Please read, understand, and follow
all instructions carefully before installing
and using this product.
Keep for future reference.
Serene

2 www.SereneLife.com
TABLE OF CONTENTS
IMPORTANT SAFETY RULES
METAL FRAME POOL PARTS LIST
POOL SETUP
FILTER PUMP INSTALLATION and INSTRUCTIONS
LADDER ASSEMBLY
POOL MAINTENANCE & CHEMICALS
GENERAL AQUATIC SAFETY
TROUBLESHOOTING GUIDE
LIMITED WARRANTY
SPECIAL INTRODUCTORY NOTE:
Please read this manual before setting up your pool. This information will help extend the pool
life and make the pool safer for your family's enjoyment. A team of 2-3 people is recommended
for pool set up. Additional people will speed up the installation.
3
5
7
11
14
16
19
19
20

3www.SereneLife.com
• Continuous and competent adult supervision of children and the disabled is required at all times.
• Secure all doors, windows and safety barriers to prevent unauthorized, unintentional or unsupervised pool
entry.
• Install a safety barrier that will eliminate access to the pool for young children and pets.
• Pool and pool accessories are to be assembled and disassembled by adults only.
• Never dive, jump or slide into an above-ground pool or any shallow body of water.
• Failure to set up pool on at, level, compact ground or over lling could result in the pool’s collapse and the
possibility that a person lounging in the pool could be swept out/ejected.
• Do not lean, straddle, or exert pressure on the inatable ring or top rim as injury or ooding could occur.
Do not allow anyone to sit on, climb, or straddle the sides of the pool.
• Remove all toys and otation devices from, in, and around the pool when it is not in use.
Objects in the pool attract young children.
• Keep toys, chairs, tables, or any objects that a child could climb on at least four feet (1.22 meters) away from
the pool.
• Keep rescue equipment by the pool and clearly post emergency numbers at the phone closest to the pool.
Examples of rescue equipment: coast guard approved ring buoy with attached rope, strong rigid pole not
less than twelve feet (12') [3.66m] long.
• Never swim alone or allow others to swim alone.
• Keep your pool clean and clear. The pool oor must be visible at all times from the outside barrier of the pool.
• If swimming at night use properly installed articial lighting to illuminate all safety signs, ladders, pool oor
and walkways.
• Stay away from the pool when using alcohol or drugs/medication.
• Keep children away from pool covers to avoid entanglement, drowning, or other serious injury.
• Pool covers must be completely removed before pool use.
Children and adults cannot be seen under a pool cover.
• Do not cover the pool while you or anyone else is in the pool.
• Keep the pool and pool area clean and clear to avoid slips and falls and objects that may cause injury.
• Protect all pool occupants from recreational water illnesses by keeping the pool water sanitized.
Don’t swallow the pool water. Practice good hygiene.
• All pools are subject to wear and deterioration. Certain types of excessive or accelerated deterioration can
lead to an operation failure, and can ultimately cause the loss of large quantities of water from your pool.
Therefore, it is very important that you properly maintain your pool on a regular basis.
• This pool is for outdoor use only.
• Empty pool completely when not in use for a longer period and safely store the empty pool in such a way
that it does not collect water from rain or any other source. See storage instructions.
• While the swimming pool is in use, you will need to operate the lter pump to ensure that there is at least one
complete turnover of water a day. Consult your pump’s manual to calculate the necessary operating hours.
IMPORTANT SAFETY RULES
Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product.

4www.SereneLife.com
POOL BARRIERS AND COVERS ARE NOT SUBSTITUTES FOR CONTINUOUS AND COMPETENT ADULT
SUPERVISION. POOL DOES NOT COME WITH A LIFEGUARD. ADULTS ARE THEREFORE REQUIRED TO ACT
AS LIFEGUARDS OR WATER WATCHERS AND PROTECT THE LIVES OF ALL POOL USERS, ESPECIALLY CHILDREN,
IN AND AROUND THE POOL.
FAILURE TO FOLLOW THESE WARNINGS MAY RESULT IN PROPERTY DAMAGE, SERIOUS INJURY OR DEATH.
Advisory:
Pool owners may need to comply with local or state laws relating to childproof fencing, safety barriers,
lighting, and other safety requirements. Customers should contact their local building code enforcement
office for further details.
Please read, understand, and follow all instructions carefully before installing and using this product.
These wamings, instructions, and safety guidelines address some common risks of water recreation, but they
cannot cover all risks and dangers in all cases. Always use caution, common sense, and good judgment when
enjoying any water activity. Keep for future reference. Packaging must be read carefully and kept for future
reference. See product for additional warnings
General
Check pins, bolts and/or screws for rust; splinters or any sharp edges regularly, especially accessible surfaces
to avoid injuries.
Non swimmers safety
• Continuous, active, and vigilant supervision of weak swimmers and non-swimmers by a competent adult is
required at all times (remembering that children under ve are at the highest risk of drowning).
Designate a competent adult to supervise the pool each time it is being used.
• Weak swimmers or non-swimmers should wear personal protection equipment when using the pool.
• When the pool is not in use, or unsupervised, remove all toys from the swimming pool and its surrounding
to avoid attracting children to the pool.
Safety devices
• It is recommended to install a barrier (and secure all doors and windows, where applicable) to prevent
unauthorized access to the swimming pool.
• Barriers, pool covers, pool alarms, or similar safety devices are helpful aids, but they are not substitutes for
continuous and competent adult supervision.
Safety equipment
• It is recommended to keep rescue equipment (e.g. a ring buoy) by the pool.
• Keep a working phone and a list of emergency phone numbers near the pool.
Safe use of the pool
• Encourage all users especially children to team how to swim.
• Learn Basic Life Support (Cardiopulmonary Resuscitation - CPR) and refresh this knowledge reguilarly.
This can make a life-saving difference in the event of an emergency.
• Instruct all pool users, including children, what to do in case of an emergency.
IMPORTANT SAFETY RULES

5www.SereneLife.com
• Never dive into any shallow body of water. This can lead to serious injury or death..
• Do not use the swimming pool when using alcohol or medication that may impair your ability to safely use
the pool
• When pool covers are used, remove them completely from the water surface before entering the pool.
• Protect pool occupants: from water related illnesses by keeping the pool water treated and practicing good
hygiene. Consult the water treatment guidelines in the user's manual.
• Store chemicals (e.g.water treatment, cleaning or disinfection products) out of the reach of children.
• Removable ladders shall be placed on a horizontal surface.
• Observe and follow the warnings and safety signs on the pool wall.
METAL FRAME POOL PARTS LIST
Item Image SLPLRND9 SLPLRND12 SLPORND15 SLPORND18
5
7
Pool cover
Support foot for the corner
vertical tube
Pool
Connection for the vertical
and horizontal tubes
12
12
1 1 1 1
1 1 1 1
12
12
12
12
12
12
16
16
16
16
16
16
16
16

6www.SereneLife.com
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents and become familiar
with all the parts.
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
(The number of pieces will vary depending on the pool size)

7www.SereneLife.com
IMPORTANT SITE SELECTION AND GROUND PREPARATION INFORMATION
• The pool location must allow you to secure all doors, windows, and safety barriers to prevent unauthorized,
unintentional or unsupervised pool entry.
• Install a safety barrier that will eliminate access to the pool for young children and pets.
• Failure to set up the pool on at, level, compact ground and to assemble, and ll with water in accordance
with the following instructions could result in the pool’s collapse or the possibility that a person lounging
in the pool could be swept out/ejected, resulting in serious injury or property damage.
• Risk of electric shock: connect the lter pump only to a grounding type receptacle protected by a ground-
fault circuit interrupter (GFCI) or residual current device (RCD). To reduce the risk of an electric shock, do not
use extension cords, timers, plug adapters or converter plugs to connect the pump to electric supply.
Always provide a properly located outlet. Locate the cord where it cannot be damaged by lawn mowers,
hedge trimmers, and other equipment. See Filter Pump manual for additional warnings and instructions.
• Risk of serious injury: DO NOT attempt to assemble pool in high wind conditions.
Select an outdoor location for the pool with the following requirements in mind:
1. The area where the pool is to be set up must be absolutely at and level.
Do not set up the pool on a slope or inclined surface.
2. The ground surface must be compacted and rm enough to withstand the pressure and weight of a fully
set up pool. Do not set up the pool on mud, sand, soft or loose soil conditions.
3. Do not set up the pool on a deck, balcony or platform, which may collapse under the weight of the lled
pool.
4. The pool requires at least 4 feet of space all around pool from objects that a child could climb on to gain
access to the pool.
5. Grass under the pool will be damaged. Splash out chlorinated pool water could damage the surrounding
vegetation.
6. Eliminate all aggressive grasses rst Certain types of grass such as St. Augustine and Bermuda, may grow
through the liner. Grass growing through the liner it is not a manufacture defect and is not covered under
warranty.
7. The area shall facilitate drainage of the pool water after each use and/or for long term pool storage.
POOL SETUP
IMPORTANT
Before allowing anyone to use the pool, hold a family meeting. Establish a set of rules that include,
at a minimum, the important safety rules and general aquatic safety information in this manual.
Review these rules on a regular basis and with all users of the pool, including guests.

8www.SereneLife.com
You may have purchased this pool with the lter pump. The pump has its own separate set of installation
instructions. First assemble your pool unit and then set up the lter pump.
Estimated assembly time 30-60 minutes, (Note the assembly time is only approximate and individual
assembly experience may vary.)
1. Liner Preparation
• Find a at, level location that is free and clear of stones, branches or other sharp objects that may puncture
the pool liner or cause injury.
• Open the carton containing the liner, joints, legs, etc., very carefully as this carton can be used to store the
pool during the winter months or when not in use.
• Take out the ground cloth (8) (if included) and spread it
over the cleared area. Then take out the liner (6) and
spread it out over the ground cloth, with the drain valve
directed towards the draining area. Place the drain valve
away from the house. Allow the sun to warm up the liner
before inserting the beams (5) into the sleeve openings.
IMPORTANT: Always set up the pool unit with at least
2 persons Do not drag the liner across the ground as this
can cause liner damage and pool leakage (see drawing 1).
• During the setup of this pool liner, point the hose connections or openings in the direction of the electric
power source. The outer edge of the pool should be within reach of the pump's electrical connection.
2. Horizontal Beams Assembly
• The frame pool's legs (7) and beams (5) fall into two groups. The larger diameters are the horizontal beams
that are slid (pushed) into the sleeve openings at the top of the liner. The smaller diameters are the vertical
legs. Both these legs and beams t into the T-joints (3).
6
1
2.1
2.2
2.3
NOTE: Sprinkle some talcum powder over the horizontal beams
before sliding them into the pool liner sleeve. This will make
removal of the beams from the liner easier during the disassembly
or the pool.
• Starting at any location, but always working in the same direction,
push the horizontal beam into the sleeve. Once the beam is centered
take one of the T-joints and attach the joint to one end of the beam.
Push the beam rmly into the T-joint. Repeat this procedure in a
circular fashion until all the beams and joints have been connected
(see drawings 2.1 & 2.2).
NOTE: It's important to start from one location and work in the
same direction until the last attachment. Do not start from multiple
locations as this will make the connections difficult for the last few
beams and joints.
The last joint connection may be dicult to complete. You can do
it though, if you rst simultaneously raise the last joint and beam
about 2 inches (5 cm). Now insert the beam into the joint while
lowering the pieces into position. The beam will easily slide into
the joint (see drawing 2.3). Ensure that the last joint is fully
connected before proceeding to connecting the legs.

9www.SereneLife.com
3. Vertical Legs Assembly
4. Filling of the pool
• The following applies to pool liners with hose connectors. The pool was purchased with a lter pump, insert
one of the two plugs (8 & 9) into the lter pump outlets. Please follow the Filter Pump Instructions rst and
then proceed to next installation step.
• Before lling the pool with water, ensure that the drain plug (1) inside the pool is closed and that the drain
cap (2) on the outside is screwed on tightly. Fill the pool with no more than 1 inch. (2.5 cm) of water.
Check to see whether the water is level.
Water level
4
For 8"x20" (244cm x 51cm):
Attach the legs end cap (4) to the bottom of each leg (7)
rst. With the beams and T-joints assembly resting on the
ground, insert the top of the leg into the bottom of the
T-joint (3) (see drawing 3.1). Continue the process with
all the vertical legs.
NOTE: This pool size does not come with an all-around
center belt.
Lift the beams assembly and make sure all the legs are a
vertical position (see drawing 3.2). Push all the T-joints
downward to ensure they are rmly connected to the legs.
For 10" (305cm) and above sizes:
Attach the legs end cap (4) to the bottom of each leg (7)
rst. With the beams and T-joints assembly resting on the
ground slide one vertical leg into the belt loop located
in the middle of the pool liner and insert the top of the
leg into the bottom of the T-joint (3) (see drawing 3.3).
Continue the process with all the vertical legs.
• Lift the beams assembly and make sure all the legs are
in a vertical position (see drawing 3.4). Push all the
T-joints downward to ensure they are rmly connected
to the legs.
• Pull gently in an outward direction, the bottom of the
leg making sure the leg is vertical and perpendicular
to the level ground.
3.1 3.2
4
3.3 3.4

10 www.SereneLife.com
IMPORTANT: If the water In the pool ows to one side, the pool is not completely level. Setting up the
pool on unlevel ground will cause the pool to tilt resulting in the sidewall material bulging and a potential
collapse or move the pool if the pool is not completely level, you must drain the pool, level the area or
move the pool to a dierent area that is level, and re-ll the pool following the above directions.
• Smooth out the bottom liner wrinkles (from inside the pool) by pushing out where the pool oor and pool
sides meet. Or, (from outside pool) reach under the side of the pool, grasp the pool oor and pull in an
outward direction. If the ground cloth is causing the wrinkles, have 2 people pull from opposite sides to
remove all wrinkles. Use the properly assembled pool ladder when entering or exiting the pool during this
process. Also make sure all the legs are vertical and perpendicular to the ground.
• Fill the pool with water up to just below the sleeve line. (see drawing 4)
CLEANING OR REPLACING FILTER CARTRIDGES
It is recommended that the lter cartridge be replaced at least Regularly monitor the lter clogging level.
1. Make sure lter pump is not operating. Disconnect line cord.
2. To prevent water from escaping the pool, unscrew the pool inlet nozzle (10) and strainer grid (11) from the
strainer connectors and insert the hat-like plugs into the strainer connectors.
3. In a counter-clockwise motion, remove the lter housing collar (12) and threaded cover (3).
Be careful not to lose the cover seal (4).
4. Remove lter cartridge (5) to clean it. The lter may be cleaned from the spray from a water hose.
5. Use judgement as to whether cartridge needs to be replaced. Only use the original lntex cartridge for
replacement. See "Parts Reference" section for detail.
6. Return cartridge to ltering position.
7. Return the seal (4) and threaded cover (3) to their original positions and in a clockwise direction re-screw
the housing collar (12) onto the lter housing.
8. After service, open the air release valve, remove the plugs, allow any air to escape through the valve before
tightening the valve again and replace the pool inlet nozzle (10) and strainer grid (11).
The pump is now primed with water again and may be turned on.
9. Check the inlet and outlet openings regularly to ensure they are not obstructed thus preventing a good
ltration.
10. The disposal of any used lter media should be in accordance with applicable local regulation and
legislation.
Filter Information
300 gallons: 3.14× 3.54 inch

FILTER PUMP INSTALLATION and INSTRUCTIONS
11www.SereneLife.com
IMPORTANT SAFETY INSTRUCTIONS
When installing and using this electrical equipment, basic safety precautions should always be followed,
including the following:
1. READ AND FOLLOW ALL INSTRUCTIONS
2. WARNING – To reduce the risk of injury, do not permit children to use this product unless they are closely
supervised at all times;
3. WARNING – Risk of Electric Shock. Connect only to a grounding type receptacle. This product is provided
with a ground-fault circuit-interrupter. If replacement of the plug or cord is needed, use only identical
replacement parts;
4. For US market only, the unit is provided with a ground-fault circuit-interrupter (GFCI). To test the GFCI, push
the test button. The GFCI should interrupt power. Push the reset button. Power should be restored. If the
GFCI fails to operate in this manner, the GFCI is defective. If the GFCI interrupts power to the pump without
the test button being pushed, a ground current is owing, indicating the possibility of an electric shock.
Do not use this pump. Disconnect the pump and have the problem corrected by a qualied service
representative before using;
5. The unit must be connected only to a supply circuit that is protected by a ground-fault circuit-interrupter
(GFCI). Such a GFCI should be provided by the installer and should be tested on a routine basis. To test the
GFCI, push the test button. The GFCI should interrupt power. Push the reset button.
Power should be restored. If the GFCI fails tooperate in this manner, the GFCI is defective. If the GFCI
interrupts power to the pump without the test button being pushed, a ground current is owing, indicating
the possibility of an electric shock. Do not use this pump. Disconnect the pump and have the problem
corrected by a qualied service representative before using;
6. Do not bury cord. Locate cord to minimize abuse from lawn mowers, hedge trimmers, and other equipment;
7. WARNING – To reduce the risk of electric shock, replace damaged cord immediately;
8. WARNING – To reduce the risk of electric shock, do not use extension cord to connect unit to electric supply;
provide a properly located outlet;
9. CAUTION – This pump is for use with storable pools only. Do not use with permanently-installed pools.
A storable pool is constructed so that it is capable of being readily disassembled for storage and reassembled
to its original integrity. A permanently-installed pool is constructed in or on the ground or in a building such
that it cannot be readily disassembled for storage;
10. SAVE THESE INSTRUCTIONS.

12 www.SereneLife.com
FILTER PUMP EXPOLDED DIAGRAM
P1 Air valve screw
P2 Air valve O ring
P3 Filter housing chamber cover
P4 Filter cover rubber ring
P5 Filter
P6 Body
P7 Seal O ring
P8 Power cable
1. Set up your Storable Pool exactly. Fill it completely with water.
2. Position the lter pump unit at least 8 inches below the highest water level in the pool.
3. And keep the lter pump at lease 2 feet away from the sidewall of the pool.
4. Place lter cartridge into the body of the lter pump.
5. Make certain that the lter chamber rubber gasket is placed in the seal groove on the top of the lter pump.
6. Screw on lter chamber cover onto top of the body of lter pump by hand.
7. Connect the hoses same as the Installation illustration, xture the pump to the wall of pool.
Remember to use hoseclamp, tighten it secondly with screwdriver.
8. Open both wall plug caps (P13) on the inside of the pool an plug in a strainer (P14) for each.
9. Allow time for lter pump chamber to full with water. Never operate the lter pump dry.
10. Connect electrical power cord into a grounded receptacle protected by a ground-fault circuit interrupter
(GFCI). Please contact a qualied electrician for verication purposes and/or installation of a GFCI
receptacle if necessary.
Please install your lter pump following the lnstallation lllustration bellow:
INSTALLATION ILLUSTRATION
Hose
P8
P8
P7 P7
P10

13www.SereneLife.com
FILTER PUMP OPERATING INSTRUCTIONS
1. The lter pump will prime itself as long as it is positioned at least 8 inches below the highest water level is
a relief is a relief valve located on the top of the pump. Simply turn the valve knob counter-clockwise, and
when a small amount of water escapes, close immediately by turning clockwise. The pump will now be
completely primed.
2. Never operate the lter pump dry. This can cause damage to seals which may result in leakage and/or
ooding.
3. Prior to each use, check to ensure that all hose-clamps are tightened.
4. Prior to each use, check to ensure that both inside wall plug caps (P13) are open and strainer (P14) have
been installed properly.
5. To prevent possible electric shock, do not attempt to plug in electrical power cord with wet hand or while
standing in water.
6. The lter pump must operate in the upright, vertical position.
7. The lter pump must be positioned on level, stable ground. The use of a riser or elevated platform is not
expected.
8. Once you have conrmed turn on the pump by plug its electrical cord into a ground fault circuit interrupter
outlet.
9. To preserve the full life of the pump and to keep the pool ltered properly, your pump should be run
approximately 4 to 6 hours per day.
10. Overuse may cause overheating and/or motor burnout. Use good judgment on extremely days and be
mindful of running the lter pump continuously for an extended period of time.
FILTER PUMP CLEANING AND REPLACEMENT
1. The lter cartridge in your pump lter system should be replaced approximately once per month.
2. Periodically cleaning of your lter cartridge can enhance the effectiveness of your lter pump and
moderately prolong the cartridge’s lifespan prior to replacement.
3. Keep the power be disconnecting to the unit when cleaning the lter cartridge.
4. Remove the Strainers inside of the pool, and close the caps of the pools Wall Plugs.
5. Turn the Air Valve Screw to release the air suction inside.
6. Remove the Filter Chamber Cover and the lter chamber rubber gasket, and then take out the lter cartridge.
7. Clean the lter cartridge with a garden hose using a direct powerful waterspray.
8. If the lter cartridge cannot be cleaned effectively in this manner, it is time to replace it with a new cartridge.
9. Your clean (or new) cartridge can be put back into the lter chamber and you can refer to the installation
instruction to re-assemble the lter pump unit.
FILTER PUMP GENERAL MAINTENANCE
1. To avoid dangerous or fatal electrical shock hazard, always disconnect power to the unit before attempting
to clean pump.
2. There is no need for any regular mechanical maintenance of the pump unit.
(Do not attempt to disassemble the pump motor at any time).
3. If necessary, clean outside of pump with a mild detergent and water, rinsing off with a hose.
4. There is no need for the use of any lubricants on the pump.
5. Do not use solvents clean the lter cartridge, as they will cause damage to the plastic components inside
the pump.

14 www.SereneLife.com
LADDER ASSEMBLY
SPARE PARTS
ITEM NO. PIC DESCRIPTION QTY
1
2
3
4
5A
5B
Screw
Stair Step
Connector for the upper
handrails
U-shaped upper
handrail
Side bar A
Side bar B
8
8
2
2
2
2
1

15www.SereneLife.com
2 3
4

16 www.SereneLife.com
REMEMBER TO:
• Protect all pool occupants from possible water-related illnesses by keeping the pool water clean and
sanitized. Do not swallow the pool water. Always practice good hygiene.
• Keep your pool clean and clear. The pool oor must be visible at all times from the outside barrier of the pool.
• Keep children away from pool covers to avoid entanglement, drowning, or other serious injury.
WATER MAINTENANCE
The maintenance of a proper water balance through appropriate use of sanitizers is the single most
important factor in maximizing the life and appearance of the liner as well as ensuring clean, healthy
and safe water. Proper technique is important for water testing and treating the pool water. See your
pool professional for chemical, test kits and testing procedures. Be sure to read and follow the written
instructions from the chemical manufacturer.
1. Never let chlorine come in contact with the liner if it is not completely dissolved. Dissolve granular or tablet
chlorine rst in a bucket of water, then add it to the pool water.
Likewise with liquid chlorine; mix it immediately and thoroughly with the pool water.
2. Never mix chemicals together. Add the chemicals to the pool water separately.
Thoroughly dissolve each chemical before adding another one to the water.
3. Do not use a pressure washer to clean the pool.
POOL MAINTENANCE & CHEMICALS
TROUBLESHOOTING
PROBLEM DESCRIPTION CAUSE SOLUTION
ALGAE
· Greenish water.
· Green or black spots on
pool liner
· Pool liner is slippery and/
or has bad odor.
Chlorine and pH level
need adjustment.
· Super chlorinate with shock
treatment. Correct pH to your
pool store's recommended
level.
· Vacuum pool bottom.
· Maintain proper chlorine level.
COLORED WATER
Water turns blue, brown, or
black when rst treated
with chlorine.
Copper, iron or
manganese in water
being oxidized by the
added chlorine.
· Adjust pH to recommended
level.
· Run lter until water is clear.
· Replace cartridge frequently.
FLOATING
MATTER IN WATER Water is cloudy or milky
· "Hard warm" caused
by a too high pH
level.
· Chlorine content is
low.
· Foreign matter in
water.
· Correct the pH level. Check
with your pool dealer for
advice.
· Check for proper chlorine level
· Clean or replace yur lter
cartridge.

17www.SereneLife.com
Do not add chemicals if the pool is occupied. This can cause skin or eye irritation. Concentrated chlorine
solutions can damage the pool liner. In no event is SERENELIFE, their related companies, authorized agents
and service centers, retailers or employees liable to the buyer or any other party for costs associated with
the loss of pool water, chemicals or water damage. Keep spare lter cartridges on hand.
Replace cartridges every two weeks.
EXCESSIVE RAIN: To avoid damage to the pool and over lling, immediately drain rain water that causes
the water level to be higher than the maximum.
HOW TO DRAIN YOUR POOL AND LONG TERM STORAGE
1. Check local regulations for specic directions regarding disposal of swimming pool water
2. Check to make sure that the drain plug inside the pool is plugged in place
3. Remove the cap from the drain valve on the outside pool wall
4. Attach the female end of the garden hose to the drain connector (1)
5. Place the other end of the hose in an area where the water can be safely drained away from the house and
other nearby structures.
6. Attach the drain connector to the drain valve.
NOTE: The drain connector will push the drain plug open. Inside the pool and water will start to drain
immediately.
7. When the water stops draining, start lifting the pool from the side opposite the drain, leading any remaining
water to the drain and emptying the pool completely.
8. Disconnect hose and adapter when nished
9. Re-insert drain plug in drain valve on inside of pool for storage
10. Replace drain cap on outside of pool.
11. Reverse set-up instructions to disassemble the pool, and remove all connecting parts.
12. Be sure that the pool and all parts are completely dry before storage. Air dry the liner in the sun until
completely dry before folding (see drawing 5). Sprinkle some talcum powder to prevent the vinyl from
sticking together and to absorb any residual missed.
13. Create a square shape. Starting at one side, fold one-sixth of liner in on itself twice.
Do the same on the opposite side (see drawings 6.1 & 6.2)
14. Once you have created two opposing folded sides, simply fold one over the other like closing a book
(see drawings 7.1 & 7.2).
PROBLEM DESCRIPTION CAUSE SOLUTION
CHRONIC LOW
WATER LEVEL
Level is lower than on
previous day
Rip or hole in pool
liner or hoses.
· Repair with patch kit
· Finger tighten all caps.
· Replace the hoses.
SEDIMENT ON
POOL BOTTOM Dirt or sand on pool oor Heavy uses, getting in
and out of pool.
Use pool vacuum to clean
bottom of pool.
SURFACE DEBRIS Leaves, insects etc. Pool too cloose to
trees. Use pool skimmer
POOL MAINTENANCE & DRAINAGE
ALWAYS FOLLOW THE CHEMICAL MANUFACTURER'S DIRECTIONS
AND THE HEALTH AND HAZARD WARNINGS.

18 www.SereneLife.com
15. Fold the two long ends to the middle (see drawing 8).
16. Fold one over the other like closing a book and nally compact the liner (see drawing 9)
17. Store the liner and accessories in a dry, temperature controlled between 32 degrees Fahrenheit
(0 degrees Celsius) and104 degrees Fahrenheit (40 degrees Celsius), storage location.
18. The original packing can be used for storage.
Winterizing your Above Ground Pool
After usage, you can easily empty and store away your pool in a safe place. You must drain, disassemble
and properly store the pool when the temperature drops below 41degree Fahrenheit (5 degrees Celsius)
to prevent ice damage to the pool and related components. Ice damage can result in sudden liner failure
or pool collapse. Also see the seetion ''How To Drain Your Pool''.
Should temperatures in your area not drop below 41degrees Fahrenheit (5 degrees Celsius), and you
choose to leave your pool out, prepare it as follows:
1. Clean the pool water thoroughly. If the type is an Rectangular or Round Frame Pool, make sure that the top
ring is properly inated.
2. Remove the skimmer (if applicable) or any accessories attached to the threaded strainer connector.
Replace strainer grid if necessary. Be sure all accessories parts are clean and completely dry before storage.
3. Plug the Inlet and Outlet tting from the inside of the pool with the plug provided (sizes 16' and below).
Close the Inlet and Outlet Plunger Valve (sizes 17' and above).
4. Remove the ladder (if applicable) and store in a safe place. Be sure the ladder is completely dry before storage.
5. Remove the hoses that connect the pump and lter to the pool.
6. Add the appropriate chemicals for the winter period. Consult your local pool dealer as to which chemicals
you should use and how to use them. This can vary greatly by region.
7. Cover pool with Pool Cover. IMPORTANT NOTE: POOL COVER IS NOT A SAFETY COVER.
8. Clean and drain the pump, lter housing and hoses. Remove and discard the old lter cartridge.
Keep a spare cartridge for the next season.
9. Bring pump and lter parts indoors and store in a safe and dry area, preferably between 32 degrees
Fahrenheit (0 degrees Celsius) and 104 degrees Fahrenheit (40 degrees Celsius).
WINTER PREPARATIONS

19www.SereneLife.com
GENERAL AQUATIC SAFETY
Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and death.
To reduce your risk of injury, read and follow all product, package and package insert warnings and
instructions. Remember, however, that product warnings, instructions and safety guidelines cover
some common risks of water recreation, but do not cover all risks and dangers.
For additional safeguards, also familiarize yourself with the following general guidelines as well as
guidelines provided by nationally recognized Safety Organizations:
• Demand constant supervision. A competent adult should be appointed as a “lifeguard” or water watcher,
especially when children are in and around the pool.
• Learn to swim.
• Take the time to learn CPR and rst aid.
• Instruct anyone who is supervising pool users about potential pool hazards and about the use of protective
devices such as locked doors, barriers, etc.
• Instruct all pool users, including children what to do in case of an emergency.
• Always use common sense and good judgement when enjoying any water activity.
• Supervise, supervise, supervise.
TROUBLESHOOTING GUIDE
PROBLEM CAUSE SOLUTION
FILTER MOTOR
FAILS TO START
· The motor is not plugged in
· The GFCI/RCD circuit breaker is
tripped
· Motor too hot and overload
protection is shut off.
· Filter cord must be plugged into a 3 wire
outlet that is protected by a Class A Ground
Fault Circuit Interrupter, or RCD.
· Reset circuit breaker. lf circuit breaker trips
repeatedly, your electrical system may have
a defect. Turn off circuit breaker and call an
electrician to correct the problem.
· Let the motor cool down.
FILTER DOESN'T
CLEAN POOL
FILTER DOESN'T PUMP
WATER OR FLOW IS
VERY SLOW
· Clogged inlet or discharge
· An air leak on the intake line.
· Scale or buildup on cartridge.
· Excessively dirty pool.
· Dirty lter cartridge.
· The nozzle and strainer connection
are reversed.
· Pool inlet air adaptor connected
to the wrong tting.
· Clear any obstructions in the intake hose
by discharging it inside pool wall.
· Tighten hose clamps, check hoses for
damage, check pool water level.
· Replace cartridge.
· Clean cartridge more often.
· Install the nozzle at the upper position of
the pool inlet, and the strainer at the lower
position of the pool outlet.
· Make sure the pool inlet air adaptor is
connected to the pool inlet upper tting.
· Improper chlorine or pH levels
· Filter cartridge is dirty
· Damaged cartridge
· Excessively dirty pool.
· The strainer screen is restricting
the water ow.
· Adjust the chlorine and pH level.
Consult your local swimming pool supply
stores.
· Clean or replace cartridge.
· Check the cartridge for holes.
Replace if damaged
· Operate the lter for longer periods.
· Clean the strainer screen at the inlet.

20 www.SereneLife.com
IMPORTANT
lf you continue to experience diculty, please contact our Consumer Service Department for assistance.
LIMITED WARRANTY
Your Pool has been manufactured useing the highest quality materials and workmanship.
All products have been inspected and found free of defects prior to leaving the factory.
This Limited Warranty applies to the SERENELIFE Pool only.
This limited warranty is in addition to, and not a substitute for, your legal rights and remedies. To the extent
that this warranty is inconsistent with any of your legal rights, they take priority. For example, consumer laws
across the European Union provide statutory warranty rights in addition to the coverage you receive from
this limited warranty: for formation on EU-wide consumer laws, please visit the European Consumer
Center Website at https://ec.europa.eu/consumers/ecc/contact-en/htm.
The provisions of this Limited Warranty apply only to the original purchaser and are not transferable.
This Limited Warranty is valid for the period noted below from the date of the initial retail purchase.
Keep your original sales receipt with this document, as proof of purchase will be required and must accompany
warranty claims or the Limited Warranty will be invalid. Pool Liner and Frame Warranty-1 Year.
PROBLEM CAUSE SOLUTION
PUMP DOESNT WORK
· Low water level
· Strainer screen plugged up
· An air leak on the intake hose
· Faulty motor or the impeller is
jammed.
· An air lock inside the cartridge
chamber.
· Fill pool to correct water level.
· Clean strainer screens at pool inlet.
· Tighten hose clamps, check hose for
damage.
· Clear any sticks or leaves in the intake hose.
· Open the release valve at top of pump.
TOP COVER LEAKING
HOSE LEAKING
· Hose clamps are not well-tted.
· Hose o-ring dislodged when
connecting the hose.
· Hose broken.
· Tighten or change hose clamps.
· Put the o-ring back into the groove.
· Replace a new hose.
· O-ring missing
· Cover or air release valve are not
tighten.
· Remove cover & check for O-ring.
· Tighten cover or valve (Manually).
AIR LOCK
POOL INLET AIR
ADAPTOR/AIR JET
VALVE LEAKING
· Hose clamps are not well-tted.
· Air jet valve is not tight and
facing up.
· Air jet valve internal seal blocked.
· Air jet valve internal seal dirty.
· Air jet valve broken.
· Tighten or reinstall hose clamps.
· Tighten air jet valve and make sure it's
facing up.
· Plug in the pump and run for few seconds,
then unplug, repeat 3 times.
· Remove air jet valve, ush dirt out with
water and replace valve back.
· Replace a new air jet valve
There's air trapped in the pump
housing and inlet hose.
Open air release valve, lift and lower the
inlet hose until water starts to ow out of
the air release valve, close air release valve.
