Splendide WD802M User manual

NOTE: Electrical Cord Location, Drain Outlet, Exhaust Outlet
and Water Inlets are located on the rear of the unit
Front Leveling
Drain Outlet
Water Inlets
Control Panel
Electrical CordLocation
(6' cord length)
(depending
on positioning
ofleveling
legs)
Side View(not to scale)
Front View(not to scale)
23 ½"
5½"
2½"
29½"
33 ¼"to 33 ¾"
2"
2"
1¼"
5½"
1¼"
36¼"
8
Plastic
U-Clamp
Flexible
Drain Hose
(5' length)
DataSheet IncludesInformation On
Splendide
Product Model Number
WD802M
Splendide 2000 LaundryCenter
Installation Location:
·Unit maybe installedin recessedarea,
closet,or alcove.
·Air Space Requirements:0"on sidesand
1"in front andback(Additional installation
spacing needsto be consideredfor easy
installation,servicing,andcompliance with
state andfederal codes.)
·Floor must support at least 280lbs.andbe
asolid,level surface.
·When locating in atowable trailer or
watercraft,position the machine over
the axlesor mid-shipwhere movement is
at aminimum.Blockunit in to prevent
extreme movement.
Electrical Requirements:
·Machine Voltage/Amperage:115V, 60Hz,
12.5Amps
·Connection:3-prong plug with6'cordis
providedwithunit.
·Circuit/Protector:3-wire single phase,120V,
60Hz, AC,on separate 15-ampere circuit.
Standpipe Drain System/SinkDraining
Requirements:
·Needsa1¼"(3.2cm)minimumdiameter
standpipe withthe minimumcarry-away
capacityof7gallons(26liters)per minute.
Topofstandpipe must be at least 25"(62
cm)highandno higher than 34"(86cm)
fromthe bottomofthe washer.
·Outlet endofdrain hose (providedwiththe
unit)must be at least 20"above bottomof
washer.An air breakmust be available at
the standpipe to avoidsiphoning.
·Faucet Adapter Kit #154187104A is
available to allowfor direct faucet
connection.See complete installation
instruction on drain hose draining directly
into sink, connection to dishwasher Wye
fitting,anddisposer/drain connection in
ownersmanual.
·Optional Drain-A-Way™Pansare
available.Pan #PI-22 for cabinet or under-
counter installations.Pan #P-24for
freestanding installations.Bothdesignedto
be drain plumbed.
Exhaust Requirements:
·DO NOTexhaust dryer into achimney,
furnace,coldair duct,attic,crawl space,or
another duct usedfor venting
·Ifcabinet door isinstalled,aminimumof8
sq. inchesshouldbe provided.Louvered
doorswithequivalent air openingsare
acceptable.Allowclearance behindthe
door(s)to avoidrubbing between backof
cabinet door(s)andfront ofunit control
panel.Additional clearancesfor wall,door
andfloor moldingsmaybe required.
·Rigidor flexible metallicduct required.
Ducting must slope downwardsandaway
fromthe machine.
Never reuse datasheets.Datasheetsare subject to change without notice.Never use datasheetsfor final installation criteria. Complete
installation instructionsare available upon request and in the owner'smanual that comeswith the unit.
H
C
8"
Exhaust
Outlet
(4" diam.)
31¼"
3
8
26¾"
1"
4"
20½"
21"
