Split-fire 2000 Series User manual

1

Thank You for Purchasing a Split-fire Log
Splitter!
We appreciate having you as our customer and wish
you many years of safe and satisfactory operation
with your machine.
SPLIT-FIRE SALES INC.
285633 Airport Road
Norwich, ON N0J 1P0
Canada
1-877-548-3473 / 519-468-3647
Please share a google review about your
Split-Fire experience

Table of Contents
1. Introduction 4
1.1 How to use your Owner’s Manual 4
1.2 Product Identification 6
1.3 Warranty 7
2. Safety 8
2.1 Safety Labels 8
2.2 Wood Handling Safety 10
2.3 Operation Safety 11
2.4 Worksite Safety 14
2.5 Option Safety / Operation 16
2.51 Log Lifter 16
3. Operating Instructions 18
3.1 Before Operation & 3 Point Hookup 18
3.2 Operation 20
3.3 After Operation & 3-Point Hookup 21
4. Maintenance 22
4.2 Log Splitter Maintenance 22
4.21 Frame 22
4.22 Valve 26
5. Storing you Splitter 24
7. Parts Breakdown 25
8. Manual Checklist 27

2000, 3000 & 4000 Series 3-Point
Introduction Owners Manual
4
1.1 How to use your Owner’s Manual
This owner’s manual is a very important part of your new machine
and should remain a permanent part of it. If the machine is sold, the
operator’s manual must go with it.
By reading the operator’s manual you will help yourself and others
avoid unnecessary personal injury and/or damage to the machine
and will also allow you to perform maintenance to keep your machine
operating properly. The information recorded in this manual will help
you use this machine safely and effectively. Once you know how to
operate the machine correctly and safely, you can train others to
operate the machine as well.
If your machine has been ordered with any options or attachments,
please refer to the option safety section of the individual operator’s
manual that is included with that specific accessory.
The machine that is used in this manual for illustration may differ
slightly from your model. It will be similar enough to help you
understand our instructions.
Throughout this manual the terms “Left Hand” and “Right Hand” will
be used. These sides are determined when standing behind the
engine and facing the knife or far stop of the machine. Also “Back”
and “Front” will be used. On the self-contained log splitter, the “Back”
is referred to the engine side and the hitch is the “Front”. The
hydraulic pump would be located on the back-left corner of the
machine.
Your machine has been tested and inspected to pass quality control
at Split-fire’s Manufacturing facility to ensure good performance prior
to leaving the factory.

2000, 3000 & 4000 Series 3-Point
Owners Manual Introduction
5
While reading the manual, important messages are used to bring the
operator’s attention where there may be safety concerns relating to
machine damage and important servicing information. Please read
all these messages to avoid personal injury and machine damage.
The three main messages will start with:
WARNING!!!: which suggests, a strong chance of personal
injury or death to the operator or bystanders if procedures are
ignored.
IMPORTANT: which suggests, a strong chance of potential
damage to the machine may occur if procedures are ignored.
NOTE: suggests to the operator, General information given to
help the operator to operate or service the machine.

2000, 3000 & 4000 Series 3-Point
Introduction Owners Manual
6
1.2 Product Identification
If you ever need to contact your dealer or the manufacturer for parts
or questions regarding the operation or servicing of the machine, it is
important to have the model number as well as all the necessary
identification numbers. Using the sample pictures on page 7 you can
find the necessary numbers to complete the spaces below.
Date of Purchase:
______________________
Dealer Name:
___________________________________________
Dealer Phone Number:
______________________
Frame Serial Number: ( XX XX XX )
______________________
Frame Serial Number

2000, 3000 & 4000 Series 3-Point
Owners Manual Introduction
7
1.3 Warranty
Split-Fire Sales Inc. guarantees the original purchaser of any new
Split-Fire machine, that the same is free of defects in workmanship or
materials that may cause performance failure, subject to the
condition’s hereafter.
Split-fire must be contacted before the problem on the machine has
been fixed. Split-fire will diagnose the problem and authorize any
warranty work that will be allowed. If Split-fire does not authorize or
parts are not sent from Split-Fire, warranty will not be applicable.
This guarantee is limited to a period of one year from the date of
purchase. Replacement of any defective part is free of charge FOB
Split-Fire Sales Inc. If Split-Fire requires the parts to be returned to
Split-Fire, Split-Fire will pay for return shipping.
This guarantee does not apply to engines or other parts that are
manufactured and guaranteed by the manufacturer thereof, nor does
this apply with respect to any part or product that:
1. has original parts removed or otherwise altered without
specific authorization beforehand from Split-Fire Sales Inc.
2. has had placed upon or attached to it, any part or product not
sold or approved by Split-Fire Sales Inc.
3. has been damaged or is not used in conformity with the
applicable instruction for the machine.
4. has not been properly adjusted or maintained by the owner.
5. has been adjusted or altered to increase the performance of
the machine.
This guarantee is in lieu of, and excluded all other guarantees and
conditions of merchantability and fitness for a purpose. Acceptance
of a Split-Fire Sales product constitutes an agreement that Split-fire
Sales shall have no liability for any special or consequential damage.

2000, 3000 & 4000 Series 3-Point
Safety Owners Manual
8
2.1 Safety Labels
The machine safety labels shown in the section below are very
important. They are placed in areas on the machine that draw the
attention of the operator to potential safety hazards on the machine.
If at any time the stickers are removed, or come off, contact your
dealer or the manufacturer immediately for replacement decals.
The operator’s manual explains the potential safety hazards in detail
associated to each decal. Special attention should be kept for these
recommendations. They are outlined for your safety.

2000, 3000 & 4000 Series 3-Point
Owners Manual Safety
9

2000, 3000 & 4000 Series 3-Point
Safety Owners Manual
10
2.2 Wood Handling Safety
WARNING!!! - NEVER HANDLE WOOD ON THE SAWN ENDS;
BLOCKS SHOULD ALWAYS BE HELD BY THE BARK SIDES!
HANDLING BLOCKS ON THE SAWN END INCREASES RISK FOR
PERSONNEL INJURY
WARNING!!! - NEVER LIFT HEAVY/OVERSIZE LOGS BY
YOURSELF. BAD POSTURE AND HEAVY LOGS MAY CAUSE
SEROIUS INJURY. IF THE LOG IS TOO HEAVY GET ASSISTANCE
OR UTILIZE A HYDRAULIC LOG LIFTER.
It is important to always wear proper PPE when operating your log
splitter.
Gloves – Gloves must be worn at all times to reduce the risk of
slivers, embedded objects (Nails, Wire, etc) and contact with natural
poisons, (Poison Ivy, Poison Oak)
Eye Protection – Eye protection must be worn to reduce the risk of
eye injury from airborne objects.
Foot Protection – Foot Protection must always be worn to reduce the
risk of foot injury from falling logs. When splitting, logs may slip when
being lifted, or may fall off the splitting bed.
Hearing Protection – Hearing protection must be worn to reduce the
risk of hearing loss. Engines are loud enough to cause risk of hearing
loss when exposed over a long period of time.

2000, 3000 & 4000 Series 3-Point
Owners Manual Safety
11
2.3 Operation Safety
Carefully read and understand all the instructions pertaining to the
log splitter in the operator’s manual before operating your new
machine. Anyone who operates or services this machine must read
the owner’s manual first. If any doubt or question arises about the
safe and/or correct method of performing anything in this manual,
contact one of our representatives at our head-office.
Avoid accidents by being alert and recognizing potential hazards.
Not all possible circumstances can be anticipated in this manual.
Keep your log splitter and work area safe for yourself and others.
Proper care and safety is your responsibility.
NOTE:If your log splitter is equipped with a Honda engine or any
other attachments, be sure to read those manuals.
All operators must have the necessary training and skills to
operate and the machine properly and safely. Use the controls
correctly and follow the safety signs and recommendations.
Never allow untrained persons to operate or service the
equipment.
Never let persons under the age of 18 operate the log splitter.
Warning:
The engine exhaust from this product contains
chemicals known to the State of California to
cause cancer, birth defects and other
reproductive harm.

2000, 3000 & 4000 Series 3-Point
Safety Owners Manual
12
The owner is responsible for accidents and injuries to themselves
and/or other persons operating their machine. If others are permitted
to use this machine it is the responsibility of the owner to train users.
New users may operate this machine in a clear, unobstructed
area under the supervision of an experienced operator, only after
they have read and understand the owner’s manual.
Only allow responsible adults who are familiar with the instructions
to operate this machine.
Inspect your machine each time before use. Special attention
should be taken that all guards are in place, damaged or missing
parts are replaced, and that all the safety decals highlighted in the
safety labels section are in place on the machine.
Each time you operate your log splitter, ensure that the handle on
the hydraulic valve returns to center position. Move handle both
ways and if it sticks, immediately call the dealer or manufacturer for
replacement parts.
Only one person may operate the machine at any time. More than
one operator greatly increases the chance of personal injury or death.
Never leave machine unattended while running.
Never operate machine when under the influence of alcohol or
drugs.
Do not alter; add accessories, or attachments to your log splitter
without the approval of the manufacturer. Doing any of the above
without the manufacturer’s approval WILL VOID THE WARRANTY. If
attachments have been added with the approval of the manufacturer,
be sure to keep safety labels visible.

2000, 3000 & 4000 Series 3-Point
Owners Manual Safety
13
Your machine is designed to split wood only! Stones, metal,
brush, gravel, and other foreign objects will cause damage to the
machine and increase the chance of personal injury or death.
It is not recommended to split wood across the grain. This may
cause wood to explode out sideways and cause personal injury or
death.
Operate your machine in a smooth manner. Do Not jam the
control handles back and forth in a uncontrolled motion. Always
maintain control and operate the controls at an even steady pace.

2000, 3000 & 4000 Series 3-Point
Safety Owners Manual
14
2.4 Worksite Safety
Keep area around the log splitter clear from tall grass, debris,
tools, and wood chunks/bark at all times.
Operate log splitter on level surface only.
Do not operate your machine in enclosed areas. Your engine
produces Carbon monoxide, which is extremely dangerous if used in
enclosed area. (E.g. Garage, Workshop, Barn)
Do not operate machine when distracted by others. Keep children
and pets at least 25 feet away from the work area to protect them
from possible injuries. Keep other distractions such as radio,
television etc. away.
Only use machine during daylight hours. Use of this machine
without proper lighting can lead to personal injury or death.
Protect yourself at all times while operating your machine. Safety
glasses, Hand Protection, Steel-toed boots and Ear Protection must
be worn at all times. Loose clothing is also not permitted around your
machine.
Keep hands and body parts clear of cutting blades and end stops
at all times.
Never handle wood on the sawn ends; blocks should always be
carried by the bark sides.

2000, 3000 & 4000 Series 3-Point
Owners Manual Safety
15
Hands should not be lower than halfway down the sides of the
block when splitting. If hands are lower and a log falls, fingers may
get pinched between the log and the shelves.
If your machine is equipped with a log lifter, it is recommended
that the operator stands on the right side of the machine and follows
the wood up with their hand to stabilize the log and keep it from
rolling off the bed. If the machine does not have a log lifter, the
operator can stand either on the left or the right side.

2000, 3000 & 4000 Series 3-Point
Safety Owners Manual
16
2.5 Option Safety / Operation
2.51 Log Lifter
The hydraulic log lifter add-on is a great addition when splitting large
oversize logs but must be operated with care. If installation is not
completed by a Split-Fire technician, follow installation manual
associated with the option.
Log Lifter Safety
- Do NOT exceed 500lbs load capacity.
- Only operate the log splitter and lifter on a level surface.
- Operate the log lifter from the left side of the machine.,
- Ensure that the log lifter is clear of any obstacles, so it
does not hit or get caught on tools or machinery.
- Keep people and pets at least 25 feet away from the Log
Lifter during operation.
- Operate the Log Lifter smoothly. Do NOT jam the handle
forward/reverse.

2000, 3000 & 4000 Series 3-Point
Owners Manual Safety
17
Log Lifter Operation
The log lifter is operated independently by the secondary valve
adjacent to the main valve.
Gradually push/pull the handle and the Log Lifter will raise/fall
into position.
NOTE!!!
If your log splitter is designed with a closed center hydraulic system,
different log lifter valving will apply. If you are experiencing difficulties
with proper log splitter and log lifter operation, contact Split-fire for
details concerning this system.

2000, 3000 & 4000 Series 3-Point
Operating Instructions Owners Manual
18
3. Operation
3.1 Before Operation and 3 Point hookup
Before operating your machine, inspect it to ensure it is in good
working order.
1. It is important that you have read and understood all safety
recommendations before operating the Log Splitter. Read
both the Log Splitter, and Tractor owners manual before
operating the machine.
2. Be sure that the knife is free of burrs and dents. This can
occur from splitting logs with embedded steel material. If the
material has burrs or is dented, sand the knife to remove the
dent and the burrs.
3. Bring the tractor to the splitter, lower the 3-point hitch bars
and slide the lower bars on the crossbar pins on the log
splitter. Secure the 3-point bars via linch pins.
4. Attach the top link via a top link bar. Adjust the top link bar so
the log splitter is sitting in the level position. Secure the top
link with ¾” pins and linch pins where needed.

2000, 3000 & 4000 Series 3-Point
Owners Manual Operating Instructions
19
5. Insert the hoses in the rear hydraulic remotes on the tractor.
The 2 hoses should be inserted in the appropriate remotes as
per the tractor owner’s manual. If the owner’s manual does
not specify, contact a local dealer that represents your
tractors’ brand.
6. Check for any hydraulic leaks around the hydraulic valve, and
cylinder. If there are any leaks replace the faulty parts or
reseal leaky fittings.
7. Verify that the log splitter 3 PT connection is completed
properly and is secure.
8. Once the “before operation inspection” has been completed,
the Log Splitter is ready for operation.

2000, 3000 & 4000 Series 3-Point
Operating Instructions Owners Manual
20
3.2 Operation
Once the “before operation checklist” has been completed, operation
can begin:
1. Put on the appropriate PPE (Ear, Eye, Foot, Hand protection
is important for safety).
2. The tractors hydraulics can be actuated to the on position. For
more details reference your tractors owner’s manual. If the
owner’s manual does not specify details, contact a local
dealer that represents your tractors brand.
3. Increase the RPM’s on the tractor to the desired speed. The
higher the RPM’s the higher the hydraulic flow. If fast cycle
time is not required, the tractor can operate the log splitter at
RPM’s just over an idle. If more speed is required, the tractor
can operate at full RPM’s which will increase log splitter cycle
time.
4. Adjust the height of the 3-point hitch arms to bring the log
splitter to a comfortable working height.
5. The machine is now ready for operation. Run the log splitter
smoothly. Do not jam or move the handle abruptly. Only
handle logs on the bark side.
Once splitting has been completed, follow the following steps:
1. The tractors rpm can be lowered slowly.
2. Actuate the tractor hydraulics to the off position.
