spo-comm KUMO IV User manual

Quick guide spo-book KUMO IV
Please check before you start the device:
• If the device temperature conforms to the recommended operating temperature.
• If the power source is correctly connected.
• If all adaptors and connectors are properly connected.
1. Front Panel:
2. Rear Panel:
1. ower Button
2. Microphone In
3. Audio Out
4. USB 2.0
5. USB 3.0
6. Display orts; max. 3840x2160 @ 60Hz
7. HDMI orts; max. 3840x2160 @ 60Hz
8. RJ45-GbE-LAN
9. WLAN-Antenna (optional)
10. 19.5V DC IN
3. Dimensions:

. Assembling :
dimensions of the boreholes:
5. BIOS:
ower on the computer and the system will start OST ( ower On Self Test) process. When the message below
appears on the screen, press „DEL“ to enter Setup.
To save the BIOS settings press „F10“.
Short description of some BIOS settings:
5.1. Wake On RTC: That allow a computer to 'wake up' after shut down to execute tasks every day or on a
certain day. -> Power-> Wake up on Alarm
5.2. Restore on AC Power Loss: This setting specifies whether your system will reboot after a power failure or
interrupt occurs. -> Power-> Restore on AC Power Loss
[[Power Off] Leaves the computer in the power off state.
[Power ON] Leaves the computer in the power on state.
[Last State] Restores the system to the previous status before power failure or interrupt occurred.
5.3. pxe-Boot: boot an OS via LAN and DHC . -> Feature -> Onboard Device Control -> Launch PXE Option Rom
Mount the kit on the backside of the
KUMO IV with four screws.

5. . Wake On LAN: Wake-on-LAN (WoL) is a particular function that allows the computer to be powered up
from a low-power state by a message from another part of a local area network.
-> Power -> LAN Wakeup Support
6. Drivers:
The drivers for the spo-book KUMO IV can be found in our product catalog on the product page under the tab
" roduct Details and Downloads" and on the supplied driver stick.
Direktlink: htttp://www.spo-comm.de/products/en/mini-pcs/spo-book-kumo-iv.html
