SPORTS ART A957 User manual

A957
OWNER'SMANUAL
ASSEMBLYINSTRUCTIONS
LEEGXTENSION
PDFcreated withpdfFactorytrialversion www.pdffactory.com

Seatbottom Guideselectionpin
Fore-and-aft
adjustment
Seatback
Mainframe
Footpad
Fronttopcover Rearcover
Sideframe
Frontcover(A)
Backcover
Cord
Stackfork
Weightstacks
(11lbs/5kgs)
Selectionpin
(3.5lbs/1.5kgs)
Selectionpin
(6.5lbs/3kgs)
Usagesticker
Frontcover(B)
Rotator
Legcushion
A.Introduction
PDFcreated withpdfFactorytrialversion www.pdffactory.com

B.ListofParts
1.Oneside
2.Onemainframe
3.Onelegcushion
4.FourhexagonheadboltsM10xP1.5xL30forframeandmainframe
5.FourspringwashersM10forframeandmainframe
6.FourhexagonnylonnutsM10xP1.5
7.Onedouble-endopenwrench17mmx23mm
8.One8mmx17mm
9.OnehexkeywrenchM6
10.OnehexkeywrenchM5
11.User'smanual
frame
side
side
forsideframeandmainframe
double-endopenwrench
PDFcreated withpdfFactorytrialversion www.pdffactory.com

C.STEPBYSTEPINSTRUCTION:
1.Holdtheframesduringassembly,thentightentheframeswithscrewsprovided
(item4,5,6aslistedinpartslist).SeeFig.1
2.Tightenthelegcushionintorotatorandtightenitwithscrewsasshowninthe
diagram.(SeeFig.2)
Fig.1
Fig.2
PDFcreated withpdfFactorytrialversion www.pdffactory.com

D.OperatingInstruction:
1.Therotatoradjustingpinisusedforadjustingtherotatortotheproperinitial
positionfortheuser.(SeeFig.3)
2.ThePlateadjustingpinisusedforusertoadjusttheplatetotheproperposition.
(SeeFig.4)
Fig.3
Fig.4
rotatoradjustingpin
plateadjustingpin
PDFcreated withpdfFactorytrialversion www.pdffactory.com

3.Therotatingrangeisshortenwhenrotatoradjustingpinmovesto"A",therotating
rangeislengthenwhenrotatoradjustingpinmovesto"B".(SeeFig.5or5-1)
Fig.5
Fig.5-1
Rotatingrangeadjustingpin
PDFcreated withpdfFactorytrialversion www.pdffactory.com

4.Pulloutthepositioningpintoadjusttheplateadjusterandthelegcushionis
movableatthistime.Movethelegcushiontoaproperpositionfortheuserand
thepositioningpingetsbackautomaticallytosecurethecushion(asshownin
diagram6or6-1).Diagram6-2showsthewaytomovetheplatefromone
locationtoanotherlocation.
Fig.6-1
Fig.6
Fig.6-2
PDFcreated withpdfFactorytrialversion www.pdffactory.com

5.Pullthepositioningpinoutandturnit90degreestoeitherrightorleftdirection(as
shownindiagram7or7-1)andtheplatestaysfree(asillustratedindiagram7-2).
Theuserneedstohookthecushionbyhis/herankles.
Fig.7-1
Fig.7
Fig.7-2
PDFcreated withpdfFactorytrialversion www.pdffactory.com

E. HOWTOUSETHEMINORWEIGHTSTACK
1.Tohaveaminorweightstackselection,inserttheupperpintoadd
3.5Lb/1.5kgorthelowerpintoadd6.5Lb/3kg.
2.Pullthepintoreleasetheminorweightstack.(SeeFig.8)
Fig.8
PDFcreated withpdfFactorytrialversion www.pdffactory.com

F.BeltAdjustingInstruction:
1.Ifthebeltistootightortooloose,loosenthenutAasshowninthediagram
first,thenadjustthenutB,ifthebeltlengthistoolong,adjustdownward;if
thebeltlengthistooshort,adjustupward.Adjustthebelttotheproper
positionthentightenthenutA.
2.ThegapbetweennutAandBhastobewithin35mm(1.4").Ifthegapstill
exceeds35mmlimitafterfirststep,pleaseloosenupthescrewsonCand
adjustthebelttotheproperlength.Tightenthescrewsandfollow1ststep
again.(SeeFig.9)
Fig.9
PDFcreated withpdfFactorytrialversion www.pdffactory.com

UsageInstruction:
