Bafo BF-376 User manual

HDMI EXTENDER
User Manual
BF-376
HDMI Extender Over Single Fiber with IR（20KM）
(Full HD 1080P TCP/IP)
Bring High-Definition to your life!

03
HDMI Extender Over Single Fiber with IR（20KM）
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future
reference.
1.0 INTRODUCTION
BAFO HDMI Extender over single fiber is a tool for extending HDMI signal
over a long distance to a compatible HDMI display. Instead of using expensive
HDMI cables, your existing fiber cables/sockets can be utilized to perform
advanced functions like transferring deep color (12 bit/color) digital video and
audio, with a bandwidth up to 225MHz. The HDMI Extender over single fiber
is your substantial HDMI extender tool and it also supports IR re-transmitting
so you can control the display source which is up to 20KM away.
2.0 FEATURES
1. Support HDMI1.3/HDCP1.2 protocol
2. Support input/output resolutions: 60fps 1080p/720p/576p/480p
3. Support IR remote control 20~60KHz
4. Audio format support: DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
5. TPC/IP protocol compliant, one transmitter and multiple receivers with a
maximum of 253 receivers
6. Simple to install, plug and play, no drivers needed
3.0 PACKAGING ACCESSORIES:
When first unpacking your extender please check to see if the following items
are included:
1. HDMI Transmitter------------- --------------------------------------------------1 PCS
2. HDMI Receiver-------------------------------------------------------------------1PCS
3. IR-TX-------------------------------------------------------------------------------1 PCS
4. IR-TX-------------------------------------------------------------------------------1 PCS
5. 12V DC Power Supply adapter ---------------------------------------------2 PCS
6. User manual----------------------------------------------------------------------1 PCS
4.0 SPECIFICATION
HDMI Version ------------------------------------------------------------------ HDMI V1.3
Transmitter Input Port ------------------------------------------------------ HDMIx1(AF)
Transmitter Output Port ---------------------- HDMIx1(AF), SC Fiberx1, IR-TXx1
Receiver Input Port --------------------------------------------- SC Fiberx1, IR-RXx1
Receiver Output Port ------------------------------------------------------- HDMIx1(AF)
Frequency Bandwidth ------------------------------------------ 2.25Gbps (single link)
Input/Output Resolutions ----------------------------------- 480p,576p,720p,1080p
Audio ------------------------------------------- Sample rate:32KHz,44.1KHz,48KHz
IR Remote Control ---------------------------------------------------- 20~60KHz; NEC
ESD Protection Human Body Model ------------------- ± 8kV (air-gap discharge)
± 4kV (contact discharge)
Operating Temperature ------------------------------- - 0˚C ~ 40˚C / 32˚F ~ 104˚F
Storage Temperature ------------------------------------20˚C ~ 60˚C / -4˚F ~ 140˚F
Relative Humidity--------------------------------------20~90% RH (non-condensing)
Dimensions (mm)---------------------------------------------------------------120x73x22

03
HDMI Extender Over Single Fiber with IR（20KM）
5.0 PANEL DESCRIPTIONS
Please study the panel drawings below and become familiar with the signal
input, output and power requirement.
HDMI Extender Transmitter
Power -------------------------------------------------------------- Power Indicator
Status ----------------------------------------------------------- Working Indicator
Reset ------------------------------------------------------------------ Reset Button
DC/12V ---------------------------------------------------------- Power Input Port
HDMI Input ------------------------------------------------------ HDMI Input Port
HDMI Output ------------------------------------------------------ HDMI Loopout
IR-TX ---------------------------------------------------------------- IR Transmitter
Fiber Output ---------------------------------------------------------- Fiber Output
HDMI Extender Receiver
Power -------------------------------------------------------------- Power Indicator
Status ------------------------------------------------------------ Working Indicator
DC/12V ----------------------------------------------------------- Power Input Port
HDMI Output -------------------------------------------------------- HDMI Output
IR-RX -------------------------------------------------------------------- IR Receiver
Fiber Input --------------------------------------------------------------- Fiber Input

03
HDMI Extender Over Single Fiber with IR（20KM）
6.0 CONNECT AND OPERATE
6.01 Transmitter and Receiver one by one application.
Before installation, please make sure all devices you wish to connect have
been turned off.
1. Connect HDMI source to the transmitter unit.
2. Use SC fiber cable to connect transmitter and receiver of HDMI Extender.
3. Connect the display device to the receiver unit.
4. Power on all connected devices.
6.02 Transmitter and Receiver one by N application, N can up to 253.

HDMI Extender Over Single Fiber with IR（20KM）
04
7.0 INSTALLATION AND PRECAUTIONS
To avoid electric shock, product damage, and for your safety, please notice
the following:
1. Please slowly plug or unplug signal cables, do not plug and unplug too often
or shake them.
2. The equipment should not be placed under the sun, rain and damp or
unventilated environment.
3. Liquid items should not be placed on the equipment.
4. Do not install the equipment near heat sources such as fire, power, or other
amplifiers that produce heat.
5. Do not insert the metal or other objects to the equipment in addition to
connecting cables to ports.
6. Do not demolish the equipment by yourself; it should be maintained by
professional maintenance staff.
