Spring MAX INDUCTION SM-351C-FT User manual

Owner’s Manual
Countertop, Portable, Sizzle
Induction Range
127 Ambassador Drive, Suite 147
Naperville, IL 60540-4079
P: 630-527-8600
F: 630-527-8677
[e-mail]
www.springusa.com
The Evolution of Intelligent Design®
June 2019
Model #
SM-351C-FT (US)
SM-351C-FTA (US)
SM-353C-FT (Int’l)
SM-353C-FTU (UK)
The Evolution of Intelligent Design®

23
Function
Spring USA’s Countertop, Portable, Sizzle Induction Range is a heating
unit for product cooking or holding. The range features a durable,
titanium colored, stainless-steel body and integrated oversized pan
support. Each range includes our exclusive SmartScan® technology with
over/under voltage protection, pan size and pan type recognition, and
large LED power/temp display.
Before You Begin
To ensure safe operation, read the following instructions in their
entirety.
Warning is used to indicate the presence of a hazard that can cause
severe personal injury, death, or substantial property damage if the
warning is ignored.
Caution is used to indicate the presence of a hazard that will or can
cause minor personal injury or property damage if the caution is
ignored.
NOTICE
Notice is used to note information that is important but not
hazard-related.
To reduce risk of injury or damage to the equipment:
•Plug only into grounded electrical outlets matching the nameplate
rated voltage.
•Do not power the equipment with extension cords, power strips, or
multipurpose sockets.
•Equipment should only be used in a flat, level position.
•Do not obstruct or cover the equipment in any way when in use.
•Do not operate unattended.
•Do not leave an empty vessel on the equipment when in use.
•Closely supervise equipment operating in public areas and/or around
children.
•Do not operate if equipment has been damaged or is malfunctioning
in any way.
•Keep equipment and power cord away from open flames, electric
burners or excessive heat.
•Unplug equipment and let it cool before cleaning.
•Unplug when not in use.
Model # Voltage Phase Hertz Watts Amps Plug
SM-351C-FT
(US) 208-240 160 3500 14.6 NEMA 6-20P
SM-351C-
FTA
(US) 208-240 160 3500 14.6 NEMA 6-20P
SM-353C-FT
(Int’l) 220-240 150-60 3500 14.6 CEE-7/7 16A Schuko
SM-353C-
FTU
(UK) 220-240 150-60 3000 12.5
BS 1363 (13A)
U.K.
Electrical Requirements:

Installation
Inspect all parts of the induction range prior to installation and use. If
the unit is damaged, do not use. Contact a supplier for a replacement.
To prepare the induction range for use, simply place the unit on a flat,
level surface. If the unit is not level, adjust the leveling legs by turning
the feet clockwise or counterclockwise until the unit sits solidly in place.
Ensure the installation location has dedicated power. There must be at
least 4” of space available around the induction range for proper
ventilation.
45
Operation
To operate the induction range, induction-ready vessels must be used.
•Glass serving vessels are not suited for use on the induction range.
•Vessels must have a flat base in order to make full contact with the
range. Vessels that are footed, or that have a raised ridge, are not
suited for the induction range.
•Vessels must have a base diameter greater than 4.7”.
Follow the below steps for operating the induction range:
1. Plug in the unit. Two horizontal lines may blink in the display
window. This does not indicate the unit is ON. The ON/OFF button
must be pressed to turn the unit ON.
2. Press the ON/OFF button.
3. Place the vessel on the induction range surface.
NOTICE:
Spring USA induction servers and induction ranges are
designed to work together as a system. Optimal
performance is achieved by using Spring USA
components in conjunction with each other. Spring USA
cannot guarantee the performance of facsimile products
offered by other companies.
4. The LED lights above each time setting will blink until a time setting
is pressed.
5. Press the desired time setting button. The LED lights will stop
blinking and only the LED light above the selected time setting
button will remain on. The display window will start to countdown
the time.
6. Once the time has expired, the unit will stop heating.
7. A different time setting can be selected during the countdown of a
previously selected time setting. This will restart the time to the
newest time setting.
NOTICE:
There are no set temperatures on the Sizzle, Induction
Range. Temperature is dependent on the type of vessel
used and the amount of time the vessel is heated.
Do not touch the top surface of the induction range
immediately after heating and removing a vessel. The
top surface may be hot due to heat transferred from the
vessel.

7
6
Warranty
For limited warranty information, visit the Spring USA website.
Service & Repair
Never attempt to service any part of The Sizzle Induction Range.
Attempting to service the unit on your own, or through an unauthorized
repair facility, automatically voids your warranty. Contact our Service
Department at 630-527-8600. For service forms, visit the Spring USA
website.
Troubleshooting/Error Codes
Error Cause Solution
E0 The induction range does
not sense an induction-
ready vessel on the surface.
Place an induction ready vessel
on the range.
E1 The range has overheated
due to blocked ventilation
and has shut down.
Clear vents, let the range cool
and restart the range.
E2 Overheating protection has
been activated and the
range has shut down.
Remove vessel from the range,
let the range cool and restart the
range.
E3 The range is experiencing
temporary voltage
overload.
Remove vessel from the range,
let the range cool and restart the
range. Review dedicated power
requirements under Installation
in this manual.
Keep the induction range away from other ovens or stoves. If the
surrounding temperature is hot, the induction range may stop heating.
Maintenance
To clean the induction range, first ensure the unit has been turned off,
unplugged from the power source and has cooled before handling.
Wipe down the unit with a sponge or cloth with a mild dishwashing
liquid. Dry with a clean, soft cloth. Do not immerse the induction
range directly in water for cleaning –this will damage the unit.
Inspect the mesh air filter on the underside of the induction range each
day. If it is soiled, remove the filter and wash with hot water, dish
washing detergent and a scrub brush. Dry and attached to the unit
before operating. If using the unit daily, recommend filter replacement
period is every 6 months.
