Springtree HD202 WW User manual

USER MANUAL AND
INSTALLATION GUIDE
HD202 WW
LED Ellipsoidal

2(615) 599-1505 www.springtree.net
Table of Contents
1. Before You Begin
What is included.......................................................................................................................3
Safety precautions....................................................................................................................3
2. Product Information
Description................................................................................................................................4
Features....................................................................................................................................4
3. Installation
Power supply.............................................................................................................................5
Mounting....................................................................................................................................5
Adjusting the shutters................................................................................................................6
Using a gobo.............................................................................................................................6
 Usingagelorlter.....................................................................................................................6
DMX linking...............................................................................................................................7
4. Operation
Menu buttons............................................................................................................................7
Operating modes......................................................................................................................7
LED display menu.....................................................................................................................8
DMX Modes..............................................................................................................................8
5. Maintenance
Cleaning your ellipsoidal..........................................................................................................10
6. Technical Specications
Troubleshooting.......................................................................................................................10
Dimensions..............................................................................................................................11
Warranty...................................................................................................................................12
Contact us...............................................................................................................................12

3
[phone] www.springtree.net
Before You Begin
What is included
When you open your package, there should
be four items inside of the box:
1. One LED Ellipsoidal light Engine
(lens sold separately)
2. One gobo holder
3. One gel frame
4. One Powercon power cord
*If any of these items is damaged or missing,
please contact Springtree Media Group.
Safety Precautions
•Toreducetheriskofelectricalshockorre,donotexposethisunittomoisture.
• Be sure that the local power outlet matches that of the required voltage for your unit
• Do not attempt to operate this unit if the power cord has been frayed or broken. Do not attempt
 toremoveorbreako󰀨thegroundprongfromtheelectricalcord.Thisprongisusedto
 reducetheriskofelectricalshockandreincaseofaninternalshort.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user serviceable parts inside.
• Never plug this unit into a dimmer pack.
• Always be sure to mount this unit in an area that will allow proper ventilation. Allow about 6”
between this device and a wall.
•ThisxtureisintendedforindooruseONLY.
• During long periods of non-use disconnect the units main power.
• Always mount this unit in a safe and stable manner.
• Keep this manual for as long as you own this product!
3.
4.
2.
1.
2.

4(615) 599-1505 www.springtree.net
• 200W WW LED
• Digital Display
• Interchangeable 19°, 26° or 36° lenses (sold
separately)
• Lightweight 13lb body
• Three pin XLR jacks
• 2 channel DMX
• Gobo holder
• Gel frame
• 4 shutters for controlled spotlighting
• Linking Powercon IN/OUT
Description
The Springtree HD202WW LED
Ellipsoidalisapowerfulxturesuitable
for theatrical performance halls, schools
and houses of worship. With this versatile
instrument,youcangetmanydi󰀨erentuses
fromonesinglexture.Youcancontrolthe
size, shape, edge and intensity of the beam
of light.
Product Information
Features

5
[phone] www.springtree.net
Power Supply
Before plugging your unit in, be sure the source voltage in your area matches the voltage
required for your lighting setup. Every unit has a power supply capable of 120V. Because line
voltage may vary from venue to venue, you should be sure your unit voltage matches the wall
outlet voltage before attempting to operate your unit.
* Always connect this product to a protected circuit with an appropriate electrical ground to
avoidtheriskofelectrocutionorre.
Mounting
When mounting your ellipsoidal, make sure there is adequate room for ventilation. Oper-
atinginaninsu󰀩cientlyventilatedroomcanleadtoanoverheatingofthedeviceandmaycause
serious accidents. Keep a minimum distance of 6 inches around and above the device. Before
deciding on a location, mount in a way that it will be easy to access the unit for maintenance and
addressing.
Installation

6(615) 599-1505 www.springtree.net
Adjusting the shutters
To adjust the width and shape of the beam, simply push or pull any of the four shutters
located around the body of the ellipsoidal.
Gel frame
Framing shutter
(top)
Framing shutter
(left)
Framing shutter
(bottom)
Using a gobo
If you want to shape your light with a gobo,
insert it into the included gobo holder so that it is
visible through the circular hole. In order for your
gobo to be projected correctly, it should be inserted
upsidedownandipped.Afteryou’veinserted
your gobo into the holder, screw the holder shut
so that the gobo is secure and does not move. Slide the holder into the slot located in front of the
top shutter. When removing the gobo, make sure to let it cool before handling.
Using a gel or lter
To alter the color of your light
beam insert a gel into the included
gel frame. Screw the frame closed
so that the gel is secure and does
not move. Slide the holder into
the slots located in front of the lens.
When removing the gel and
holder, make sure to let it
cool before handling.
To look like this Insert like this
Gobo holder

7
[phone] www.springtree.net
DMX linking
An LED Ellipsoidal can be connected to a DMX controller by a 3-pin DMX cable, allowing
total control over one or more lights. To do this, connect a DMX cable from the DMX-input (labeled
DMX IN) on your lighting unit to the DMX-output of the controller. Connect a second light via its
DMX-inputtotherstunit’sDMX-output(labeledDMXOUT)tocontrolandsynchronizemultiple
lighting units at once.
DMX IN
DMX IN DMX IN
DMX OUT DMX OUT
Operation
Menu Buttons
There are buttons on the back of this unit: MENU, UP, DOWN and ENTER. Normally the LED
willdisplaythecurrentDMXaddresscodeofthexture.PressMENUtochoosethedesiredfunc-
tionandpressENTERtoconrm.
Operating modes
This light can operate in 2 modes:
• DMX control mode- this function will allow you to control each individual unit with a standard
DMX 512 controller
• Stand Alone- each ellipsoidal will operate in a manual stand alone mode. No DMX wire nec-
essary.
Power IN

8(615) 599-1505 www.springtree.net
Operation - Menu/DMXTraits

9
[phone] www.springtree.net
Maintenance
Cleaning your ellipsoidal
Due to fog residue, smoke, and dust cleaning the internal and external optical lenses must
be carried out periodically to optimize light output.
  1.Usenormalglasscleanerandasoftclothtowipeo󰀨theoutsidecasing.
2. Clean the external optics with glass cleaner and a soft cloth every 20 days.
3. Always be sure to dry all parts completely before plugging the unit back in.
*Cleaning frequency depends on the environment in which
the unit operates (i.e. smoke, fog residue, dust, dew).
Troubleshooting
Listed below are a few common problems that you may encounter
when using this product:
Unit not responding to DMX:
1. Check that the DMX cables are
connected properly and are
wired correctly. DMX output DMX input
2. Check that all cables are connected to the right connectors; it does matter
which way the inputs and outputs are connected.

10 [phone] www.springtree.net
 TechnicalSpecications
• Power Supply: AC120V, 50/60Hz
• Power Consumption: Max. 200W
• LED: WW COB
• ElectronicStrobe:1-20ash/s
• Display: 4-digit LED
• Data In/Out: XLR 3Pin
• Cooling: heat sink plus 2 fans
• Housing: Plastic
• Housing Color: Black
• IP Rating: IP20
• Environment Temp: -30°C-50°C
• Dimensions(mm): L25in x W6.5in
• Net Weight: 13lbs
Dimensions:

11
[phone] www.springtree.net
 Ocehours:
Monday-Friday, 8:30 AM to
5:00 PM CT
Telephone:
[phone]
Contact Us!
Springtree Media Group would like to thank you for choosing our company for
your lighting needs! If you have any questions or concerns, please contact us.
WARRANTY
1st YEAR - Parts and labor. Advanced replacement - First 90 days with shipping
covered by Springtree Media.
2nd YEAR - Repair/ Replace Springtree discretion. Return shipping covered by
customer.
E-mail:
[email protected]
Website:
www.springtree.net
