Sprintis S68 User manual

S68
+++++++ Complete Manual for S68 +++ English +++++++
www.sprintis.de
Comb binding machine
Manual

2 3
Thank you for purchasing the comb binding
machine S68. The S68 is a plastic binding
machine with 21 rings and a binding capacity
of 500 sheets.
Please read this instruction carefully before
use.
Please keep this manual on file as reference
book and for troubleshooting.
Please read before use
Table of contents
Safety adivce & advantages............................ S. 3
Layout .............................................................. S. 4
Operating instructions & technical data........S. 5
Safety advice, content & advantages
Safety advice
To prevent damage of the device and
inju- ries of the operator, it is absolutely
neces- sary to comply the safety notes in
this manual.
The mentioned warnings describe possible
injuries and damages, which are due to
wrong usage or maintenance of the device.
Please read and follow these safety notes
before reading the manual.
1) Do not injure yourself when transporting
the unit. It has a weight of approx.
9 kilograms
2) Use only paper and PVC cover sheets for
punching, otherwise the punches could
be damaged and dull.
3) Do not insert your fingers into the paper
tray. There is a risk of injury.
4) Be sure to place the unit in a stable place.
5) Keep the unit free from dust and
moisture.
Content & Advantages
1) Adjustable paper depth stop (3-8mm)
2) Large-volume removable collection bin
for punching waste
3) Two levers for easy operation
4) Seven individually adjustable punches
1x Binding machine
2x Lever
2x Screws
1x Manual

4 5
Layout
1
2
5
3
8
7
4
11
9
10
6
1. insertion comb
2. tie lever
3. paper stop
4. punch lever
5. casing
6. base plate; casing
7. selector control
8. depth stop indicator
9. paper insert
10. waste bin
11. punch individual adjustable
Binding spine 6 mm 8 mm 10 mm 11 mm 12 mm
Sheets 80 g/m2max. 25 max. 45 max. 65 max. 80 max. 95
Binding spine 14 mm 16 mm 19 mm 22 mm 25 mm
Sheets 80 g/m2max. 125 max. 145 max. 180 max. 210 max. 240
Binding spine 28 mm 32 mm 38 mm 45 mm 51 mm
Sheets 80 g/m2max. 270 max. 310 max. 375 max. 440 max. 500
Layout, operating instructions & technical data
A) Set depth stop
B) Adjusting the paper stop
C) Loading paper
D) Punching
E) Remove punched paper
F) Insert binding spine
G) Carefully open the binding halfway
H) Inserting punched paper
I) Close
J) Remove finished binding
Grafic operating instructions
Punching capacity
Binding capacity
Paper depth stop
Punch / adjustable
Dimensions
Weight
max. 22 sheets 80 g/m2
max. 500 sheets (51 mm)
3 - 8 mm
21 / 7 individually adjustable
497 x 353 x 235 mm
approx. 9 kg
Technical data
