SR PORTABLES CLEO User manual

Portable Lithium Solar Generator
Instruction Manual
Please visit our website www.srportables.com to register your product
Packing List
1
CLEO
1 Pcs Cleo Portable Solar Generator
1 Pcs AC Adaptor (including AC charging cable)
1 Pcs Cigaree Lighter Cable
(cigaree port to DC7909 connector male)
1 Pcs MC4 Cable (MC4 connector to
DC 7909 connector male)
1 Pcs User Manual
1 Pcs Warranty Card

2
Part Description
Safety Warning
Safety and Precautions
Please read all the safety warnings and labels before using the product.
Avoid exposing the product to rain or using the product in a humid environment.
Do not install the product near heat sources, such as electric furnaces and heaters.
Wipe the product clean with a dry cloth.
In case of fire, use dry powder fire extinguishers for this product. Do not use water fire extinguisher, which may cause electric shock.
Please do not alter or disassemble this product.
1.
2.
3.
4.
5.
6.

3
Storage and Maintenance
Safety and Precautions
Operating and storage environment may influence product life and the reliability of performance. Remember to:
(i) Place the product in a dry and well- ventilated area with mild temperature
(suitable temperature: 0°C -45°C, suitable relative humidity 10% ~ 90% )
(ii) Place the product in a safe area where it will not fall or shake.
(iii) Keep the product away from corrosive and combustible material.
The product will turn itself o when the baery voltage is very low. If this happens, you need to charge the baery within 2-3 months.
If you are not going to use it for a long time, please charge it fully before storage and then charge it at least once every month. Store
the product in a dry environment.
1.
2.
3.
Solar Panel to Charge the Product
How to Charge this Product?
Choose a suitable solar panel (recommended DC14~40V/120W).
Keep the solar panel under direct sunlight and facing the sun.
Connect the solar panel to the product at the AC port( Part 12 in
the Part Description) using the MC4 cable.
Please charge the product under Operational Temperature:
Charge 0°C ~ 45°C, Discharge -20°C ~ 60°C (powering
appliances)
When the product is fully charged by the sun, it will stop
charging automatically.(The charging time is dierent under
dierent sunlight intensity)
All products can be charged and used simultaneously
During charging, it is normal for the product to get a lile hot.
Please make sure the cable connections are secure and stable,
or it might result in overheating and short circuits.
1.
2.
3.
4.
5.
6.
7.
8.
AC Charger to Charge the Product
Always use the standard AC charger that comes with the product.
Insert one end of the adapter into the wall outlet and insert the other end into the input port( Part 12 in the Part Description)
of the product.
Please unplug the charger after charging is completed.
(It takes about 5-6hrs to fully recharge the product if using a 90W AC adapter charger).
During charging, it is normal for the product to get a lile hot.
Make sure that the wiring is connected properly, otherwise the contact terminals may melt or ignite at high temperatures.
1.
2.
3.
4.
5.
Car Charger to Charge the Product
Connect the product to the cigaree lighter socket( Part 12 in the Part Description) in the car with the cigaree lighter cable provided in
the package.
The product will be fully charged with a 24V car baery, but only partially charged with a 12V car baery.
Charge the product after starting the car.
Make sure that the wiring is connected properly, otherwise the contact terminals may melt or ignite at high temperatures.
1.
2.
3.
4.

4
Turn ON/OFF the Product
AC/DC Output
1. Turn on the product: Press and hold the master power buon about 2 seconds to turn on the product.
The LED indicator light and the display screen will light up.
2. Turn o the product: Press and hold the master power buon about 2 seconds to turn o the product.
The display screen and the LED indicator light would turn o.
1. Turn on AC/DC output: Press and hold the AC/DC power buon to turn on the product. The corresponding
LED indicator light would light up and the display screen would show “AC ON/DC ON”.
2. Turn o AC/DC output: Press and hold the AC/DC power buon to turn o the product.
The LED indicator light would turn o and the display screen would show “AC OFF/ DC OFF”.
Note: Check to make sure the product is turned on. Otherwise, you cannot turn on the AC/ DC output.
Output
AC Port Output DC Port Output

5
Technical Specifications
Visit our website www.srportables.com for more information or contact our technical team on [phone]
Output
AC output
Rated voltage100 - 102 Vac 220 - 240 Vac
Rated power 300 W
Peakpower 450W
Overload
Capability
300W≤load<450W@120S;
450W≤load@1s;
Frequency 50/60Hz(adjustable)
DC12VOutput
(cigaree
lighter)
Rated voltage12Vdc (12 14V workable)
Rated current 10A ①
DC12V Output
(5521)
Rated voltage9.6 - 12.6Vdc ②
Rated current 3A
USB output
QC BC1.2,Apple,Samsung
Rated voltage 5V
Rated current 3A
Type C Output QC PD2.0(45W)
Rated output 5V3A, 9V3A ,12V3A ,15V3A ,20V2.25A
LED Torch While the power buon is on, press the LED light buon repeatedly.
The order of LED light will be: full brightness-half brightness-SOS- O
Solar PV Input ③
Input voltage 14 - 40 Vdc
Input power 120W MAX
Baery
Rated capacity 416Wh
Rated voltage11.1 Vdc
Baery cell type Li - ion
Voltage range 9.6 - 12.6Vdc
General
Protection level IP21
Working environment condition Relative humidity:10% - 90%
Size 300*159*219mm
Net weight 6.2 kg
Temperature:0°C - 45°C
Operating Conditions
Operational Environment: Indoor and Outdoor (non waterproof)
Operational Temperature: Charge 0°C ~ 45°C, Discharge -20°C ~ 60°C (powering appliances)
Storage: -20°C ~ 45°C
1.
2.
3.
