SR PORTABLES MC4 User manual

Monocrystalline Foldable Solar Panel 200W
Instruction Manual
Please visit our website www.srportables.com to register your product
Product Features
1
• Eco-friendly
• High eiciency
• Portable and lightweight
• Easy to set-up
• Support simultaneous charging of devices
• Waterproof rugged durability
SOLAR PANEL 200W

2
Safety & Warranty
Safety Tips
• Do not bend the solar panel.
• Do not immerse the solar panel in water.
• Keep the solar panel away from extreme heat or fire.
• Clean the solar panel with a dry cloth.
• Do not pierce the solar panel casing with any sharp objects.
• Do not disassemble the panel – contact our technical team if you have any issues with the panel.
Warranty
Please refer to the Warranty section on www.srportables.com for more details on product warranty.
The solar panels DO NOT include a Solar Charge Controller. A 10A Solar Charge Controller can be purchased separately.
MC4 charging cable provided with the panel.

3
Technical Specifications
Visit our website www.srportables.com for more information or contact our technical team on [phone]
Maximum Power
Solar Cell Type
Cell Eiciency
Maximum Operating Current (Imp)
Maximum Power Voltage (Vmpp)
Open Circuit Voltage (Voc)
Short Circuit Current (Isc)
Output Tolerance Waage
DC Output Connector
DC Output Current
USB-A Output
USB-A Output
IP Rating
Working Temperature
Expanded Size
Foldable Size
Net Weight
200W
Monocrystalline
21.4%
10.7A
18.7V
22.1V
11.21A
±3%
DC5521 x1 or Other Type
18V 5A Max.
5V 3A (Optional)
QC3.0 5V/3A 9V/2A 12V/1.5A (Optional)
IPX4
-40°C ~ 80°C
2240x565x3mm
585x565x50mm
8kg
ITEMS SPECIFICATIONS
