ALTA Bliss Automation Installation and operating manual

BLISS™Automation by ALTA
SOLAR PANEL
INSTALLATION AND REFERENCE GUIDE
Declarations
Safety Instructions
BLISS™ Solar Panel Overview
Before Installation - What do you need to know!
BLISS™ Solar Panel Installation Guide
Troubleshooting
2
3
4
5
7
9

BLISS SOLAR PANEL | REFERENCE GUIDE
2
Declarations
U.S. RADIO FREQUENCY FCC COMPLIANCE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
ISED RSS WARNING:
This device complies with Innovation, Science and Economic Development Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’ISED applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le
fonctionnement.

BLISS SOLAR PANEL | REFERENCE GUIDE
3
AMP25B
Instruction
Attention
-1-
The motor is suitable for motorization of roller blinds, sheer shadings, roman shades, and zebra shades.
Never drop, knock, drill or submerge the motor. Keep the power cable in right position as following.
Important safety instructions to be read before installation.
Incorrect installation can lead to serious injury and will void manufacturer’s liability and warranty.
Declarations
Do not dispose of in general waste.
Please recycle batteries and damaged electrical products appropriately.
-2-
Safety
1. Do not expose motor to humid, damp or extreme temperature conditions.
2. Do not drill into motor.
3. Do not cut the antenna and keep it clear from metal objects.
4. Do not allow children to play with this device.
5. If power cable or connector is damaged, do not use.
6. Ensure correct crown and drive adaptor are used.
7. Ensure power cable and aerial is clear and protected from moving parts.
8. Cable routed through walls shall be properly isolated.
9. Motor is to be mounted in horizontal position only.
10. Before installation, remove unnecessary cords and disable equipment not needed for powered
operation.
11. Installation and programming to be performed by a qualified professional, use or modification outside
the scope of this instruction may void warranty.
Features
Fields of Application
Specifications
Following data for reference
Working temperature: -10℃ ~ +50℃
Input Voltage: USB 5V 1A / USB 5V 2A
Radio Frequency: 433.925MHz
Maximum Running Time: 6 minutes
Model Rated Torque
(N.m)
Rated Speed
(rpm)
Rated Power
(W)
AMP25B - 0.7/34 0.7 34 8
AMP25B -1.1/28 1.1 28 8
Charging Instructions
This motor has a built in Li-ion battery pack with integrated charge management.
Max power input for recharging: 5V 2A.
Before first use please charge motor for 6 hours. Using 5V charger (most phones charger is 5V ) .
During operation, when the motor starts, the buzzer will beep 10 times, indicating a low-voltage alarm and
needs to be charged.
During operation, the voltage was detected to be too low, the battery was about to run out, the battery stopped
running and needed to be recharged.
Rechargeable Battery
Blinking red:
Low battery alert
Blinking green:
Charging is processing
Solid green:
Battery has
finished charging.
FCC Text - text 01
Add A zoom in on the
charging port
P1 Button Instructions
P1 button
Lithium Battery Switch
LED light
Micro-USB Port
Add visual explanation of P1 - file 02
Sheer
Roller Revolve Roman shades
Do not dispose of in general waste.
Please recycle batteries and damaged electrical products appropriately.
Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS TO BE READ PRIOR TO OPERATION:
IMPORTANT SAFETY INSTRUCTIONS:
ATTENTION: IMPORTANT SAFETY INSTRUCTION TO BE READ BEFORE INSTALLATION:
• It is important for the safety of persons to follow the enclosed instructions. Save these instructions for future references.
• Persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience or knowledge should
not be allowed to use this product.
• Keep Solar Panel away from children.
• Frequently inspect for improper operations. Do not use if repair or adjustment is necessary.
• Do not expose motor to moisture or extreme temperature.
• Do not allow children to play with this device.
• Use or modication outside the scope of this instruction manual will void warranty.
• Installation and programming to be performed by a suitable quality installer.
• For use with Li-ion Motors and Re-chargeable battery packs only.
• Do not cut power cables.
• NOT suitable for exterior application.
• Do not drill into motor body or Solar panel body.
• The routing of cable through walls shall be protected by isolating bushing or grommets.
• Ensure power cable is clear and protected from moving parts.
• If cable or power connector is damaged do not use.
• Any changes or modications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
• Incorrect installation can lead to serious injury and will void manufacturer’s liability and warranty.
×× ×

BLISS SOLAR PANEL | REFERENCE GUIDE
4
BLISS™Solar Panel Overview
1. AVAILABLE PRODUCTS
2. SPECIFICATIONS
Working Voltage (Vm): 5V Electrical performance tolerance: voltage ± 10%;
current ± 10%
Open circuit voltage (Voc): 6.3V International solar energy inspection
standards:
solar radiation 1000W/m2; 1.5
Air Mass; humidity 25° C
Short-circuit current (lsc): 659mA
Electricity requirements
(each solar panel includes solar battery
cells):
conversion eciency 21%;
open circuit voltage (Voc) 6.3V
Working current (lm): 606mA IP Rating: IP55
Max. Output Power (Under
1000W/m2): 3W Temp Working Range: 14°F to122°F (-10°C to 50°C)
Roller Shades Honeycomb Shades Window Shadings Dual Shades Wood / Faux
Tilt-Only
Natural Woven
3. DIMENSIONS
2"
52mm
18.7"
475mm
15.6"
395mm
59"
1.5m
4. SOLAR PANEL PARTS
1
2
3 4 5
1. Solar Panel
2. Cable: Male Micro USB (compatible with all BLISS rechargeable battery products).
3. VHB™ Installation tape (Recommended method).
4. Metal “C” Installation Bracket (Alternative method).
5. Screws and Anchors (x4pcs).

BLISS SOLAR PANEL | REFERENCE GUIDE
5
Before Installation - What do you need to know!
1. CONSIDER THE GEOGRAPHIC LOCATION OF THE INSTALLATION
Understanding the sun’s motion relative to a site is a crucial element to predict the solar panel performance. In other words, a solar panel
located in Texas will harvest more energy than a unit installed in Canada (considering both facing south, using similar window). The same can
be said between Summer and Winter harvest performance.
As a main recommendation, installations on northern areas are recommended only for small and middle size shades (up to 48” x 60”), with
up to one cycle per day. More aspects aect the performance of solar panels and should be considered, not being possible a “one size ts all”
approach.
Source: http://www.fsec.ucf.edu
Understanding the sun’s motion relative to a site is a crucial element to predict the solar panel performance. A solar panel located in Texas
will harvest more energy than a unit installed in Canada (considering both facing south, using similar window).
Suns path on Summer solstice at a southern latitude Suns path on Winter solstice at a southern latitude
The Solar Panel may not be a good t for every window. In the summer, the sun rises higher in the sky than in the winter months. The further
north, the lower the midday winter sun will be. Due the sun position, Solar panels installed facing north produce 4 times less energy than a
device installed facing south. For this reason, we do no recommend the use of solar panel on windows facing North.
Summer Performance Winter Performance
North Face 100% 70%
West Face 95% 90%
East Face 90% 70%
South Face 25% 25%

BLISS SOLAR PANEL | REFERENCE GUIDE
6
Before Installation - What do you need to know!
3. DEFINE THE BEST LOCATION TO INSTALL
The solar panel is designed for indoor use only. To maximize the performance of the solar panel, it should be installed as close as possible to
the window glass, allowing as much natural light as possible to reach the panel.
Important
Any element between the Sun light and the solar panel will impact the charging time, and in some situations, prohibit the use of a solar panel.
Overcast weather is an example of possible obstruction that impossible to predict or control, but there are other elements that we should
consider before installing a solar panel, like:
• Awnings
• Trees
• Deep Eaves
• Tall buildings and walls
• Insect Screen
• Others
Other elements are not so obvious but can make it dicult to use a solar panel. The solar panel will have a low performance when installed on
locations with:
• Tinted windows
• High performance glass (also known as energy eciency glass)
• Multi panel glass
• Any window with treatment that reduces the light transmission below 65%
• Window dividers overlapping solar panel
Awnings Vegetation Blocking Light Insect Screen
Do Not Use Solar Panel Under Below Conditions
Deep Eaves
Be Aware Of Window Type
Clear Tinted
Light Transmission >65%Single or Double Pane OK
Awnings Vegetation Blocking Light Insect Screen
Do Not Use Solar Panel Under Below Conditions
Deep Eaves
Be Aware Of Window Type
Clear Tinted
Light Transmission >65%Single or Double Pane OK

BLISS SOLAR PANEL | REFERENCE GUIDE
7
Before Installation - What do you need to know!
4. HOW EFFICIENT MY SOLAR PANEL WILL PERFORM?
There is no direct answer for this question. Beside all the elements already described that impact how much energy will be
harvested from the sun, there is also the question of how fast the energy will be drained by the shade itself due to:
• Shade composition (fabric weight)
• Number of cycles per day
• Size of shade (how long the motor will run per cycle)
The answer for these questions should be considered to evaluate if solar panel is the best t for the application.
BLISS Solar Panel Installation Guide
1. INSTALLATION USING PROVIDED INSTALLATION TAPE
The solar panel must always be install indoors, directly against the window glass to allow as much natural light as possible to reach the panel.
For your convenience, the solar panel can be installed using VHB™ installation tape (recommended method) or Metal “C” Installation Bracket
(alternative method).
First, clean solar panel corners and window area using alcohol and a cloth pad. Let dry for a few minutes. On a at surface, place the solar
panel facing up and carefully apple the VHB™ installation tape on both sides of the solar panel.
Remove the “face” of the applied adhesive. Position the solar panel facing to outdoors, then press entire panel with rm, even pressure into
the glass for 10-15 seconds. The panel is now supported by the adhesive to glass bond but will require 24 hours of cure time to allow full
strength characteristics. Do not disturb during this period.

BLISS SOLAR PANEL | REFERENCE GUIDE
8
BLISS Solar Panel Installation Guide
2. METAL “C” INSTALLATION BRACKET
The Metal “C” Installation Bracket is provided as an option when an installation direct on the glass is not possible. A common application is
to mount the Metal “C” bracket directly on the shades bracket. This is a great option for shades installed as ceiling mount with at least 1”
clearance between the shade and the glass.
Another application is using a “L” bracket (not provided) to support the metal “C” clip. Ensure the Solar panel and it’s bracket is not blocking
the free movement of the bottom rail.
With the metal “C” bracket secured at the shade’s bracket/wall, rmly connect the solar panel on it.

BLISS SOLAR PANEL | REFERENCE GUIDE
9
Solar Panel
USB charging cable
Micro-USB Port
Solar Panel
USB charging cable
Micro-USB Port
BLISS Solar Panel Installation Guide
1. CONNECT WITH BUILT IN RECHARGEABLE BATTERY MOTOR
2. CONNECT WITH EXTERNAL RECHARGEABLE BATTERY PACK
Troubleshooting
Issues Possible Causes Solution
The motor has no response
Battery in motor is depleted Recharge with compatible charger and check connection
and positioning of solar panel
Insucient charging from Solar Panel Check connection and orientation of solar PV panel
Remote control battery is discharged Replace battery
Battery is inserted incorrectly into remote
control Check battery polarity
Radio interference / shielding Ensure remote control and the antenna on the motor are positioned
away from metal objects
Motor/Receiver distance is too far from Remote
Control Move remote control to a closer position
Power failure Check power supply to motor is connected and active
Incorrect wiring Check that wiring is connected correctly (refer to motor installation
instructions)
Motor beeps 10 times when
in use Battery voltage is low/PV (solar panel issue) Recharge with charger or check connection and positioning of solar panel
