SR STAGE RIGHT 612601 User manual

2
CONTENTS
SAFETY WARNINGS AND GUIDELINES........................................................................3
INTRODUCTION................................................................................................................................4
CUSTOMER SERVICE....................................................................................................................4
PACKAGE CONTENTS .................................................................................................................5
MENU CONTROLS..........................................................................................................................5
MENU FUNCTIONS........................................................................................................................6
DMX MODES......................................................................................................................................8
DMX Mode A (2-channel)................................................................................................8
DMX Mode d (3-channel) ..............................................................................................10
DMX Mode C (4-channel)..............................................................................................10
DMX Mode E 4-Zone Split (14-channel).............................................................11
DMX Mode P (7-channel)...............................................................................................12
DMX Mode H 8-Zone Split (26-channel).......................................................... 13
MASTER/SLAVE OPERATION..............................................................................................14
DMX TERMINATION...................................................................................................................16
TROUBLESHOOTING ..................................................................................................................16
TECHNICAL SUPPORT............................................................................................................... 17
SPECIFICATIONS............................................................................................................................18
REGULATORY COMPLIANCE...............................................................................................18
Notice for FCC.........................................................................................................................18
Notice for Industry Canada.........................................................................................20
EU Conformity with applicable directives .....................................................20

3
SAFETY WARNINGS AND GUIDELINES
Please read this entire manual before using this device, paying
extra attention to these safety warnings and guidelines. Please
keep this manual in a safe place for future reference.
Do not expose this device to rain, water, or moisture of any
kind. Do not use in extremely dusty environments. Do not
touch the device with wet hands. If this device is exposed to
water or moisture, immediately unplug it from the power
source and allow it to fully dry before applying power again.
Prior to operation, check the unit and power cord for
physical damage. Do not use if physical damage has
occurred.
Before plugging the unit into a power outlet, ensure that the
outlet provides the same type and level of power required
by the device.
This device uses a grounded power cord and requires a
ground connection for safe operation. Ensure that the power
source has a proper ground connection. Do not modify the
plug or use a “cheater” plug to bypass the ground
connection.
This device has an AC power outlet, which is intended for
chaining multiple 612601 light bars together. Do not chain
more than 32 units together onto the same circuit. Do not
plug anything other than another 612601 light bar into the
power outlet.
This device has no user serviceable parts. Do not attempt to
open, service, or modify this device.
Do not look directly into the light source.

4
Keep the original packaging material for use when
transporting the device.
If the device will not be used for any lengthy period of time,
it should be unplugged from the wall.
When installing this device, ensure that the mount is
sufficiently robust to support the weight of the unit and to
prevent unwanted movement.
INTRODUCTION
This light features 252 10mm LEDs (84 red, 84 green, 84 blue)
enclosed within an aluminum case. It includes 13 built-in automatic
programs, plus a sound activated mode with sensitivity control. It
supports six DMX512 control modes (2, 3, 4, 7, 14, and 26-channels)
that you can control using a DMX controller, such as the
Monoprice 612120 DMX512 Controller. Please thoroughly review
this manual for safety and operating instructions.
CUSTOMER SERVICE
The Monoprice Customer Service department is dedicated to
ensuring that your ordering, purchasing, and delivery experience is
second to none. If you have any problem with your order, please
give us an opportunity to make it right. You can contact a
Monoprice Customer Service representative through the Live Chat
link on our website www.monoprice.com or via email at
[email protected]. Check the website for support times and
links.

5
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you
have all the items listed below. If anything is missing or damaged,
please contact Monoprice Customer Service for a replacement.
1x 3-color LED light bar
1x AC power cable (IEC 60320 C13 to NEMA 5-15)
1x User's manual
NOTE: Your Monoprice 612601 Light Bar has an AC power output
outlet, which allows you to chain multiple 612601 light bars
together. Do not chain more than 32 units together onto the same
circuit. Do not plug anything other than another 612601 light bar
into the power outlet.
MENU CONTROLS
The LED display serves as the operating menu, allowing you to
control all of the functions listed in the MENU FUNCTIONS section
below.
DOWN: Press the Down button to select the next function in the
MENU FUNCTIONS list.
UP: Press the Up button to select the previous function in the
MENU FUNCTIONS list.
