SR STAGE RIGHT 612830 User manual

2
CONTENTS
SAFETY WARNINGS AND GUIDELINES................................................................................................................................... 3
INTRODUCTION..........................................................................................................................................................................................4
FEATURES........................................................................................................................................................................................................4
CUSTOMER SERVICE ..............................................................................................................................................................................5
PACKAGE CONTENTS............................................................................................................................................................................5
CONTROLS AND MENU DISPLAY................................................................................................................................................6
MENU FUNCTIONS .................................................................................................................................................................................. 7
MASTER/SLAVE MODE........................................................................................................................................................................8
BLIND MODE ................................................................................................................................................................................................8
9-CHANNEL DMX MODE....................................................................................................................................................................9
12-CHANNEL DMX MODE ................................................................................................................................................................. 11
TECHNICAL SUPPORT..........................................................................................................................................................................14
SPECIFICATIONS......................................................................................................................................................................................14
REGULATORY COMPLIANCE .........................................................................................................................................................15
Notice for FCC.....................................................................................................................................................................................15
Notice for Industry Canada......................................................................................................................................................16

3
SAFETY WARNINGS AND GUIDELINES
•This device is intended for indoor use only.
•Do not expose this device to water or moisture of any kind. If moisture does get in
or on the device, immediately unplug it from the power outlet and allow it to fully
dry before reapplying power.
•Prior to operation, check the unit and power cord for physical damage. Do not use if
physical damage has occurred.
•Take care to prevent damage to the power cord. Do not allow it to become
crimped, pinched, walked on, or become entangled with other cords. Ensure that
the power cord does not present a tripping hazard.
•Before plugging the unit into a power outlet, ensure that the outlet provides the
same type and level of power required by the device.
•This device uses a grounded power cord and requires a ground connection for safe
operation. Ensure that the power source has a proper ground connection. Do not
modify the plug or use a "cheater" plug to bypass the ground connection.
•When disconnecting the power cord do not pull on the cord itself. Instead, grasp
the plug connector head to disconnect it from the power socket.
•Do not look directly into the light source.
•If the device will not be used for any lengthy period of time, it should be unplugged
from the power source.
•When installing this device, ensure that the mount is sufficiently robust to support
the weight of the unit and to prevent unwanted movement.
•This device ventilates excessive heat through the slots and openings in the case. Do
not block or cover these openings. Ensure that the device is in an open area where
it can get sufficient airflow to keep from overheating.
•Clean using a soft, dry cloth only. Do not use chemical cleaners, solvents, or
detergents. For stubborn deposits, moisten the cloth with warm water.
•Ensure there are no flammable materials or any obstructions within 1.5 feet (0.5m)
around the fixture to ensure fire safety and sufficient cooling.

4
INTRODUCTION
Thank you for purchasing this stage light!
This moving head beam light uses a high-power, 30-watt white LED. It features an internal
color wheel with 7 color filters (Orange, Cyan, Lavender, Yellow, Green, Blue, Red, and
Open/White), as well as a gobo wheel with 7 gobo patterns. It has 3 built-in programs, plus
9-channel and 12-channel DMX modes. It can be controlled using a DMX-512 controller or
can be used as a Master or Slave with the built-in programs.
FEATURES
•Uses a single, 30-watt white LED
•8-position gobo wheel with 7 gobo patterns and a non-template open beam option
•8-position color wheel with 7 color filters (Orange, Cyan, Lavender, Yellow, Green,
Blue, and Red) and a non-filtered Open/White option
•8 built-in programs
•9-channel and 12-channel DMX control modes
•540° of pan movement, 190° of tilt movement
•Reversible Pan and Tilt control for inverted or mirrored operation
•Reversible menu for inverted operation
•Includes sound-responsive program
•Accepts 100 ~ 240 VAC, 50/60 Hz input power

5
CUSTOMER SERVICE
The Monoprice™ Customer Service department is dedicated to ensuring that your ordering,
purchasing, and delivery experience is second to none. If you have any problem with your
order, please give us an opportunity to make it right. You can contact a Monoprice
Customer Service representative through the Live Chat link on our website
www.monoprice.com or via email at [e-mail]. Check the website for
support times and links.
PACKAGE CONTENTS
Please take an inventory of the package contents to ensure you have all the items listed
below. If anything is missing or damaged, please contact Monoprice Customer Service for a
replacement.
1x Moving head 30-watt beam light with internal gobos and color filters
1x Mounting bracket
2x Hex head bolts
2x Flat washers
1x AC power cord (NEMA® 5-15 to IEC 60320 C13)
1x User's manual

6
CONTROLS AND MENU DISPLAY
The 4-digit LED display indicates the mode and the value for the selected function or
mode.
•Press the MENU button as a "back" button when editing an entry. If already at the
top level, press the MENU button to return to the top of the menu list (A###).
•Press the UP button to increase the value of the selected function or mode. Press
and hold the button to rapidly increase the displayed value. The list will cycle back
to the beginning after the maximum value is reached.
•Press the DOWN button to decrease the value of the selected function or mode.
Press and hold the button to rapidly decrease the displayed value. The list will cycle
back to the end after the minimum value is reached.
•Once the desired value is displayed, press the ENTER button to set that value for the
displayed function or mode and allow for selection of another function or mode.
•If you want to discard any changes made to the value of the selected function or
mode, simply press the MENU button to back out of the previous menu level.

7
MENU FUNCTIONS
Function
Values
Description
Addr
A001-A512
DMX starting address.
CHnd
12Ch
19-channel DMX mode.
9Ch
9-channel DMX mode.
SLnd
nASt
Master mode.
SL1
Slave mode 1. With this mode, the fixture will exactly
duplicate the Master fixture.
SL2
Slave mode 2. With this mode, the fixture will duplicate
the Master fixture, but with all motion inverted.
SHnd
SH0
Motor rotation effect 0.
SH1
Motor rotation effect 1.
SH2
Motor rotation effect 2.
SH3
Motor rotation effect 3.
Soud
on / oFF
Turns the sound activated mode on or off.
SenS
00-99
Sound activated mode sensitivity, from low to high.
bLnd
bLAc
The fixture will clear its state if the DMX signal is lost.
Auto
The fixture will enter auto mode if the DMX signal is lost.
Soun
The fixture will enter sound activated mode if the DMX
signal is lost.
HoLd
The fixture will retain the last state if the DMX signal is
lost.
LEd
oFF
The LED display will turn off after 5 seconds with no
button input.
on
The LED display will remain on at all times.

8
Function
Values
Description
diSP
no
The LED display is not inverted.
yES
The LED display is inverted.
rPAn
no
X motor (pan) normal operation.
yES
X motor (pan) inverted.
rTiL
no
Y motor (tilt) normal operation.
yES
Y motor (tilt) inverted.
rESt
yES
System reset.
MASTER/SLAVE MODE
This fixture can be configured as a Master (nASt), Slave 1 (SL1), or Slave 2 (SL2). In Slave 1
(SL1) mode, the fixture will perform the same functions as the Master. When in Slave 2
(SL2) mode, the fixture will respond with the same motions as the Master, but inverted so
that if the Master moves to the right, the Slave 2 fixtures will move to the left.
BLIND MODE
Blind mode is automatically activated if the DMX control signal is lost. The fixture will
respond in one of four ways, depending on which value is set for the bLnd function in the
menu.
bLAc: The fixture is reset.
Auto: The fixture automatically enters auto mode.
Soun: The fixture automatically enters Sound Responsive mode.
HoLd: The fixture continues to execute the last command it received.

9
9-CHANNEL DMX MODE
The following table lists the functionality of each channel in 9-channel DMX mode.
Channel
DMX Value
Range
Function
1
000-255
Pan control
2
000-255
Tilt control
3
000-009
Color wheel open (white)
010-019
Color wheel orange
020-029
Color wheel cyan
030-039
Color wheel lavender
040-049
Color wheel yellow
050-059
Color wheel green
060-069
Color wheel blue
070-079
Color wheel red
080-089
Two color 1 red + blue
090-099
Two color 2 blue + green
100-109
Two color 3 green + yellow
110-119
Two color 4 yellow + lavender
120-129
Two color 5 lavender + cyan
130-139
Two color 6 cyan + orange
140-255
Auto change color, speed from slow to fast
4
000-007
Gobo wheel open (no pattern)
008-015
Gobo wheel 1
016-023
Gobo wheel 2
024-031
Gobo wheel 3

10
Channel
DMX Value
Range
Function
4
032-039
Gobo wheel 4
040-047
Gobo wheel 5
048-055
Gobo wheel 6
056-063
Gobo wheel 7
064-071
Gobo wheel open (no pattern)
072-079
Gobo wheel 1 shaking, from slow to fast
080-087
Gobo wheel 2 shaking, from slow to fast
088-095
Gobo wheel 3 shaking, from slow to fast
096-103
Gobo wheel 4 shaking, from slow to fast
104-111
Gobo wheel 5 shaking, from slow to fast
112-119
Gobo wheel 6 shaking, from slow to fast
120-127
Gobo wheel 7 shaking, from slow to fast
128-255
Auto change gobo, from slow to fast
5
000-255
Master dimmer, from dark to bright
6
000-255
Strobe speed, from slow to fast
7
000-255
Pan/Tilt speed, from slow to fast
8
000-059
No effect
060-084
Auto mode 1
085-109
Auto mode 2
110-134
Auto mode 3
135-159
Auto mode 4
160-184
Sound mode 1
185-209
Sound mode 2

11
Channel
DMX Value
Range
Function
8
210-234
Sound mode 3
235-255
Sound mode 4
9
000-020
No effect
021-100
Pan motor auto mode
101-200
Tilt motor auto mode
201-249
Pan/Tilt motor auto mode
250-255
Reset (hold for 5 seconds)
12-CHANNEL DMX MODE
The following table lists the functionality of each channel in 12-channel DMX mode.
Channel
DMX Value
Range
Function
1
000-255
Pan control
2
000-255
Pan fine control
3
000-255
Tilt control
4
000-255
Tilt fine control
5
000-255
Pan/Tilt speed, from slow to fast
6
000-255
Master dimmer, from dark to bright
7
000-255
Strobe speed, from slow to fast
8
000-009
Color wheel open (white)
010-019
Color wheel orange
020-029
Color wheel cyan

12
Channel
DMX Value
Range
Function
8
030-039
Color wheel lavender
040-049
Color wheel yellow
050-059
Color wheel green
060-069
Color wheel blue
070-079
Color wheel red
080-089
Two color 1 red + blue
090-099
Two color 2 blue + green
100-109
Two color 3 green + yellow
110-119
Two color 4 yellow + lavender
120-129
Two color 5 lavender + cyan
130-139
Two color 6 cyan + orange
140-255
Auto change color, speed from slow to fast
9
000-007
Gobo wheel open (no pattern)
008-015
Gobo wheel 1
016-023
Gobo wheel 2
024-031
Gobo wheel 3
032-039
Gobo wheel 4
040-047
Gobo wheel 5
048-055
Gobo wheel 6
056-063
Gobo wheel 7
064-071
Gobo wheel open (no pattern)
072-079
Gobo wheel 1 shaking, from slow to fast
080-087
Gobo wheel 2 shaking, from slow to fast

13
Channel
DMX Value
Range
Function
9
088-095
Gobo wheel 3 shaking, from slow to fast
096-103
Gobo wheel 4 shaking, from slow to fast
104-111
Gobo wheel 5 shaking, from slow to fast
112-119
Gobo wheel 6 shaking, from slow to fast
120-127
Gobo wheel open (no pattern)
128-255
Gobo wheel 1
10
000-059
No effect
060-084
Auto mode 1
085-109
Auto mode 2
110-134
Auto mode 3
135-159
Auto mode 4
160-184
Sound mode 1
185-209
Sound mode 2
210-234
Sound mode 3
234-255
Sound mode 4
11
000-020
No effect
021-100
Pan motor auto mode
101-200
Tilt motor auto mode
201-249
Pan/Tilt motor auto mode
250-255
No effect
12
000-250
No effect
251-255
Reset (hold for 5 seconds)

14
TECHNICAL SUPPORT
Monoprice™ is pleased to provide free, live, online technical support to assist you with any
questions you may have about installation, setup, troubleshooting, or product
recommendations. If you ever need assistance with your new product, please come online
to talk to one of our friendly and knowledgeable Tech Support Associates. Technical
support is available through the online chat button on our website www.monoprice.com
or through email by sending a message to [e-mail]. Check the website for
support times and links.
SPECIFICATIONS
P/N
612830
Light Source
1x 30-watt white LED
Beam Angle
13°
DMX Control
9-channels or 12-channels
DMX Input/Output
3-pin XLR input and pass-through output
Pan Movement Range
540°
Tilt Movement Range
190°
Color Wheel
7 colors plus open/white
Gobo Wheel
7 gobo patterns plus open/white
Maximum Power Consumption
42 watts
Input Voltage
100 ~ 240 VAC, 50/60 Hz
Dimensions
12.7" x 9.8" x 10.6" (323 x 250 x 270 mm)
Weight
5.5 lbs. (2.5kg)

15
REGULATORY COMPLIANCE
Notice for FCC
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
Modifying the equipment without Monoprice's authorization may result in the equipment
no longer complying with FCC requirements for Class B digital devices. In that event, your
right to use the equipment may be limited by FCC regulations, and you may be required to
correct any interference to radio or television communications at your own expense.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.

16
Notice for Industry Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Monoprice™, Stage Right™, the Stage Right logo, and all Monoprice logos are trademarks
of Monoprice Inc.
