ST STM32F-1 User manual

February 2014 DocID025866 Rev 1 1/31
UM1728
User manual
STM32F1xx DALI slave interface
Introduction
This document describes the implementation of the digital addressable lighting interface
(DALI) into the STM32F1xx 32-bit microcontroller family.
The DALI slave library for STM32F1xx microcontrollers simplifies integration of the DALI
slave interface into customer applications. The implementation of DALI into STM32,
together with the various STM32 features (peripherals, computation power, communication
interfaces), is mainly used in light control applications (example, electronic ballast control).
The STM32 DALI slave library was tested according to the DALI specification.
The DALI slave library comes with a simple application example (DALI slave device). The
example was designed (and tested) for use with the following evaluation boards:
•STM32VLDISCOVERY
•DALI transceiver board (see UM1032: STEVAL-ILM001V1 hardware module)
The application example controls the light of the on-board LED diode. Light intensity is
controlled by the PWM method using a built-in timer. The external DALI master device must
control this application example (which is the DALI slave device). The DALI master devices
were tested using the ST7DALI evaluation kit (master device board and PC software).
Useful information and links about DALI interface can be found on http://www.dali-ag.org.
www.st.com

Contents UM1728
2/31 DocID025866 Rev 1
Contents
1 DALI information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1 DALI standard overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1.1 DALI purpose and properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1.2 DALI physical layer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.1.3 DALI stack layer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2 STM32 DALI slave library overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2 Structure of final user application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.1 User application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2 I/O pin driver layer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Function description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 I/O pin driver layer functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3.1.1 STM32F10x_it.c . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1.2 DALIslave.c . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 DALI stack layer functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.1 dali.c . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.2 dali_cmd.c . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.2.3 dali_pub.c . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.2.4 dali_reg.c . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2.5 eeprom.c . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.2.6 lite_timer_8bit.c . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2.7 dali_config.c . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4 Application setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5 Application description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
6 Running the PC software for DALI-STM32 . . . . . . . . . . . . . . . . . . . . . . 26
6.1 Basic commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6.2 Light level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8 Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

DocID025866 Rev 1 3/31
UM1728 List of figures
31
List of figures
Figure 1. Example of DALI device connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 2. Voltage and currents on the DALI bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Figure 3. Structure of DALI stack layer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Figure 4. Structure of I/O pin driver layer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Figure 5. Hardware for testing DALI: STM32 discovery kit with DALI transceiver board and
ST7 DALI master board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Figure 6. Bottom side connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 7. Schematic of connector J2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 8. STM32-discovery board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 9. Slave device setup (STEVAL-ILM001V1 and STM32-discovery board). . . . . . . . . . . . . . . 23
Figure 10. Master device setup (ST7 DALI master board) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 11. Complete DALI setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Figure 12. Main window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Figure 13. Search for ballast window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Figure 14. Screen overview after a quick search. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 15. Light level window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Figure 16. Ballasts window after clicking on update . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 17. Light level window during fading. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

DALI information UM1728
4/31 DocID025866 Rev 1
1 DALI information
1.1 DALI standard overview
DALI is an international standard (IEC 62386) lighting control system that provides a single
interface for electronic control gears (light sources) and devices (lighting controllers).
The DALI standard enables dimmable ballasts, transformers, relay modules, emergency
fittings and controllers from different manufacturers to be mixed and matched into a single
control system. A DALI system provides designers, installers, building owners, facility
managers and end-users a powerful and flexible digital lighting system with security of
supply from many sources.
The DALI standard is overseen by the “AG-DALI” activity group which comprises engineers,
manufacturers, and institutions working in the field of digital lamp/ lighting control.
More information about the DALI standard can be found in the following documents:
•IEC 62386
•NEMA standard 243-2004
The following sections provide an overview of the DALI standard. They describe the basic
principles of the DALI interface.
Note: To better understand the STM32 DALIF1xx slave library, a knowledge of the DALI interface
specification is essential. This application note does not provide a description of this
specification.
1.1.1 DALI purpose and properties
The DALI protocol was designed to control modern light sources using a computer.
Functions include:
•Dimming
•ON/ OFF switching
•Grouping lights to a common control
•Scene storage and selection
The DALI design properties include:
•Simple wiring using standard electrical installation cables
•No special wiring topology (as with power electrical cables)
•Simple installation giving cable polarity independence
•Automated light source addressing
•Use of low cost microcontrollers on the light source side to minimize cost of light source
•Use of a simple protocol to control light dimming and switching.
1.1.2 DALI physical layer
The DALI interface consists of a physical layer from two wires. This is a simple installation
for which the polarity is independent.

DocID025866 Rev 1 5/31
UM1728 DALI information
31
The protocol used on these cables is a standard serial protocol.There is 1 start bit, 8 data
bits and 2 stop bits.The communication speed is fixed at 1200 Bd.Manchester coding is
used for better resynchronization: rising edge is logical 1 and falling edge is logical 0.
Bytes are grouped into frames. One frame usually consists of 1 or 2 bytes which is either
data only (answer from the device) or address + data (command to device).
Voltage levels present on DALI communication wires are higher than the transistor-
transistor logic (TTL) levels that are usually used. This is due to better noise immunity
because of higher interference present on nearby power installation cables. Voltage levels
are defined as follows:
•Low level state
– -4.5 to 4.5 V (transmitter)
– -6.5 to 6.5 V (receiver)
•High level state
– 11.5 to 20.5 V (transmitter)
– 9.5 to 22.5 V (receiver)
Low level state is dominant on the DALI bus. The device can force this level to the DALI bus
by shortening the DALI wires. Consequently, current levels are defined for devices used on
the DALI bus. There are two device types:
1. DALI master or DALI slave communication devices. In these devices the current is
sunk from the DALI bus. They consume a maximum of 2 mA to receive high level state
and sink a minimum of 250 mA to transmit low level state.
2. DALI power supply. These devices power the DALI bus and are the source current for
it. Supply is limited to a maximum of 250 mA.
The maximum length of the DALI bus depends on the cables used for the DALI
communication wires (for example, a 1.5 mm2 cable (which is typically used in light
installation cables) allows a maximum bus length of up to 300 m.). The length is linearly
dependent on the cross section of the conductor.
Collisions between several DALI masters on the DALI bus are solved on the basis of timing
priorities. When a collision is detected (the DALI master should check the sent data),
communication is muted for a period of time according to the assigned master priority. There
are five defined priority levels: 12 ms, 13 ms, 14 ms, 15 ms, and 16 ms. The longest waiting
time has less priority.

DALI information UM1728
6/31 DocID025866 Rev 1
Figure 1. Example of DALI device connections
Figure 2. Voltage and currents on the DALI bus
1.1.3 DALI stack layer
The DALI stack is the higher DALI layer which implements DALI commands, DALI
structures, timing management, and error management according to the DALI specification.
The most important feature of the DALI stack layer is the DALI commands. These
commands are used for:
•Direct light control such as dimming, on/off switching, and scene selection.
•Device configuration to set DALI variables, read device properties, address
assignments, and query device status.
The DALI stack layer is fully implemented in microcontroller software.

DocID025866 Rev 1 7/31
UM1728 DALI information
31
1.2 STM32 DALI slave library overview
The STM32F1xx DALI slave library contains instructions for implementing software of the
DALI protocol into STM32 microcontrollers.
The DALI slave library consists of two layers:
•Upper layer (DALI stack layer)
•Hardware layer (I/O pin driver layer)
The upper layer of the DALI slave library (also known as the DALI stack layer), consists of
routines for processing the required DALI commands and other necessary control functions
(including timing control, error management, memory management, and light control). The
hardware layer (also known as the direct I/O pin driver layer), contains the physical layer
implementation. This is necessary because STM32 microcontrollers do not support DALI
communication peripherals.

Structure of final user application UM1728
8/31 DocID025866 Rev 1
2 Structure of final user application
The final user application uses the DALI slave library and so, consists of the following three
layers:
•Main user application
•DALI stack layer
•I/O pin driver layer
2.1 User application
The structure of the user application is comprised completely of IAR project files. The
application code is in one source file, “main.c”, in which the whole user ballast control is
implemented. This code calls the DALI slave library functions.
The user application example included in the DALI slave library package is designed to work
with the “STM32 discovery kit” and “STEVAL_ILM001V1 (DALI transceiver board)”. The
STM32 discovery kit is a small printed circuit board (PCB) with an integrated
STM32F100RBT6 device which demonstrates STM32 capabilities. The DALI transceiver
board is connected to the STM32 discovery kit as a physical layer extension. It provides
voltage level conversion and optical isolation between the DALI bus and the STM32
discovery kit (according to the DALI specification requirements).
The main task of the user application is to initialize the DALI stack and to implement the light
intensity control function (callback function). This function is ballast dependent. The user
application also periodically controls some event flags. If the DALI slave library sets an
event flag and it indicates a pending event, the user application must call the appropriate
service routines (from the DALI slave library) to execute the necessary commands.
The user application example uses timer 3 to control the light intensity of the LED diode
present on the STM32 discovery kit. Timer 3 generates the pulse-width modulation (PWM)
for the LED diode (using the callback function). The main program loop checks event flags,
executes actions for active flags, and provides power management (Low power state if the
DALI bus is quiet) and error management (reports hardware errors). For all these purposes
the user application calls functions from the DALI slave library.

DocID025866 Rev 1 9/31
UM1728 Structure of final user application
31
Figure 3. Structure of DALI stack layer
The DALI stack is hardware independent. It calls the I/O pin driver for low level hardware
dependent functions. After initialization of the DALI stack layer (after calling initialization
functions), most of the tasks run automatically. Tasks include receiving commands and
running timer tasks (light dimming, timeouts).
Note: To get the complete source code of DALI STACK library, please contact nearest sales office.
2.2 I/O pin driver layer
The I/O pin driver layer of the DALI slave library implements physical and link layers of the
DALI interface. The DALI protocol requires two pins for communication. The I/O pin driver
layer implements reception and transmission through direct control of two arbitrary GPIO
pins. It also controls the required DALI speed and correct bit timing, solves DALI bus error
recovery, and collects received bits into DALI frames (using address and command bytes).
Figure 4 displays the structure of the DALI I/O pin driver layer
Figure 4. Structure of I/O pin driver layer
The I/O pin driver layer occupies one timer (systick timer), one GPIO interrupt, one timer
interrupt, and direct control of two GPIO pins (assignment of which is software selectable).

Structure of final user application UM1728
10/31 DocID025866 Rev 1
Timing events are invoked inside the timer interrupt service routine. Such events control the
I/O pin driver layer behavior by calling callback functions from the DALI stack layer at given
1 ms intervals (timer ticks).
Figure 5. Hardware for testing DALI: STM32 discovery kit with DALI transceiver board
and ST7 DALI master board

DocID025866 Rev 1 11/31
UM1728 Function description
31
3 Function description
This section describes the most important STM32F1xx DALI slave library functions for the
user.
3.1 I/O pin driver layer functions
The I/O pin driver layer implements hardware dependent functions (designed for use with
STM32F1xx devices and the DALI transceiver board).
3.1.1 STM32F10x_it.c
These files contain two interrupt service routines (ISR):
void SysTick_Handler(void)
This function:
•Generates timer ticks for the DALI bit receive and transmit functions
•Calls, in given intervals, the transmit/receive function (sampling is eight times per DALI
bit).
•Generates timer ticks for the upper DALI layer timing by calling callback functions fr om
the DALI stack layer
•Checks for DALI interface failure such as loss of voltage on the DALI bus for more than
500 ms (disconnection from DALI bus).
Void EXTI0_IRQHandler(void)
This function:
•Calls receiving routines if there is a voltage level change on the DALI RX pin
•Detects the start of the DALI packet. This ISR is inactive during DALI packet
reception.It is activated after DALI packet reception
3.1.2 DALIslave.c
These file contains the reception and transmission routines for building the DALI packet
from received bits according to the DALI specification. It also contains the initialization
functions of the DALI I/O pin driver layer.
The functions of these files are given below in bold.
Void init_DALI (port_out, pin_out, invert_out, port_in, pin_in, invert_in,
DataReceivedFunction, ErrorFunction,RTC_1ms_Function)
This function:
•Initializes the DALI I/O pin driver layer
•Defines the DALI RX and DALI TX pins and their inversion.

Function description UM1728
12/31 DocID025866 Rev 1
This depends on the physical connection to the DALI bus (i.e. the converter between the
DALI bus and the I/O pins).
•Defines the callback functions:
– if the complete DALI packet is received (address, command/data)
– if an error occurs on the DALI bus (loss of idle voltage)
– if 1 ms callback timer ticks are generated for the DALI stack layer
•After this function is called, the I/O pin driver is able to receive DALI packets and can
call upper layer callbacks. This function should be called as th e last initialization
function (after DALI stack initialization).
bool get_DALIIN(),
bool get_DALIOUT(),
void set_DALIOUT(pin_value)
This set of functions:
•Obtains/sets the logical level from/to the DALI pin (DALI Rx and DALI Tx)
•Accepts the hardware implementation of the driver (its eventual inversion)
void receive_data (void)
This function is called from the interrupt routine when the first start bit of DALI packet
occurs. It:
•Starts the receiving process
void send_data (byteToSend)
This function:
•Starts the transmission process
void receive_tick (void)
This function is called from systick interrupt service routine when receiving has already
started. It:
•Performs bit receiving from the DALI RX pin for building the DALI packet
•Checks the packet errors on the DALI bus
void send_tick (void)
This function is called from systick service routine when transmitting has already started. It:
•Performs transmitting of DALI packet to DALI bus (bit coding to physical layer)

DocID025866 Rev 1 13/31
UM1728 Function description
31
void check_interface_failure(void)
This function:
•Checks the DALI bus idle voltage presence (500 ms disconnection from the DALI bus)
•Calls error callback function if an error occurs
u8 get_timer_count(void)
This function:
•Returns the current systick timer content
•Is used for general purpose use, for example, random number generation
u8 get_flag(void)
This function:
•Returns the current DALI I/O driver state (receiving, transmitting)
void check_interface_failure(void)
This function:
•Checks the DALI bus idle voltage presence (500 ms disconnection from the DALI bus)
•Calls error callback function if an error occurs
u8 get_timer_count(void)
This function:
•Returns the current systick timer content
•Is used for general purpose use, for example, random number generation
u8 get_flag(void)
This function:
•Returns the current DALI I/O driver state (receiving, transmitting)
3.2 DALI stack layer functions
The DALI stack layer implements all DALI commands processed on the logical level
according to the DALI specification.
3.2.1 dali.c
These main files contain the most commonly used functions that are called from the user
application. They contain initialization of the entire DALI slave library, DALI slave library
event flag signaling, command execution calls, and reporting of user hardware error.

Function description UM1728
14/31 DocID025866 Rev 1
void DALI_Init(LightControlFunction)
This function:
•Initializes the entire DALI slave library (both I/O pin driver layer and DALI stack layer
and is called from the user application as the main initialization function
•Initializes all necessary modules of the DALI slave library
•Starts execution of receiving commands from the DALI bus, timing management,
callback calls, and setting of event flags.
void DALI_InterruptConfig (void)
This function:
•Configures the used IRQ Channels and sets their priority.
u8 DALI_CheckAndExecuteReceivedCommand(void)
This function should be cyclically called from the main user application in the main program
loop. It:
•Checks if there is a pending received DALI packet. If so, the given DALI command from
the packet is executed.
•Returns the execution status
– 0 = no pending command
– 1 = pending DALI command executed
– 2 = DALI bus error present and processed
u8 DALI_CheckAndExecuteReceivedCommand(void)
This function should be cyclically called from the main user application in the main program
loop. It:
•Checks if there is a pending received DALI packet. If so, the given DALI command from
the packet is executed.
•Returns the execution status
– 0 = no pending command
– 1 = pending DALI command executed
– 2 = DALI bus error present and processed

DocID025866 Rev 1 15/31
UM1728 Function description
31
u8 DALI_CheckAndExecuteTimer(void)
This function should be cyclically called from the main user application in the main program
loop at least every 1 ms. It:
•Checks if there is a pending timer flag. If so, the given timer callbacks (fading functions,
timeouts, ...) are executed.
•Returns the number of pending remaining 1 ms timer cycles for a given timer task
(example, number of timer cycles to finish light dimming cycle).
void DALI_halt(void)
This function contains the entry to the microcontroller low power state (halt mode without
timer interrupt). The user must check before calling this function that there are no pending
timer cycles and DALI packets.
void DALI_Set_Lamp_Failure(failure)
This function:
•Sets or resets the failure state of the lighting element (for example, a damaged bulb).
u8 Get_DALI_Random(void)
This function:
•Returns a random number
•Is used for general purpose use
3.2.2 dali_cmd.c
These files contain all DALI commands according to the DALI specification. In addition, they
contain auxiliary functions for command processing such as checking command parameters
and correct timing.
Many functions execute a given DALI command and other functions execute auxiliary
commands. A given function is called automatically when the user calls the
DALI_CheckAndExecuteReceivedCommand(void) function.
The most important functions of these files are given below in bold. For information about
other functions, the user can refer inside these source files and to the DALI specification.
void DALIC_Init(void)
This function:
•Initializes the entire DALI command modules

Function description UM1728
16/31 DocID025866 Rev 1
u8 DALIC_isTalkingToMe(void)
This function:
•Detects if the received DALI packet is addressed to the device
void DALIC_ProcessCommand(void)
This function:
•Selects the correct command execution according to received data
void DALIC_Direct_Arc(val),
void DALIC_Direct_Arc_NoFade(val)
This function is called from many DALI commands as a request for light intensity change. It:
•Executes the light intensity control
3.2.3 dali_pub.c
These files contain the lower level DALI stack layer functions. The user can modify some
functions if required. All functions of these files are called from other DALI stack modules
(mainly from the “dali_cmd.c”) as requests to execute lower level commands.
The most important functions of these files are given below in bold.
void DALIP_Init(LightControlFunction)
This function:
•Initializes the public module
•Contains as an input parameter a user callback function for light control:
– it is called if there is a need to change the light level
– the user implements it (implementation is user hardware dependent)
– it has only one input parameter (unsigned int) which is the requested light level
– (see header file “dali_pub.h” for this function type definition).
void DALIP_Direct_Arc(u8 val)
This function is called from the “dali_cmd.c”. It:
•Executes the light intensity control using a logarithmic curve
u8 DALIP_Getxxx(void),
void DALIP_Setxxx(u8 val)
This set of functions:
•Reads or sets a given “xxx” DALI parameter (usually a DALI register or flag in RAM)

DocID025866 Rev 1 17/31
UM1728 Function description
31
void DALIP_Off(void),
void DALIP_On_And_Step_Up(void),
void DALIP_Step_Down_And_Off(void),
void DALIP_Recall_Max_Level(void),
void DALIP_Recall_Min_Level(void),
void DALIP_Up(void),
void DALIP_Down(void),
void DALIP_Step_Up(void),
void DALIP_Step_Down(void)
This set of functions
•Implements the DALI commands for controlling light level
3.2.4 dali_reg.c
These files contain the DALI register management functions. The DALI registers can be
stored in RAM, EEPROM, or ROM memory (see the DALI specification definitions). The
functions of these files implement automatic memory selection depending on the register
index and register read and write routines.
void DALIR_Init(void)
This function:
•Initializes the DALI register module
•Clears all RAM registers
void DALIR_ResetRegs(void)
This function:
•Sets all registers to the default state (according to the DALI specification)
u8 DALIR_ReadReg(idx),
void DALIR_WriteReg(idx, newval),
u8 DALIR_ReadStatusBit(bit),
void DALIR_WriteStatusBit(bit, val),
u8 DALIR_ReadEEPROMReg(idx),
void DALIR_WriteEEPROMReg(idx, val)
This set of functions:
•Is used for register reading and writing

Function description UM1728
18/31 DocID025866 Rev 1
void DALIR_DeleteShort(void)
This function:
•Clears the DALI short address (unassigned address state)
3.2.5 eeprom.c
These files contain the EEPROM (flash emulated as EEPROM) management, read and
write routines.
void EEPROM_Init (void)
This function:
•Initializes the MCU for emulated EEPROM
•Initializes the variables related to emulated EEPROM
void E2_ResetEEPROM(void)
This set of functions:
•Resets the EEPROM header
uint16_t E2_WriteMem(u16 VirtAddress, u16 Data),
void E2_WriteBurst(u16 addr, u16 times, u16* buf)
This set of functions:
•Writes data to EEPROM
u16 E2_ReadMem(u16 VirtAddress,uint16_t* Data)
This set of functions:
•Read data from EEPROM
static FLASH_Status EE_Format(void)
This set of functions:
•Erases PAGE0 and PAGE1 and writes VALID_PAGE header to PAGE0
static uint16_t EE_FindValidPage(uint8_t Operation)
This set of functions:
•Find valid Page for write or read operation
static uint16_t EE_VerifyPageFullWriteVariable(uint16_t VirtAddress, uint16_t
Data)
This set of functions:
•Verify if active page is full and Writes variable in EEPROM
static uint16_t EE_PageTransfer(uint16_t VirtAddress, uint16_t Data)
This set of functions:
•Transfers last updated variables data from the full Page to an empty one.

DocID025866 Rev 1 19/31
UM1728 Function description
31
3.2.6 lite_timer_8bit.c
These files are the timing module. They contain all virtual timers which are needed for DALI
timing such as intervals for the dimming function and DALI timeouts. Reference timer ticks
come from the DALI I/O pin driver layer.
void Timer_Lite_Init(void)
This function:
•Initializes the timing module
•Initializes the internal variables to their default state
void RTC_LaunchTimer(timer_value)
This function:
•Initializes a timeout for DALI command repetition
void RTC_LaunchUserTimer(TimerCount),
void RTC_DoneUserTimer(void)
This set of functions:
•Dims the update intervals (start and stop)
void RTC_LaunchBigTimer(mins)
This function:
•Initializes the timeout (usually 15 minutes) - expiration of the DALI “Initialize” command
void RTC_LaunchDAPCTimer(void)
This function:
•Initializes the timeout (200 ms) - expiration of the DALI “DAPC sequence” command
void PowerOnTimerReset(void)
This function:
•Stops the power-on timeout (600 ms) which was started during power-on (using the
Timer_Lite_Init() function)
void Lite_timer_Interrupt(void)
This function is the main timer function servicing all timers. It:
•Is a callback function that receives 1 ms timer ticks from the DALI I/O pin driver layer
•Runs in interrupt
•Updates the timer event flag used for updating the virtual timers (1 ms each)
u8 Process_Lite_timer_IT(void)
This function is called cyclically from the user main program loop in 1 ms intervals when the
timer event flag is signalled. It:
•Services timer events (if necessary)
•Calls callbacks or updates virtual timer values

Function description UM1728
20/31 DocID025866 Rev 1
3.2.7 dali_config.c
These files contain the DALI stack module configurations. The user can change them
according to his needs, the final ballast hardware/software implementation, the light element
used, the type of light control, the STM32 pinout, and the user/device description
information.
The most important variables and definitions in these files are given below in bold.
const u16 DALIP_ArcTable[]
This variable is the logarithmic table for light control. It:
•Implements the logarithmic table according to the DALI specification
•Converts 8-bit linear values to 16-bit logarithmic output for direct light power control
(see the DALI specification).
const u32 DALIP_FadeTimeTable[]
This variable:
•Implements the fade time table according to the DALI specification
const u16 DALIP_FadeRateTable[]
This variable:
•Implements the fade rate table according to the DALI specification
const u8 DaliRegDefaults[]
This variable:
•Implements the default DALI register content according to the DALI specification
#define USE_ARC_TABLE
This definition:
•Enables the logarithmic table to be used instead of direct light control
#define OUT_DALI_PORT,
#define OUT_DALI_PIN,
#define INVERT_OUT_DALI,
#define IN_DALI_PORT,
#define IN_DALI_PIN,
#define INVERT_IN_DALI
This set of definitions:
•Contains DALI Rx and DALI Tx signal assignments to given pins according to user
requirements. The Rx pin must have interrupt capability.
•Define if a pin is inverted or not on the user hardware DALI transceiver board
