Roland Texart RT-640 User manual

Setup Guide
Thank you very much for purchasing this product.
- To ensure correct and safe usage with a full understanding of this product's performance, please be sure to read through
this manual completely and store it in a safe location.
- Unauthorized copying or transferral, in whole or in part, of this manual is prohibited.
- The contents of this manual and the specications of this product are subject to change without notice.
- This manual and the product have been prepared and tested as much as possible. If you nd any misprint or error, please
inform us.
- Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage which may occur through use of this
product, regardless of any failure to perform on the part of this product.
- Roland DG Corp. assumes no responsibility for any direct or indirect loss or damage which may occur with respect to any
article made using this product.

Company names and product names are trademarks or registered trademarks of their respective holders.
http://www.rolanddg.com/
Copyright © 2014 Roland DG Corporation
Contents
Contents........................................................................................................1
1. Installation Environment............................................................................3
Deciding on an Installation Site .................................................................................................. 3
Temperature and Humidity .......................................................................................................... 4
Installation Space ............................................................................................................................. 4
2. Included Items...........................................................................................5
3. About the Symbols ....................................................................................7
4. Assembling and Installing..........................................................................8
Assembling and Installing............................................................................................................. 8
5. Filling with Ink..........................................................................................20
Filling with Ink for the First Time...............................................................................................20
6. Network Settings .....................................................................................36
Step 1: Make the Network Settings for the Computer......................................................36
Step 2: Make the Network Settings on the Machine .........................................................38
Step 3: Make the Port Settings for the Software RIP..........................................................39

2

3
1. Installation Environment
Deciding on an Installation Site
Install in a quiet, stable location oering good operating conditions. An unsuitable location can cause accident,
re, faulty operation, or breakdown.
WARNING Install the machine in a location that is level, stable, and able to bear the
weight of the machine.
The total weight may reach over 241 kg (518 lbs). Installation in an unsuitable
location may cause a major accident, including tip over, fall, or collapse.
WARNING Never install out of doors or in any location where exposure to water or
high humidity may occur.
Current leakage may cause electrical shock, electrocution, or combustion and
re.
WARNING Never install close to any ammable object or in a gas-lled location.
Combustion or explosion may be a danger.
WARNING Install in a clean, brightly lit location.
Conduct operations in a clean, brightly lit location. Working in a location that
is dark or cluttered may lead to an accident, such as becoming caught in the
machine as the result of an inadvertent stumble.
WARNING Position so that the power plug is within immediate reach at all times.
This is to enable quick disconnection of the power plug in the event of an emer-
gency. Install the machine next to an electrical outlet. Also, provide enough
empty space to allow immediate access to the electrical outlet.
CAUTION Ensure adequate ventilation for the work area.
Failing to perform ventilation may result in a health hazard or danger of com-
bustion due to ink fumes.
Unsuitable Installation Sites
Locations subject to large uctuations in temperature or humidity
Locations subject to shaking or vibration
Locations where the oor is tilted, not level, or unstable
Dusty locations
Locations exposed to direct sunlight
Locations exposed to direct near air-conditioning or heating equipment
Locations exposed to water or moving air
Locations exposed to considerable electrical or magnetic noise, or other forms of electro-
magnetic energy

1. Installation Environment
4
Temperature and Humidity
Maintain the specied temperature and humidity even when the machine is not in use. If temperatures are
too high or too low, it may cause malfunction.
Installation Space
The space shown in the gure is required in order to use this machine.
During operation: Temperature 18 to 25˚C (64.4 to 77 ˚F), relative humidity 35 to 65 % RH (no con-
densation)
During non-operation: Temperature 15 to 30˚C (59 to 86 ˚F), relative humidity 20 to 80% (no con-
densation)
3,600 mm (141.8 in)
800 mm (31.5 in)
2,600 mm (102.4 in)
Machine Space
Work Space
2,000 mm (78.8 in)

5
2. Included Items
The following items are packed together with the machine. Make sure they are all present and accounted for.
Printer unit
Power cord (1) Arms (one for right and
left each) Casters (2) Stand legs (one for
right and left each)
Stand stay (1) Shafts (2)
Feed adjusters (2) Feed adjuster stays (2)
Shaft clamps (2) Bolts (long) (38) Bolts (short) (8) Hexagonal wrench
(1 large, 1 small)
Pipe (1) Cable clamp (1)
Media holders / Media
holder retaining screws
(one for right and left each)
Media clamps*(one for
right and left each)
Cleaning sticks Replacement blades for
separating knife (1) Drain bottles (2) Tweezers (1)

2. Included Items
6
Ink color labels (1) Tube caps
(for 8 colors)* Replacement wiper (1) Replacement felt wiper
(1)
Software RIP (1) User's Manual (1) Setup Guide (This
document) (1) Read this rst (1)
INKJET PRINTER MAIN-
TENANCE GUIDE (1)
* Not required when using four colors (cyan, magenta, yellow, and black).
Roland Ink System
Ink pouch holder (1) Subtank guard (1)
Ink tube cover (top) (1) Ink tube covers (bottom)
(one for right and left each) Subtank cartridges (8)
Square bushes (4) Y-shaped tubes (8) Screws (11) Ink color labels (1)

7
3. About the Symbols
The meanings of the symbols used in this document are as follows.
The symbol indicates things that must be followed in relation to operation.
Always follow these instructions to prevent accident or damage due to
misoperation.
The symbol indicates things that must be checked visually in relation to op-
eration. Always perform a visual check to prevent accident or damage due
to failure to check.
The symbol indicates "additional information".

8
4. Assembling and Installing
Completed drawing
About the picture
Assembling and Installing
WARNING Perform this task with all power switches left switched off.
Otherwise sudden movement of the machine may cause injury.
CAUTION Unpacking and installation must be carried out by six or more personnel.
Otherwise the machine or the stand may fall, resulting in injury.
Necessary tools
Included items Commercial item
Hexagonal Wrench
(large)
Hexagonal Wrench
(small)
Pipe
(Use this pipe if the
hexagonal wrench is
too short to tighten the
bolt)
Phillips screwdriver
Tighten temporary Tighten fully
