Stack-On GCB-2SF-BB User manual

WELDED-STEEL
GARAGE STORAGE
Assembly Instructions
You can be killed or seriously injured if you don't follow
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual. Always read all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol with the word or “WARNING.”
These words mean:
instructions.
WARNING
TABLE OF CONTENTS
CABINET/LOCKER SAFETY .................... 1
BASE CABINET: ASSEMBLY INSTRUCTIONS .................... 2
TALL STORAGE CABINET: ASSEMBLY INSTRUCTIONS .................... 4
WALL CABINET: ASSEMBLY INSTRUCTIONS .................... 5
FLOOR LOCKING CABINET: ASSEMBLY INSTRUCTIONS .................... 6
WARRANTY .................... 7

2
BASE CABINET: ASSEMBLY INSTRUCTIONS
Install the Casters
WARNING
Excessive Weight Hazard
Use two or more people to move, assemble or install
cabinet.
Failure to do so can result in back or other injury.
1. If equipped with drawers, push in completely to lock in place.
2. Close the cabinet doors.
3. Using two or more people, turn the cabinet upside down.
4. Preassemble the screw and nut to the caster.
5. Insert the carriage flat-head bolts into the keyhole slots and
slide the bolts into place as shown.
6. Position the two brake casters over the bolts in the front
cabinet location, with the brakes toward the outside, and start
four self-locking nuts for each caster.
7. Hold the casters in place making sure the bolts are seated in
the narrow ends of the keyhole slots. Tighten the self-locking
nuts with a ⁷⁄₁₆" wrench.
8. To attach the two swivel casters to the rear caster location,
repeat steps 2 and 3.
9. Return the cabinet to its upright position.
10. Place the top mat with the textured side facing up.
GCB-2SF-BB
GCB-2SF-BR
GCB-3DR-BB
GCB-3DR-BR
Tools and Parts
Gather the required tools and parts before starting installation.
Tools Needed:
Parts Supplied:
Unpack the Cabinet
NOTE: Keep the packing materials to cushion the cabinet during
assembly and then dispose of/recycle all packaging materials.
1. Verify contents. See “Parts Supplied.”
⁷⁄₁₆" Wrench
Top mat (1)
Swivel casters (4)
¹⁄₄" - 20 Self-locking nuts (16)
¹⁄₄" - 20 x ¹⁄₂" Carriage flat-head bolts (16)
Handels (2)
Models
B
C
D
A. Brake caster
B. Rear caster D. Front of cabinet
C. Caster plate
A

3
Install the Door Handles
1. Open the doors.
2. Insert Phillips head screws through pre-drilled holesin door.
3. Align door handles with screws and tighten. (Do not overtighten)
4. Repeat this procedure for the other doorhandle.
Removing/Installing the Drawers
(select models only)
Removing the Drawer
1. Unload the contents from the drawer.
2. Slide the drawer out as far as it will go.
3. Press the lever down on the right-hand track and lift the lever up
on the left track to release the drawer.
A. Lever
A
..........
..........
..........
..........
Replacing the Drawer
1. Align the drawer guides with the receiving
glides.
2. Hold the receiving glides firmly and insert the drawer guide.
NOTE: It is normalfor the convertible tray or drawer to close
tightly the first time after it has been removed.
3. Push the drawer in completely.

4
Install the Casters
WARNING
Excessive Weight Hazard
Use two or more people to move, assemble or install
cabinet.
Failure to do so can result in back or other injury.
TALL STORAGE CABINET: ASSEMBLY INSTRUCTIONS
1. Close the cabinet doors.
2. Using two or more people, lay the cabinet on its side with the
bottom facing your work area. Be careful the doors do not
swing open when moving or proceeding with caster installation.
3. Preassemble the screw and nut to the caster.
4. Insert the carriage flat-head bolts into the keyhole slots and
slide the bolts into place as shown.
5. Position the two rigid casters over the bolts in the front of the
cabinet location, with the brakes toward the inside, and start
four self-locking nuts for each caster.
6. Hold the casters in place making sure the bolts are seated in
the narrow ends of the keyhole slots. Tighten the self-locking
nuts with a ⁷⁄₁₆" wrench. (Do not overtighten)
7. To attach the two swivel casters to the rear caster location,
repeat steps 2 and 3.
8. Return the cabinet to its upright position.
Front of cabinet
Bottom of cabinet
Caster plate
Tools and Parts
Gather the required tools and parts before starting installation.
Tools Needed:
Parts Supplied:
Unpack the Cabinet
NOTE: Keep the packing materials to cushion the cabinet during
assembly and then dispose of/recycle all packaging materials.
1. Verify contents. See “Parts Supplied.”
⁷⁄₁₆" Wrench
Swivel casters (4)
¹⁄₄" - 20 Self-locking nuts (16)
¹⁄₄" - 20 x ¹⁄₂" Carriage flat-head bolts (16)
Install the Door Handles
1. Open the doors.
2. Insert Phillips head screws through holesin door.
3. Align door handles with screws and tighten. (Do not overtighten)
4. Repeat this procedure for the other doorhandle.
..........
..........
..........
..........
Phillips screwdriver
GCTL-4SF-BB
GCTL-4SF-BR
Models
B
C
D
A. Brake caster
B. Rear caster D. Front of cabinet
C. Caster plate
A

5
2
A
WALL CABINET: ASSEMBLY INSTRUCTIONS
WARNING
Excessive Weight Hazard
Use two or more people to move, assemble or install
cabinet.
Failure to do so can result in back or other injury.
Install the Door Handles
1. Open the doors.
2. Insert Phillips head screws through the pre-drilled holesin door.
3. Align door handles with screws and tighten. (Do not overtighten)
4. Repeat this procedure for the other doorhandle.
..........
..........
..........
..........
2. Wall Mounting
The hardware used to secure the cabinet may vary depending on the
type of wall and spacing of wall supports. Please contact your local
hardware retailer for fastening hardware.
These instructions provide a general guideline for hanging the cabinet.
Fastening hardware is included for wood frame wall construction.
The cabinet should be mounted flush and level on the wall. You must
use the top 2 mounting pre-drilled holes when securing the cabinet to
the wall. We recommend using 4 mounting holes to secure the cabinet.
TIP: A securely fastened cleat (A) mounted level and at the appropriate
height will aid in mounting the cabinet.
Tools and Parts
Gather the required tools and parts before starting installation.
Tools Needed:
Parts Supplied:
Unpack the Cabinet
NOTE: Keep the packing materials to cushion the cabinet during
assembly and then dispose of/recycle all packaging materials.
1. Verify contents. See “Parts Supplied.”
⁷⁄₁₆" Wrench
Phillips screwdriver
Screw 10-24 x ¹⁄₂" (10)
GCW-2SF-BB
GCW-2SF-BR
Models

FLOOR LOCKING CABINET: ASSEMBLY INSTRUCTIONS
6
WARNING
Excessive Weight Hazard
Use two or more people to move, assemble or install
cabinet.
Failure to do so can result in back or other injury.
NOTE: This cabinet must be mounted and secured to wall studs
in the top pre-drilled holes in the back of the cabinet so that it is
anchored to the wall studs in two locations. The cabinet must
also be mounted to the floor. Failure to do so will compromise
the safety and security of the cabinet. Use the hardware
provided or consult your hardware retailer for fastening
hardware for your particular mounting surfaces.
Drill (2) ³⁄₁₆" pilot holes into the wall studs lining up with the top (2)
mounting holes in the back of the cabinet. Secure the cabinet to the
wall using (2) lag bolts and washers.
Drill (2) pilot holes and secure the cabinet bottom to the floor with (2)
lag bolts and washers.
Tools and Parts
Gather the required tools and parts before starting installation.
Tools Needed:
Parts Supplied:
⁷⁄₁₆" Wrench
Key and backup key (2)
8-32 x ¹⁄₂" screw (10)
8-32 x nut (10)
¹⁄₄" x 1-¹⁄₂" lag screw (4)
Washers (4)
Unpack the Cabinet
NOTE: Keep the packing materials to cushion the cabinet during
assembly and then dispose of/recycle all packaging materials.
1. Verify contents. See “Parts Supplied.”
GCL-2SF-BB
GCL-2SF-BR
Models

LIMITED ONE YEAR WARRANTY
STEEL GARAGE CABINETS
Stack-On®Steel Garage Cabinets, are warranted to be free from defects in material and workmanship for a
period of one (1) year from the date of original purchase by a consumer. This warranty extends to the initial
consumer only.
If you believe there is a defect in material or workmanship in your Steel Garage Cabinets, during the
one-year warranty period, please contact our customer service department, by regular mail or email at the
address listed below, and include with your correspondence proof of purchase information and the model
number of the product.
Cannon Security Products
2895 W. Capovilla Ave, Suite 140
Las Vegas, NV 89119
[email protected]
1-847-665-1602
If Stack-On is properly notified during the one-year warranty period and, after inspection confirms there is a
defect, Stack-On will, at its sole option, provide repair parts or exchange the product at no charge, or refund
the purchase price of the product.
THIS WARRANTY DOES NOT COVER ANY PRODUCT, OR ANY PART OF ANY PRODUCT, WHICH
HAS BEEN SUBJECT TO EXCESSIVE USE, ACCIDENT, NEGLIGENCE, ABUSE OR MISUSE, INCOR-
RECT MAINTENANCE, ALTERATION OR REPAIR BY ANYONE OTHER THAN STACK-ON. IN ADDI-
TION, THIS WARRANTY DOES NOT COVER ANY ACCESSORIES OR PARTS USED WITH OR IN THE
PRODUCT, WHICH ARE NOT INCLUDED WITH THE ORIGINAL PURCHASE.
THIS WARRANTY IS EXCLUSIVE AND EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES
EXPRESSED OR IMPLIED INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, WHICH ARE HEREBY DISCLAIMED AND EXCLUDED. STACK-ON
SHALL NOT BE SUBJECT TO ANY OTHER OBLIGATIONS OR LIABILITIES. STACK-ON NEITHER
ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT, ANY OTHER LIABILITY IN
CONNECTION WITH THE SALE OF STACK-ON’S STEEL GARAGE CABINETS.
STACK-ON WILL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE TO THE INITIAL CONSUMER FOR
ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, EXEMPLARY, OR PUNITIVE DAMAGES ARISING
OUT OF THE PURCHASE OR USE OF ANY STACK-ON STEEL GARAGE CABINETS.
STACK-ON’S LIABILITY FOR ANY BREACH OF THIS WARRANTY SHALL BE LIMITED EXCLUSIVELY
TO REPAIR OR REPLACEMENT OF THE DEFECTIVE PRODUCT, AS DESCRIBED ABOVE, OR A
REFUND OF THE PURCHASE PRICE OF THE PRODUCT.
IN NO EVENT SHALL STACK-ON’S OBLIGATION UNDER THIS WARRANTY EXCEED THE PRICE OF
THE PRODUCT. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE
OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
