FUJITSU Storage
ETERNUS DX, ETERNUS AF
Configuration Guide -Server Connection-
(Fibre Channel) for Oracle Solaris
Driver Settings for Non-Fujitsu Fibre Channel Cards
P3AM-6312-18ENZ0

This page is intentionally left blank.

Preface
This manual briefly explains the operations that need to be performed by the user in order to connect an
ETERNUS DX/AF to a server running Solaris OS and using non-Fujitsu Fibre Channel cards via a Fibre Channel
interface.
This manual is used when performing the setup procedure described in "Installing Drivers and Setting Up the
Server" and "Recognizing the Logical Units" of the "Configuration Guide -Server Connection- (Fibre Channel)
for Oracle Solaris".
This manual should be used in conjunction with any other applicable user manuals, such as those for the
ETERNUS DX/AF, server, OS, Fibre Channel cards, and drivers.
Refer to "Configuration Guide -Server Connection- Notations" for the notations used in this manual such as
product trademarks and product names. For storage systems that are supported by the OS, refer to the Server
Support Matrix of the ETERNUS DX/AF.
18th Edition
December 2017
The Contents and Structure of this Manual
This manual is composed of the following four chapters and an appendix.
•"Chapter 1 Operations When Using Oracle Fibre Channel Cards" (page 6)
This chapter describes the workflow required to establish a connection between a server with Oracle Fibre
Channel cards and an ETERNUS DX/AF.
•"Chapter 2 Setup Procedure for Emulex Fibre Channel Cards" (page 27)
This chapter describes the workflow required to establish a connection between a server with Emulex Fibre
Channel cards and an ETERNUS DX/AF.
•"Chapter 3 Setup Procedure for QLogic Fibre Channel Cards" (page 54)
This chapter describes the workflow required to establish a connection between a server with QLogic Fibre
Channel cards and an ETERNUS DX/AF.
•"Chapter 4 Operations When Using Brocade Fibre Channel Cards" (page 73)
This chapter describes the workflow required to establish a connection between a server with Brocade Fibre
Channel cards and an ETERNUS DX/AF.
An appendix contains the various management tables that are used in "Setting Up the Server".
3
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

Table of Contents
Chapter 1 Operations When Using Oracle Fibre Channel Cards 6
1.1 Workflow ........................................................................................................................................ 6
1.2 Installing the Fibre Channel Card Driver ......................................................................................... 7
1.3 Setting Up the Server...................................................................................................................... 8
1.3.1 Oracle Driver for QLogic OEM Fibre Channel Cards ................................................................................................9
1.3.2 Oracle Driver for Emulex OEM Fibre Channel Cards .............................................................................................13
1.4 Setting Up the Server to Recognize the Logical Units ................................................................... 17
1.4.1 For Direct Connection..........................................................................................................................................17
1.4.2 For Switch Connection.........................................................................................................................................19
1.5 Required Driver Parameters ......................................................................................................... 20
1.5.1 Emulex OEM Fibre Channel Card Setup ...............................................................................................................20
1.5.2 emlxs.conf Parameter List ..................................................................................................................................22
1.5.3 emlxs.conf Parameter Example ..........................................................................................................................23
Chapter 2 Setup Procedure for Emulex Fibre Channel Cards 27
2.1 Workflow ...................................................................................................................................... 27
2.2 Installing the Fibre Channel Card Driver ....................................................................................... 28
2.2.1 Solaris 10 OS Update1 or Later............................................................................................................................28
2.2.2 Solaris 10 OS, Solaris 9 OS, or Solaris 8 OS...........................................................................................................30
2.3 Setting Up the Server.................................................................................................................... 31
2.3.1 Creating a WWN Instance Management Table for the Server ..............................................................................31
2.3.2 Creating a WWN Instance Management Table for Storage System......................................................................33
2.3.3 Creating a Target Binding Table..........................................................................................................................34
2.3.4 Setting the Configuration File .............................................................................................................................35
2.3.5 Re-checking the Settings ....................................................................................................................................35
2.4 Setting Up the Server to Recognize the Logical Units ................................................................... 36
2.4.1 Recognizing Logical Units with the sd Driver ......................................................................................................36
2.5 Required Driver Parameters ......................................................................................................... 40
2.5.1 For Driver Versions V6.30g and Later ..................................................................................................................41
2.5.2 For Driver Versions Before V6.30g.......................................................................................................................47
Chapter 3 Setup Procedure for QLogic Fibre Channel Cards 54
4
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

3.1 Workflow ...................................................................................................................................... 54
3.2 Installing the Fibre Channel Card Driver ....................................................................................... 55
3.3 Setting Up the Server.................................................................................................................... 55
3.3.1 Creating a WWN Instance Management Table for the Server ..............................................................................56
3.3.2 Creating a WWN Instance Management Table for Storage System......................................................................60
3.3.3 Creating a Target Binding Table..........................................................................................................................61
3.3.4 Setting the Configuration File .............................................................................................................................62
3.3.5 Re-checking the Settings ....................................................................................................................................62
3.4 Setting Up the Server to Recognize the Logical Units ................................................................... 63
3.4.1 Recognizing Logical Units with the sd Driver ......................................................................................................63
3.5 Required Driver Parameters ......................................................................................................... 66
3.5.1 Setting Up the Parameters..................................................................................................................................66
Chapter 4 Operations When Using Brocade Fibre Channel Cards 73
4.1 Workflow ...................................................................................................................................... 73
4.2 Installing the Fibre Channel Card Driver ....................................................................................... 74
4.3 Setting Up the Server.................................................................................................................... 74
4.3.1 Creating a WWN Instance Management Table for the Server ..............................................................................75
4.3.2 Setting Up the Fibre Channel Cards.....................................................................................................................77
4.3.3 Setting the Configuration File (/etc/system) .......................................................................................................80
4.4 Setting Up the Server to Recognize the Logical Units ................................................................... 81
Appendix A Various Management Table Templates 82
A.1 WWN Instance Management Table for the Server ........................................................................ 82
A.2 WWN Instance Management Table for Storage System ................................................................ 82
A.3 Target Binding Table.................................................................................................................... 83
Table of Contents
5
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

Chapter 1
Operations When Using Oracle Fibre Channel
Cards
This chapter describes the procedures for "Installing the Driver and Setting Up the Server" and "Recognizing
the Logical Units" required to establish a connection between a server with Oracle Fibre Channel cards and
an ETERNUS DX/AF.
1.1 Workflow
Workflow
Installing the Fibre Channel Card Driver
Install the driver. Download the proper driver from the Oracle web-site as required.
•"1.2 Installing the Fibre Channel Card Driver" (page 7)
•Used for driver installation
-Driver (downloaded from the Oracle web-site)
Creating Various Management Tables
Enter necessary information in "WWN Instance Management Table for the Server".
•"1.3 Setting Up the Server" (page 8)
•"Appendix A Various Management Table Templates" (page 82)
Editing the Configuration File
Set the driver parameters by editing the configuration file.
•"1.3 Setting Up the Server" (page 8)
•"1.5 Required Driver Parameters" (page 20)
•Checking the Oracle driver notes
-"Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris"
6
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

Setting Up the Server to Recognize the Logical Units (LUNs)
Make the server recognize the ETERNUS DX/AF logical units using the ssd driver.
•"1.4 Setting Up the Server to Recognize the Logical Units" (page 17)
After completing all the required procedures in this manual, proceed to "Setting the Multipaths" in
"Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris".
1.2 Installing the Fibre Channel Card Driver
Install the Fibre Channel card driver.
Required procedure varies depending on the Solaris OS version.
Refer to the following Oracle web-site for installation procedures.
https://www.oracle.com/
•Solaris 11 OS or Solaris 10 OS
Driver installation is not necessary because the OS-bundled driver is used.
•Solaris 9 OS or Solaris 8 OS
Download and install the appropriate driver from the Oracle web-site.
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.2 Installing the Fibre Channel Card Driver
7
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

1.3 Setting Up the Server
The server setup will vary according to how the ETERNUS DX/AF storage systems and server are to be connec-
ted. There are two possible connection topologies: direct connection and switch connection.
Edit the server's configuration file to match the chosen topology. Configuration files may also differ depend-
ing on which Fibre Channel card drivers are to be used. Check the Fibre Channel card product ID in the follow-
ing table and follow the procedure detailed in the indicated section ("1.3.1 Oracle Driver for QLogic OEM Fi-
bre Channel Cards" (page 9) or "1.3.2 Oracle Driver for Emulex OEM Fibre Channel Cards" (page 13)).
Procedure Supplier Fibre Channel card product ID
"1.3.1 Oracle Driver for QLogic OEM Fibre Channel
Cards" (page 9)
Fujitsu •SP1X7FAS2F
•SP1X7FAR2F
•SP1X7FAB2F
•SP1X7FAA2F
•SP1X5FAS2F
•SP1X5FAR2F
•SP1X5FAA2F
•SE0X7F22X
•SE0X7F21X
•SE0X7F22F
•SE0X7F21F
•XSPFC212A
•XSPFC211A
•XSPFC202A
•XSPFC201A
•X6799A
•X6768A
•X6767A
•X6727A
Oracle (Former Sun) •7101682
•7101681
•7101674
•7101673
•SG-XPCIE2FC-QF8-Z
•SG-XPCIE1FC-QF8-Z
•SG-XPCIE2FC-QF4
•SG-XPCIE1FC-QF4
•SG-XPCI2FC-QF4
•SG-XPCI1FC-QF4
•SG-XPCI2FC-QF2-Z
•SG-XPCI2FC-QF2
•SG-XPCI1FC-QF2
•SG-XPCI1FC-QL2
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.3 Setting Up the Server
8
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

Procedure Supplier Fibre Channel card product ID
"1.3.2 Oracle Driver for Emulex OEM Fibre Channel
Cards" (page 13)
Fujitsu •SP1X7FBS2F
•SP1X7FBR2F
•SP1X7FBA2F
•SP1X5FBS2F
•SP1X5FBR2F
•SP1X5FBA2F
•XSEFC401AF
•XSEFC402A
•XSEFC401A
Oracle (Former Sun) •7101690
•7101689
•7101684
•7101683
•SG-XPCIE2FC-EM8-Z
•SG-XPCIE1FC-EM8-Z
•SG-XPCI2FC-EM4-Z
•SG-XPCI1FC-EM4-Z
•SG-XPCE2FC-EM4
•SG-XPCE1FC-EM4
•SG-XPCI2FC-EM2
•SG-XPCI1FC-EM2
1.3.1 Oracle Driver for QLogic OEM Fibre Channel Cards
Oracle Driver for QLogic OEM Fibre Channel Cards
When connecting using QLogic OEM Fibre Channel cards with an Oracle Fibre Channel card driver, the config-
uration file will need to be edited as follows.
The "command queue depth" setting must be adjusted for both direct connection and switch connection. The
"command queue depth" setting is specified in the configuration file (/etc/system).
●For direct connection
Instance name data of the Fibre Channel card is necessary. Refer to the following sections to set.
•"1.3.1.1 Creating a WWN Instance Management Table for the Server" (page 9)
•"1.3.1.2 Setting the Configuration File (/etc/system)" (page 12)
●For switch connection
The Fibre Channel card Instance name, target WWN, and target ID information are necessary. Check each
item and enter them in the table. Edit the configuration file according to those information and make set-
tings. Refer to the following sections to set.
•"1.3.1.1 Creating a WWN Instance Management Table for the Server" (page 9)
•"1.3.1.2 Setting the Configuration File (/etc/system)" (page 12)
1.3.1.1 Creating a WWN Instance Management Table for the Server
Create a "WWN instance management table for the server" with information regarding the Fibre Channel card
installed in the server. For each Fibre Channel card that is installed in the server, check the physical slot
names, WWN, instance names, physical path names, and controller number of the target connected to the
Fibre Channel card and enter them in the "WWN instance management table for the server" (provided in
"Appendix A Various Management Table Templates" (page 82)).
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.3 Setting Up the Server
9
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

WWN Instance Management Table for the Server
Physical slot name WWN Controller number Instance name Physical path name
1Check the instance names.
"qlc + instance number" is the format used to represent Fibre Channel card instance names.
The instance number that corresponds to the physical path in which the Fibre Channel card is installed
is stored in the "/etc/path_to_inst" file at the Fibre Channel card driver installation.
Extract necessary parts using the "grep" command.
# grep '"qlc"' /etc/path_to_inst
Example:
# grep '"qlc"' /etc/path_to_inst
"/pci@9,600000/SUNW,qlc@1" 0 "qlc"
"/pci@9,600000/SUNW,qlc@2" 1 "qlc"
The underlined portion "/pci@9,600000/SUNW,qlc@2" indicates the physical path name, and "1" indi-
cates the instance number.
2Enter the results in "Instance name" and "Physical path name" columns of the "WWN instance manage-
ment table for the server".
Example:
Physical slot
name WWN Controller num- ber Instance name Physical path name
qlc0 /pci@9,600000/SUNW,qlc@1
qlc1 /pci@9,600000/SUNW,qlc@2
3Enter the slot number of the Fibre Channel card installed in the server in the "Physical slot name" field
of the "WWN instance management table for the server".
Use the "/usr/platform/'uname-i'/sbin/prtdiag -v" command to check the installed Fibre Channel card
slot number.
Example: Excerpt from "/usr/platform/SUNW,SPARC-Enterprise-T5220/sbin/prtdiag -v" output
# /usr/platform/SUNW,SPARC-Enterprise-T5220/sbin/prtdiag -v
========================= IO Configuration =================================================
Location Type Slot Path Name Model
MB/PCIE1 PCIE 1 /pci@9,600000/SUNW,qlc@2 SUNW,qlc-pciex1077,2432 QLE2460
MB/PCIE0 PCIE 0 /pci@9,600000/SUNW,qlc@1 SUNW,qlc-pciex1077,2432 QLE2460
Physical slot name WWN Controller number Instance name Physical path name
PCIE 0 qlc0 /pci@9,600000/SUNW,qlc@1
PCIE 1 qlc1 /pci@9,600000/SUNW,qlc@2
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.3 Setting Up the Server
10
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

4Check the WWN of each Fibre Channel card.
(1) Use the following command to check the display order of the Fibre Channel card physical path
names.
# prtpicl -v -c scsi-fcp | grep devfs-path
Example:
# prtpicl -v -c scsi-fcp | grep devfs-path
:devfs-path /pci@9,600000/SUNW,qlc@1
:devfs-path /pci@9,600000/SUNW,qlc@2
(2) Use the following command to check the WWN of the Fibre Channel card that corresponds to the
physical path name. The result is displayed in the same order as shown in Step (1).
# prtpicl -v -c scsi-fcp | grep port-wwn
Example:
# prtpicl -v -c scsi-fcp | grep port-wwn
:port-wwn 21 00 00 e0 8b 12 6d 70
:port-wwn 21 00 00 e0 8b 16 cf fd
5Add the results in the "WWN instance management table for the server".
Example:
Physical slot
name WWN Controller num- ber Instance name Physical path name
PCIE 0 210000e08b126d70 qlc0 /pci@9,600000/SUNW,qlc@1
PCIE 1 210000e08b16cffd qlc1 /pci@9,600000/SUNW,qlc@2
6Check the controller number of the target connected to the Fibre Channel card.
Use the following command to check the controller number of the target connected to the Fibre Chan-
nel card. The controller number corresponds to the physical path displayed in Step (1).
# cfgadm -v
Example:
# cfgadm -v
Ap_Id Receptacle Occupant Condition Information
When Type Busy Phys_Id
c4 connected unconfigured unknown
unavailable fc-fabric n /devices/pci@9,600000/SUNW,qlc@1/fp@0,0:fc
c5 connected unconfigured unknown
unavailable fc-fabric n /devices/pci@9,600000/SUNW,qlc@2/fp@0,0:fc
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.3 Setting Up the Server
11
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

7Add the results in the "WWN instance management table for the server".
Example:
Physical slot
name WWN Controller num- ber Instance name Physical path name
PCIE 0 210000e08b126d70 c4 qlc0 /pci@9,600000/SUNW,qlc@1
PCIE 1 210000e08b16cffd c5 qlc1 /pci@9,600000/SUNW,qlc@2
This completes the "WWN instance management table for the server".
1.3.1.2 Setting the Configuration File (/etc/system)
1Edit the configuration file.
Edit the configuration file (/etc/system) and specify the command queue depth.
The appropriate command queue depth is determined by the ETERNUS DX/AF model, as follows:
Model Setting value
Command queue depth
ETERNUS DX/AF Arbitrary (*1)
(Up to 1024 for each FC port of the ETERNUS DX/AF)
*1: Recommended value = 1024 ¸ (number of Fibre Channel ports that are connected to a single CA
port) ¸ number of LUNs
(Round the result down)
•Use the value of "8" if the actual result is lower.
•To achieve maximum system performance, this value can be changed according to the server
load and the peak operating times.
•The number of simultaneous command executions per CA port for the ETERNUS DX/AF is limited
to 1024. This value is used by multiple servers that share the CA port. A maximum of 1024 com-
mands can be executed per CA port.
•For the ETERNUS DX/AF
The parameter to be specified for the command queue depth is determined by the CPU which is in-
stalled in the server to be connected.
-For SPARC
Specify the command queue depth for the "ssd_max_throttle" parameter.
Add this parameter if it does not exist.
Example:
set ssd:ssd_max_throttle = 20
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.3 Setting Up the Server
12
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

-For x86
Specify the command queue depth for the "sd_max_throttle" parameter.
Add this parameter if it does not exist.
Example:
set sd:sd_max_throttle = 20
2After editing the configuration file, save it.
3After the setting is complete, check the configuration file for incorrect settings.
4Reboot the server.
# /usr/sbin/shutdown -y -g0 -i6
1.3.2 Oracle Driver for Emulex OEM Fibre Channel Cards
When connecting using an Emulex OEM Fibre Channel card and Oracle Fibre Channel card driver, the configu-
ration file will need to be edited as follows.
The "command queue depth" setting must be adjusted for both direct connection and switch connection. The
"command queue depth" setting is specified in the configuration file (/etc/system).
●For direct connection
Instance name data of the Fibre Channel card is necessary. Refer to the following sections to set.
•"1.3.2.1 Creating a WWN Instance Management Table for the Server" (page 13)
•"1.3.2.2 Setting the Configuration File (emlxs.conf)" (page 16)
•"1.3.2.3 Setting the Configuration File (/etc/system)" (page 16)
●For switch connection
The Fibre Channel card Instance name, target WWN, and target ID information are necessary. Check each
item and enter them in the table. Edit the configuration file according to those information and make set-
tings. Refer to the following sections to set.
•"1.3.2.1 Creating a WWN Instance Management Table for the Server" (page 13)
•"1.3.2.2 Setting the Configuration File (emlxs.conf)" (page 16)
•"1.3.2.3 Setting the Configuration File (/etc/system)" (page 16)
1.3.2.1 Creating a WWN Instance Management Table for the Server
Create a "WWN instance management table for the server" with information regarding the Fibre Channel card
installed in the server.
For each Fibre Channel card that is installed in the server, check the physical slot names, WWN, instance
names, physical path names, and controller number of the target connected to the Fibre Channel card and
enter them in the "WWN instance management table for the server" (provided in "Appendix A Various Man-
agement Table Templates" (page 82)).
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.3 Setting Up the Server
13
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

WWN instance management table for the server
Physical slot name WWN Controller number Instance name Physical path name
1Check the instance names.
"emlxs + instance number" is the format used to represent Fibre Channel card instance names.
The instance number that corresponds to the physical path in which the Fibre Channel card is installed
is stored in the "/etc/path_to_inst" file at the Fibre Channel card driver installation.
Extract necessary parts using the "grep" command.
# grep "emlxs" /etc/path_to_inst
"/pci@9,600000/SUNW,emlxs@1" 0 "emlxs"
"/pci@9,600000/SUNW,emlxs@1,1" 1 "emlxs"
The underlined portion "/pci@9,600000/SUNW,emlxs@1,1" indicates the physical path name, and "1"
indicates the instance number.
2Enter the results in "Instance name" and "Physical path name" columns of the "WWN instance manage-
ment table for the server".
Example:
Physical slot
name WWN Controller num- ber Instance name Physical path name
emlxs0 /pci@9,600000/SUNW,emlxs@1
emlxs1 /pci@9,600000/SUNW,emlxs@1,1
3Enter the slot number of the Fibre Channel card installed in the server in the "Physical slot name" field
of the "WWN instance management table for the server".
Use the "/usr/platform/`uname -i`/sbin/prtdiag" command to check the installed Fibre Channel card slot
number.
Example: Excerpt from "/usr/platform/SUNW,SPARC-Enterprise-T5220/sbin/prtdiag" output
# /usr/platform/SUNW,SPARC-Enterprise-T5220/sbin/prtdiag
========================= IO Configuration =================================================
Location Type Slot Path Name Model
MB/PCIE1 PCIE 1 /pci@9,600000/SUNW,emlxs@1,1 SUNW,emlxs-pci10df,fd+LP11002-M4
MB/PCIE0 PCIE 0 /pci@9,600000/SUNW,emlxs@1 SUNW,emlxs-pci10df,fd+LP11002-M4
Physical slot name WWN Controller number Instance name Physical path name
PCIE 0 emlxs0 /pci@9,600000/SUNW,emlxs@1
PCIE 1 emlxs1 /pci@9,600000/SUNW,emlxs@1,1
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.3 Setting Up the Server
14
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

4Check the WWN of each Fibre Channel card.
(1) Execute the following command to check the WWN that corresponds to the Fibre Channel card in-
stance name.
# prtpicl -v -c scsi-fcp | grep devfs-path
Example:
# prtpicl -v -c scsi-fcp | grep devfs-path
:devfs-path /pci@9,600000/SUNW,emlxs@1
:devfs-path /pci@9,600000/SUNW,emlxs@1,1
:devfs-path /pci@9,600000/SUNW,emlxs@2
:devfs-path /pci@9,600000/SUNW,emlxs@2,1
(2) Use the following command to check the WWN of the Fibre Channel card that corresponds to the
physical path name.
# cat /var/adm/messages | grep emlxs0
Example:
# cat /var/adm/messages | grep emlxs0
Sep 12 09:46:50 sfv890b emlxs: [ID 349649 kern.info] [B.125B]emlxs0: NOTICE: 100: Driver attach.
(WWPN:10000000C94CDC42 WWNN:20000000C94CDC42)
# cat /var/adm/messages | grep emlxs1
Sep 12 09:47:15 sfv890b emlxs: [ID 349649 kern.info] [B.125B]emlxs1: NOTICE: 100: Driver attach.
(WWPN:10000000C94CDC43 WWNN:20000000C94CDC43)
5Add the results in the "WWN instance management table for the server".
Example:
Physical slot
name WWN Controller num- ber Instance name Physical path name
10000000C94CDC42 emlxs0 /pci@9,600000/SUNW,emlxs@1
10000000C94CDC43 emlxs1 /pci@9,600000/SUNW,emlxs@1,1
6Check the controller number of the target connected to the Fibre Channel card.
Use the following command to check the controller number of the target connected to the Fibre Chan-
nel card.
# cfgadm -v
Example:
# cfgadm -v
Ap_Id Receptacle Occupant Condition Information
When Type Busy Phys_Id
c4 connected unconfigured unknown
unavailable fc-fabric n /devices/pci@9,600000/SUNW,emlxs@1/fp@0,0:fc
c5 connected unconfigured unknown
unavailable fc-fabric n /devices/pci@9,600000/SUNW,emlxs@1,1/fp@0,0:fC
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.3 Setting Up the Server
15
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

7Add the results in the "WWN instance management table for the server".
Example:
Physical slot
name WWN Controller num- ber Instance name Physical path name
10000000C94CDC42 C4 emlxs0 /pci@9,600000/SUNW,emlxs@1
10000000C94CDC43 C5 emlxs1 /pci@9,600000/SUNW,emlxs@1,1
This completes the "WWN instance management table for the server".
1.3.2.2 Setting the Configuration File (emlxs.conf)
Set the "topology" and "link speed" by editing the configuration file "emlxs.conf".
For setting procedure and parameters, refer to "1.5 Required Driver Parameters" (page 20).
•Solaris 11 OS
If the "/etc/driver/drv/emlxs.conf” file does not exist, copy the "/kernel/drv/emlxs.conf" file to the "/etc/driv-
er/drv" directory and add the line to the newly copied "emlxs.conf" file.
If the "/etc/driver/drv/emlxs.conf” file exists, do not copy over the file but instead add the line to the exist-
ing "emlxs.conf" file.
•Solaris 10 OS
Edit the "/kernel/drv/emlxs.conf" file.
1.3.2.3 Setting the Configuration File (/etc/system)
1Edit the configuration file.
Edit the configuration file (/etc/system) and specify the command queue depth.
The appropriate command queue depth is determined by the ETERNUS DX/AF model, as follows:
Model Setting value
Command queue depth
ETERNUS DX/AF Arbitrary (*1)
(Up to 1024 for each FC port of the ETERNUS DX/AF)
*1: Recommended value = 1024 ¸ (number of Fibre Channel ports that are connected to a single CA
port) ¸ number of LUNs
(Round the result down)
•Use the value of "8" if the actual result is lower.
•To achieve maximum system performance, this value can be changed according to the server
load and the peak operating times.
•The number of simultaneous command executions per CA port for the ETERNUS DX/AF is limited
to 1024. This value is used by multiple servers that share the CA port. A maximum of 1024 com-
mands can be executed per CA port.
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.3 Setting Up the Server
16
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

•For the ETERNUS DX/AF
The parameter to be specified for the command queue depth is determined by the CPU which is in-
stalled in the server to be connected.
-For SPARC
Specify the command queue depth for the "ssd_max_throttle" parameter.
Add this parameter if it does not exist.
Example:
set ssd:ssd_max_throttle = 20
-For x86
Specify the command queue depth for the "sd_max_throttle" parameter.
Add this parameter if it does not exist.
Example:
set sd:sd_max_throttle = 20
2After editing the configuration file, save it.
3After the setting is complete, check the configuration file for incorrect settings.
4Reboot the server.
# /usr/sbin/shutdown -y -g0 -i6
1.4 Setting Up the Server to Recognize the Logical Units
Make the server recognize the ETERNUS DX/AF logical units using the ssd driver.
If Oracle Fibre Channel cards are used, the logical unit recognition method will depend on the ETERNUS
DX/AF storage systems to server connection topology. There are two possible connection topologies: direct
connection and switch connection.
1.4.1 For Direct Connection
Confirm that the logical units have been correctly recognized by servers.
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.4 Setting Up the Server to Recognize the Logical Units
17
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

1Use the following command to confirm that the storage system has been correctly recognized.
# cfgadm -al
# cfgadm -al
Ap_Id Type Receptacle Occupant Condition
c4 fc-private connected configured unknown
c4::21ff00e000a8ffaf disk connected configured unknown
c5 fc-private connected configured unknown
c5::25ff00e000a8ffaf disk connected configured unknown
The underlined portion indicates that the ETERNUS DX/AF CA (WWN:25 ff00e000a8ffaf) is connected to
the Fibre Channel card port with controller number "c5".
2Use the following command to confirm that the storage system and all the logical units have been cor-
rectly recognized.
# format
# format
Searching for disks...done
c4t16d0: configured with capacity of 7.98GB
c4t16d1: configured with capacity of 7.98GB
c5t16d0: configured with capacity of 7.98GB
c5t16d1: configured with capacity of 7.98GB
AVAILABLE DISK SELECTIONS:
0. c1t0d0 <SUN36G cyl 24620 alt 2 hd 27 sec 107>
/pci@8,600000/SUNW,qlc@2/fp@0,0/ssd@w21000004cf6851ce,0
1. c4t16d0 <FUJITSU-ETERNUS_DX8000 cyl 1022 alt 2 hd 64 sec 256>
/pci@9,600000/SUNW,qlc@1/fp@0,0/ssd@w21ff00e000a8ffaf,0
2. c4t16d1 <FUJITSU-ETERNUS_DX8000 cyl 1022 alt 2 hd 64 sec 256>
/pci@9,600000/SUNW,qlc@1/fp@0,0/ssd@w21ff00e000a8ffaf,1
3. c5t16d0 <FUJITSU-ETERNUS_DX8000 cyl 1022 alt 2 hd 64 sec 256>
/pci@9,600000/SUNW,qlc@2/fp@0,0/ssd@w25ff00e000a8ffaf,0
4. c5t16d1 <FUJITSU-ETERNUS_DX8000 cyl 1022 alt 2 hd 64 sec 256>
/pci@9,600000/SUNW,qlc@2/fp@0,0/ssd@w25ff00e000a8ffaf,1
Specify disk (enter its number):
The underlined portion indicates that the ETERNUS DX8100/DX8400/DX8700 target ID=16, lun=0 and 1
are connected to physical path /pci@9,600000/SUNW,qlc@1, and that c4t16d0 and c4t16d1 are as-
signed to each of these LUNs.
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.4 Setting Up the Server to Recognize the Logical Units
18
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

1.4.2 For Switch Connection
Use the following commands to enable the server to access the logical units.
1Execute the following commands to check the path of the ETERNUS DX/AF to be connected.
# cfgadm -al
Example:
# cfgadm -al
Ap_Id Type Receptacle Occupant Condition
c4 fc-fabric connected unconfigured unknown
c4::21ff00e000a8ffaf disk connected unconfigured unknown
c5 fc-fabric connected unconfigured unknown
c5::25ff00e000a8ffaf disk connected unconfigured unknown
2Use the following command for each path obtained in Step 1.
Repeat this step for all paths to be used.
# cfgadm -c configure
The underlined portion indicates the path obtained in Step 1.
Example:
# cfgadm -c configure c4::21ff00e000a8ffaf
# cfgadm -c configure c5::25ff00e000a8ffaf
3Use the following command to confirm that the paths to the ETERNUS DX/AF are now usable.
"Occupant" status changes from "unconfigured" to "configured".
# cfgadm -al
# cfgadm -al
Ap_Id Type Receptacle Occupant Condition
c4 fc-fabric connected configured unknown
c4::21ff00e000a8ffaf disk connected configured unknown
c5 fc-fabric connected configured unknown
c5::25ff00e000a8ffaf disk connected configured unknown
The underlined portion indicates that the ETERNUS DX/AF CA (WWN:25ff00e000a8ffaf) is connected to
the Fibre Channel card port with controller number "c5".
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.4 Setting Up the Server to Recognize the Logical Units
19
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0

4Use the following command to confirm that the storage system and all the logical units have been cor-
rectly recognized.
# format
# format
Searching for disks...done
c4t16d0: configured with capacity of 7.98GB
c4t16d1: configured with capacity of 7.98GB
c5t16d0: configured with capacity of 7.98GB
c5t16d1: configured with capacity of 7.98GB
AVAILABLE DISK SELECTIONS:
0. c1t0d0 <SUN36G cyl 24620 alt 2 hd 27 sec 107>
/pci@8,600000/SUNW,qlc@2/fp@0,0/ssd@w21000004cf6851ce,0
1. c4t210000E000A8FFAFd0 <FUJITSU-ETERNUS_DX8000 cyl 1022 alt 2 hd 64 sec 256>
/pci@9,600000/SUNW,qlc@1/fp@0,0/ssd@w210000e000a8ffaf,0
2. c4t210000E000A8FFAFd1 <FUJITSU-ETERNUS_DX8000 cyl 1022 alt 2 hd 64 sec 256>
/pci@9,600000/SUNW,qlc@1/fp@0,0/ssd@w210000e000a8ffaf,1
3. c5t250000E000A8FFAFd0 <FUJITSU-ETERNUS_DX8000 cyl 1022 alt 2 hd 64 sec 256>
/pci@9,600000/SUNW,qlc@2/fp@0,0/ssd@w250000e000a8ffaf,0
4. c5t250000E000A8FFAFd1 <FUJITSU-ETERNUS_DX8000 cyl 1022 alt 2 hd 64 sec 256>
/pci@9,600000/SUNW,qlc@2/fp@0,0/ssd@w250000e000a8ffaf,1
Specify disk (enter its number):
The underlined portion indicates that the target ID=250000E000A8FFAF, lun=0 and 1 are connected
and that c5t250000E000A8FFAFd0 and c5t250000E000A8FFAFd1 are assigned to each of these LUNs.
1.5 Required Driver Parameters
1.5.1 Emulex OEM Fibre Channel Card Setup
If an Oracle driver for an Emulex OEM Fibre Channel card is used, the parameters of the "emlxs.conf" configu-
ration file needs to be edited using the "vi" command. Edit the file in accordance with the
"1.5.2 emlxs.conf Parameter List" (page 22).
•Solaris 11 OS
If the "/etc/driver/drv/emlxs.conf” file does not exist, copy the "/kernel/drv/emlxs.conf" file to the "/etc/driv-
er/drv" directory and edit the newly copied "emlxs.conf" file.
If the "/etc/driver/drv/emlxs.conf” file exists, do not copy over the file but instead edit the existing
"emlxs.conf" file.
•Solaris 10 OS
Edit the "/kernel/drv/emlxs.conf" file.
Chapter 1 Operations When Using Oracle Fibre Channel Cards
1.5 Required Driver Parameters
20
FUJITSU Storage ETERNUS DX, ETERNUS AF Configuration Guide -Server Connection- (Fibre Channel) for Oracle Solaris
Copyright 2017 FUJITSU LIMITED
P3AM-6312-18ENZ0
