Stagg Blaxx User manual

SPECIFICATIONS
D.I
FEATURES
- Input impedance: 1M ohms
- Output Impedance: 1K ohms
- Working current: 12 mA
- Power supply: 9 V AC adapter (negative tip)
- Dimensions: 95 x 45 x 48 mm
- Weight: 240 g (with box)
EMD Music - 11-2015
Pour obtenir ce mode d’emploi en français,
veuillez vous rendre sur www.staggmusic.com
Um die Gebrauchsanweisung in Deutsch zu erhalten,
gehen Sie bitte auf www.staggmusic.com
Deze handleiding is beschikbaar in het Nederlands op
www.staggmusic.com
Para obtener este modo de empleo en español,
vayan sobre www.staggmusic.com
Per ottenere questo manuale in italiano,
consultare www.staggmusic.com
- Stable and strong full aluminium alloy housing
- LED indicator shows the working status of the pedal

OPERATING INSTRUCTIONS
Thank you for purchasing our D.I Pedal.
Before operating this product, please
read the enclosed operating instructions.
1
2
4
5
3
8
7
6
1. CABINET SIMULATOR
Switch on to activate the cabinet simulator.
2. LED INDICATOR
Indicates the working status of the pedal.
3. GAIN SELECTOR
Allows to reduce or increase the signal.
4. INPUT
Connect the input of the effect pedal to your guitar or
another effect unit with the 6.3 mm audio plug.
5. GROUND LIFT
Switch on to cancel ground hum loops.
6. UNBALANCED OUT
Connect the INPUT of the D.I box to your guitar
amplifier or another effect unit with the 6.3 mm
audio plug.
7. BALANCED OUT
Connect the balanced output to your mixer.
8. AC ADAPTER JACK
DC 9 V regulated AC adapter (negative tip).
!
Use only the specified AC adapter and connect it to an
AC outlet of the correct voltage. Do not use any other
AC adapter since this may cause malfunction.
