Stam-F1 LT8
Owner’s Manual
Stam-F1 Laquered Tweed

IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol within an equilateral triangle is intended
to alert the user to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-
over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15) To completely disconnect this apparatus from the AC mains, disconnect the power supply
cord plug from the AC receptacle.
16) The mains plug of the power supply cord shall remain readily operable.
17) WARNING – To reduce the risk of fire or electric shock, do not expose this apparatus to rain
or moisture.
18) Do not expose this equipment to dripping or splashing and ensure that no objects filled with
liquids, such as vases, are placed on the equipment.
19) Maintain at least 6 inches (15.25 cm) of unobstructed air space behind the unit to allow for
proper ventilation and cooling of the unit.
20) CAUTION – For rack mounted power amplifiers, keep all wiring and materials away from
the sides of the unit and allow the unit to cool down for 2 minutes before pulling from a rack
enclosure.
21) Amplifiers and loudspeaker systems are capable of producing very high sound pressure levels
which may cause temporary or permanent hearing damage. Use care when setting and
adjusting volume levels during use.
22) FCC Part 15 Compliance Statement (for digital products, as applicable) - Part 15.21: Changes
or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment. NOTE: The manufacturer is not responsible for
any radio or TV interference caused by unauthorized modifications to this equipment. Such
modifications could void the user’s authority to operate the equipment.
23) WARNING – To maintain product safety, products with internal or external (battery pack)
batteries: tBatteries and/or the product in which they are installed, shall not be exposed to
excessive heat such as sunshine, fire or the like. tThere may be a danger of explosion if the
battery is incorrectly connected/replaced. Replace only with the same or equivalent type
battery specified in the instructions or on the product.
ENGLISH - PAGES . . . . . ......3-4

Features include:
tHand-wired all-tube circuitry onturret board with premium components throughout
t Late 1950s 5F1 circuit - produces about 7 Watts
tSingle“chicken head” volume control – work everythingfrom the guitar’s controls!
t8” Jensen®P8R speaker with Alnico magnet – for dynamic, sensitive response
tTube Amp Doctor™6V6GT output tube, 12AX7 preamp tube, and JJ™ 5Y3GT rectimer tube
tDisconnectable internal speaker - allows use ofexternal 4 Ohm speaker enclosure
tFinger-joined solid pine cabinet resonates with a warm, woody tone
tGenuinelacquered tweedcovering with vintage oxblood grille cloth and leather strap handle
tHand-built inApache Junction,Arizona, USA.
Limited Lifetime Warranty (Excludes Tubes and Speaker)
The Champ amp of the late 1950s is well known as the
small-but-mighty tone machine that belongs in every
serious guitarist’s collection. The tweed Champ is a terri c
practice amp, and has been a prized possession of countless
pro players for its great sounding, low output, easy-to-record
capabilities. Most people like to turn the amp’s volume all the
way up, and to manipulate the guitar’s controls for a variety
of sounds from pristine clean to swampy overdrive. It’s a
uniquely inspiring, complex reed-like voice.
This faithful recreation of the 1957 Champ amp is not just for
collectors or retro-minded guitarists. Any player seeking the
ultimate in low-powered, top-quality tube performance need
look no further!
A. FUSE ---Protects the unit from electrical faults.
B. POWER JEWEL --- Indicates when the ampli er is ON.
C. POWER / VOLUME --- loudness of the ampli er.
D. INPUT 1 --- Full sensitivity input for most guitars.
E.
output guitars with cleaner response.
NOTE: Both inputs become equal in sensitivity when used
simultaneously.
INPUT 2 --- Lower sensitivity input (-6db) to provide high-
3
Top Panel
Stam-F1 LT8 Amplifier
2 AMP OFF VOLUME ON INSTRUMENTS
t6QHSBEFPVUQVUQPXFSUPXBUUTCZTJNQMZTXBQQJOHSFDUJmFSBOEPVUQVUUVCFTà

TYPE: LT8
PART NUMBERS: STAMF1LT8US (120V~, 60Hz) STAMF1LT8TW (110V~, 60Hz) TW STAMF1LT8AUS (240V~, 50Hz) AUS
STAMF1LT8UK (230V~, 50Hz) UK STAMF1LT8ARG (220V~, 50Hz) ARG STAMF1LT8EUR (230V~, 50Hz) EUR
STAMF1LT8JPN (100V~, 50/60Hz) JPN STAMF1LT8ROK (220V~, 60Hz) ROK
POWER REQUIREMENT: 60W
INPUT IMPEDANCE: 1M
POWER AMP OUTPUT: 7W into 4 @ < 10% THD, 1kHz
SPEAKERS: One 4Ω, 8", Jensen with AlNico magnet, (P/N 8034028640063)
TUBES: One 5Y3GT, One 6V6GT, One 12AX7
FUSE: F2.0AL, 250V (100-120V versions) F1.0AL, 250V (220-240V versions)
DIMENSIONS: Height: 13.5 in (34.3 cm) Width: 12.5 in (31.8 cm) Depth: 7.8 in (19.8 cm)
WEIGHT: 16.5 lb (7.5 kg)
Product specifications are subject to change without notice.
F. POWER--- Connect to a grounded A/C outlet in
accordance with the voltage and frequency ratings speci ed on
the information label {J} of your ampli er.
G.
H.
minimum speaker load must always be connected at this jack
when the ampli er is ON to avoid damage to the ampli er.
I.
CAUTION: Tubes get hot!
Technical information about your
ampli er is listed here.
Your new Stam-F1 ampli er comes equipped with the highest
quality tubes available, sourced from various manufacturers all
over the world. Because of occasional irregularities in supply,
the speci c tube type used in each ampli er is subject to
change without notice.
When replacing output tubes, please note the speci c tube
markings on the original tubes factory supplied with your
ampli er. For example, 6L6 output tube types used by Stami
include, but are not limited to: 6L6GC; 6L6WXT; 6L6C; 6L6GE;
etc. The installation of a di erent type may require signi cant
adjustment by a quali ed technician to avoid reduction in
performance and tube life.
Additionally, TubeAmpDoctor™ sorts and tests many of our
output tubes, and labels them with plate current (PC) and trans-
conductance (TC). If your amp came supplied with, for example,
6L6WXT tubes, then a new set of 6L6WXT tubes with matching
PC/TC numbers will be the perfect direct replacement.
If you have questions or concerns, contact Stami’s Customs
Model Stam-F1 LT8 Ampli er
Tube locations left to right at rear:
12
AX
7
5
Y
3
GT
6
V
6
GT
Vacuum Tubes
4
Specifications
Rear Panel
Special Feature --- Upgraded power and output transformers
allow for 7 or 11 watt operation. Simply swap the 5Y3GT recti-
er and 6V6GT power tubes for a GZ34 rectier and 6L6WGC
power tubes and you are now operating @ 11 watts. This also
changes the tonal characteristics of the amp so try it out to see
which avor suits your playing style!
