Stanley SRP 6570 User manual

© 2015 Stanley Black & Decker, Inc.
New Britain, CT 06053
U.S.A.
75890 2/2016 Ver 3
USER MANUAL
Safety, Operation and Maintenance
SRP 6570
HYDROSTATIC
REVERSIBLE PLATE
SRP 6570

2 ► SRP 6570 User Manual
DECLARATION OF CONFORMITY
DECLARATION OF CONFORMITY
ÜBEREINSTIMMUNGS-ERKLARUNG
DECLARATION DE CONFORMITE CEE
DECLARACION DE CONFORMIDAD
DICHIARAZIONE DI CONFORMITA
Hydraulic Tools
______________________________________________________________________
I, the undersigned:
Ich, der Unterzeichnende:
Je soussigné:
El abajo firmante:
lo sottoscritto:
Weisbeck, Andy
Surname and First names/Familiennname und Vornamen/Nom et prénom/Nombre y apellido/Cognome e nome
hereby declare that the equipment specified hereunder:,bestätige hiermit, daß erklaren Produkt genannten Werk oder Gerät:,
déclare que l’équipement visé ci-dessous:,Por la presente declaro que el equipo se especifica a continuación:,
Dichiaro che le apparecchiature specificate di seguito:
1. Category: Compaction Reversable Plate
Kategorie:
Catégorie:
Categoria:
Categoria:
2. Make/Marke/Marque/Marca/Marca Stanley
3. Type/Typ/Type/Tipo/Tipo: SRP 65701D
4. Serial number of equipment:
Seriennummer des Geräts:
Numéro de série de l’équipement:
Numero de serie del equipo:
Matricola dell´attrezzatura:
All
5. Mass/Masse/Masse/Masa/Massa 491 kg / 1082.47 lb
Has been manufactured in conformity with, Wurde hergestellt in Übereinstimmung mit, Est fabriqué conformément
Ha sido fabricado de acuerdo con, E’ stata costruita in conformitá con
Directive/Standards
Richtlinie/Standards
Directives/Normes
Directriz/Los Normas
Direttiva/Norme
No.
Nr
Numéro
No
n.
Approved body
Prüfung durch
Organisme agréé
Aprobado
Collaudato
Machinery Directive
2006/42/EG
2006/42/EC
2006/42/CE
2000/14/EG
2000/14/EC
2000/14/CE
2005/88EG
2005/88/EC
2005/88/CE
2004/108/EG
2004/108/EC
2004/108/CE
Self
Self
Self
Self
Self
Self
Self
Self
Self
Self
Self
Self
Measurements:
Messungen
Mesures
Mediciones
Misurazioni
SRP 6570 Hatz
1D81 10.1 kW
107 dB
109 dB*
6. Special Provisions: Harmonized standards: 7. Measurements: Measured Sound Power Level
Spezielle Bestimmungen: EN 500-1; EN500-4 Messungen Guaranteed Sound Power Level*
Dispositions particulières: Mesures Annex VIII of 2000/14/EC
Provisiones especiales: Mediciones
Disposizioni speciali:Misurazioni
8. Representative in the Union: Patrick Vervier,Stanley Dubuis 17-19, rue Jules Berthonneau-BP 3406 41034 Blois Cedex, France.
Vertreter in der Union/Représentant dans l’union/Representante en la Union/Rappresentante presso l’Unione
Done at/Ort/Fait à/Dado en/Fatto a Stanley Hydraulic Tools, Milwaukie, Oregon USA Date/Datum/le/Fecha/Data 18-01-2013
Signature/Unterschrift/Signature/Firma/Firma
Position/Position/Fonction/Cargo/Posizione Director of Product Development

SRP 6570 User Manual ◄ 3
DECLARATION OF CONFORMITY ..........................................................................................................................2
TABLE OF CONTENTS.............................................................................................................................................3
SAFETY SYMBOLS ..................................................................................................................................................4
FORWORD................................................................................................................................................................5
SAFETY................................................................................................................................................................6 - 7
TECHNICAL DATA ...............................................................................................................................................8 - 9
OPERATION.....................................................................................................................................................10 - 14
TRANSPORT ..........................................................................................................................................................14
MAINTENANCE ...............................................................................................................................................15 - 20
BATTERY .........................................................................................................................................................21 - 22
TROUBLESHOOTING ............................................................................................................................................23
SERVICING: This manual contains safety, operation, and routine maintenance instructions. Stanley Hydraulic Tools
recommends that servicing this machine, other than routine maintenance, must be performed by an authorized and
certied dealer. Please read the following warning.
For the nearest authorized and certied dealer, call Stanley Hydraulic Tools at the number listed on the back of this
manual and ask for a Customer Service Representative.
WARNING
SERIOUS INJURY OR DEATH COULD RESULT FROM THE IMPROPER REPAIR OR
SERVICE OF THIS TOOL.
REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY AN
AUTHORIZED AND CERTIFIED DEALER.
TABLE OF CONTENTS
IMPORTANT
To ll out a Product Warranty Validation form, and for information on your warranty,
visit Stanleyhydraulics.com and select the Company tab, Warranty.
(NOTE: The warranty Validation record must be submitted to validate the warranty).

4 ► SRP 6570 User Manual
Always observe safety symbols. They are included for your safety and for the protection of the tool.
LOCAL SAFETY REGULATIONS
Enter any local safety regulations here. Keep these instructions in an area accessible to the operator and mainte-
nance personnel.
Safety symbols and signal words, as shown below, are used to emphasize all operator, maintenance and repair ac-
tions which, if not strictly followed, could result in a life-threatening situation, bodily injury or damage to equipment.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury
or death.
DANGER
This safety alert and signal word indicate an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
WARNING
This safety alert and signal word indicate a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION
This safety alert and signal word indicate a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION
This signal word indicates a potentially hazardous situation which, if not avoided,
may result in property damage.
NOTICE
This signal word indicates a situation which, if not avoided, will result in damage to
the equipment.
IMPORTANT
This signal word indicates a situation which, if not avoided, may result in damage
to the equipment.
SAFETY SYMBOLS

SRP 6570 User Manual ◄ 5
FOREWORD
PLEASE ENTER (DATA ON MACHINE TYPE PLATE)
1. MACH.-TYPE:
2. MACH.-NO.:
3. ENGINE-TYPE:
4. ENGINE-NO.:
Stanley Hydraulic Tools
3810 SE Naef Rd
Milwaukie, OR 97267
Ph: 503-659-5660
Fax: [phone]
www.stanleyhydraulics.com
These instructions include:
• Safety regulations
• Operating instructions
• Maintenance instructions
These instructions have been prepared for operation on the
construction site and for the maintenance engineer.
These instructions are intended to simplify operation of the
machine and to avoid malfunctions through improper opera-
tion.
Observing the maintenance instructions will increase the
reliability and service life of the machine when used on the
construction site and reduce repair costs and downtimes.
Always keep these instructions at the place of use of the ma-
chine.
Only operate the machine as instructed and follow these
instructions.
Do not fail to comply with all County and State safety provi-
sions, as well as the rules for safety and health.
Also observe the corresponding rules and regulations valid in
your country.
Stanley is not liable for the function of the machine when
used in an improper manner and for other than the intended
purpose.
Operating errors, improper maintenance and the use of incor-
rect operating materials are not covered by the warranty.
The above information does not extend the warranty and li-
ability conditions of business of Stanley.
We reserve us the right to make changes due to technical
development without announcement.

6 ► SRP 6570 User Manual
SAFETY
Safety information contained in the operating and
maintenance instructions
The following terms and symbols are used in this operating
manual that draw attention to important information:
Refers to special information and/or orders and
prohibitions directed towards preventing damage
Refers to orders and prohibitions designed to
prevent injury or extensive damage.
Refers to special information on how to use the machine
most efciently.
Attention
Danger
Important
This Stanley machine has been built according to the state of
the art in compliance with the pertinent rules. Nevertheless,
these machines can still constitute a hazard to persons and
property if:
• not used for the intended purpose,
• not operated by suitably qualied and instructed personnel,
• modied or converted in an improper manner,
• the pertinent safety regulations are not observed
For this reason, any person entrusted with the operation,
maintenance or repair of the machine is obliged to read and
follow the operating instructions and particularly to observe
the safety regulations. If necessary, it must be conrmed by
the signature of the company using the machine.
Furthermore, the following must be made known and observed:
• pertinent regulations for the prevention of accidents,
• generally recognized safety rules,
• country-specic regulations
Normal use
The machine is suitable for all compaction jobs in civil works and
road construction. All ground materials such as sand, gravel,
sludge, crushed stone, asphalt and composite sett paving can be
compacted.
Improper use
The machine can constitute hazards if not used by instructed
personnel or for other than the intended purpose.
Weighing down and riding on the machine is forbidden.
The machine must not be used on slopes with a gradient of more
than 25°.
Do not use the machine on hard concrete, set asphaltic surfaces,
highly frozen or unstable surfaces.
Who is allowed to operate the machine?
Only suitable qualied, instructed and authorised persons over 18
years of age may operate the machine.
In variance from this, minors can be employed, as long as it is
necessary to their training objective and their protection is assured
by a supervisor.
Persons under the inuence of alcohol, medication or drugs must
not operate, maintain or repair the machine.
Maintenance and repairs, in particular of hydraulic systems and
electronic components require special knowledge and must be
carried out only by skilled persons (mechanics specializing in
construction and agricultural machinery).
Conversions and modications to the machine
Unauthorized modications and conversion of the machine are not
permitted for safety reasons.
Spare parts and special equipment not delivered by Stanley are
also not approved by Stanley. The installation and/or the use of
such parts can also have a detrimental effect on the operating
safety.
The manufacturer disclaims all liability for any damage resulting
from the use of non-original parts or special equipment.
Transporting the machine
Always shut off the motor when loading and transporting.
Only load and transport the machine as specied in the operating
instructions.
Only use suitable means of transport and hoisting with sufcient
loading capacity! Attach suitable slinging means to the points of
attachment provided.
Secure the machine to prevent it from tilting or slipping.
It is highly dangerous to walk or stand under suspended loads.
Secure the machine on transport vehicles to prevent it from rolling,
slipping and tilting.
Starting the machine (Prior to starting)
Familiarise yourself with the operating and control elements and
the mode of operation of the machine and the working environ-
ment. This includes, e.g. obstacles in the working area, loading
capacity of the ground and the necessary safety provisions.
Use personal protective equipment (safety footwear, hearing
protectors, etc.). Check to ensure that all safety devices are rmly
in place. Do not start the machine if instruments or control devices
are faulty.
Starting
For machines with hand start, only use the safety cranks tested by
the manufacturer, and precisely follow the operating instructions of
the motor manufacturer.
To crank-start diesel motors; Important is the correct position to the
motor and the correct hand position on the crank.
The hand crank must be turned with maximum force until the motor
starts, otherwise the crank can rebound.
Precisely follow the starting and stopping procedures specied in
the operating instructions and observe indicator lights.
Only start and operate machines with an electrical starter from the
instrument panel. Starting and operation of the machine in poten-
tially explosives atmospheres is forbidden!
Starting with battery junction cables
Connect «positive» to «positive» and «negative» to «negative»
(earthing lead). Always connect the earthing lead last and discon-
nect rst! Incorrect connection will cause serious damage to the
electrical system.
Starting in enclosed spaces, tunnels, mines or deep ditches
Engine exhaust gas are highly dangerous!
For this reason, when operating the machine in enclosed spaces,
tunnels, mines or deep ditches, it is important to ensure that there
is sufcient air to breath (see UVV „Construction work“, VBG 37,
paragraphs 40 and 41).

SRP 6570 User Manual ◄ 7
SAFETY
Machine control
Operating devices which adjust themselves automatically when re-
leased in normal use, must not be locked.
Check protective devices and brakes for proper functioning prior
to operation.
When reversing, particularly on the edges and banks of ditches,
as well as in front of obstacles, the machine operator cannot fall or
be crushed.
Always keep a safe distance away from the edges and banks of
ditches and refrain from any actions which could cause the ma-
chine to topple over!
Always control the machine, so that hand injuries through hard
objects are avoided!
Always ascend slopes carefully in a direct path.
Reverse up steep slopes to prevent the machine from toppling over
on to the machine operator.
If faults on the safety devices or other faults detrimental to the safe
operation of the machine are noticed, operation of the machine
must be stopped immediately and the faults remedied.
When undertaking compaction work in the vicinity of buildings or
above pipelines and similar, check the effect of the vibrations on
the buildings and pipes and stop compaction work if necessary.
Parking the machine
Park the machine on a rm and level surface.
Shutdown the drive and secure it to prevent accidental movement
and unauthorized use. If available, close the fuel valve. Do not
place or store equipment with integrated moving gear on the
chassis. The moving device is intended only for transportation
purposes.
Filling Fuel
Only ll fuel by switched-off motor. No open re, do not smoke.
Do not spill any fuel, collect discharging fuel in a suitable
container, prevent fuel from seeking into the soil.
Ensure that the ller cap is tight.
Leaky fuel tanks constitute an explosion hazard and must
therefore be replaced immediately.
Maintenance and repairs
Observe the maintenance, inspection and adjustments and inter-
vals specied in the operating instructions, as well as the informa-
tion for part replacement.
Maintenance work must be undertaken only by qualied and
authorised persons.
Maintenance and repairs only by switched-off drive.
Only carry out maintenance and repairs when the machine is
parked on a rm and even surface and is secured to prevent it from
rolling.
When changing larger assemblies and individual components, only
use suitable and perfectly functioning hoisting and lifting gears with
suitable loading capacity. Attach and secure parts on hoisting care-
fully!
Spare parts must comply with the technical requirements of the
manufacturer. Therefore only use original spare parts.
Hydraulic lines must previously be rendered pressureless, before
working on them. Hydraulic oil discharging under pressure can
cause serious injuries.
Replace externally damaged hydraulic hoselines at regular inter-
vals (depending on time used), even when no safety-relevant faults
are visible.
Before working on the electrical system of the machine, discon-
nect the battery and insulate by covering or remove.
Inspect the electrical equipment of the machine at regular intervals.
Faults such as loose connections, worn or scorched cables must
be immediately eliminated.
During transport, secure the battery to prevent it from tilting, short-
circuit, slipping and damage.
Dispose of used batteries in a proper manner. Do not place any
tools on the battery.
Handling acid-batteries
Transport lled batteries upright to prevent acid spillage.
Keep away from sparks, open re and other sources of ignition.
Avoid contact of acid with skin and clothing. In case of contact,
wash off acid immediately with clear water and go to medical in-
stitution.
Properly ret and inspect all protective devices after maintenance
and repairs.
Disposal of the machine after nish of its service life
At disposal of the machine after nish of its service life, the owner
is obliged to comply with national regulations and laws on wastes
and protection of environment. Therefore we recommend in such
cases to contact the following:
• professional specialized companies engaged in such activities
and having the relevant certicate
• the manufacturers or contracting service organizations
authorized by him.
The manufacturer is not responsible for damages to health of own-
ers neither for damages to the environment in events of failing to
comply with above mentioned hygienic and ecological principles.
Testing
Road rollers, trench rollers and vibrating plates must be tested for
safety by an expert depending on the particular application and
operating conditions as required, however at least once a year.
Work on hydraulic devices must be undertaken only by persons
with a special knowledge of hydraulics and the necessary experi-
ence!
Do not adjust pressure relief valves.
Drain hydraulic oil at operating temperature—caution risk of
scalding!
Collect discharging hydraulic oil and dispose of the same in an
environmentally-friendly manner.
Do not start the motor when hydraulic oil has been drained off.
After completing all work (by pressureless system), inspect all
connections and bolted connections for leaks.
Inspect all hoses and bolted connections for leaks at regular
intervals and any externally visible damage! Rectify any damage
immediately.

8 ► SRP 6570 User Manual
TECHNICAL DATA
SRP 6570
1. DIMENSIONS
L 1840 MM (72.44 IN)
L1 930 MM (36.61 IN)
L2 470 MM (18.50 IN)
H 870 MM (34.25 IN)
H1 CA. 1000 MM (39.37 IN)
H2 CA. 1500 MM (59.06 IN)
WORKING WIDTH, BASE UNIT 550 MM (21.65 IN)
W. MOUNT. BRACKETS 75 / 150 MM 700 / 850 MM (21.56 / 33.46 IN)
2 WEIGHTS
BASIC UNIT
W. MOUNT. BRACKETS 75 MM
W. MOUNT. BRACKETS 150 MM
ELECTRICAL STARTER
ELECTR. DEAD MAN’S CONTROL
ACEecon
491 KG (1082.47 LB)
515 KG (1135.38 LB)
527 KG (1161.84 LB)
+ 18 KG (39.68 LB)
+ 19 KG (41.89 LB)
+ 18 KG (39.68 LB)
3. DRIVE
ENGINE HATZ 1D81 S
TYPE 1-CYL-4-STROKE DIESEL
POWER OUTPUT 10.1 KW (13.7 HP)
SPEED 3000 1/MIN
COOLING AIR
FUEL CAPACITY 7 L (1.85 GAL)
FUEL CONSUMPTION 2,5 L /H (0.66 GAL/H)
MAX. SLOPING POSITION 30°

SRP 6570 User Manual ◄ 9
TECHNICAL DATA
1) AS THE PERMISSIBLE RATING SOUND LEVEL OF 85 DB (A) CAN BE EXCEEDED BY THIS MACHINE, OPERATORS
MUST WEAR HEARING PROTECTORS.
SRP 6570
MAX. GRADE ABILITY 36%
DRIVE HYDRAULIC
CONTROL (FORWARD / REVERSE) HYDRAULIC
4. OPERATING SPEED
0 - 32 M/MIN (0 - 34.5 YD.)
5. VIBRATION
CENTRIFUGAL POWER 65 KN
VIBRATION FREQUENCY 55 HZ
6. SUPERFICIAL POWER
BASE UNIT 1056 m2/h (11366.69 ft2/h)
W. MOUNT. BRACKETS 75/150 MM 1344 (14466.7 ft2/h) / 1632 m2/h (17566.7 ft2/h)
7. SPECIAL EQUIPMENT
VULKOLLAN PLATES
EXTENSION PLATE 75 MM/3 IN.
EXTENSION PLATE 150 MM/6 IN.
HOUR METER
CONTROL SYSTEM
E STOP
DEAD MANS HANDLE
SEE PARTS MANUAL PAGE 5 (ITEM 7) ALSO
REQUIRES HARDWARE TO ATTACH.
STANDARD P/N-75972
O P/N-75973
STANDARD
O
O
O
O = Option / S = Serial / — = Not available
9. NOISE AND VIBRATION DATA
THE FOLLOWING NOISE AND VIBRATION DATA ACCORDING TO EC MACHINERY DIRECTIVE
IN THE VERSION (2006/42/EC), WAS DETERMINED, TAKING INTO ACCOUNT THE FOLLOWING
STANDARDS AND DIRECTIVES. IN OPERATIONAL USE, VALUES CAN DEVIATE DEPENDING ON
THE PREVAILING CONDITIONS.
9.1 NOISE DATA
THE NOISE DATA SPECIFIED IN APPENDIX 1, SUB-CLAUSE 1.7.4.U OF THE EC MACHINERY
DIRECTIVE IS FOR:
SOUND PRESSURE LEVEL AT THE
WORKPLACE LPA
95.0 dB
MEASURED SOUND POWER LEVEL
LWA,M
107 dB
GUARANTED SOUND POWER LEVEL
LWA,G
109 dB
THE NOISE VALUES WERE DETERMINED, TAKING INTO ACCOUNT THE FOLLOWING DIREC-
TIVES AND STANDARDS: DIRECTIVE 2000/14/EC / EN ISO 3744 / EN 500-4
9.2 VIBRATION DATA
HAND/ARM VIBRATION VALUES ACCORDING TO APPENDIX 1, SUB-CLAUSE 3.6.3.1 OF THE EC
MACHINERY DIRECTIVE:
TOTAL VIBRATION VALUE OF THE
ACCELERATION AHV
6.4 m/s² (6.99 yd/s²)
UNCERTAINTY K 1.0 m/s² (1.09 yd/s²)
THE ACCELERATION VALUE WAS DETERMINED, TAKING INTO ACCOUNT THE FOLLOWING
DIRECTIVES AND STANDARDS: EN 500-4 / DIN EN ISO 5349

10 ► SRP 6570 User Manual
OPERATION
Description
Danger
Operating control on the tow-bar
Overview of components
The SRP 6570 is a reversible vibrating plate operating on
the basis of the twin-shaft resp. three-shaft vibration system
principle. The Engine drives the exciter on the baseplate via
hydraulic components.
The exciter produces the vibration required for compaction
owing to the incorporated out-of-balance weights.
The machine is guided at the tow-bar grip. It is operated with
the operating controls on the tow-bar.
The SRP 6570 is suitable for all heavy compaction work in
the leds of civil Engineering and road construction.
It can be used to compact all ground materials such as sand,
gravel, slag, crushed stone, asphalt and composite sett
paving.
Take great care on downslopes. The machine
could slip down causing to loose material or if the
surface is slippery.
Do not work on hard concrete or set asphalt
surfacing.
1 BASEPLATE WITH EXCITER
2 ENGINE
3 CENTRAL-POINT SUSPENSION
4 TOW-BAR
5 OPERATING CONTROLS / TOW-BAR
1 Engine speed control lever
0 Engine stop
I Idle (detent position)
II Full load
The Engine speed can be adjusted with the control lever. At
minimum Engine speed (I), the drive to the exciter is discon-
nected at the centrifugal clutch and the Engine idles.
The centrifugal clutch engages when the control lever is
moved approximately ¼ of its adjustment travel.
The Engine speed should always be well below
or well above the engaging speed of the centrifu-
gal clutch, otherwise, the clutch linings will wear
very quickly or could even be destroyed.
Attention
2 Drive lever
a Forward
b Reverse
The drive lever serves to adjust the movements in the
exciter and therefore provides a stepless control:
• of the travel direction forwards (a) / backwards (b)
• of the speed
3 Emergency stop connection
The emergency stop switch serves to immediately stop the
machine in emergency situations.
Once the switch knob is pressed the power transmission is
interrupted and the machine itself stops though the Engine
continues to run.
Following the pressing of the switch during operation:
• The switch is released by withdrawing it (pull back out).
• Normal operation can then be immediately resumed. (The
travel direction and speed do not need to be reselected).
Important
Engine start is possible with the switch depressed.

SRP 6570 User Manual ◄ 11
OPERATION
Adjusting / Locking the tow-bar
Before Operation
Danger
Use personal protective equipment (in particular
hearing protectors and safety shoes). Observe all
safety conditions.
Observe the operation and maintenance instruc-
tions.
Read the engine operating instructions. Observe
the Importants on safety, operation and
maintenance contained in them.
• Stand the machine on an even surface.
• Check
• the engine oil level
• the hydraulic oil level
• the fuel supply
• that screw connections are secure
• the condition of the engine and the machine.
• Top-off any missing lubrication in accordance with the
lubrication table.
Attention
Adjusting the tow-bar
The two stops (1) on the tow-bar element can be adjusted
to any position in order to achieve the best working height
on the tow-bar grip.
Locking the tow-bar
The handle can be xed in upright (2) position.
The tow-bar lock makes it easier to handle the machine
when loading it.
To prevent deection, the tow-bar must not be
locked during normal operation.

12 ► SRP 6570 User Manual
• Set the engine speed lever to full load.
• Machines with emergency-stop-connection: Press
emergency-stop-connection.
• Insert the ignition key (1) and turn to «I»; the charge
indicator (2) lights up and a horn* (3) sounds.
• Turn the ignition key (1) to «II».
If the engine starts,
• release the ignition key (1) and
• set the engine speed lever to idle.
• Allow the engine to run for 1-2 minutes in order to
warm up.
OPERATION
Engine Operation
Warm up Instructions:
Important
Starting the Engine
Attention
The load indicator light (2) monitors the functioning
of the alternator. It illuminates when the engine is
stopped and in the ignition on (position «I») and
must go out when engine runs.
Only operate the starter with a stationary engine.
Do not operate the starter for more than 20 – 30
seconds.
Immediately release the ignition key when the
engine runs.
Wait for 30 seconds before trying again.
Never turn the key to the «0» position when the
engine is running. The regulator can be destroyed
and the battery will not charge !
Hand Start
Attention
Machines with electrical starter: Never hand
start with a disconnected battery, this leads to
immediate destruction of the regulator.
• Set the engine speed control lever to full load.
• Machines with emergency-stop-connection : Press
emergency-stop-connection.
• Machines with electrical start :Turn ignition key via
position I.
• Move the decompressor (1) lever until it stops in start
position.
• Insert the starting crank (2) and turn it with increasing
speed.
After starting of the engine,
• release ignition key.
• Set the speed lever to idle.
• Allow the engine to run for 2-3 minutes in order to
warm up.
• If misre ignition return the decompressor lever to its
initial position and repeat steps 1-5.

SRP 6570 User Manual ◄ 13
Important
Switching-Off the Engine
OPERATION
Attention
Danger
DO NOT SWITCH-OFF THE ENGINE WHILE UN-
DER FULL LOAD AND DO NOT USE THE DE-
COMPRESSOR LEVER.
• Allow the engine to run a short while on idling.
• Set the speed lever to stop. Additionally by electrostart:
• Turn the ignition key to «0» position. (The indicator lamps
should go out.)
The horn will sound if the ignition key is not re-
turned to the «0» position; a risk of total battery
discharge exists.
• Remove the key.
At the end of a working day or on a break protect
the key from unauthorised access.
Automatic engine cut-off
Machines are equipped with a safety engine cut-off.
The engine switches-off automatically if
• the oil pressure is too low
• the lubrication oil is unstable as a result of
• excessively high oil temperature
• incorrect baisc viscosity
• dilution of the oil by fuel or water
• the lubricating oil lter is blocked
• a leakage in the oil relief valve
• leakages in pipes and seals
• the oil pumps and bearings are worn.
If the oil level is too low or the machine is tilted
too much, it can lead to a mixture of air/oil and
thus to a loss of viscosity.
Attention
If the engine cuts-out because the supply of lubricating oil is
insufcient, proceed as follows :
• Locate the fault and have it rectied.
• Press the lever few seconds.
• Start the engine.
Air lter maintenance indicator
The motors are equipped with a maintenance indicator for
air lters. In case of pollution of the lter element the rubber
bellow contracts by underpressure.
In this case, switch-off the motor and clean or replace the
air-lter.

14 ► SRP 6570 User Manual
OPERATION / TRANSPORT
Attention
Important
Operation
Under adverse conditions start-up of the exciter
may be impeded. Then the engine cannot reach its
nominal RPM. This can be remedied by activating
the drive lever (2) several times.
Important
• Set the speed lever (1) in full load direction.
To avoid coupling damages, take care that the mo-
tor speed of the machine with centrifugal clutches are
clearly above or resp. below the starting speed (about
1200 rpm).
The motor has to be shut-off during long working
breaks; long idle time can cause motor damages.
• Adjust the drive direction and speed at the drive lever (2).
• Guide and steer the machine at the tow bar; during this
operation the operator should stand alongside the tow
bar for safety reasons until the machine is functioning
normaly.
For compaction of paving stones, it is recom-
mended to use Vulkollan plates and protective
brackets (special accessories) to prevent damag-
es to the compaction material and to the machine.
If the machine is used without protective bracket, the
threaded fastenings in the base plate must be sealed
with the supplied screw plugs .
Loading and Transportation
Danger
Only use sufciently strong and secure loading
ramps when loading.
Check the contact points (frame, lifting rings)
before use for damage and wear. Immediately
replace damaged parts.
Secure the machine against rolling or slipping off
and against tipping over.
Ensure that no persons will be endangered.
When loading, lashing down and lifting the
machine always use the provided lifting points.
Persons are in danger, if they:
• go near swinging loads or
• stand under swinging loads
After loading lock the tow bar.
After loading, the machine has to be attached in place (1).
Use the centre-of-gravity suspension point (2) in order to lift
the machine.

SRP 6570 User Manual ◄ 15
Maintenance:
increased service life
increased function
reduced downtimes
increased reliability
reduced repair costs
– Observe the safety regulations!
– Maintenance works should only be carried out when
the engine is shut off.
– The engine and machine should be cleaned thorougly
before carrying out maintenance work.
– Park the machine on a at surface and secure it against
rolling away and slipping.
– Ensure that operating materials and replaced parts are
disposed of safely and in an environmentally-friendly
way.
General Information
Maintenance Schedule
Maintenance-
Works
Intervals Daily 20 h 50 h 100 h 250 h 500 h 1000 h If
Necessary
Clean machine •
Check engine oil level 1)•
Change engine oil 1)• 3)•
Clean engine oil lter 1)• 3)
Check air lter 1)•
Change air lter element 1)• •
Check suction air intake 1)•
Check valve clearance 1)• 3)•
Drain water (Fuel tank 1)•
Change fuel lter 1)•
Check rubber buffers •
Exciter: Check oil level •
Exciter: Change oil ²) • 3)•
Check hydraulic oil level •
Change hydraulic oil ²) • 3)•
Change return lter element ²) • 3)•
Change ventilation lter ²) • 3)•
Clean suction lter ²) • 3)•
Check the hydraulic hose lines •
Check screwed connections for
tightness • 3)•
1)See engine operating manual
2)Minimum once a year
3)for the rst time
MAINTENANCE
– Before commencing work on any electrical equipment,
disconnect the battery and cover it with insulating
materials.
– Do not exchange «PLUS» and «MINUS» poles on the
battery.
– It is essential that short-circuits be prevented in cables
carrying current.
– Before welding work on the machine disconnect all
battery connections and cables.
– Burn-out lightbulbs in indicator lamps should be
replaced immediately.
– When cleaning the machine with a high-pressure water
jet, do not spray the electrical components directly.
– After cleaning the components, blow-dry them with
compressed air in order to prevent surface corrosion.

16 ► SRP 6570 User Manual
MAINTENANCE
Lubrication Schedule
Lubricating point Quantity (l) Changing intervals
[operating hours] Lubricant
1. Engine (incl. oil lter)
SRP 6570 1.8 l (1.9) / 0.47 (0.50)
GAL 250
Engine oil
API SG-CE
SAE 10W40
2. Exciter
SRP 6570 1.8 l / 0.47 GAL 250
or annually
Gear oil in acc.
with JDM J 20 C
3. Hydraulic
SRP 6570 2.0 l / 0.52 GAL
First time after 500,
then every 1000 or
annually
Hydro-Oil
HVLP 46
4. Return lter element
SRP 6570
First time after 20,
then with each hydr. oil
change
5. Ventilation lter
SRP 6570 with each hydr. oil
change
6. Clean suction lter
SRP 6570 with each hydr. oil
change
Alternative Lubrication Schedule

SRP 6570 User Manual ◄ 17
Maintenance Work on the engine
MAINTENANCE
Danger
Check the engine oil level
Environment
Attention
Attention
Attention
Only maintenance work which has to be performed
daily is included in the Operating Manual. Please
refer to the engine Operating Manual and to the
maintenance instructions and intervals listed
therein.
Overview
1 Fuel lling socket
2 Oil lling socket
3 Air lter maintenance indicator
4 Cooling air intake
5 Cooling air outlet
6 Oil outlet
7 Oil measuring dip
8 Oil lter
9 Fuel lter
10 Water outlet, fuel tank
11 Air lter
12 Suction orice - Combustion air
Filling-up with fuel
Only top-off fuel with the motor off.
No open re. Do not smoke.
Do not ll-up in closed rooms.
Do not inhale petrol fumes.
Collect spilt fuel in a suitable container and pre-
vent spillage entering the soil.
• Clean around the fuel ller socket (1).
• Open the fuel ller socket and
• Visually check the fuel level.
• Top-off if necessary. All diesel oils sold as fuel must
complying with the following minimum specication
can be used: EN 590 or DIN 51601 - DK or BS 2869
A1 / A2 or ASTM D 975 - 1D /2D
• Close the tank tightly.
Immediately replace damaged seals.
Collect old oil and dispose of it in an environment
friendly manner.
Do not permit oil to run onto the oor into the drains.
• Park the machine horizontally.
• Clean the area around the measuring dipstick.
• Draw out the measuring dipstick (7), wipe-off with clean,
lint free cloth.
• Insert measuring dipstick again until it stops.
• Draw out measuring dipstick again and check oil level.
• If necessary, rell oil to the upper marking.
• Clean area around ller socket.
• Open the ller socket (2).
• Fill-in required oil quantity.
• Secure oil lling socket.
• Insert measuring dipstick.
• Allow the motor to run for approx. 1 min. and check oil
level; repeat if necessary.
Check area around combustion air and cooling
air system
Check intake opening for combustion air and cooling air in-
takes. Remove coarse obstructions such as leaves, stones
and earth.
Draining off water (fuel tank)
The fuel tank must be checked once a week for accumala-
tions of water in order to prevent water from penetrating into
the sensitive injection system.
• Unscrew screw (10) to the last turn on the threads.
• Collect any drops which ow out into a clear container.
• Determine by visual inspection whether water is draining
out (water settles to the bottom of the container).
• As soon as fuel ows out, close and tighten the screw.
Cleaning the air lter element
• Remove air-cover
• Carefully pull out lter element.
• Use a jet of dry compressed air (max. 5 bar/70 psi) to blow
through the lter element from the inside outwards, moving it
up and down at the same time, until no further dust emerges.
• Tilt the lter element and hold it against the light (or shine
a light through it) to check for any cracks or other damage.
Change lter element if:
• The lter element or sealing ring is damaged
• After cleaning twice
• There are soot-containing deposits
• Moist or oily
• When engine performance reduces or
• The color of the exhaust gas changes
Never operate the engine without air lter element
• Clean the air cover and -housing with lintfree cloth.
• Carefully install the lter element.
• Install the cover.

18 ► SRP 6570 User Manual
Maintenance Machine
MAINTENANCE
Cleaning
Clean the machine thoroughly daily.
Attention
Tightening Torque
After cleaning
– all cables, hoses, connections and connectors are
to be checked for leakage, loose connections,
chang points and other damage.
– Detected faults are to be eliminated immediately.
No combustible or aggressive materials are to be
used for cleaning.
Strength classes for screws with untreated, non-lubricated
surface.
The values result in 90% utilisation of the apparent yielding
point at a friction coefcient µges= 0.14.
Tightening torques are checked for correctness using
torque wrenches.
When using lubricant MoS2, the specied values do not
apply.
Renew self-locking nuts after each removal.
Important
With vibrating machines, it is important to check all
screwed connections for tightness at regular intervals.
Observe tightening torques.
Screwed Connections
Changing rubber buffer
Inspect the rubber buffers for cracks and chipping as well as
tightness and immediately replace if damaged.
Exciter: Oil change / Oil level
Check / change exciter oil when its warm.
The venting screw (3) must always be unscrewed
rst when checking the oil level or changing the
oil.
Important
• Unscrew venting screw (3), oil lling plug (1) and oil drain
plug (2).
• Drain-off old oil.
Care is to be taken with the draining of hot oil
: danger of scalding!
Danger
Collect oil which has run out or overowed and
dispose it in an environment friendly manner.
Environment
• Screw-in oil drain screw (2).
• Fill-in new oil through the oil ll hole (1). See lubrication
plan for quantity and quality.
Attention
When the dipstick is screwed in, the optimal
oil level is between the «MIN» and «MAX»
markings.
• Replace oil lling plug (1) and venting screw (3).
• Unscrew oil lling plug (1), check the oil level again and
top off with oil if necessary.
• Replace oil ll plug/dipstick (1).

SRP 6570 User Manual ◄ 19
MAINTENANCE
Hydraulic Check the hydraulic oil level
Hydraulic Hose Lines
Before working on any hydraulic system or lines
make the system make sure the system or line
pressure has been released or discharged.
Carry out the change of hydraulic oil while it is still
warm in accordance to the lubrication plan and the
lubrication table.
Do not start the motor while the hydraulic oil is drain-
ing under any circumstance.
Immediately replace any damaged seals.
Change the return lter element and the air lter
with each change of hydraulic oil.
Change the hydraulic oil also after each major re-
pair on the hydraulic unit.
Collect the drained-off hydraulic oil and dispose it
in an environment friendly manner.
Attention
Environment
1 Serial No.
2 Manufacturer/Month and year of manufacture
3 Max. operating pressure
The function of hydraulic hose lines must be tested at reg-
ular intervals (minimum once a year) by an expert (with a
knowledge of hydraulics).
Hose lines must immediately be replaced in the following
instances:
• Damage to the outer layer to the inner lining (abrasion
marks, cracks, cuts, etc.).
• Brittleness of the outer layer (cracking of hose covering).
• Unnatural deformations of the hose line. This applies to
both a pressureless and pressurized condition (e.g. layer
separation, blister formation, crushed areas, kinks).
• Leaks.
• Damage or deformation of hose ttings (impaired sealing
function).
• Hose slips out of the tting.
• Corrosion of tting (degrading of function and strength).
• Improper installation.
• Use beyond the expiry date of max. 6 years.
• Check the oil level through the oil gauge glass.
• If necessary top off the oil level up to the upper area of the
glass.
If hydraulic oil is not visible through the guage
glass, the components, hoses and connections
need to be checked immediately for leaks.
Attention

20 ► SRP 6570 User Manual
MAINTENANCE
Changing the return lter element Hydraulic oil change
• Remove the lter cover (1) take care not to damage the
o-ring (2). Allow the oil in the lter housing to run through the
lter element (3) and into the tank.
• Lift the lter element out with a screwdriver and remove it
together with the lter head from the head section.
• Remove the lter element by turning and pulling it at the
same time from the lter head and dispose it in an environ-
ment friendly manner.
• Drain the remaining oil from the lter head into an old oil
container and dispose it in an environment friendly manner.
• Clean the lter head with washing petrol or diesel oil.
• Check the surface seal and O-ring (2) and if necessary
change them.
• Insert a new lter element in the lter head.
• Install the lter head with lter element into the head;
taking care not to damage the O-ring.
• Screw on the lter cover and tighten with hand, check that
the surface seal (2) is properly sealed.
• Take a test-run to ensure the lter is functioning properly.
Care is to be taken with the draining of hot oil :
danger of scalding !
Wear eye protection - danger of eye injury!
• Open the oil ll screw (2) and the oil drain screw, drain
off the oil and dispose it in an environment friendly
manner.
• Remove the cover (3).
• Remove the intake lter (4) in the tank by unscrewing it.
• Wash out the intake lter in cold cleaner or washing petrol
and blow out with compressed air.
• Thoroughly clean the hydraulic tank.
• Insert the clean intake lter.
• Carefully clean the seal and the seal surfaces.
• Install new sealing compound.
• Install the hydraulic tank cover
• Screw-in the oil drain screw, if necessary use a new seal.
• Replace the air lter (1) taking care with the O-ring.
• Add new oil, For oil quantity and type see the lubrication
chart.
• Screw in the oil ll screw and tighten (if necessary use a
new seal).
• Take a test run, check the oil level and if necessary top off.
Danger
