Stanley Fatmax SFMCPP32 User manual

WWW.STANLEY.COM SFMCPP32

B
Copyright STANLEY FATMAX
English (original instructions) 3

1
Fig. A
Fig. B Fig. C
7
8
8
7
XXXX XX XX
9
4
8
7
5
6
1
2
3
15

2
Fig.D Fig.E
Fig.F Fig.G
Fig.H
13
14
12
5
3
8
1
4
3
7
1
4
5
6
11
10 5

ENGLISH
3
DECLARATION OF CONFORMITY
THE SUPPLY OF MACHINERY SAFETY
REGULATIONS 2008
Pruner
SFMCPP32
STANLEY FATMAX declares that these products described under
Technical Data are in compliancewith:
The Supply of Machinery (Safety) Regulations, 2008, S.I.
2008/1597 (as amended), EN62841‑1:2015.
The Noise Emission in the Environment by Equipment for use
Outdoors Regulations 2001, S.I. 2001/1701 (as amended). Schedule 8.
LWA (measured sound power level) 74dB(A),
uncertainty (K) = 3.1 dB (A),
LWA (guaranteed sound power) 87dB(A).
These products conform to the following UK Regulations:
EC-Declaration of Conformity
Machinery Directive
o
Pruner
SFMCPP32
STANLEY FATMAX declares that these products described under
Technical Data are in compliance with:
2006/42/EC, EN62841‑1:2015.
2000/14/EC, Annex V.
LWA (measured sound power level) 74dB(A),
Uncertainty (K) = 3.1 dB (A),
LWA (guaranteed sound power) 87dB(A).
These products also comply with Directive 2014/30/EU and
2011/65/EU. For more information, please contact STANLEY
FATMAX at the following address or refer to the back of
themanual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf ofSTANLEY FATMAX.
Patrick Diepenbach
General Manager, Benelux
STANLEY FATMAX
Egide Walschaertsstraat 14‑18
2800 Mechelen, Belgium
12.29.2021
The vibration and/or noise emission level given in this
information sheet has been measured in accordance with
a standardised test given in EN62841 and may be used to
compare one tool with another. It may be used for a preliminary
assessment ofexposure.
WARNING: The declared vibration and/or noise emission
level represents the main applications of the tool. However
if the tool is used for different applications, with different
accessories or poorly maintained, the vibration and/or
noise emission may differ. This may significantly increase
the exposure level over the total workingperiod.
An estimation of the level of exposure to vibration and/
or noise should also take into account the times when the
tool is switched off or when it is running but not actually
doing the job. This may significantly reduce the exposure
level over the total workingperiod.
Identify additional safety measures to protect the
operator from the effects of vibration and/or noise such
as: maintain the tool and the accessories, keep the
hands warm (relevant for vibration), organisation of
workpatterns.
SFMCPP32
Voltage VDC 18
Type 1
Battery type Li‑Ion
Cut capacity mm 32
Weight (without battery pack) kg 1.3
Noise values and/or vibration values (triax vector sum) according to EN62841:
LPA (emission sound pressure level) dB(A) 64
K (uncertainty for the given sound level) dB(A) 3,0
LWA (sound power level) dB(A) 74
K (uncertainty of measured sound power level) dB(A) 3,1
LWA (guaranteed sound power level) dB(A) 87
Vibration emission value a
h
= m/s22,5
Uncertainty K = m/s21,5
Congratulations!
You have chosen a STANLEY FATMAX tool. Years of experience,
thorough product development and innovation make STANLEY
FATMAX one of the most reliable partners for consumer power
toolusers.
English (original instructions)
18V PRUNER
SFMCPP32

4
ENGLISH
The term “power tool” in the warnings refers to your
mains‑operated (corded) power tool or battery‑operated (cordless)
powertool.
Work Area Safety
a ) Keep work area clean and well lit. Cluttered or dark
areas inviteaccidents.
b ) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which
may ignite the dust orfumes.
c ) Keep children and bystanders away while operating
a power tool. Distractions can cause you to losecontrol.
Electrical Safety
a ) Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of
electricshock.
b ) Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if
your body is earthed orgrounded.
c ) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electricshock.
d ) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving
parts. Damaged or entangled cords increase the risk of
electricshock.
e ) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electricshock.
f ) If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
electricshock.
Personal Safety
a ) Stay alert, watch what you are doing and use
common sense when operating a power tool. Do not
use a power tool while you are tired or under the
influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in
serious personalinjury.
b ) Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask,
non‑skid safety shoes, hard hat or hearing protection used
for appropriate conditions will reduce personalinjuries.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings, instructions,
illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, fire and/or seriousinjury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTUREREFERENCE
aWARNING: To reduce the risk of injury, read the
instructionmanual.
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to
thesesymbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
seriousinjury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or
seriousinjury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or
moderateinjury.
NOTICE: Indicates a practice not related to
personal injury which, if not avoided, may result in
propertydamage.
Denotes risk of electricshock.
Denotes risk offire.
Electromagnetic Compatibility Regulations, 2016, S.I.2016/1091
(asamended).
The Restriction of the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment Regulations 2012, S.I.
2012/3032 (as amended).
For more information, please contact STANLEY FATMAX at the
following address or refer to the back of the manual.
The undersigned is responsible for compilation of the technical
file and makes this declaration on behalf of STANLEY FATMAX.
Paul Featherstone
Vice President Professional Power Tools EANZ GTS
STANLEY FATMAX UK, 270Bath Road, Slough
Berkshire, SL1 4DX
England
12.29.2021
Batteries
Chargers/Charge Times (Minutes)
Cat #
DC
Weight
*Date code 201811475B or later
**Date code 201536or later
Batteries Chargers/Charge Times (Minutes)
Cat # VDC Ah Weight (kg) SFMCB12
SFMCB202 18 2.0 0.4 X
SFMCB204 18 4.0 0.6 X
SFMCB206 18 6.0 0.9 X

5
ENGLISH
Residual Risks
In spite of the application of the relevant safety regulations
and the implementation of safety devices, certain residual risks
cannot be avoided. These are:
• Impairment ofhearing.
• Risk of personal injury due to flyingparticles.
• Risk of burns due to accessories becoming hot
duringoperation.
• Risk of personal injury due to prolongeduse.
SAVE THESE INSTRUCTIONS
h ) Keep handles and grasping surfaces dry, clean and
free from oil and grease. Slippery handles and grasping
surfaces do not allow for safe handling and control of the
tool in unexpectedsituations.
Battery Tool Use and Care
a ) Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used with
another batterypack.
b ) Use power tools only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury andfire.
c ) When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause burns
or afire.
d ) Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help. Liquid
ejected from the battery may cause irritation orburns.
e ) Do not use a battery pack or tool that is damaged
or modified. Damaged or modified batteries may exhibit
unpredictable behaviour resulting in fire, explosion or risk
ofinjury.
f ) Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or temperature
above 130°C may causeexplosion.
g ) Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
range specified in the instructions. Charging
improperly or at temperatures outside the specified range
may damage the battery and increase the risk offire.
Service
a ) Have your power tool serviced by a qualified repair
person using only identical replacement parts. This
will ensure that the safety of the power tool ismaintained.
b ) Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized serviceproviders.
c ) Prevent unintentional starting. Ensure the switch
is in the off‑position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on
invitesaccidents.
d ) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached
to a rotating part of the power tool may result in
personalinjury.
e ) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power tool
in unexpectedsituations.
f ) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be
caught in movingparts.
g ) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust‑relatedhazards.
h ) Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause severe
injury within a fraction of asecond.
Power Tool Use and Care
a ) Do not force the power tool. Use the correct power
tool for your application. The correct power tool
will do the job better and safer at the rate for which it
wasdesigned.
b ) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must berepaired.
c ) Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the
power toolaccidentally.
d ) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrainedusers.
e ) Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by
poorly maintained powertools.
f ) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less
likely to bind and are easier tocontrol.
g ) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations different
from those intended could result in a hazardoussituation.

6
ENGLISH
charger cavities. Always unplug the charger from the
power supply when there is no battery pack in the cavity.
Unplug charger before attempting toclean.
• DO NOT attempt to charge the battery pack with any
chargers other than the ones in this manual. The charger
and battery pack are specifically designed to worktogether.
• These chargers are not intended for any uses other than
charging STANLEY FATMAX rechargeable batteries.
Any other uses may result in risk of fire, electric shock
orelectrocution.
• Do not expose charger to rain orsnow.
• Pull by plug rather than cord when disconnecting charger.
This will reduce risk ofdamage to electric plug andcord.
• Make sure that cord is located so that it will not be
stepped on, tripped over, or otherwise subjected to
damage orstress.
• Do not use an extension cord unless it is absolutely
necessary. Use of improper extension cord could result in risk
of fire,electric shock, orelectrocution.
• Do not place any object on top of charger or place
the charger on a soft surface that might block the
ventilation slots and result in excessive internal heat.
Place the charger in a position away from any heat source. The
charger is ventilated through slots in the top and the bottom
of thehousing.
• Do not operate charger with damaged cord or plug—
have them replacedimmediately.
• Do not operate charger if it has received a sharp blow,
been dropped, or otherwise damaged in any way. Take it
to an authorised servicecentre.
• Do not disassemble charger; take it to an authorised service
centre when service or repair is required. Incorrect reassembly
may result in a risk of electric shock, electrocution orfire.
• In case of damaged power supply cord, the supply cord must
be replaced immediately by the manufacturer, its service agent
or similar qualified person to prevent anyhazard.
• Disconnect the charger from the outlet before attempting
any cleaning. This will reduce the risk of electric shock.
Removing the battery pack will not reduce thisrisk.
• NEVER attempt to connect two chargerstogether.
• The charger is designed to operate on standard
230V household electrical power. Do not attempt to
use it on any other voltage. This does not apply to the
vehicularcharger.
Charging a Battery (Fig.B)
1. Plug the charger into an appropriate outlet before inserting
batterypack.
2. Insert the battery pack 7 into the charger, making sure the
battery pack is fully seated in the charger. The red (charging)
light will blink repeatedly indicating that the charging
process hasstarted.
3. The completion of charge will be indicated by the red
light remaining ON continuously. The battery pack is fully
charged and may be used at this time or left in the charger.
Chargers
STANLEY FATMAX chargers require no adjustment and are
designed to be as easy as possible tooperate.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the battery pack voltage corresponds to the
voltage on the rating plate. Also make sure that the voltage of
your charger corresponds to that of yourmains.
iYour STANLEY FATMAX charger is double insulated
in accordance with EN60335; therefore no earth wire
isrequired.
If the supply cord is damaged, it must be replaced only by
STANLEY FATMAX or an authorised serviceorganisation.
Mains Plug Replacement
(U.K.& Ireland Only)
If a new mains plug needs to be fitted:
• Safely dispose of the oldplug.
• Connect the brown lead to the live terminal in theplug.
• Connect the blue lead to the neutralterminal.
WARNING: No connection is to be made to the
earthterminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 3A.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for the
power input of your charger (see Technical Data). The minimum
conductor size is 1mm2; the maximum length is30m.
When using a cable reel, always unwind the cablecompletely.
Important Safety Instructions for All BatteryChargers
SAVE THESE INSTRUCTIONS: This manual contains important
safety and operating instructions for compatible battery
chargers (refer to TechnicalData).
• Before using charger, read all instructions and cautionary
markings on charger, battery pack, and product using
batterypack.
WARNING: Shock hazard. Do not allow any liquid to get
inside charger. Electric shock mayresult.
WARNING: We recommend the use of a residual current
device with a residual current rating of 30mA orless.
CAUTION: Burn hazard. To reduce the risk of injury,
charge only STANLEY FATMAX rechargeable batteries.
Other types of batteries may burst causing personal injury
anddamage.
CAUTION: Children should be supervised to ensure that
they do not play with theappliance.
NOTICE: Under certain conditions, with the charger
plugged into the power supply, the exposed charging
contacts inside the charger can be shorted by foreign
material. Foreign materials of a conductive nature such
as, but not limited to, steel wool, aluminum foil or any
buildup of metallic particles should be kept away from

7
ENGLISH
The battery pack is not fully charged out of the carton. Before
using the battery pack and charger, read the safety instructions
below. Then follow charging proceduresoutlined.
READ ALL INSTRUCTIONS
• Do not charge or use battery in explosive atmospheres,
such as in the presence of flammable liquids, gases or
dust. Inserting or removing the battery from the charger may
ignite the dust orfumes.
• Never force battery pack into charger. Do not modify
battery pack in any way to fit into a non‑compatible
charger as battery pack may rupture causing serious
personalinjury.
• Charge the battery packs only in STANLEY FATMAX chargers.
• DO NOT splash or immerse in water or otherliquids.
• Do not store or use the tool and battery pack in locations
where the temperature may fall below 4˚C (39.2˚F)
(such as outside sheds or metal buildings in winter), or
reach or exceed 40˚C (104˚F) (such as outside sheds or
metal buildings insummer).
• Do not incinerate the battery pack even if it is severely
damaged or is completely worn out. The battery pack can
explode in a fire. Toxic fumes and materials are created when
lithium‑ion battery packs areburned.
• If battery contents come into contact with the skin,
immediately wash area with mild soap and water. If
battery liquid gets into the eye, rinse water over the open eye
for 15minutes or until irritation ceases. If medical attention
is needed, the battery electrolyte is composed of a mixture of
liquid organic carbonates and lithiumsalts.
• Contents of opened battery cells may cause respiratory
irritation. Provide fresh air. If symptoms persists, seek
medicalattention.
WARNING: Burn hazard. Battery liquid may be
flammable if exposed to spark orflame.
WARNING: Never attempt to open the battery pack for
any reason. If battery pack case is cracked or damaged,
do not insert into charger. Do not crush, drop or damage
battery pack. Do not use a battery pack or charger that
has received a sharp blow, been dropped, run over or
damaged in any way (i.e., pierced with a nail, hit with
a hammer, stepped on). Electric shock or electrocution
may result. Damaged battery packs should be returned to
service centre forrecycling.
WARNING: Fire hazard. Do not store or carry the
battery pack so that metal objects can contact
exposed battery terminals. For example, do not place
the battery pack in aprons, pockets, tool boxes, product kit
boxes, drawers, etc., with loose nails, screws, keys,etc.
CAUTION: When not in use, place tool on its side on
a stable surface where it will not cause a tripping
or falling hazard. Some tools with large battery packs
will stand upright on the battery pack but may be easily
knockedover.
Battery Packs
Important Safety Instructions for All
BatteryPacks
When ordering replacement battery packs, be sure to include
catalogue number andvoltage.
To remove the battery pack from the charger, push the
battery release button 8 on the batterypack.
NOTE: To ensure maximum performance and life of lithium‑ion
battery packs, charge the battery pack fully before firstuse.
Charger Operation
Refer to the indicators below for the charge status of the
batterypack.
Charge Indicators
FCharging I
GFully Charged J
HHot/Cold Pack Delay* K
*The red light will continue to blink, but a yellow indicator light
will be illuminated during this operation. Once the battery pack
has reached an appropriate temperature, the yellow light will
turn off and the charger will resume the chargingprocedure.
The compatible charger(s) will not charge a faulty battery pack.
The charger will indicate faulty battery by refusing tolight.
NOTE: This could also mean a problem with acharger.
If the charger indicates a problem, take the charger and battery
pack to be tested at an authorised servicecentre.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot or too
cold, it automatically starts a Hot/Cold Pack Delay, suspending
charging until the battery pack has reached an appropriate
temperature. The charger then automatically switches to the pack
charging mode. This feature ensures maximum battery packlife.
A cold battery pack will charge at a slower rate than a warm
battery pack. The battery pack will charge at that slower rate
throughout the entire charging cycle and will not return to
maximum charge rate even if the battery packwarms.
Electronic Protection System
Li‑Ion tools are designed with an Electronic Protection
System that will protect the battery pack against overloading,
overheating or deepdischarge.
The tool will automatically turn off if the Electronic Protection
System engages. If this occurs, place the lithium‑ion battery
pack on the charger until it is fullycharged.
Charger Cleaning Instructions
WARNING: Shock hazard. Disconnect the charger
from the AC outlet before cleaning. Dirt and grease
may be removed from the exterior of the charger using a
cloth or soft non‑metallic brush. Do not use water or any
cleaning solutions. Never let any liquid get inside the tool;
never immerse any part of the tool into aliquid.

8
ENGLISH
Markings on Tool
The following pictograms are shown on the tool:
a Read instruction manual beforeuse.
Package Contents
The package contains:
1 Pruner
1 Instruction manual
1 18V 4Ah Battery pack (SFMCB204) M1 version only
1 2A Charger (SFMCB12) M1 version only
NOTE: Battery packs, and chargers are not included with Bmodels.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Battery Type
The following tools operate on a 18 volt battery pack: SFMCPP32
These battery packs may be used: SFMCB202, SFMCB204,
SFMCB206. Refer to Technical Data for moreinformation.
LRead instruction manual beforeuse.
p See Technical Data for chargingtime.
q Do not probe with conductiveobjects.
r Do not charge damaged batterypacks.
s Do not expose towater.
t Have defective cords replacedimmediately
u Charge only between 4˚C and 40˚C.
v Only for indooruse.
x Discard the battery pack with due care for
theenvironment.
y Charge STANLEY FATMAX battery packs only with
designated STANLEY FATMAX chargers. Charging
battery packs other than the designated STANLEY
FATMAX batteries with a STANLEY FATMAX
charger may make them burst or lead to other
dangeroussituations.
z Do not incinerate the batterypack.
Transportation
WARNING: Fire hazard. Transporting batteries can
possibly cause fire if the battery terminals inadvertently
come in contact with conductive materials. When
transporting batteries, make sure that the battery
terminals are protected and well insulated from
materials that could contact them and cause a short
circuit. NOTE: Lithium‑ion batteries should not be put in
checkedbaggage.
STANLEY FATMAX batteries comply with all applicable shipping
regulations as prescribed by industry and legal standards which
include UN Recommendations on the Transport of Dangerous
Goods; International Air Transport Association (IATA) Dangerous
Goods Regulations, International Maritime Dangerous Goods
(IMDG) Regulations, and the European Agreement Concerning
The International Carriage of Dangerous Goods by Road
(ADR). Lithium‑ion cells and batteries have been tested to
section 38.3of the UN Recommendations on the Transport of
Dangerous Goods Manual of Tests andCriteria.
In most instances, shipping a STANLEY FATMAX battery pack
will be excepted from being classified as a fully regulated Class
9Hazardous Material. In general, only shipments containing a
lithium‑ion battery with an energy rating greater than 100Watt
Hours (Wh) will require being shipped as fully regulated Class 9.
All lithium‑ion batteries have the Watt Hour rating marked on
the pack. Furthermore, due to regulation complexities, STANLEY
FATMAX does not recommend air shipping lithium‑ion battery
packs alone regardless of Watt Hour rating. Shipments of tools
with batteries (combo kits) can be air shipped as excepted if the
Watt Hour rating of the battery pack is no greater than 100Wh.
Regardless of whether a shipment is considered excepted
or fully regulated, it is the shipper's responsibility to consult
the latest regulations for packaging, labeling/marking and
documentationrequirements.
The information provided in this section of the manual is
provided in good faith and believed to be accurate at the time
the document was created. However, no warranty, expressed or
implied, is given. It is the buyer’s responsibility to ensure that its
activities comply with the applicableregulations.
Storage Recommendations
1. The best storage place is one that is cool and dry away
from direct sunlight and excess heat or cold. For optimum
battery performance and life, store battery packs at room
temperature when not inuse.
2. For long storage, it is recommended to store a fully charged
battery pack in a cool, dry place out of the charger for
optimalresults.
NOTE: Battery packs should not be stored completely
depleted of charge. The battery pack will need to be recharged
beforeuse.
Labels on Charger and Battery Pack
In addition to the pictographs used in this manual, the
labels on the charger and the battery pack may show the
followingpictographs:

9
ENGLISH
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and
applicableregulations.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
Inserting and Removing the Battery Pack
from the Tool (Fig.C)
NOTE: Make sure your battery pack 7 is fullycharged.
To Install the Battery Pack into the Tool Handle
1. Align the battery pack with the rails inside the tool’s
handle(Fig. C).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap intoplace.
To Remove the Battery Pack from the Tool
1. Press the battery release button 8 and firmly pull the
battery pack out of the toolhandle.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig.B)
Some STANLEY FATMAX battery packs include a fuel gauge
which consists of three green LED lights that indicate the level
of charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button15. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end‑userapplication.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
WARNING: Use only STANLEY FATMAX battery packs
andchargers.
Description (Fig.A)
WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1 Trigger switch
2 Lock‑off button
3 Lock‑off switch
4 Main handle
5 Cutting blade
6 Fixed blade
7 Battery
8 Battery release button
Intended Use
Your STANLEY FATMAX, SFMCPP32 pruner has been designed
for professional landscapingapplications. This pruner is
intended to be used on plant materialsonly.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This pruner is a professional powertool.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
Date Code Position (Fig.A)
The date code 9, which also includes the year of manufacture,
is printed into thehousing.
Example:
2022XX XX
Year and Week of Manufacture
f Wear eyeprotection.
Do not expose the tool to rain or high humidity or
leave outdoors while it israining.
Keep handsaway.
Cutter continues to run after the motor is switched off
Thrown objects can causeinjury.
Keep bystandersaway.
Switch the tool off. Before performing any maintenance
on the tool, remove the battery from thetool.
Directive 2000/14/EC guaranteed soundpower.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.

10
ENGLISH
Removing and Installing Blade (Fig. A, F, G)
DANGER: RISK OF INJURY. WHEN REASSEMBLING THE
BLADE SYSTEM, ENSURE EACH PART IS REINSTALLED
CORRECTLY, AS DESCRIBED BELOW. IMPROPER ASSEMBLY
OF THE BLADE OR OTHER PARTS OF THE BLADE SYSTEM
CAN CAUSE SERIOUSINJURY.
DANGER: To reduce the risk of serious personal
injury, turn unit off, remove battery pack before
making any adjustments or removing/installing
attachments or accessories. An accidental start‑up can
causeserious personalinjury.
WARNING: Use gloves and proper eye protection. Be
careful of the sharp edges on theblade.
Replacement blades are available from your nearest
authorised servicecentre. This pruner requires replacement
blade SFMCPPRB1.
1. Remove thebattery.
2. Wear proper eye protection and gloves and be careful not
to cutyourself.
3. Place the product on a smooth, levelsurface.
4. Remove the nut cap11 by turning itcounterclockwise.
NOTE: If the nut cap is difficult to remove, a 5mm hex
wrench (not included) can be used to removeit.
5. Slide out the blade cover10.
6. Remove the cutting blade5 as shown in Fig.G.
7. Install the new cuttingblade.
NOTE: Ensure the cutting edge faces toward the fixed
cutting blade as shown in Fig.G.
8. Reinstall the bladecover.
9. Screw the nut cap back in clockwise, making sure it issecure.
MAINTENANCE
Your power tool has been designed to operate over a long
period of time with a minimum of maintenance. Continuous
satisfactory operation depends upon proper tool care and
regularcleaning.
WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
The charger and battery pack are notserviceable.
Pruning Instructions (Fig.A, E)
DANGER: Keep hands and other body parts away from
the blade. Contact with the blade will result in serious
personalinjury.
WARNING: To guard against injury, observe
thefollowing:
• Read instruction manual before using. Save
instructionmanual.
• Check the shrub for foreign objects such as wires or
fences before eachuse.
• Keep hand on firmly on tool and other hand far away
from cutting action. Don'toverreach.
• Do not use under wetconditions.
CAUTION: Do not use blade to cut branches greater than
25mm. Use the pruner only for cutting normal shrubbery
around houses andbuildings.
Working Position (Fig.D, E)
Maintain proper footing and balance and do not overreach.
Wear safety goggles, non‑skid footwear and gloves when
pruning. Hold the tool firmly. Always hold the pruner, as shown
in Fig. D, E. Refer to Proper Hand Position for more information.
Never hold the tool by theblades.
Switching On (Fig.A, D, E)
DANGER: Keep hands and other body parts: away from
the blade. Contact with the blade will result in serious
personalinjury laceration and amputationhazard.
WARNING: Never attempt to lock a switch in the
ONposition.
1. Keeping your hands and other body parts away from the
blade, push the lock‑off button2 down and squeeze the
lock‑off switch3 then squeeze the trigger switch1.
2. The cutting blade5 will make a cut cycle. Once this cycle is
complete you must release the trigger switch1.
3. To make repeated cuts, squeeze the trigger switch1again
while continuing to hold down lock off switch3.
4. To turn the tool off, release the trigger switch1 and the
lock‑off switch3.
NOTE: In order to keep the unit powered on, you must
continue to squeeze the lock‑off switch3. If held too long
the tool will time out and will need to release switches and
startagain.
NOTE: If the lock‑off button2 or lock‑off switch3 are
unintentionally depressed without squeezing the trigger
switch1, the tool will poweroff.
Proper Hand Position (Fig.D, E)
WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.
WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Proper hand position requires one hand on the main handle4.
Keep other hand far from the cuttingaction.
1. Position the branch to be cut between the cutting
blade5 and fixed blade6.
2. Push the lock‑off button2 down and squeeze the lock‑off
switch3 then squeeze the trigger switch1.
3. The cutting blade5 will make a cut cycle and cut the
branchoff.
NOTE: Cut branches at an angle for a cleanercut.
4. Release the triggerswitch.
NOTE: If more branches need to be cut, at the same time,
the lock‑off switch3 can be held down and actuate the
trigger switch1 as needed. Otherwise, repeat steps 1‑4.

11
ENGLISH
Protecting the Environment
wSeparate collection. Products and batteries marked
with this symbol must not be disposed of with
normal householdwaste.
Products and batteries contain materials that can be
recovered or recycled reducing the demand for raw materials.
Please recycle electrical products and batteries according to local
provisions. Further information is available at www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails to produce
sufficient power on jobs which were easily done before. At the end
of its technical life, discard it with due care for ourenvironment:
• Run the battery pack down completely, then remove it from
thetool.
• Li‑Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed ofproperly.
Optional Accessories
WARNING: Since accessories, other than those offered
by STANLEY FATMAX, have not been tested with this
product, use of such accessories with this tool could be
hazardous. To reduce the risk of injury, only STANLEY
FATMAX recommended accessories should be used with
thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
D
Cleaning
WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.
WARNING: Never use solvents or other harsh chemicals
for cleaning the non‑metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
C
Lubrication
Your power tool requires no additionallubrication.
Blade Maintenance (Fig.H)
WARNING: Use gloves and proper eye protection while
removing, sharpening, and installingblade.
The cutting blades are made from high quality, hardened steel
and with normal usage, they will not require resharpening.
However, if you accidentally hit a wire fence, stones, glass, or
other hard objects, you may put a nick in the blade. There is no
need to remove this nick as long as it does not interfere with the
movement of the blade. If you drop the trimmer, carefully inspect
it for damage. If the blade is bent, housing cracked, handles
broken or if you see any other condition that may affect the tool's
operation contact your local authorised service centre for repairs
before putting it back intouse.
1. Remove thebattery.
2. Remove blade from pruner. See instructions for Removing
and InstallingBlade.
3. Wear proper eye protection and gloves and be careful not
to cutyourself.
4. Secure blade5 in a vise14 as shown in Fig.H.
5. Carefully file the cutting edge12 of the cutting blade with
a fine tooth file13 (not included) or sharpening stone (not
included), maintaining the angle of the original cuttingedge
of the cuttingblade.
6. Inspect the edge of the fixed blade and remove any burrs
with a fine toothfile.
7. Install sharpened cutting blade as described in the
Removing and InstallingBladesection.
Blade Lubrication (Fig.A)
1. After use, remove thebattery7.
2. Carefully apply a resin solvent to the exposedblades.
Storage (Fig.A)
WARNING: Keep your hands away from theblade.
1. After use, remove thebattery.
2. Store in a dry location, away from the reach ofchildren.

NA190611 4/22
United Kingdom
Stanley Fat Max Tel. [phone]
270 Bath Road Fax [phone]
Slough, Berkshire SL1 4DX www.stanleytools.co.uk
