DIGITAL CAMERA
+ WEB SERVER
= NETCAM
•Cost Effective Remote Imaging
•ExcellentTool forManagement,
Construction, Tourism, Marketing, Web
Site Traffic Building, Security
•IP-Addressable, Built-in Web Server,
Requires No PC to Operate!
•Connects Directly to LAN, Cable, DSL,
Wireless or Modem (with ISPAccount)
•Excellent Digital Image Quality, Up to
1280x960 Resolution (NetCam MP)
•View and Configure with any Graphical
Web Browser, No Plug-Ins Required
•AutomaticallyArchives on Remote Server
•Outdoor Enclosures and Wide Selection
of Lenses Available
•Easy to Use, Turnkey Solution
•Compatible with StarDot DVR security
recording software
netcam
IP-Addressable Camera with
Integrated Web Server Offers
Highest Quality Live Images
The StarDotTechnologiesNetCamis both a high
quality digital camera and a powerful web server,
all in one small package. NetCammakes it easy to
viewhighqualitylivedigitalimagesfromanywhere
inthe world via theInternet...onlya web browser is
required. Regardless of what type of computer you
ownandwhat type of Internetconnectionyouhave,
NetCam can provide you or the world with high
resolution live images.
Digital Internet Camera with Integrated Web Server
For more information, call us at 1-888-STARDOT
(888-782-7368) or visit us at www.stardot-tech.com

Software and Web Server
Built Into NetCam
Excellent Digital Image
Quality up to 640x480 NetCam Specifications
Imaging
• NetCam = Sharp 1/3” CCD sensor, 640x480 RGB, Frame Transfer
• NetCam MP = Sony 1/2” CCD sensor, 1280x960 RGB, Frame Transfer
• Exposure range: 1/100,000 second - 1.3 seconds
• Auto/manual exposure, auto/manual color balance, sharpening
• Contrast enhancement, gamma correction
• Customizable date/time/text overlay
• Image format: JPEG, adjustable quality / filesize
• Transfer Speed: 320x240 (LAN, 1 second; modem, 5-10 seconds)
640x480 (LAN, 4 seconds; modem, 8-20 seconds)
1280x960* (LAN, 7 seconds; modem, 15-40 seconds)
(*1280x960 resolution only available on NetCam MP model)
• Lens: 8mm C-Mount with manual iris and focus rings
• Lens Mount: Industry standard CS-Mount, includes C-Mount adapter
Operating System / CPU
• uClinux operating system
•MotorolaColdfireCPU
• Built-in web server, telnet server and FTP client
•Supported protocols:TCP/IP, HTTP, FTP,ARP,Telnet, Daytime
• 16MB DRAM, 2MB Flash Memory
• Security: Password-protected user accounts for viewing and configuring NetCam
Connectivity
• 1 x 10-baseT Ethernet, RJ-45
• 2 x RS-232 Serial Ports, DB9 Male, up to 115.2Kb
• 4 x digital alarm inputs or 4 x 5V swing output pins
• 1 x fully isolated relay rated at 28VDC 2A or 125VDC 0.5A
Physical
• Dimensions: 3.25” W (82.5mm) x 2.20” H (55.9mm) x 6.56” L (166.6mm)
Included lens adds 1.1” (27.9mm) to length, Included (removable) ¼” tripod mount
adds 0.4” (10.1mm) to height
• Weight: 19.5 ounces (553 grams)
• Case: Aluminum clam shell body, argentan alloy front cover
• Mounting: Universal ¼” tripod mount, top or bottom of camera
• Operating temperature range: -40° - +120° F (-40° - +48° C)
• Power Requirements: 8VDC-15VDC, 500mA @ 12V, 12VDC power supply included
• EMI Approval: FCC, Class A
Built-in Ethernet Port - Plug
NetCam directly to LAN, Cable
Modem or DSL network
Two Serial Ports - Connect NetCam to
analog or wireless modem, or accessories
like weather station & automation controller
Aux and I/O Ports - Connect
to alarm system and
motorized zoom lens
Power Jack - Includes single
cable for both power and
data -- great for rooftop,
ceiling and remote installations
Contents Include:
• NetCamCamerawith Integrated WebServer
• 8mm C-Mount Lens with Manual Iris/Focus
• 50ft. Combination Power/NetworkCable
• Power Supply (12VDC, 1A)
• Indoor Wall Mount
• Dial-Out Package Includes External Modem
• Easy-to-Use StarDot Tools Setup Software
These are actual NetCam customer images.
They have not been modified or enhanced
in any way.
© Copyright 2003 StarDot Technologies, Information Subject to Change
6820-H Orangethorpe Ave, Buena Park, CA 90620
714.228.9282 • 714.228.9283 fax • 888-STARDOT
