StarEcho PT0570A2S-1 User manual
Assembly Instructions
Item Number: PT0570A2S-1/2
Thank you for your purchase!
We are pleased that you have chosen StarEcho for your outdoor gazebo purchase.
We hope that you enjoy the unmatched quality, comfort, and style of your new patio
item. Every piece is meticulously considered all the way down to the smallest details,
exclusively for you, by our world class design team. We know you have a choice when
it comes to your patio gazebo needs, so from our team to yours, thank you for letting
us be a part of your outdoors.
Made in China
SAFE INFORMATIONS
WARNING:
When assembling and using this product, basic safety precautions should always be
followed to reduce the risk of personal injury and damage to equipment. Please read all
instructions before assembly and usage.
Some parts may contain sharp edges, wear protective gloves if necessary.
This unit is heavy! Do not assemble this item alone. At least two or more people are
recommended for safe assembly.
Keep all children and pets away from assembly area.
Begin assembly not less than 6feet from any obstruction such as fence, garage, house,
overhanging branches, laundry line or electrical wires.
Install on level ground. This gazebo cannot be permanently staked or attached to
concrete floor or platform. The provided stakes are for soft ground use only. If
assembling on ahard surface like adeck or concrete, other forms of attachment must
be used such as expansion bolts that can be purchased locally.
This gazebo is intended for decorative and sunshade purposes only and is not meant to
withstand inclement weather including high winds, rain and snow. Gazebo fabric is
water resistant, not water proof and may leak during exposure to precipitation.
Please lay out all parts before assembling, checking to make sure all parts are there. If
expedited to you.
Do not leave the gazebo where there is arisk of high wind, as possible damage will
occur to the structure. Remove all excess snow from the roof.
Do not climb on top of the gazebo. Falling off the gazebo can result in serious injury.
KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS GAZEBO FABRIC. This Gazebo
is made with fabric that meets CPAI-84specifications for flame resistance. It is not fire
proof. The fabric will burn if left in continuous contact with any flame source. The
application of any foreign substance to the gazebo fabric may render the flame-
resistant properties ineffective.
Parts Name Item No.
Top Leg Post
A1
Lower Leg
Post
A2
Across
Beam 1
C1
Across
Beam 2
C2
Upper Slant
Bar
G1
Lower Slant
Bar
G2
I1
I2
Parts Images
Qty.
4
4
4
4
4
4
4
4
io
。口门汇
2
People
Parts Name Item No.
K4
K5
O1
Short
Extension
Tube
O2
Long
Extension
Tube
P1
Big Canopy
BB
Small
Canopy
II
Netting
LL
Stake
Ring
Parts Images
Qty.
4
4
1
1
4
16
8
32
Parts List
Middle Top
Bar 1
Middle Top
Bar 2
Needed for assembly: (The following tools are not included)
Hammer
Ladder
Top
Connector
J
1
Bolt
M6x18mm
Hook
N
-3
1
Step 1: Connect Across Beam 1 (C1) and Across Beam 2 (C2).
Step 2: Attach Top Leg Post (A1) to Assembled Across Beam 1/2 (C1/C2) by Bolt (BB).
(Attention: lay flat assembled beam on the ground, netting bar face up.)
＠
＼
�、、
/ \
l
＼
、
＼
＼＼
＼＼
Step 3: Attach Across beam 1/2 (C1/C2) to assembled Top Leg Post (A1) by Bolt (BB).
Step 4: Connect Across Beam 1 (C1) and Across Beam 2 (C2).
因
I ／ 了
Il
＠
／
I2 \/
\
I
Il
Step 5: Insert Upper Slant Bar (G1) into Lower Slant Bar (G2 1);
Insert Middle Top Bar (I1) into Middle Top Bar 2 (I2).
Step 6: Connect Middle Top Bar 1 (I1) and Top Connector (J);
Connect Middle Top Bar 2 (I2) and Across Beam 1/2 (C1/C2) by Bolt (BB).
丁Gl
\
I
Al
Step 7: Connect Upper Slant Bar (G1) and Top Connector (J).
Insert Lower Slant Bar (G2) into Upper Leg Post (A1).
Step 8: Put Big Canopy (O1) on big roof.
＠K5
G2
冈
02 K4
Step 9: Insert Upper Slant Bar (G1) into Short Extension
Tube (K4); Insert Lower Slant Bar (G2) into Long
Extension Tube (K5).
Step 10: Put Small Canopy (O2) on small roof frame, fix four corners to Short Extension Tube (K4) and adjust
tube to suitable length.
且-
/ /�
0 0 0
J
＇ ＼
』]
1
。
I
＼
＼
＼／
／
＼
＼／
[/
＿
＿
l
三
l
-
l
-l
/l
\A
\
／＼
／＼
／＼
＼
I\
\v
|l\
ll
_＇
'
，
I
l
K5
I2
包
Al I
\
J
A2
[
／
\y
／
\
＼
Al
A2
A2
Step 11: Insert to Middle Top Bar 2 (I2) into side edge
pocket on Big Canopy (O1); Insert Long Extension
Tube (K5) into big canopy corner pocket, adjust the tube
to suitable length.
Step 12: Connect Lower Leg Post (A2) and Top Leg Post (A1).
(Attention:this step require two person).
罚
/
／
/1
\
/I
\＼＼
IIII
\
＼
＼
＼
l
\
l
\
I
II
Step 13: Hang Netting (P1) on Across Beam 1/2 (C1/C2) by Ring
(LL); Fix assembled Gazebo Lower Leg Post (A2) on the ground by
Stake (II).
Step 14: Connect the Hook to the Top Connector (J).
Attention: the hook should be under the Top Connector (J).
14
CARE AND MAINTENANCE
Our steel components for garden accessories and furniture are treated with rust
inhibiting paint that protects it from rusting. However, due to the nature of steel,
surface oxidation (rusting) will occur once these protective coatings are
scratched. This is not a defect and thus not covered by the warranty.
To minimize this condition, we recommend care when assembling & handling the
product to prevent scratching the paint. Should any scratching or damage
occur, we recommend immediate touch‐up with rust inhibiting paint.
Surface rust can also be easily removed with a very light application of common
cooking oil. If surface oxidation (rusting) occurs and if no measure is taken to prevent
this, the oxidation may start dripping on to deck or patio and caused damaging stains
which may be difficult to remove.
This can be prevented if the above-mentioned measures are taken to keep the product
from oxidizing.
Use damp cloth to wipe off the stains as quickly as possible.
If necessary, wash with a mild solution of soap and water; rinse thoroughly and dry
completely.
Periodically check and ensure that all bolts are well‐tighten during use.
