StarTech.com ICUSBANDR232 User manual

Manual Revision: 08/04/2017
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
ICUSBANDR232
Micro USB to RS232 Serial Adapter Cable
for Android™ with USB Charging
*actual product may vary from photos

Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual
i
Table of Contents
Product Overview ..................................................................................1
Introduction............................................................................................2
Packaging Contents ................................................................................................................................. 2
System Requirements.............................................................................................................................. 2
Installation ..............................................................................................2
Operation ................................................................................................3
Specications..........................................................................................3
Technical Support ..................................................................................5
Warranty Information............................................................................5

Instruction Manual
1
Product Overview
USB Micro-B
USB A - Power Only
DB9/RS-232

Instruction Manual
2
Introduction
Packaging Contents
• USB to RS-232 Serial Adapter Cable for Android
• Instruction Manual
System Requirements
• Available USB A Female Port for power/charging capabilities (eg: PC USB or
USB Wall Charger)
• AOA HyperTerm Application for Android
• Android OS Version 3.2 Honeycomb or later
Installation
1. Connect the USB A connector to the USB port of a computer, or to a 5V/1A USB
wall charger.
2. Connect the USB Micro-B connector to the Micro USB port on your mobile Android™
device.
3. When the message appears saying that no installed apps work with this USB
accessory, click View to follow the link to the Google Play store to download the
appropriate application.
4. Select the AOA HyperTerm application, and on the next screen select INSTALL.
Note: FTDI recommends using the AOA HyperTerminal Basic app, but any app that
supports the FT312D chipset should work with this adapter.
The application will download and install automatically, and auto loads once you
connect the adapter to your Android device.
5. Connect your RS-232 serial device to the DB9 connector of the adapter.
Note: This device will only work on the original infrastructure of the Android
operating system and may not function with any modied versions.

Instruction Manual
3
Operation
The application will launch once the USB to RS-232 adapter is connected to your
Android device. You should also see a AOA HyperTerm icon within your applications
lists, or on one of your home screens.
• To congure attributes such as Baud Rate, Stop(bit), Data(bit), Parity, and Flow
Control, select Setting.
Specications
Host Interface Android USB Micro
Chipset FT312D
Connectors
1x USB A (4 pin) Male
1x USB Micro-B (5 pin) Male
1x DB-9 (9 pin; D-Sub) Male
Flow Control None, CTS/RTS, DTR/DSR, XOFF/XON
Max Baud Rate 921.6 Kbps
Serial Protocol RS-232
Data Bits 7, 8
Parity None, Odd, Even, Mark, Space
Stop Bits 1,2
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature 0°C to 80°C (32°F to 176°F)
Humidity 5~90% RH
Product Dimensions(LxWxH) 1000mm x 35mm x 15 mm
Weight 85 g
Compatible Operating Systems Android OS Version 3.2 Honeycomb
or later

Instruction Manual
4
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
