STATESMAN TNF1860W User manual

Please read these instructions carefully before use and retain for future reference.
Before switching on your appliance – Always check for any damage that may have been caused in transit.
Instruction Manual
TNF1860W/TNF1860X
60CM 60/40 TOTAL NO FROST FRIDGE FREEZER
WITH LED DISPLAY
Serial number:

2
CONTENTS
Important Safety Instructions ...................................... .3-5
Appliance Overview..........................................................6
Technical Specication.....................................................7
Installation .................................................................. 8-10
Door Reversal........................................................... 10-15
Operating Instructions.............................................. 16-21
Cleaning and maintenance.............................................21
Fuse Replacement .........................................................22
Disposal Information ......................................................22
Troubleshooting guide....................................................23

3
IMPORTANT SAFETY INSTRUCTIONS
Read and follow all of the instructions even if you feel you are
familiar with the product, and nd a place to keep this manual
handy for future reference.
Important: This product is intended for domestic use only;
to store and freeze food products only. When using electrical
appliances, basic safety precautions should always be followed:
1. Do not operate the appliance with a damaged cord or plug,
after it malfunctions or has been dropped or damaged in any
way. All electrical repairs must be carried out by a qualied
electrician. Inadequate repairs may result in a major source of
danger for the user and invalidate the warranty.
2. Check the voltage of the appliance matches the household
voltage, which is located on the rating label.
3. Use of an extension cord is not recommended with this
product.
4. This appliance can be used by children aged from 8 years
and above if they have been given supervision or instruction
concerning the use of the appliance in a safe way and
understand the hazards involved.
5. Cleaning and user maintenance shall not be made by
children
6. Keep the appliance and its cord out of reach of children.
7. Children shall not play with the appliance.
8. Keep all packaging well away from children. There is a risk of
suocation
9. Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.

4
10.Always unplug the appliance before attempting to move.
When disconnecting from the electricity supply, pull the plug
and not the cord.
11.This product is for indoor use only.
12.Do not store explosive substances such as aerosol cans with
a ammable propellant in this appliance.
13.Always keep the ventilation openings clear of obstruction.
Should they become blocked, clear them straight away.
14.The refrigerant of this product is R600a which is ammable.
Ensure when moving the appliance or during installation that
the cooling system does not get damaged.
15.Do not use mechanical devices or other means to accelerate
the defrosting process.
16.Do not touch the light bulb if it has been on for a long period
of time because it could be very hot.
17.During transportation and installation of the appliance, be
certain that none of the components of the refrigerant circuit
become damaged.
18.Make sure that the power plug is not squashed or damaged
by the back of the appliance. A squashed or damaged power
plug may overheat and cause a re.
19.Do not remove or touch items from the freezer compartment
if your hands are damp/wet, as this could cause skin
abrasions or frost/freezer burns.
20.If the bulb needs to be replaced, contact a local service
engineer. Do not attempt to change it yourself.
WARNING: The appliance is heavy and care is needed
when unpacking and moving it.
Get extra help and only hold the appliance by the casing –
never hold by the door or the trim.
WARNING: Risk of child entrapment.

5
WARNING: During use, servicing and disposal of the
appliance, please pay attention to this symbol
which is located on rear of appliance.
There are internal ammable materials.
Ensure that during use, servicing and
disposal it is far away from re.
WARNING: When positioning the appliance, ensure the
supply cord is not trapped or damaged.
Before disposal of the old appliance, make sure that any locking
mechanisms have been broken o, doors have been removed but
shelves have been left in so that children cannot easily climb inside.
Also remove the plug so the appliance is unusable.

6
APPLIANCE OVERVIEW
Freezer Drawers
Fridge Balconies
Fridge Shelves
Crisper Cover
Crisper
Fresh Converter
Drawer
Leveling Feet

7
SPECIFICATION
Trade Mark Statesman
Model Number TNF1860W/TNF1860X
Category Type Refrigerator - Freezer
Energy Eciency Class A+
Annual Energy Consumption 317 kWh/year
Total Net Storage Volume (Litre) 315L
Freezing Capacity 12kg/24 hours
Fridge Net Storage Volume (Litre) 199L
Freezer Net Storage Volume (Litre) 97L
Applicable Star Rating of Freezer Compartment 4-star
Refrigeration System Total No Frost
(Frost Free, Static, Total No Frost)
Temperature Rise Time 20 hours
Climate Class SN-ST
This appliance is intended to be used at an ambient
temperature between 10°C and 38°C
Noise Emission (dB) 41 dB
Built-in appliance No
Construction Stationary

8
INSTALLATION
• Unpack the appliance and check if there are damages on it. Do not
connect the appliance if it is damaged. Report possible damages
immediately to the retailer. Make sure to retain the packaging.
• It is advisable to wait at least four hours before connecting the appliance to
allow the oil to ow back in the compressor.
• Ensure there is adequate air circulation around the appliance to prevent
overheating. To achieve sucient ventilation follow the instructions relevant
to installation.
• Wherever possible the spacers of the product should be against a wall to
avoid touching or catching warm parts (compressor, condenser) to prevent
possible burn.
• The appliance must not be located close to radiators or cookers.
• Make sure that the mains plug is accessible after the installation of
the appliance.
Space Requirement
• Select a location without direct exposure to sunlight;
• Select a location with enough space for the refrigerator doors to open
easily;
• Select a location with level (or nearly level) ooring;
• Allow sucient space to install the refrigerator on a at surface;
• Allow clearance to the right, left, back and top when installing. This will
help reduce power consumption and keep your energy bills lower.
• Keep at least 50mm gap at two sides and back.

9
Levelling
If the oor is not perfectly horizontal, you can
adjust the height by tightening or loosening
the two levelling feet at the front of the
appliance.
Note: If the appliance is not level, the doors
and magnetic seal alignments will not be
covered properly.
Climate Class Ambient Temperature
SN +10°C to +32°C
N +16°C to +32°C
ST +16°C to +38°C
T +16°C to +43°C
Install this appliance at a location where the ambient temperature
corresponds to the climate class indicated on the rating plate of the
appliance:
Positioning
Location
The appliance should be installed well away from sources of heat such as
radiators, boilers, direct sunlight etc. Ensure that air can circulate freely
around the back of the cabinet. To ensure best performance, if the appliance
is positioned below an overhanging wall unit, the minimum distance between
the top of the cabinet and the wall unit must be at least 100mm. Ideally,
however, the appliance should not be positioned below overhanging wall
units. Accurate leveling is ensured by one or more adjustable feet at the base
of the appliance.
Warning! It must be possible to disconnect the appliance from the
mains power supply; the plug must therefore be easily accessible after
installation.

10
Electrical connection
Before plugging in, ensure that the voltage and frequency shown on the
rating plate correspond to your domestic power supply. The appliance must
be earthed. The power supply cable plug is provided with a contact for
this purpose. If the domestic power supply socket is not earthed, connect
the appliance to a separate earth in compliance with current regulations,
consulting a qualied electrician.
The manufacturer declines all responsibility if the above safety precautions
are not observed.
This appliance complies with the E.E.C. Directives.
DOOR REVERSAL
Before reversing the door, please ensure you have the following tools
and materials: straight screwdriver, cross screwdriver, spanner and the
components included in the poly bag:
Left Door Hinge Cover x1 Left Closing-Aid on Upper Door x1 Left Closing-Aid on Lower
Door x 1
1. Unscrew the top hinge cover and disconnect the door switch and harness connectors.

11
2. Unscrew the top hinge.
3. Remove the pin using a screwdriver. Flip the hinge bracket and then ret the pin.
4. Remove the door switch from the existing hinge cover and attach to the replacement
(opposite) hinge cover.
5. Remove the upper door cover and move the harness from one side to the opposite side.
Then reattach the door cover.

12
6. Unscrew the rectangular cover and reattach on the opposite side.
7. Remove the upper door and remove the hinge situated between the upper and lower door
using a cross screwdriver. Then remove the lower door.
8. Remove the hinge hole covers from one side and reattach them on the other side.
WARNING! When moving the appliance, always seek assistance.

13
9. Lay down the fridge freezer and then remove the adjustable feet from both sides.
10. Using a spanner, unscrew the bottom hinge pin. Flip the bracket and then ret the pin.
11. Screw the bottom hinge pin in to the opposite side.

14
12. Remove the closing-aids from the bottom of both the upper and lower doors.
Use the replacement (opposite) closing-aids and attach them the opposite side.
13. Remove both the fridge and freezer door gaskets, rotate them 180° and then reattach them.
14. Reinstall the lower door and x the hinge situated between the upper and lower door.

15
15. Reinstall the upper door, ensuring that the door is correctly aligned. If the door is not,
the gasket may not seal tightly during use. Connect the door to the unit by tightly screwing
in the top hinge.
16. Connect the harnesses between the door and the unit. Attach the top hinge cover ensuring
that the terminals of the door switch are connected.

16
OPERATING INSTRUCTIONS
Using the Control Panel
A. Temperature Control of Fridge Compartment
B. Temperature Control of Freezer Compartment
C. Mode / Locking / Unlocking
1. Temperature of Fridge Compartment
2. Temperature of Freezer Compartment
3. ECO Mode
4. Holiday Mode
5. Super Freeze Mode
6. Lock / Unlock
- When switching on the appliance the control panel will illuminate for
3 seconds, and will operate with the mode and temperature set before
the appliance was switched o. The panel will then automatically lock 25
seconds after the last operation. After locking, the light of the panel will
show for an additional 30 seconds before switching o.
- Both preset temperatures of the fridge compartment and freezer
compartment will be shown on the display.
Display
The panel will light up for 2 minutes once the door of fridge compartment
or freezer compartment is opened (one door signal is sensed at a time).
The panel will be lit up by any operation and the light will turn o 2 minutes
after the last operation.
Display during normal operation:
• Temperature Display of the Fridge Compartment: Indicates the
temperature of the current setting.
• Temperature Display of the Freezer Compartment: Indicating the
temperature of the current setting.

17
Daily Use
To avoid contamination of food, please follow the below instructions.
• Opening the door for long periods can cause a signicant increase of the
temperature.
• Regularly clean surfaces that can come in contact with food.
• Store raw meat and sh in suitable containers in the refrigerator, so that it
is not in contact with or drips onto other food.
• If the appliance is left empty for long periods, switch o, defrost, clean,
dry and leave the door open to prevent mold developing within the
appliance.
Compartment Type of food
Door or door shelves of the fridge
compartment
Foods with natural preservatives such as
jams, juices, drinks and condiments.
No perishable foods.
Salad crisper drawer Fruits, herbs and vegetables. Do not store
bananas, onions, potatoes or garlic in the
salad crisper drawer.
Fridge shelf - bottom chiller
Dairy products and eggs.
Place food in dierent compartments following the advise in the below table:
Raw meat, poultry and sh. Short term
storage only.
Fridge shelf – middle
Foods that do not need to be cooked such
as ready-to-eat foods, deli meats and
leftovers.
Fridge shelf – top
Freezer drawers/shelves - Foods intended to be stored long-term.
- Top drawer/shelf: ice cream, frozen
fruit and frozen baked goods.
- Middle drawer/shelf: frozen
vegetables and chips.
- Bottom drawer/shelf: raw meat,
poultry and sh.

18
Fresh Converter Drawer Temperature Control
• Temperature of the fresh converter drawer can be adjusted to best
suit the food stored.
• Push the slider control up and the temperature in
the fresh zone will gradually decrease.
• When the slider control is placed at the “CRISPER”
position the fresh converter drawer will function as
a crisper zone and will maintain the
appropriate temperature and humidity
for fruits and vegetables.
• When the slider control is placed at the “CHILLER”
position, it is suitable for short-term storage
of sh or other fresh food. The food will keep
fresh and will not freeze which makes it ideal
for storing fresh food.
• When the “CHILLER” function is selected,
it is recommended that the refrigerator
temperature is set below 4°C. It is suggested
to use this for no longer than 3 days, to ensure
the food is fresh as possible.
DISPLAY KEY FUNCTIONS
Temperature Control of the Fridge Compartment
This function can be used in both the User Dened Mode as well as
Super Freeze Mode. After entering the temperature control of the fridge
compartment, this button will ash. By touching the key consecutively, the
temperature will change in a cycle of “2°C, 3°C, 4°C, 5°C, 6°C, 7°C, 8°C, after
which 5-second ashing means the temperature has been selected.
Shuto of the Fridge Compartment
Press the button for “Temperature Control of Fridge Compartment” and select
“OFF”, the display will then ash for 5 seconds meaning the temperature has
been selected and the fridge compartment will stop operating.

19
This button can be used in both the User Dened Mode as well as Holiday
Mode. After entering the temperature control of the freezer compartment, the
button will ash. By pressing this consecutively, the temperature will change
in a cycle from -14°C to -22°C, after which a 5-second ashing means the
temperature has been selected.
Temperature Control of the Freezer Compartment
By pressing this button repeatedly, the operation mode will cycle through
‘ECO Mode - Holiday Mode - Super Freeze Mode - User Dened Mode’.
Once the desired mode has been selected the display will ash for 5
seconds.
Mode / Selection
Lock / Unlock
Press MODE button and hold for 3 seconds to lock other two buttons,
then the LOCK icon will show following a beep.
To unlock, press MODE button and hold for 3 seconds, then LOCK icon
will show unlocked following a beep. In the unlocked mode, all buttons
can be used. If there is no interaction with the display within 25 seconds,
the display will be locked automatically. Press “MODE” button to show the
display.
Press Button Alert
Short beep after pressing each button. Buttons only operational when display
is unlocked.
Auto Lock Function
The display will automatically lock if not used for 25 seconds.
ECO mode
Press MODE button to choose ECO mode. After ashing for 5 seconds the
ECO icon will stay illuminated meaning the ECO mode has been conrmed.
In ECO mode, the refrigerator will automatically set the temperature of the
fridge compartment to 5°C,
and the temperature of the freezer compartment to -18°C. Apart from the
MODE button, no other buttons will respond when this is engaged.
Press the MODE button to exit the ECO mode.

20
Holiday Mode
Press the MODE button to choose the Holiday mode. After ashing for 5
seconds, the Holiday mode icon will stay illuminated meaning the Holiday
mode has been conrmed.
In Holiday mode, the temperature of the fridge will be set at 17°C. The
“FRIDGE” button will not respond when this is engaged. Press the “MODE”
button to exit Holiday mode.
Super Freeze Mode
Press the MODE button to select the Super Freeze mode. The Super Freeze
icon will ash for 5 seconds and then the function will be conrmed.
In the Super Freeze mode, the “FREEZER” button will not respond.
To exit Super Freeze mode:
- Change the mode by using the MODE button
- Or after 50 hours of the Super Freeze mode being engaged, the refrigerator
will automatically revert to the previous setting.
If you plan to freeze a large amount of food at the same time, set the Super
Freeze mode at least 24 hours before hand.
Warning: In the Super Freeze mode, the refrigerator will be louder.
Freezing fresh food
• The freezer compartment is suitable for freezing fresh food and storing
frozen and deep frozen food for a long time.
• Place the fresh food to be frozen in the bottom compartment.
• The maximum amount of food that can be frozen in 24 hours is specied
on the rating plate.
• The freezing process lasts 24 hours: during this period do not add other
food to be frozen.
Storing frozen food
When rst starting-up the appliance or after a period out of use, make sure to
let the appliance run at least 2 hours on the higher settings before putting any
products in the freezer compartment.
Important! In the event of accidental defrosting, the defrosted food must be
consumed quickly or cooked immediately and then re-frozen (after cooking).
Please check the product specications for the “temperature rising time” in
the scenario of a power outage.
