STATESMAN FF1755X User manual

Please read these instructions carefully before use and retain for future reference.
Before switching on your appliance – Always check for any damage that may have been caused in transit.
Instruction Manual
FRIDGE FREEZER
FF1755X

2
CONTENTS
Important Safety Instructions ................................ 3-5
Technical Specication...............................................6
Appliance Overview.....................................................7
Installation.............................................................. 8-12
- Door Reversal ...................................................... 8-10
- Space Requirement .................................................11
- Leveling the Unit ......................................................11
- Positioning ...............................................................12
- Location ...................................................................12
- Electrical Connection...............................................12
Using Your Appliance.......................................... 13-17
- First use ...................................................................13
- Temperature Setting ................................................13
- Freezing Fresh Food ................................................13
- Storing Frozen Food ................................................14
- Thawing ...................................................................14
- Temperature Setting Recommendation...................14
- Accessories .............................................................15
- Using the Water Dispenser ................................ 15-16
- Hints for Freezing.....................................................16
- Hints for Refrigeration..............................................17
Cleaning and Maintenance.......................................18
Fuse Replacement.....................................................18
Troubleshooting Guide..............................................19
Disposal Information.................................................19

3
IMPORTANT SAFETY INSTRUCTIONS
Read and follow all of the instructions even if you feel you are familiar with the product, and
nd a place to keep this manual handy for future reference.
Important: This product is intended for domestic use only; to store and freeze food products only.
When using electrical appliances, basic safety precautions should always be followed:
• This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved
• Children ages from 3 to 8 years are allowed to load and unload this appliance
• Children should be supervised to ensure that they do not play with the appliance
• Cleaning and user maintenance shall not be made by children unless they are aged from 8 years
and above and supervised
• Keepallpackagingwellawayfromchildren.Thereisariskofsuocation
• If you are discarding the appliance pull the plug out of the socket, cut the connection cable (as
closetotheapplianceasyoucan)andremovethedoortopreventplayingchildrentosuer
electric shock or close themselves into it.
• If this appliance featuring magnetic door seals is to replace an older appliance having a spring
lock (latch) on the door or lid, be sure to make that spring lack unusable before you discard the
old appliance. This will prevent it from becoming a death trap for a child.
WARNING! Keep ventilation openings, in the appliance enclosure or the built-in structure,
clear of obstruction
WARNING! Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer
WARNING! Do not damage the refrigerant circuit
WARNING! Do not use other electrical appliances (such as ice cream makers) inside of
refrigerating appliances, unless they are approved for this purpose by the manufacturer
WARNING! Do not touch the light bulb if it has been on for a long period of time because it
could be very hot
WARNING! When positioning the appliance, ensure the supply cord is not trapped or
damaged
WARNING! Do not locate multiple portable socket-outlets or portable power suppliers at the
rear of the appliance
• Donotstoreexplosivesubstancessuchasaerosolcanswithaammablepropellantinthis
appliance
• The refrigerant isobutane (R-600a) is contained within the refrigerant circuit of the appliance, a
naturalgaswithahighlevelofenvironmentalcompatibility,whichisneverthelessammable
• During transportation and installation of the appliance, be certain that none of the components
of the refrigerant circuit become damaged
-avoidopenamesandsourcesofignition
- thoroughly ventilate the room in which the appliance is situated
• Itisdangeroustoalterthespecicationsormodifythisproductinanyway.Anydamagetothe
cordmaycauseashortcircuit,reand/orelectricshock
• This appliance is intended to be used in households and similar applications such as:
-stakitchenareasinshops,ocesandotherworkingenvironments,
- farm houses and by clients in hotels, motels and other residential type environments,
- bed and breakfast type environments,
- catering and similar non-retail applications

4
WARNING! Any electrical components (plug, power cord, compressor etc) must be replaced
byacertiedserviceagentorqualiedservicepersonnel
WARNING! The light bulb supplied with this appliance is a ‘special use lamp bulb’ usable
only with the appliance supplied. This ‘special use lamp’ is not usable for domestic lighting
• Power cord must not be lengthened
• Make sure that the power plug is not squashed or damaged by the back of the appliance. A
squashedordamagedpowerplugmayoverheatandcauseare
• Make sure that you can access the mains plug of the appliance
• Do not pull the mains cable
• If the power plug socket is loose, do not insert the power plug. There is a risk of electric shock
orre
• You must not operate the appliance without the lamp
• This appliance is heavy. Care should be taken when moving it
• Donotremoveortouchitemsfromthefreezercompartmentifyourhandsaredamp/wet,asthis
couldcauseskinabrasionsorfrost/freezerburns
• Avoid prolonged exposure of the appliance to direct sunlight
• Do not put hot objects on the plastic parts of the appliance
• Do not place food products directly against the rear wall
• Frozen food must not be re-frozen once it has been thawed out
• Store pre-packed frozen food in accordance with the frozen food manufacturer’s instructions
• Appliance’s manufacturers storage recommendations should be strictly adhered to. Refer to
relevant instructions
• Donotplacecarbonatedorzzydrinksinthefreezercompartmentasthiscreatespressurein
the container and may cause it to explode, resulting in damage to the appliance
• To avoid contamination of food, please respect the following instructions:
• Openingthedoorforlongperiodscancauseasignicantincreaseofthetemperatureinthe
compartments of the appliance
• Clean regularly surfaces that come into contact with food and accessible drainage systems
• Cleanwatertanksiftheyhavenotbeenusedfor48hours;ushthewatersystemconnectedto
a water supply if water has not been drawn for 5 days
• Storerawmeatandshinsuitablecontainersintherefrigerator,sothatitisnotcominginto
contact with or can drip onto other food
• Two-star frozen food compartments (if they are included in the appliance) are suitable for storing
pre-frozen food, storing or making ice cream and making ice cubes
• One-, two- and three-star compartments (if they are included in the appliance) are not suitable
for the freezing of fresh food
• Iftheapplianceisleftemptyforlongperiods,switcho,defrost,clean,dryandleavethedoor
open to prevent mould developing within the appliance
Care and Cleaning
• Beforemaintenance,switchotheapplianceanddisconnectthemainsplugfromthemains
socket
• Do not clean the appliance with metal objects
• Do not use sharp objects to remove frost from the appliance. Use a plastic scraper
• Regularly examine the drain in the refrigerator for defrosted water. If necessary, clean the drain.
If the drain is blocked, water will collect in the bottom of the appliance
Installation
Important! Forelectricalconnectioncarefullyfollowtheinstructionsgiveninspecicparagraphs
Unpack the appliance and check if there are damages on it. Do not connect the appliance if it is
damaged. Report possible damages immediately to the place you bought it. In that case retain
packaging

5
• Itisadvisabletowaitatleastfourhoursbeforeconnectingtheappliancetoallowtheoiltoow
back into the compressor
• Adequate air circulation should be around the appliance, lacking this leads to overheating. To
achievesucientventilationfollowtheinstructionsrelevanttoinstallation
• Wherever possible the spacers of the product should be against a wall to avoid touching or
catching warm parts (compressor, condenser) to prevent possible burn
• The appliance must not be located close to radiators or cookers
• Make sure that the mains plug is accessible after the installation of the appliance
Service
• Any electrical work required to do the servicing of the appliance should be carried out by a
qualiedelectricianorcompetentperson
• This product must be serviced by an authorised service centre, and only genuine spare parts
must be used
Energy Saving
• Don’t put hot food back into the appliance
• Don’t pack food close together as this prevents air from circulating
• Make sure food doesn’t touch the back of the compartments
• Iftheelectricitygoeso,don’topenthedoors
• Don’t open the door frequently
• Don’t keep the doors open for too long at a time
• Don’t set the thermostat to exceedingly cold temperatures
• All accessories, such as drawers, shelves, balconies etc, should be kept there for lower energy
consumption
Environment Protection
This appliance does not contain gasses which could damage the ozone layer, in either its
refrigerant circuit or insulation materials. The appliance shall not be discarded together with
theurbanrefuseandrubbish.Theinsulationfoamcontainsammablegasses;theapplianceshall
be disposed according to the appliance regulations obtained from your local authorities. Avoid
damaging the cooling unit, especially the heat exchanger. The materials used on this appliance
marked by the symbol are recyclable
Packaging Materials
The materials with the symbol are recyclable. Dispose the packaging in a suitable collection
container to recycle it
Disposal of the Appliance
1. Disconnect the mains plug from the mains socket
2. Cutothemainscableanddiscardit
WARNING! During use, service and disposal of the appliance, please pay attention to the
left symbol, which is located on the rear of the appliance (rear panel or compressor) and
is yellow or orange in colour.
Itisariskofrewarningsymbol.Thereareammablematerialsinrefrigerantpipesand
compressor.Pleasebefarawayfromresourcesduringusing,serviceanddisposal

6
TECHNICAL SPECIFICATION
SupplierName/TradeMark Statesman
Model Number FF1755X
Category Type Fridge Freezer
EnergyEciencyClass(Old) A+
EnergyEciencyClass(New) F
EU Eco-Label Award N/A
Annual Energy Consumption 276kWh
Freezing Capacity 3.2Kg/24h
Fridge Storage Volume (Litre) and Applicable Star Rating Compartment 161
Freezer Storage Volume (Litres) 71
Applicable Star Rating Compartment N/A
Refrigeration System Frost Free
Temperature Rise Time N/A
Climate Class N,ST
Noise Emissions (dB) 40
Built-In Appliance N/A
Wine Storage Appliance N/A
Voltage (V) 220-240
Wattage Power (W) 105
Frequency (Hz) 50
Power Source AC

7
PRODUCT OVERVIEW
Thermostat
and Light
Glass Shelves
Crisper Cover
Crisper
Freezer
Drawers
Leveling Feet
Balconies
Water Tank
This illustration is only for reference, for details please check your appliance

8
Door reversal
Tools required:Phillipsscrewdriver,atheadscrewdriver,hexagonalspanner
• Ensure the unit is unplugged and empty.
• Totakethedooro,itisnecessarytotilttheunitbackwards.Youshouldresttheuniton
something solid so that it will not slip during the door reversing process.
• All parts removed must be saved to do the re installation of the door.
• Donotlaytheunitatasthismaydamagethecoolantsystem.
• It’s better that 2 people handle the unit during assembly.
INSTALLATION
1. Remove four screws in top cover and remove top cover
2. Unscrew top hinge and then remove door and place it on
a soft pad to avoid scratching.
3. Removethepinwithascrewdriverandipthehinge
bracket.Thenretthepinintothehingebracket

9
4. Unscrew middle hinge and then remove lower door and
place it on a soft pad to avoid scratching.
5. Move the hinge hole covers from left side to right side
6. Unscrew bottom hinge. Then remove the adjustable feet
from both sides.
7. Unscrew and remove the bottom hinge pin, turn the bracket over and replace it.
Note: Remove this screw if it presents

10
8. Retthebracketttingthebottomhingepin.Replace
both adjustable feet. Transfer the lower door to the proper
position.
9. Turn the middle hinge 180°C, then transfer it to the left
position Make the middle hinge pin in the upper hole of
the lower door, then tighten the bolts.
10.Place the upper door back on. Ensure the door is aligned
horizontally and vertically so that the seals are closed on
allsidesbeforenallytighteningthetophinge.Theninsert
the hinge and screw it to the top of the unit.
11.Replace the top cover and tighten the screws back in.
12.Detach the fridge and the freezer door gaskets, rotate and
reattach.

11
Space Requirement
Keep enough space for the door to open
Note: This refrigerating appliance is not intended to be used as a built-in appliance
Leveling the Unit
To do this adjust the two leveling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal align-
ments will not be covered properly

12
Positioning
Install this appliance in a location where the ambient temperature corresponds to the climate class
indicated on the rating plate of the appliance:
Ambient Room Temperature Limits
Class Symbol Ambient average temperature °C
Extended temperature SN +10 to +32
Temperature N +16 to +32
Subtropical ST +16 to +38
Tropical T +16 to +43
Location
The appliance should be installed well away from sources of heat such as radiators, boilers, direct
sunlight etc. Ensure that air can circulate freely around the back of the cabinet. To ensure best
performance, if the appliance is positioned below an overhanging wall unit, the minimum distance
between the top of the cabinet and the wall unit must be at least 50 mm. Ideally, however, the
appliance should not be positioned below overhanging wall units. Accurate leveling is ensured by
one or more adjustable feet at the base of the cabinet.
This refrigerating appliance is not intended to be used as a built-in appliance;
Warning! It must be possible to disconnect the appliance from the mains power supply; the
plug must therefore be easily accessible after installation.
Electrical Connection
Before plugging in, ensure that the voltage and frequency shown on the rating plate correspond
to your domestic power supply. The appliance must be earthed. The power supply cable plug
is provided with a contact for this purpose. If the domestic power supply socket is not earthed,
connect the appliance to a separate earth in compliance with current regulations, consulting a
qualiedelectrician.
The manufacturer declines all responsibility if the above safety precautions are not observed. This
appliance complies with E.E.C Directives.

13
USING YOUR APPLIANCE
First Use - Cleaning the Interior
Beforeusingtheapplianceforthersttime,washtheinteriorandallinternalaccessorieswith
lukewarm water and some neutral soap so as to remove the typical smell of a brand new product,
then dry thoroughly.
Important: Donotusedetergentsorabrasivepowders,asthesewilldamagethenish
Temperature Setting
Plug in your appliance. The internal temperature is controlled by a
thermostat. There are 3 settings, MIN, NORMAL AND MAX. MIN is
the warmest setting and MAX is the coldest setting.
The appliance may not operate at the correct temperature if it is in
a particularly hot environment or if you open the door often.
Positiondierentfoodineachcompartmentaccordingtothebelowtable
Refrigerator
Compartments
Type of Food
Door or balconies of
fridge compartment
• Foods with natural preservatives, such as jams,juices, drinks,
condiments.
• Do not store perishable foods.
Crisper drawer
(salad drawer)
• Fruits, herbs and vegetables should be placed separately in the
crisper bin.
• Do not store bananas, onions, potatoes, garlic in refrigerator
Fridge shelf
• Dairy products, eggs
• Foods that do not need cooking, such as ready to eat foods, deli
meat, leftovers
Freezer compartment
• Foods for long-term storage
• Bottomdrawer/shelfforrawmeat,poultry,sh
• Middledrawer/shelfforfrozenvegetables,chips
• Topdrawer/shelfforicecream,frozenfruit,frozenbakedgoods
Freezing Fresh Food
• The freezer compartment is suitable for freezing fresh food and storing frozen and deep-frozen
food for a long time.
• Place the fresh food to be frozen in the bottom compartment
• Themaximumamountoffoodthatcanbefrozenin24hoursisspeciedontheratingplate
• The freezing process lasts for 24 hours; during this period do not add any more food to be frozen

14
Storing Frozen Food
• Whenrststartinguporafteraperiodoutofuse,beforeputtingtheproductinthedrawerletthe
appliance run at least 2 hours on the higher settings.
• Important!Intheeventofaccidentaldefrosting,forexamplethepowerhasbeenoforlonger
than the value shown in the technical characteristics chart under ‘rising time,’ the defrosted food
must be consumed quickly or cooked immediately and then re-frozen (after cooking)
Thawing
Deep-frozen or frozen food, prior to being used, can be thawed in the fridge compartment or at
room temperature, depending on the time available for this operation.
Small pieces may even be cooked still frozen, directly from the freezer. In this case, cooking will take
longer.
Ice Cube
This appliance may be equipped with one or more trays for the production of ice cubes.
Temperature Setting Recommendation
Environment
Temperature Temperature Setting
Summer Set on 5-6
Normal Set on 3-5
Winter Set on 1-3
Impact on Food Storage
• Under recommended setting, the best storage time in the fridge is no more than 3 days
• Under recommended setting, the best storage time in the freezer is no more than 1 month
• Thebeststoragetimemayvaryunderdierentcircumstances

15
ACCESSORIES
Movable Shelves
The walls of the refrigerator are equipped with a series of runners so that
the shelves can be positioned as desired
Positioning the Door Shelves
To permit storage of food packages of various sizes, the door shelves can
beplacedatdierentheights.Tomaketheseadjustments,proceedas
follows: gradually pull the shelf in the direction of the arrows until it comes
free, then reposition as required.
Using the Water Dispenser
Important! Beforeusingthewaterdispenserforthersttime,removeandcleanthewatertank
located inside the refrigeration compartment
1. Lift and remove the tank balcony
2. Remove the water tank. Detach the top cover and wash and clean both the tank and the cover

16
3. After cleaning, reposition water tank, cover and tank balcony as below:
4. Clean the dispenser lever outside the refrigerator door
Filling the Water Tank
1. Open the small lit in the top of the tank balcony
2. Fill the water tank with drinkable water up to the 2.5L line
3. Closethelid,ensuringitisrmlyshut
Dispensing Water
Push the dispenser lever gently with a glass or container. To stop the
ow,pulltheglassawayfromthelever.
Hints for Freezing
To help you make the most of the freezing process, here are some important hints:
• The maximum quantity of food that can be frozen in 24 hours is shown on the rating plate
• The freezing process takes 24 hours. No further food to be frozen should be added during this
period
• Onlyfreezetopquality,freshandthoroughlycleanedfoodstus
• Prepare food in small portions to enable it to be rapidly and completely frozen and to make it
possible subsequently to thaw only the quantity required
• Wrap up the food in aluminium foil or polythene and make sure that the packages are airtight
• Do not allow fresh, unfrozen food to touch food that is already frozen, thus avoiding a rise in
temperature of the latter
• Lean foods store better and longer than fatty ones; salt reduces the storage life of food
• Ice cubes, if consumed immediately after removal from the freezer, can possibly cause freeze
burns to the skin
• It is advisable to show the freezing date on each individual pack to enable you to keep tabs of
the storage time

17
Hints for Storage of Frozen Food
• To obtain the best performance from this appliance you should:
• makesurethatthecommerciallyfrozenfoodstuswereadequatelystoredbytheretailer,
• besurethatfrozenfoodstusaretransferredfromthefoodstoretothefreezerintheshortest
possible time,
• not open the door frequently or leave it open longer than absolutely necessary.
• Once defrosted, food deteriorates rapidly and cannot be refrozen.
• Do not exceed the storage period indicated by the food manufacturer.
Hints for Fresh Food Refrigeration
To obtain the best performance:
• Do not store warm food or evaporating liquids in the refrigerator
• Coverorwrapfood,particularlyifithasastrongavour
Hints for Refrigeration
Useful hints:
• Meat (all types): wrap in polythene bags and place on the glass shelves above the vegetable
drawer
• For safety, store in this way for only one or two days at the most
• Cooked food, cold dishes etc should be covered and placed on any shelf
• Fruit and vegetables should be thoroughly cleaned and placed in the special drawer(s) provided
• Butter and cheese should be placed in special airtight containers or wrapped in aluminium foil or
polythene bags to exclude as much air as possible
• Milk bottles should have a cap and should be stored in the shelves in the door
• Bananas, potatoes, onions and garlic, if not packed, must not be kept in the fridge

18
CLEANING AND MAINTENANCE
For hygienic reasons the appliance interior, including interior accessories, should be cleaned
regularly.
Caution! The appliance should be disconnected from the mains during cleaning. Danger of electrical
shock!Beforecleaningswitchtheapplianceoandremovetheplugfromthemains,orswitcho
or turn out the circuit breaker or fuse. Never clean the appliance with a steam cleaner. Moisture
could accumulate in electrical components, danger of electrical shock! Hot vapours can lead to the
damage of plastic parts. The appliance must be allowed to dry fully before being placed back into
service.
Important! Ethereal oils and organic solvents can attack plastic parts, e.g. lemon juice or the juice
from orange peel, butyric acid, cleansers that contain acetic acid.
• Do not allow such substances to come into contact with the appliance parts
• Do not use any abrasive cleaners
• Remove the food from the appliance. Store them in a cool place, well covered
• Switchtheapplianceoandremovetheplugfromthemains,orswitchoorturnoutthecircuit
breaker or fuse
• Clean the appliance and the interior accessories with a cloth and lukewarm water. After cleaning
wipe with fresh water and rub dry
• After everything is fully dry place appliance back into service
Replace the Lamp
The internal light is a LED type. To replace the lamp, please
contactaqualiedtechnician.
Fuse Cover
Fuse Replacement (Class I)
Thisappliancemustbeearthed.Removethefusecoverwithasmallat
head screw driver. Take out the fuse and replace with a new fuse of the
same Amp. Replace the fuse cover and push back into place.

19
TROUBLESHOOTING
If you are having problems with your appliance, please use our troubleshooting guide below. If you
are unable to resolve the issue using this guide please ring our Customer Service Department on
0844 848 5861. Please have the model code and purchase information available.
Problem Possible Cause Solution
Appliance does not
work
Temperature regulation knob is
set to ‘0’
Set the knob to another number to
switch on the appliance
Mains plug is not plugged in or
is loose Insert mains plug correctly
Fuse has blown or is defective Check fuse, replace if necessary
Socket is defective Mains malfunctions are to be corrected
by an electrician
The food is too warm
Temperature is not properly
adjusted Refer to the Temperature Setting section
Door was open for an
extended period Open the door only as long as necessary
A large quantity of warm food
was placed in the appliance in
the last 24 hours
Turn the temperature regulation to a
colder setting temporarily
The appliance is near a heat
source Please refer to the Installation section
Appliance cools too
much Temperature is set too cold Turn the temperature regulation knob to a warmer setting temporarily
Unusual noises
Appliance is not level Re-adjust the feet
The appliance is touching the
wall or other objects Move the appliance slightly
A component, e.g. a pipe, on
the rear of the appliance is
touching another part of the
appliance or the wall
If necessary, carefully bend the
component out of the way
Waterontheoor Water drain hole is blocked Clean the drain hole with a cleaner
DISPOSAL
TheEuropeanDirective2012/19/EUonWasteElectricalandElectronicEquipment
(WEEE), requires that old household electrical appliances must not be disposed of in
normal unsorted municipal waste.
Old appliances must be collected separately in order to optimise the recovery and
recycling of the materials they contain and reduce the impact on human health and the
environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation,
that when you dispose of the appliance it must be separately collected. Consumers
should contact their local authority or retailer for information concerning the correct
disposal of their old appliance.

0844 848 5861
38 Bluestem Road,
Ransomes Europark
Ipswich, IP3 9RR
