STATESMAN TL335LW User manual

Please read these instructions carefully before use and retain for future reference.
Before switching on your appliance – Always check for any damage that may have been caused in transit.
TL335LW
UPRIGHT LARDER FRIDGE
Instruction Manual

2
CONTENTS
Important Safety Instructions ........................................3
Specication..................................................................4
Appliance Overview.......................................................4
Installation ................................................................. 5-6
Operating Instructions............................................... 6-7
Cleaning and Maintenance........................................ 7-8
Fuse Replacement ........................................................8
Trouble Shooting Guide.................................................9
Disposal Information .....................................................9
Terms and Conditions and Warranty Information.. 10-11

3
IMPORTANT SAFETY INSTRUCTIONS
Read and follow all of the instructions even if you feel you are familiar with the product, and
nd a place to keep this manual handy for future reference.
Important: This product is intended for domestic use only, for food refrigeration and frozen food
storage only.
When using electrical appliances, basic safety precautions should always be followed:
1. Do not operate the appliance with a damaged cord or plug, after it malfunctions or has been
 droppedordamagedinanyway.Allelectricalrepairsmustbecarriedoutbyaqualied
electrician. Inadequate repairs may result in a major source of danger for the user and invalidate
the warranty.
2. Check the voltage of the appliance matches the household voltage, which is located on the
rating label.
3. Use of an extension cord is not recommended with this product.
4. Do not use electrical appliances inside the food storage compartments of the appliance, unless
they are recommended by the manufacturer.
5. This appliance can be used by children aged from 8 years and above if they have been given
supervision or instruction concerning the use of the appliance in a safe way and understand the
hazards involved.
6. Cleaning and user maintenance shall not be made by children
7. Keep the appliance and its cord out of reach of children.
8. Children shall not play with the appliance.
9. Appliances can be used by persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved.
10. Always unplug the appliance before attempting to move.
11. Always unplug the appliance before cleaning. When disconnecting from the electricity supply,
pull the plug, not the cord.
12. This product is for indoor use only.
13.Donotstoreexplosivesubstancessuchasaerosolcanswithaammablepropellantinthis
appliance.
14. Always keep the ventilation openings clear of obstruction. Should they become blocked, clear
them straight away.
15.TherefrigerantofthisproductisR600awhichisammable.Ensurewhenmovingtheappliance
or during installation that the cooling system does not get damaged.
16. Important: Always allow 12 hours before turning on the appliance to allow coolant gases time
to settle after the appliance is in place.
WARNING: The appliance is heavy and care is needed when unpacking and moving it. Get extra
help and only hold the appliance by the casing – never hold by the door or the trim.
WARNING: Risk of child entrapment.
Beforedisposaloftheoldappliance,makesurethatanylockingmechanismshavebeenbrokeno,
doors have been removed but shelves have been left in so that children cannot easily climb inside.
Also remove the plug so the appliance is unusable.

4
Specication
Supplier Name / Trade Mark Statesman
Model Number TL335LW
Category Type Upright Larder
EnergyEciencyClass A+
EUEco-LabelAward N/A
AnnualEnergyConsumption 135kWh/annum
Freezing Capacity N/A
Fridge Storage Volume (Litre) and
Applicable Star Rating Compartment 335L
Freezer Storage Volume (Litre) N/A
Applicable Star Rating Compartment N/A
Refrigeration System (Frost Free, Static, Totally No Frost) Static
Temperature Rise Time N/A
Climate Class ST
This appliance is intended to be used at an ambient temperature between “16” (lowest temperature)
°C and “38”(highest temperature) °C
NoiseEmission(dB) 42dB
Built-in Appliance N/A
Wine Storage Appliance N/A
Voltage (V) 220-240V~
Wattage Power (W) 85W
Frequency (Hz) 50Hz
Power Source AC
Appliance Overview Internal light and
thermostat control
Door shelves
Lower door shelf
Salad drawer
Glass shelves
Adjustable feet

5
INSTALLATION
Location and Air Circulation
Theappliancemuststandverticallyonaat,evensurface,toleveltheapplianceusethelevelling
feet by turning them until the appliance is as level as possible.
Install the appliance in a well ventilated room with an average room temperature of between 16°C
and 38°C. The appliance is supplied with rear spacers, these are to be screwed to the rear of the
appliance to ensure enough ventilation at the rear of the appliance. The appliance should not be
placed near to sources of heat e.g. cookers, radiators, direct sunlight or in any unheated rooms e.g.
garages,orouthouses,asextremetemperatureswillaecttheperformanceofyourappliance.
Do not expose the appliance to damp conditions, open air or rain.
Do not lift the appliance by the pipes or the door when moving.
Neverplacetheapplianceinawallrecess,ttedcabinetorfurnitureasthiswillnotallowadequate
ventilationandcauseapotentialrehazard.Allow50mmofspaceatthesidesoftheappliance.
Never push the appliance against the wall, leave at least a 15mm gap. If the appliance is positioned
below an overhanging wall unit, the minimum distance between the top of the appliance and the
wall unit must be at least 100mm.
Providing you follow the recommended ventilation requirements you will:
• Increasethelifeoftheappliance.
•Minimisetheriskofcondensationontheoutsideoftheappliance.
•Minimiseoperatingnoisescausedbyvibration.
Door Fitting
Theappliancedoorcanbettedtoopentoeithertheleftor
the right depending on its location.
Ensuretheapplianceisunpluggedandempty.
1. Unscrewhingecover(g1).
2 Opendoorandunscrewthetophinge(g2). 
3. Remove door from appliance and store in safe place.
4. Removethecoverandscrewsontheleftsideandre-t
 ontherightside(g3).
5. Removethehingecover(g4).
6. With help, carefully lie down the appliance
 andremovethetwolevellingfeet(g5).
7. Unscrew the door hinge and left foot base. Caution! If there
 isascrewontheleftfrontcoverthenremoverstbefore
installing hinge.
8. Unscrew and remove bottom hinge pin, turn bracket over
 andreplace(g5).
Fig1.
Fig2.
Fig3.

6
9. Installhingeonleftsideandfootbaseontherightside.Retthelevellingfeetwith
 theiroriginalparts(g6).
10.Unscrewtophingepinandre-tontheleftside(g7).
11.Standtheapplianceupandputthedooronthebottomhinge.Re-ttheupperhingewiththe
door. Before tightening check all the seals, if all sealed properly then the hinge screws can
be tightened.
Note: Check that the door is aligned horizontally and vertically and that the seals are closed on all
sides before tightening the bottom hinge. Re-adjust the levelling feet to minimise operation noises
caused by vibration.
OPERATING INSTRUCTIONS
Before using your Appliance
• Allow12hoursbeforeturningontheappliancetoallowcoolantgasestimetosettleafterthe
appliance is in place. Failure to do this may result in damage to the appliance and such damage is
not covered by the guarantee.
• Beforeplacingfoodintheapplianceturnonandwait24hours,thisistomakesureitisworking
correctly and also to allow for the optimal internal temperature to be reached.
The interior of the appliance needs to be cleaned prior to use by wiping with a soft cloth and using
warm water. Wipe the appliance completely dry before replacing any shelves or salad drawers.
Using your Appliance
• Oncedry,plugtheapplianceintothemainssocket.
• Adjustthetemperaturecontrolwhichislocatedinsidetheapplianceto4,thisisthecorrect
setting to use in a room with an average ambient temperature of 20°C.
• Allowtheapplianceatleast24hoursbeforestoringanyfoodinsidetoallowforsucient
cooling temperature to be reached.
Adjusting the Temperature
The ideal internal temperature of your appliance should be between 0°C to 5°C. This is regulated
by the temperature control located internally at the top of the appliance. There are 6 settings on the
temperature control, with position 6 being the coldest setting, position 1 being the warmest setting
and0beingtheoposition.
The temperature control should be set to position 4 when operating at normal room temperature
(between 16°C and 38°C). Avoid setting the thermostat too high, as this may reduce the temperature
to a point where some foods begins to freeze. If this happens turn down the thermostat slightly.
Reverse Door
Fig4. Fig5. Fig6. Fig6.

7
The temperature in the appliances compartment can be monitored by using a fridge thermometer.
DONOTUSEaMercurylledthermometer,asabreakagewouldcauseahealthhazard.Your
appliance must NOT be placed in a room where the temperature goes below 16°C or above 38°C for
prolonged periods, as the internal appliance temperature will not be maintained.
Using your Appliance Eciently
•Avoidopeningthedoorforlongperiodsorunnecessarily.
•Tomaintainadequateaircirculation,donotoverlltheappliance.
•Allowhotorwarmfoodstocooltoroomtemperaturebeforestoringintheappliance.
Storing Food in your Appliance
•Packandstorecookedandfreshfoodseparately
•Wraprawordefrostingmeatsandpoultryinpolytheneorfoilandensuretheyarestored
below any cooked meats to avoid contamination from any juices that may drip.
•Keepfoodscoveredtohelpretainmoistureandtohelppreventodour.Plasticbags,aluminiumfoil
(heavy duty grade), plastic food wrap and containers with lids are ideal.
•Emptyleftovertinnedfoodintoplasticcontainers.Donotstorefoodsintinsintheappliance.
•Positionfoodintheappliancetoallowcoldairtocirculatefreely,makingsurethatnothing
touches the back wall of the appliance.
CLEANING AND MAINTENANCE
Switchotheelectricalsupplyandremovetheplugfromthemainssocketbeforecleaning.
Interior
1. Remove all food from the appliance and cover to help keep cool.
2. Remove all the shelves and salad crisper carefully from the appliance and wash in warm soapy
water with a soft cloth and dry thoroughly. Never replace the shelves or salad crisper into the
appliance if wet.
3. Wipe the interior of the appliance with a damp clean cloth. For extra cleaning use a solution of one
teaspoon of bicarbonate of soda to one pint of water.
4. Dry the interior thoroughly with a clean cloth and replace the shelves.
5. Plug in and switch on and allow the temperature in the appliance to drop back to an adequate
temperature.
6. Replace the food in the appliance.
NOTE: Avoid getting water into the electric components of the appliance i.e. the thermostat, as this
may damage your appliance.
Exterior
Use a clean, damp soft cloth to wipe the exterior surface of the appliance and dry thoroughly.
WARNING: Do not use abrasive cloths, powders, household cleaners, bleach or wax polish to
clean the appliance as these can leave a smell in the appliance and can damage the exterior. Use
a vacuum cleaner to remove dust from underneath the appliance and from around the compressor
which is situated at the back of the appliance, regularly to maintain adequate ventilation. Use
caution not to damage the coolant system.
Door Seal
Use a clean, damp soft cloth to wipe the door seal and in between the creases, avoid damaging the
doorsealasthiswillaecttheperformanceofyourappliance.

8
Drainage Channel
The drainage channel must be cleaned regularly to prevent a build-up of impurities; this can be
found on the interior back wall of your appliance. Use a damp clean cloth and wipe the channel
clean,thenuseapipecleanerorsimilarexibleobjecttocleanthedrainageholetoprevent
blockages.
Going away
Ifyouaregoingawayanddonotwanttoleavetheapplianceswitchedon,switchoatthesocket
and remove the plug from the mains socket ensuring not to pull the cord. Remove any food and
follow the cleaning instructions in the “Cleaning and Maintenance” section.
Note: Leave the door ajar as this will prevent odours and mould accumulating in the appliance and
will allow the appliance to dry completely.
Power Cut
In the event of a power cut keep the appliance door closed to maintain the temperature inside.
Bulb Replacement
TheinternalLightisLED,itisadvisedtocontactaqualiedelectriciantoreplacethebulb.
Operating Sounds
Youmaynoticesomeunusualnoisesfromyourappliance,theseareperfectlynormal,butyou
should be aware of them.
The compressor can make a buzzing or humming sound when it is running. This can be louder
whentheapplianceisrstswitchedonbutshouldbecomequieterinafewmonths.Gasesowing
through the cooling systems can cause gurgling, bubbling or similar sounds. These noises are
normalandhavebecomemorepronouncedsincetheintroductionofCFCfreegases.Expansion
and contraction of parts inside the appliance can produce a cracking noise as they rapidly change
temperature.
Fuse Replacement
This appliance must be earthed. There are 3 screws on
the plug, remove them and open the shell. Take out fuse
and replace with a new fuse of the same Amp. Install the
shell again and tighten the screws.

9
Troubleshooting
If you are having problems with your appliance, please use our troubleshooting guide below. If you
are unable to resolve the issue using this guide please ring our Customer Service Department on
01473 271 272. Please have the model code, batch number and purchase information available.
Appliance does
not work
Temperature regulation knob
is set at number “0”.
Mains plug is not plugged in
or is loose
Insert mains plug.
Fuse has blown or is defective Check fuse, replace if necessary.
Socket is defective Mains malfunctions are to be
corrected by an electrician.
Temperature is not properly
adjusted.
Door was open for an extended
period.
Open the door only as long as
necessary.
A large quantity of warm food
was placed in the appliance
within the last 24 hours.
Turn the temperature regulation
to a colder setting temporarily.
The appliance is near a heat
source.
Please look in the installation
location section.
Temperature is set too cold. Turn the temperature regulation knob
to a warmer setting temporarily.
Appliance is not level. Re-adjust the feet.
The appliance is touching the
wall or other objects.
Move the appliance slightly.
Water drain hole is blocked. See the Cleaning and care section.
It’s normal. Heat exchange parts
are in the sides.
Use gloves to touch sides.
A component, e.g. a pipe, on the rear
of the appliance is touching another
part of the appliance or the wall.
If necessary, carefully bend the
component out of the way.
Set the knob at other number to
switch on the appliance.
Fault Possible cause Solution
The food is too
warm.
Please look in the initial
Temperature setting section.
Appliance cools
too much
Unusual noises
Waterontheoor
Side panels are hot.
Disposal
TheEuropeanDirective2012/19/EUonWasteElectricalandElectronicEquipment
(WEEE),requiresthatoldhouseholdelectricalappliancesmustnotbedisposedofin
normal unsorted municipal waste.
Old appliances must be collected separately in order to optimise the recovery and
recycling of the materials they contain and reduce the impact on human health and
the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance it must be separately collected.
Consumers should contact their local authority or retailer for information concerning
the correct disposal of their old appliance.

10
Statesman Warranty Terms & Conditions
This product is guaranteed for a period of 12 months as standard from the date of purchase
againstmechanicalandelectricaldefects.Youcanextendyourwarrantyforafurther12months
by registering your product.
Upon registration we will cover your product for a period of 24 months from the original purchase
date against any mechanical or electrical defects.
To qualify for the guarantee, the product must be used for domestic household use only and in
accordance with the instructions in the user manual. Any misuse of the product will result in the
warranty being void.
The guarantee does not cover accidental damage, misuse, neglect, tampering or incorrect
adjustment or installation.
The guarantee will be rendered invalid if the product is resold, has had its serial number removed
(or has an invalid serial number), or if an unauthorised person has carried out any repairs or
alterations.
The warranty does not cover accessories or consumable parts that require replacement under
normaluse.Thisincludesshelving,dials,lters,beltsandtraysetc.
In the unlikely event of a breakdown please refer to the Troubleshooting guide in your user manual
and check all plugs, fuses and the electricity supply.
If you still require assistance please contact our Customer Service department on
0844 8485860 or write to us at the following address:
Customer Service Department
Pik-a-Pak Electrical Distributors
38 Bluestem Road, Ransomes Europark
Ipswich, IP3 9RR
Please quote the serial number and give details of the exact fault. We will then decide whether to
repair or replace the item.
Before we arrange the repair or replacement you will be required to return a copy of your proof
of purchase. Please retain your original.
If an item is replaced within the agreed guarantee period, the guarantee for the replacement item
will be calculated from the purchase date of the original.
In the event that the product is inspected and no fault is found or the product is not within the
guarantee period you will be charged for the repair and any carriage costs.

11
Thank you for choosing Statesman
AsavaluedcustomerwewouldliketooeryouaFREE2yearwarrantytocoveryourproduct
against any electrical or mechanical defects.
This means that in the unlikely event you develop a fault or problem with your product we will
happily repair or replace the item free of charge.
To qualify for the 2 year warranty you must register your product within 30 days of purchase. The
full Terms & Conditions of our warranty policy are shown on the opposite page. They are also
available on our website. www.igenix.co.uk
To register your product, please complete all sections of the form below and return to us at the
followingaddress:StatesmanAppliances,Pik-a-PakElectricalDistributors,38BluestemRoad,
RansomesEuropark,Ipswich,IP39RR.
Alternatively you can visit the Statesman website and complete the form online.
www.statesmanappliances.co.uk
Customer Details:
Title: First Name Surname:
Address:
Post Code:
Email:
Telephone:
Product Information:
Product Code: Product Description:
Batch Number (Beginning 5): Serial Number (If applicable):
Date of Purchase:
Retailer Name:
Retailer Location:
PleasetickheretoconrmyouhavereadandacceptourTerms&Conditions
Please tick here if you DO NOT wish to receive marketing information from us
Customer Signature: Date:
