Steelcraft click & go User manual

0 - 9kg
(newborn -6 months approx.)
IMPORTANT KEEP THIS BOOKLET IN A SAFE
PLACE FOR FUTURE REFERENCE
SERIES PB8346 | britax.com.au
Compatible with Strider SignatureV5,Strider Mini Signature,
Gravity Signature,One2 and One2V2.
(All products are sold separately)

02 |
WARNINGS IMPORTANT NOTES:
• Click & Go™ Signature Bassinet is designed to t Strider
Signature, Strider Mini Signature, Gravity Signature and
One 2 strollers.
• Remove the stroller seat or baby capsule from the frame
before tting the bassinet.
• Always remove your child from the bassinet before tting
or removing the bassinet from the stroller frame.
• The bassinet must always face towards
the handle.
• The bassinet must be removed from the frame
before folding.
• Do not lift the stroller by the bassinet.
• The Click & Go™ Bassinet is designed to comply with:
AS/NZS 8811.1:2013 “Methods of testing infant products.
Method 1: Sleep surfaces – Test for rmness”
EN 1466:2014/AC:2015 “Safety requirements and test methods for
child use and care articles – Carry cots and stands”
• DO NOT USE THE BASSINET ONCE THE
CHILD CAN SIT UP.
• IT IS UNSAFE TO USE ACCESSORIES NOT
APPROVED FOR USE WITH THIS STROLLER.
• DO NOT USE ANY ACCESSORIES OTHER
THAN THOSE APPROVED FOR USE WITH
THIS STROLLER BY BRITAX.
• THE MAXIMUM WEIGHT OF THE CHILD USING
THIS PRODUCT IS NOT TO EXCEED 9KGS.
Warnings & Important Notes

CLICK & GO BASSINET | 03
Lift & Carry Correctly
The SMART lifting technique: This technique can be
used to pick up small light loads from low levels.
Size up the load
• Assess the load (size, shape, and weight).
• Assess whether the load needs to be moved;
• Where is it going to be placed” Check that there are no
obstructions;
• Assess whether mechanical or human assistance is required.
Move the load as close to the body as possible
• A load is heavier to lift or carry if it is not close to the body.
• The whole hand should be used to ensure a rm grip.
Always bend your knees
• Maintain balance.
• Keep feet apart and in a comfortable position.
• Minimise lower back bending.
• Bend knees preferable at as large an angle as possible
but not at a right angle - use a semi-squat in preference
to a full squat.
Raise the load with your legs
• Achieve the lift smoothly and without jerkiness.
• Maintain the normal curvature of the spine to allow the
force of the load to be distributed evenly from the spine
to the pelvis.
Turn your feet in the direction that you want to
move the load.
• Avoid unnecessary bending, twisting, and reaching.
• Change direction by turning your feet and not your back.
• To set the load down, squat down, keep your head up and
let your legs do the work.
Remember to THINK TALL - chest lifted, shoulders
relaxed, chin tucked in, and head level.

04 |
What’s in the Box: Parts
1 x Bassinet Frame 1 x Bassinet Liner
1 x Bassinet Boot Cover 1 x Bassinet Mattress with Removable
Reversible Seasonal Cover
Compatible with:
• Strider SignatureV5
(with Click & Go™ Adaptors - included with stroller)
• Strider Mini Signature
• One 2V2
(with Click & Go™ Adaptors; contact our customer
service team for availability)
• Gravity
(with Click & Go™ Adaptors; contact our customer
service team for availability)
IMPORTANT NOTE: For the most up to date
compatibility please refer to our compatibility list at:
britax.com

CLICK & GO BASSINET | 05
Bassinet Features
Sun visor
Carry handle
Ventilation panel
Bassinet liner
Mattress
Body bands
Bassinet
release
lever
Viewing window
Canopy
adjuster
buttons
Bassinet
connectors

06 |
4x
Bassinet Assembly
Opening the Bassinet Canopy Opening the Bassinet Frame
ARotate the canopy to
the upright position by
pressing in and holding
the canopy adjuster
buttons on both sides.
APull the bassinet
frame support rods
outward by the
straps until each
rod slides and locks
under all 4 clips.
Push down lightly
on the top edges
of the bassinet to
ensure that the
frame support rods
are rmly locked in
place.
BPress down on the
base of the bassinet
& pull up on the
canopy handle to
raise the sides.
A
B
A

CLICK & GO BASSINET | 07
Bassinet Assembly
Attaching the Liner Inserting the Mattress
APlace the liner in the
bassinet and attach the
hook and loop around the
bassinet.
APlace the mattress
into the bassinet. Place
the body band on the top
surface of the mattress.
A A

08 |
Bassinet Operation
Using the Canopy Attaching the Boot Cover
AFasten 3 canopy hook
tabs to the base located
on the rear and both
sides of the canopy.
Press the canopy
adjuster buttons on both
sides and to rotate the
canopy to the desired
position.
APlace the bassinet
boot cover over the
bassinet and snap the
press studs on each side
of the boot cover to the
each side of the canopy.
BThere is a viewing
window for ventilation
and observation.
A
A
B
CAUTION: ENSURE THE CANOPY
IS SECURELY ENGAGED BEFORE YOU LIFT THE
BASSINET BY THE HANDLE.

CLICK & GO BASSINET | 09
Bassinet Operation
Attaching the Bassinet to the Stoller Removing the Bassinet from the Stroller
AAlign the bassinet
directly over the
Click & Go adaptors
and push down until
it locks.
Pull up on the
bassinet to ensure it
is locked.
AHolding and lifting the
bassinet release buttons
on both sides and lift the
bassinet up and away
from the stroller.
A
A
IMPORTANT NOTE:
• Always remove your baby from the bassinet
before installing or removing the bassinet.
• Always remove the bassinet before folding.
PLEASE NOTE: The bassinet can only be installed rearward
position (parent facing) on the stroller frame. Must use each
compatible stroller with correct Click & Go adaptors.

10 |
Bassinet Operation
Using the Body Band Using the Ventialtion Panel
APlace the mattress
into the bassinet. Place
the body band on the top
surface of the mattress.
Place the baby band
around the baby’s
abdomen close to
the body without
constricting the baby
and carefully fasten the
two sides of the body
band with the hook and
loop strips.
AUnzip the zippers on
both sides to reveal the
ventilation mesh.
BFasten the ventilation
panel with hook and loop.
AA
B
TIP: The body band can be used for additional safety.
TIP: The ventilation panel can be opened to cool and
provide more air ow to the baby.

CLICK & GO BASSINET | 11
Bassinet Operation
Attaching the Rain Cover Attaching the Sun Shade
AFit the rain cover over
the canopy and pull to
the front then secure
with elasticised end.
A
A
B
IMPORTANT NOTE:
• Ensure the rain cover is kept away from
the child’s face.
• Ret the rain cover if required to ensure
your child is safe.
Sold Separately Sold Separately
AFit the sun shade over
the canopy front and
secure the toggle and
elastic loop around the
canopy frame then pull
to the front and secure
with elasticised end.
BLift the sun shade
cover ap to use mesh
panel for ventilation and
open zipper to access
the baby.

12 |
Care & Maintenance
General Maintenance & Repair
• Ensure all safety devices, locks, harness, and brakes are in
working order.
• Ensure all joints and folding areas move freely as intended.
• Should any moving or locking parts become stiff or hard to
operate, ensure these are free from tension, or dirt by wiping
clean with a damp cloth to remove any dirt, sand, or debris.
Allow to dry and lightly spray with a dry silicon lubricant. Please
carefully read the lubricant instructions prior to use.
• Ensure wheels are regularly cleaned with a damp cloth by
removing dirt, sand, or debris. Allow to dry and lightly spray
the wheel pivot pin with a dry silicon lubricant to keep the
wheels moving smoothly. Please carefully read the lubricant
instructions prior to use.
• Regularly spray all moving parts with a dry silicon lubricant.
Please carefully read the lubricant instructions prior to use.
• Ensure all connecting rivets and screws are secure.
Tighten if required.
• If there are compression marks on the tyres, use a domestic
hair dryer to gently warm (DO NOT OVERHEAT) the tyre and the
compression marks should slowly disappear.
• To maintain the safety and longevity of the stroller, seek prompt
repairs or replacement for bent, torn, worn, or broken parts. Do
not continue to use the stroller if unsafe.
• All repairs should only be carried out by an authorised Britax/
Steelcraft repairer. Only Britax/Steelcraft replacement parts
should be used with the stroller. It may be unsafe to use parts
supplied from another manufacturer.
General Tips
Do not store the stroller in your car for prolonged periods of time
during summer as it may lead to damage to some of the plastics
components.
Do not leave the stroller in direct sunlight for extended periods
of time, as colours of some fabrics may fade, and tyres may
deteriorate.
Do not fold or store the stroller if damp or wet, as fabric may
develop mould or mildew. Always store the stroller inside in a dry,
well-ventilated area.
Do not place heavy objects on top of the stroller as it may alter
the shape.
Should you have any further questions on care & maintenance
of the stroller, please contact our Consumer Service Team at:
[email protected]
Care & Maintenance
Cleaning
Fabrics
• Removable fabrics may be cleaned using lukewarm water and
soap or mild detergent. Rinse thoroughly and allow to dry away
from direct sunlight.
• Non-removable fabrics can be spot cleaned using a damp
sponge and soap or mild detergent. Allow to dry completely
before re-use or storage.
• Never use bleach, or abrasive cleaning products.
• DO NOT iron or dry clean.
NOTE: DO NOT place any of the stroller fabrics in the dryer. Allow
to dry naturally, away from direct sunlight.
Frame
• Remove dirt and dust away from any moving mechanism.
• Clean frame with a soft damp cloth and soap or mild detergent
and allow to dry thoroughly.
• DO NOT use abrasive cleaning products as it may cause stains,
discolouration or scratches to the frame.
• DO NOT soak or submerge frame in water.
• DO NOT remove, dismantle or alter any part of the stroller
mechanism or brakes.
Leatherette
• Spot clean with a damp soft cloth.
• DO NOT use a dripping wet cloth or wet the
leatherette excessively.
Wheels
• Remove wheels from stroller.
• Clean with damp cloth and soap or mild detergent. Use brush
to remove dirt and mud build up around the tyre. Allow to dry
thoroughly before placing wheels back on the frame.
• If necessary lubricate wheel shaft with a small amount of
lubricant before placing into the stroller.
• Ensure the stroller is cleaned thoroughly after using it on the
beach as sand and salt can damage stroller mechanism, wheel
assembly, causing premature wear and corrosion.
PLEASE NOTE:
Our product warranty does not cover any rust to the rivets or
screws, if you are caught in the rain or at the beach always
thoroughly dry the frame to avoid any rust damage.

CLICK & GO BASSINET | 13
Care & Maintenance
General Maintenance & Repair
• Ensure all safety devices, locks, harness, and brakes are in
working order.
• Ensure all joints and folding areas move freely as intended.
• Should any moving or locking parts become stiff or hard to
operate, ensure these are free from tension, or dirt by wiping
clean with a damp cloth to remove any dirt, sand, or debris.
Allow to dry and lightly spray with a dry silicon lubricant. Please
carefully read the lubricant instructions prior to use.
• Ensure wheels are regularly cleaned with a damp cloth by
removing dirt, sand, or debris. Allow to dry and lightly spray
the wheel pivot pin with a dry silicon lubricant to keep the
wheels moving smoothly. Please carefully read the lubricant
instructions prior to use.
• Regularly spray all moving parts with a dry silicon lubricant.
Please carefully read the lubricant instructions prior to use.
• Ensure all connecting rivets and screws are secure.
Tighten if required.
• If there are compression marks on the tyres, use a domestic
hair dryer to gently warm (DO NOT OVERHEAT) the tyre and the
compression marks should slowly disappear.
• To maintain the safety and longevity of the stroller, seek prompt
repairs or replacement for bent, torn, worn, or broken parts. Do
not continue to use the stroller if unsafe.
• All repairs should only be carried out by an authorised Britax/
Steelcraft repairer. Only Britax/Steelcraft replacement parts
should be used with the stroller. It may be unsafe to use parts
supplied from another manufacturer.
General Tips
Do not store the stroller in your car for prolonged periods of time
during summer as it may lead to damage to some of the plastics
components.
Do not leave the stroller in direct sunlight for extended periods
of time, as colours of some fabrics may fade, and tyres may
deteriorate.
Do not fold or store the stroller if damp or wet, as fabric may
develop mould or mildew. Always store the stroller inside in a dry,
well-ventilated area.
Do not place heavy objects on top of the stroller as it may alter
the shape.
Should you have any further questions on care & maintenance
of the stroller, please contact our Consumer Service Team at:
[e-mail]
Care & Maintenance
Cleaning
Fabrics
• Removable fabrics may be cleaned using lukewarm water and
soap or mild detergent. Rinse thoroughly and allow to dry away
from direct sunlight.
• Non-removable fabrics can be spot cleaned using a damp
sponge and soap or mild detergent. Allow to dry completely
before re-use or storage.
• Never use bleach, or abrasive cleaning products.
• DO NOT iron or dry clean.
NOTE: DO NOT place any of the stroller fabrics in the dryer. Allow
to dry naturally, away from direct sunlight.
Frame
• Remove dirt and dust away from any moving mechanism.
• Clean frame with a soft damp cloth and soap or mild detergent
and allow to dry thoroughly.
• DO NOT use abrasive cleaning products as it may cause stains,
discolouration or scratches to the frame.
• DO NOT soak or submerge frame in water.
• DO NOT remove, dismantle or alter any part of the stroller
mechanism or brakes.
Leatherette
• Spot clean with a damp soft cloth.
• DO NOT use a dripping wet cloth or wet the
leatherette excessively.
Wheels
• Remove wheels from stroller.
• Clean with damp cloth and soap or mild detergent. Use brush
to remove dirt and mud build up around the tyre. Allow to dry
thoroughly before placing wheels back on the frame.
• If necessary lubricate wheel shaft with a small amount of
lubricant before placing into the stroller.
• Ensure the stroller is cleaned thoroughly after using it on the
beach as sand and salt can damage stroller mechanism, wheel
assembly, causing premature wear and corrosion.
PLEASE NOTE:
Our product warranty does not cover any rust to the rivets or
screws, if you are caught in the rain or at the beach always
thoroughly dry the frame to avoid any rust damage.

14 |
We recommend servicing your
stroller every 6 months and
completing an inspection once a
month. To prolong the life of your
stroller, a regular maintenance
should be performed.
5 STEP CHECK LIST
01 INSPECT SAFETY DEVICES tether strap, frame lock,
harness, buckle and brakes, and ensure all are in
working order and free from dirt, sand, and debris.
02 INSPECT all connecting rivets and screws are secure.
03 MAKE SURE FOLDING JOINTS are free of dirt, dust, and
debris by cleaning with a damp cloth, allow to dry and
lightly spray with a dry silicon lubricant. Please carefully
read the lubricant instructions prior to use.
04 REMOVE WHEELS and wipe clean with a damp cloth to
remove any dirt, sand or debris. Allow to dry and lightly
spray the wheel pivot pin with a dry silicon lubricant to
keep the wheels moving smoothly. Please carefully read
the lubricant instructions prior to use.
05 ENSURE WHEN FOLDING AND STORING to wipe down
your stroller frame and allow to dry before storing in a
dry place without direct sunlight.
Service every
6 Months
Inspect
Monthly
RECOMMENDATION
Just like servicing your car or bicycle,
prams and strollers also need regular
maintenance checks. These checks
can improve product performance,
extend the life of your stroller and help to
provide you and your children a safe and
smooth journey.
Care & Maintenance
Warranty
Making A Warranty Claim
Your rights under a Britax company warranty are separate from and independent
of your rights under the statutory consumer guarantees. What you need to do to
enforce your rights under a statutory consumer guarantee is set out in the
Australian Competition and Consumer Commission’s Consumer Guarantees -
A Guide for Consumers.
To make a claim under a Britax company warranty, please contact our customer
service team on:
Australia: 1300 303 330 / New Zealand: 0508 688 822 or alternatively by email at:
Australia: [e-mail] / New Zealand: nzo [e-mail]
You will be required to :
• Return the product to the place of purchase or to a designated repair agent;
• Present your receipt as proof of purchase;
• Identify the defect in the product; and
• Present the product to Britax for inspection on request.
Britax will advise you whether the product is covered by the Britax company
warranty. Britax’s decision of whether a product is covered by a Britax company
warranty is fi nal. Britax will act reasonably when determining whether a product
is covered by a company warranty.
Did you know?
Registering your product online simplifi es
proof of purchase in the event of a
warranty claim.
Head to our website to fi ll out the product
registration form: britax.com.au

CLICK & GO BASSINET | 15
We recommend servicing your
stroller every 6 months and
completing an inspection once a
month. To prolong the life of your
stroller, a regular maintenance
should be performed.
5 STEP CHECK LIST
01 INSPECT SAFETY DEVICES tether strap, frame lock,
harness, buckle and brakes, and ensure all are in
working order and free from dirt, sand, and debris.
02 INSPECT all connecting rivets and screws are secure.
03 MAKE SURE FOLDING JOINTS are free of dirt, dust, and
debris by cleaning with a damp cloth, allow to dry and
lightly spray with a dry silicon lubricant. Please carefully
read the lubricant instructions prior to use.
04 REMOVE WHEELS and wipe clean with a damp cloth to
remove any dirt, sand or debris. Allow to dry and lightly
spray the wheel pivot pin with a dry silicon lubricant to
keep the wheels moving smoothly. Please carefully read
the lubricant instructions prior to use.
05 ENSURE WHEN FOLDING AND STORING to wipe down
your stroller frame and allow to dry before storing in a
dry place without direct sunlight.
Service every
6 Months
Inspect
Monthly
RECOMMENDATION
Just like servicing your car or bicycle,
prams and strollers also need regular
maintenance checks. These checks
can improve product performance,
extend the life of your stroller and help to
provide you and your children a safe and
smooth journey.
Care & Maintenance
Warranty
Making A Warranty Claim
Your rights under a Britax company warranty are separate from and independent
of your rights under the statutory consumer guarantees. What you need to do to
enforce your rights under a statutory consumer guarantee is set out in the
Australian Competition and Consumer Commission’s Consumer Guarantees -
A Guide for Consumers.
To make a claim under a Britax company warranty, please contact our customer
service team on:
Australia: 1300 303 330 / New Zealand: 0508 688 822 or alternatively by email at:
Australia: [email protected] / New Zealand: nzo [email protected]
You will be required to :
• Return the product to the place of purchase or to a designated repair agent;
• Present your receipt as proof of purchase;
• Identify the defect in the product; and
• Present the product to Britax for inspection on request.
Britax will advise you whether the product is covered by the Britax company
warranty. Britax’s decision of whether a product is covered by a Britax company
warranty is fi nal. Britax will act reasonably when determining whether a product
is covered by a company warranty.
Did you know?
Registering your product online simplifi es
proof of purchase in the event of a
warranty claim.
Head to our website to fi ll out the product
registration form: britax.com.au

16 |
Warranty
Australian Consumer Law
On all of our goods, you have the benefi t of a statutory
consumer guarantee. In summary, goods are guaranteed to be
of “acceptable quality” (fi t for purpose), goods are guaranteed to
match any sample against which they are sold. These consumer
guarantees are provided for by the Australian Consumer Law
and, if you believe any one of these guarantees is not satisfi ed
by a Britax product, you have rights under the Australian
Consumer law to enforce that guarantee.
Your rights under the statutory consumer guarantees are set
out in the Australian Competition and Consumer Commission’s
Consumer Guarantees - A Guide for Consumers.
In addition to the statutory consumer guarantees, Britax
offers its own company warranty on all of its products. You
therefore have the option of seeking redress for defective or
faulty product either under the Britax company warranty or the
statutory guarantees.
After the Britax company warranty expires, you still have your
rights under the statutory consumer guarantees.
Depending on the product involved, the Britax company
warranty on the following page applies:
Warranty
Steelcraft Warranty
Steelcraft products are covered by this company warranty
against faulty materials and workmanship (normal wear and tear
excluded) that affects the normal operation of your Steelcraft
product. In the unlikely event that you fi nd that your Steelcraft
product does not satisfy this warranty, Britax will (at its option)
repair or replace that product within a reasonable period of you
making a claim in accordance with this policy.
In the event that a replacement product is no longer available,
Britax reserves the right to provide what it considers to be a
suitable alternative.
For this company warranty to apply, you must make an
application before the expiration of the following periods
from date of purchase*.
This company warranty does not apply to second hand or after
market goods or goods used for rental, hire or other commercial
purposes or to any claim where the damage or fault is, in whole
or part, the result of incorrect installation, mistreatment,
intentional damage, any use other than use in normal conditions
or any use otherwise than in accordance with the instruction
manual for that product.
Please read your instruction manual carefully before using any
of our products.
INTERNATIONAL WARRANTY
Britax products are available through a network of retailers in
Australia and New Zealand. If you are an international customer
we do not offer a warranty service outside of these regions.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE
2 years on Steelcraft strollers and
Steelcraft stroller accessories.*

CLICK & GO BASSINET | 17
Warranty
Australian Consumer Law
On all of our goods, you have the benefi t of a statutory
consumer guarantee. In summary, goods are guaranteed to be
of “acceptable quality” (fi t for purpose), goods are guaranteed to
match any sample against which they are sold. These consumer
guarantees are provided for by the Australian Consumer Law
and, if you believe any one of these guarantees is not satisfi ed
by a Britax product, you have rights under the Australian
Consumer law to enforce that guarantee.
Your rights under the statutory consumer guarantees are set
out in the Australian Competition and Consumer Commission’s
Consumer Guarantees - A Guide for Consumers.
In addition to the statutory consumer guarantees, Britax
offers its own company warranty on all of its products. You
therefore have the option of seeking redress for defective or
faulty product either under the Britax company warranty or the
statutory guarantees.
After the Britax company warranty expires, you still have your
rights under the statutory consumer guarantees.
Depending on the product involved, the Britax company
warranty on the following page applies:
Warranty
Steelcraft Warranty
Steelcraft products are covered by this company warranty
against faulty materials and workmanship (normal wear and tear
excluded) that affects the normal operation of your Steelcraft
product. In the unlikely event that you fi nd that your Steelcraft
product does not satisfy this warranty, Britax will (at its option)
repair or replace that product within a reasonable period of you
making a claim in accordance with this policy.
In the event that a replacement product is no longer available,
Britax reserves the right to provide what it considers to be a
suitable alternative.
For this company warranty to apply, you must make an
application before the expiration of the following periods
from date of purchase*.
This company warranty does not apply to second hand or after
market goods or goods used for rental, hire or other commercial
purposes or to any claim where the damage or fault is, in whole
or part, the result of incorrect installation, mistreatment,
intentional damage, any use other than use in normal conditions
or any use otherwise than in accordance with the instruction
manual for that product.
Please read your instruction manual carefully before using any
of our products.
INTERNATIONAL WARRANTY
Britax products are available through a network of retailers in
Australia and New Zealand. If you are an international customer
we do not offer a warranty service outside of these regions.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE
2 years on Steelcraft strollers and
Steelcraft stroller accessories.*

18 |
Notes

CLICK & GO BASSINET | 19
Notes

Britax Childcare Pty. Ltd.
A.B.N. 55 006 773 600
Level 4, 650 Lorimer Street, Port Melbourne, Victoria 3207, Australia
Phone: [phone] Fax: [phone]
Customer Service
Australia: 1300 303 330 / New Zealand: 0508 688 822
Due to our continuing program of development, Britax reserves the right to alter the
specications, color or design without any further notice.
The Steelcraft trademark is the property of Britax Childcare Pty.Ltd - Australia.
The Britax trademark is the property of Britax Childcare Holdings Limited - UK.
Visit the Britax website at: www.britax.com.au or email us at [email protected]
Due to the variations in the style and design of our products the illustrations used in this
instruction booklet are generic.
This product is designed to comply with:
AS/NZS 8811.1:2013 “Methods of testing infant products. Method 1: Sleep surfaces – Test
for rmness”
EN 1466:2014/AC:2015 “Safety requirements and test methods for child use and care
articles – Carry cots and stands”
Copyright © 2021 Britax Childcare Pty. Ltd. Australia
Art No. 4002314/B
