Steljes Audio Calliope User manual

Calliope
HIGH PERFORMANCE
TV SOUNDBAR
Steljes Calliope Product Manual EM.indd 1 25/01/2016 11:50

2Steljes Audio . Calliope User Guide
Steljes Calliope Product Manual EM.indd 2 25/01/2016 11:50

Steljes Audio . Calliope User Guide 3
CONTENTS
Important Information ..................................................... 4
Wiring Information .......................................................... 6
Wall Mounting .............................................................. 8-9
Trouble Shooting.........................................................10-11
Hook Up Diagram....................................................... 12-15
Controls and Function .................................................... 16
Remote Control.............................................................. 17
Limited Warranty ........................................................... 18
Specifications................................................................. 19
Calliope
HIGH PERFORMANCE
TV SOUNDBAR
Beautifully engineered
& designed in Great Britain
Steljes Calliope Product Manual EM.indd 3 25/01/2016 11:50

4Steljes Audio . Calliope User Guide
ATTENTION
The owner’s manual contains important operating and
maintenance instructions, for your safety, it is necessary
to refer to the manual.
DANGEROUS VOLTAGE
Conductor dangerous voltage, that may be of sufficient
magnitude to constitute a risk of electric shock to persons is
present within this product’s enclosure.
Important InformatIon
SAFETY INSTRUCTIONS
• Do not use this product near water or
moisture
• Do not install near any heat sources
• Clean only with a dry cloth. Unplug this
product from the wall outlet
• Do not attempt to service this product
yourself.
• Opening or removing covers may expose
you to dangerous voltages or other
hazards.
• Please contact the manufacturer to be
referred to an authorized service center
near you.
• Do not block any ventilation openings.
• To prevent risk of fire or electric shock,
avoid over loading wall outlets,
• Do not let objects or liquids enter the
product.
• Protect the power cord from being
walked on or pinched, particularly at
plugs and the point where they exit from
the product.
READ BEFORE OPERATING EQUIPMENT
Read all the instructions carefully before
using the unit and keep them for future
reference.
Steljes Calliope Product Manual EM.indd 4 25/01/2016 11:50

Steljes Audio . Calliope User Guide 5
POWER SOURCES
• This audio system is designed to operate
on 230 volts 50Hz, AC current. The main
plug is used as the disconnect device
and should remain readily accessible. To
prevent electric shock, do not use the
soundbar’s mains cable with an extension
cord, receptacle, or other outlet unless
the blades and ground terminal can be
fully inserted to prevent blade exposure.
Never connect the audio system to 60 Hz
DC, or anything other than the specified
voltage.
DISPOSAL
• In the EU, electronic devices cannot
be disposed of with regular household
waste. Please use the return or collections
systems of the retailer from whom you
purchased the soundbar. Please dispose
of batteries in an environmentally friendly
manner. Do not dispose of batteries with
regular household waste. Please use
the return or collections systems of the
retailer from whom you purchased the
soundbar.
CAUTION
• Never remove the back covers of the
soundbar as this can expose you to very
high voltages and other hazards. If the
system does not operate properly, unplug
the audio system and call your authorised
dealer or service centre for advice. Adjust
only those controls that are covered in
the instructions.
WARNING
• To reduce the risk of fire or electric shock,
do not expose this soundbar to rain or
moisture.
• The system should not be exposed to
dripping or splashing and objects filled
with liquids, such as vases, should not be
placed on the system.
• This soundbar should only be connected
to a mains socket outlet with a protective
earthing connection.
ELECTRICAL INFORMATION
• This system is fitted with a BS1363/A
13 amp plug. If it is not suitable for your
supply sockets it must be removed and
replaced with an appropriate plug. If the
plug becomes damaged and/or needs
to be replaced please follow the wiring
instructions below. The plug removed
must be disposed of immediately. It must
not be plugged into a supply socket as
this will be an electrical hazard. If the
fuse needs to be replaced it must be of
the same rating and ASTA approved to
BS1362. If the plug is changed, a fuse of
the appropriate rating must be fitted in
the plug, adapter or at the distribution
board. If the fuse in a moulded plug is
replaced, the fuse cover must be refitted
before the appliance can be used.
WIRING INSTRUCTIONS
• Follow the appropriate wiring instructions
given below. In both cases ensure that
the outer sheath of the cable is firmly held
by the cable clamp.
Steljes Calliope Product Manual EM.indd 5 25/01/2016 11:50

6Steljes Audio . Calliope User Guide
WIrIng InstructIons
Follow the appropriate wiring instructions given below.
In both cases ensure that the outer sheath of the cable is
firmly held by the cable clamp.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
The lightning flash with arrowhead symbol, within an equilateral triangle,
is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the soundbar’s enclosure that may be of a sufficient
magnitude to constitute a risk of electric shock.
2 - CORE PLUG
WarnIng!
Do not connect either wire to the earth terminal.
This symbol indicates that this
2-core appliance is Class II and
does not require an earth connection.
The wire coloured blue must be
connected to the terminal marked with
the letter N or coloured black.
The wire coloured brown must be
connected to the terminal marked with
the letter L or coloured red.
Blue
(Neutral)
Fuse
Brown
(Live)
WarnIng! This appliance must be earthed.
3 - CORE PLUG
The wire coloured green and yellow
must be connected to the terminal
marked with the letter E, or by the earth
symbol or coloured green or green
and yellow. The wire coloured blue must
be connected to the terminal marked
with the letter N or coloured black.
The wire coloured brown must be
connected to the terminal marked with
the letter L or coloured red.
Blue
(Neutral)
Fuse
Brown
(Live)
Green &
Yellow
(Earth)
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT PLUG A CABLE INTO A WALL
OUTLET, EXTENSION CORD, OR OTHER RECEPTACLE UNLESS THE METAL BLADES
CAN BE FULL Y INSERTED TO PREVENT BLADE EXPOSURE.
cautIon
rIsk of electrIc shock do not open!
Steljes Calliope Product Manual EM.indd 6 25/01/2016 11:50

Steljes Audio . Calliope User Guide 7
KEY FEATURES
• The Calliope TV Sound Bar is designed to provide a high quality alternative to the
loudspeakers in your flat-panel TV. To this end it has HDMI inputs, optical digital, analogue,
and Bluetooth aptX inputs. The Bluetooth input allows you to stream music content direct
from your mobile, laptop or tablet wirelessly, straight to the Calliope . The Calliope TV
Sound Bar is designed to mount either on a desktop or on a wall with the supplied wall
mount fixings.
• The Calliope TV Sound Bar is suitable for use with any size of TV where its compact size
and styling should unobtrusively complement your TV and the room décor.
ADVANCED TECHNOLOGIES IN THE CALLIOPE TV SOUND BAR
• Wider Sound Stage: The Calliope TV Sound Bar features an acoustic design utilising 2x 2.5
inch base drivers, 2x 2.5 inch broadband drivers and 2x passive membranes. It provides for
3x DSP presets of Movie, Music and Voice, each tailored to provide what we believe to be
the best possible performance in each programme category.
• The inputs available on the Calliope TV Sound Bar should accommodate all TVs currently
available, with 2x HDMI inputs and 1x HDMI output (with ARC), analogue (3.5mm stereo
input), optical (Stereo) input and Bluetooth aptX (for wireless connectivity).
Steljes Calliope Product Manual EM.indd 7 25/01/2016 11:50

8Steljes Audio . Calliope User Guide
• Determine how you want to set up your Calliope TV Sound Bar Soundbar.
• The Calliope TV Sound Bar Soundbar is supplied with wall fixings. The input jacks and
power cord are designed to allow a flush mount.
MOUNTING YOUR CALLIOPE SOUND BAR
• Measure the width of the TV - the Calliope TV Sound Bar should be mounted so it
is centered with the TV. Divide the TV width measurement by 2 - that will be the
centerline distance from the edges of the TV.
• If the Calliope TV Sound Bar is to be mounted below the TV, measure from the TV
edge to the centerline distance on the open wall below the TV. Mark an appropriate
distance below the bottom of the TV.
• Make a mark 230 mm on each side of the centerline. Make sure the mark is the same
distance down from the TV on each side.
• Drill a hole in the wall at either of the two marks.
• Hammer the 2 wall mount anchors into the holes - the anchors should be flush with
the wall.
• Now, using a Phillips screwdriver, screw the wall screws into the anchors.
• Tilting the bottom of the Calliope TV Sound Bar slightly away from the wall, guide the
exposed screw heads into the matching holes on the back of Calliope. The Calliope
TV Sound Bar is now securely wall mounted.
Wall mountIng
remove all?
Steljes Calliope Product Manual EM.indd 8 25/01/2016 11:50

Steljes Audio . Calliope User Guide 9
1. Find centerline
of TV.
3. Make a pencil
mark on each side
of centerline.
X/2” X/2”
++
230 mm 230 mm
2. Make a pencil mark
38mm or more below
the bottom of TV.
38mm
or more
X”
+
++ +
230 mm 230 mm
38mm
or more
30mm
4. Make another pencil mark
on each side of centerline.
Wall mountIng dIagram
Steljes Calliope Product Manual EM.indd 9 25/01/2016 11:50

10 Steljes Audio . Calliope User Guide
If you encounter problems when using the Calliope TV Sound Bar, check the following
points before requesting a service.
In order to keep the warranty valid, please DO NOT attempt to repair the system yourself.
Note: due to EEC regulations this product will switch to standby mode as follows
The Calliope switches to standby mode in the following situation:
The device is idle for 30mins when powered by AC supply;
The L/R Audio in or 3.5mm jack is disconnected or when there is no input signal or the
input signal is too low.
If using the 3.5mm jack input to Calliope, we recommend to default the output volume
at 75% or above on the external devices to ensure that it does not automatically go into
standby mode.
1. No power
- Make sure power cords are securely connected to the AC output.
- Make sure that there is power at the AC output.
- Press the power button on the remote control or the front of the Calliope .
2. No audio
- Press the Volume + (Up) button on the remote control or the front of the Calliope.
- Make sure that you selected correct input (Input 1, Input 2, or Input 3).
- Press MUTE on the remote to make sure the Calliope TV Sound Bar is not muted.
- Make sure audio cables are securely connected at the terminals of the Calliope and
the external devices.
trouble shootIng
Steljes Calliope Product Manual EM.indd 10 25/01/2016 11:50

Steljes Audio . Calliope User Guide 11
3. Buzzing or humming noise
- Make sure audio cables are securely connected at the terminals of the Calliope and the
external devices.
- Test on an alternate device or replace the audio cable.
- Test the device and cable on an alternate input on the Calliope .
4. The remote control is not functioning
- Aim the remote control directly at the sensor on the front of the Calliope .
- Reduce the distance between the remote control and the Calliope .
- Make sure that the battery is inserted with its polarities (+/– signs) aligned as indicated.
- Replace the battery.
5. The sound bar and remote are not responsive
- Unplug the power cord from the AC output, and plug back in after a few seconds.
Steljes Calliope Product Manual EM.indd 11 25/01/2016 11:50

12 Steljes Audio . Calliope User Guide
TV/DVD/Set Top Box Hookup - Option 1 HDMI ARC
HDMI with ARC - Use this output to connect your Calliope to your TV. Please note if
your TV is not ARC (Audio Return Channel) enabled you will not be able to connect
this way - if this is the case, please refer to either case 2 or 3 below.
TV
HDMI Cable
To HDMI (ARC)
connection of TV
Calliope TV Sound Bar Rear Connectors
To HDMI (ARC) connection
of Calliope TV Sound Bar
connectIon optIons
Steljes Calliope Product Manual EM.indd 12 25/01/2016 11:50

Steljes Audio . Calliope User Guide 13
Satellite/Freeview
TV
HDMI Cable
To any HDMI enabled device
Calliope TV Sound Bar Rear Connectors
From HDMI (ARC) connection of
Calliope TV Sound Bar to HDMI
input (non ARC) on TV
To HDMI inputs of Calliope TV
Sound Bar
HDMI Cable
TV/DVD/Set Top Box - Option 2 HDMi
HDMI Inputs 1 & 2 - Use these inputs to connect any HDMI enabled device - you will also
have to connect an HDMI lead via ARC to your TV as this will act as an output to stream
video to your TV.
connectIon optIons
Steljes Calliope Product Manual EM.indd 13 25/01/2016 11:50

14 Steljes Audio . Calliope User Guide
To Input 3 (Optical)
of Calliope TV
Sound Bar
Optical Cable
To Audio Output
Other Device
Blu-ray Players
DVD Players
CD Players
Home Video
Game Systems
TV or Other Device Hookup - Option 3 Optical
Optical Input – Use this input to connect a TV (as above) or any other device such as
a DVD or CD player or games console.
connectIon optIons
Steljes Calliope Product Manual EM.indd 14 25/01/2016 11:50

Steljes Audio . Calliope User Guide 15
IMPORTANT SET UP NOTE
If you are using Option 3, you will need to change the output signal from the source device -
this will be accessed in the sources menu and will need to be changed to either Stereo, 2.1 or
PCM dependant on the terminology used in the source device.
3.5 mm Mini Stereo
Cable (Supplied)
To Headphone
output of TV
Calliope TV Sound Bar Rear Connectors
To Input 2 (Mini Stereo
jack) of Calliope TV
Sound Bar
TV
TV Audio Hookup - Option 4 Auxiliary
If your TV has a headphone output, plug a 3.5 mm mini stereo cable into the headphone
output from your TV and plug the other end to the Input 2 jack on the back of your Calliope.
connectIon optIons
Steljes Calliope Product Manual EM.indd 15 25/01/2016 11:50

16 Steljes Audio . Calliope User Guide
Front Panel Controls / LED Indicators
1. REMOTE CONTROL Sensor Area
Point your remote control at this area
when you use the remote control.
2. POWER Button
The Calliope TV Sound Bar goes to the
standby mode. Press this button to
turn the Calliope TV Sound Bar on; this
Power indicator will turn off to indicate
the Calliope TV Sound Bar is on. If the
input becomes inactive the Calliope TV
Sound Bar will change to standby mode
to conserve power and this indicator
will illuminate.
3. VOLUME + Button
Adjust the main volume up respectively.
4. VOLUME - Button
Adjust the main volume down
respectively
.
1
5 6 432
5. Mode Button
Press this button to select DSP
mode for Movies, Music or Voice.
6. SOURCE Button
Press this button to scroll through
the inputs.
controls and functIons
Steljes Calliope Product Manual EM.indd 16 25/01/2016 11:50

Steljes Audio . Calliope User Guide 17
POWER
Press this button
to turn the Calliope
TV Sound Bar on
or off.
MODE
This button is used
to select one of the
three presets DSP
programmes, MOVIE,
MUSIC or VOICE.
MUTE
Press this button when
you want to activate the
audio mute. Press it again
to deactivate the mute
function.
INPUT SELECTOR
Press this button to scroll
through the inputs
MAIN VOLUME
Press the + or - button to
adjust the main volume
up or down respectively.
Remote Control
remote control
Steljes Calliope Product Manual EM.indd 17 25/01/2016 11:50

18 Steljes Audio . Calliope User Guide
lImIted Warranty
LIMITED WARRANTY
This product had been designed and
manufactured to the highest quality
standards; however, should you encounter
any problems with this product please
contact your local dealer or your country
distributor.
This limited warranty is valid for the original
owner for a period of one year from the date
of purchase, it is not transferable.
What is covered by the limited warranty:
The limited warranty covers all production
and material defects of the product, except
for the specifics stated below.
What is not covered by the limited
warranty:
Damage caused by packing and transport.
Defects caused by accidents, misuse, normal
wear and tear, mis-maintenance, voltage
variation and overloading.
Damage caused by incorrect installation or
operation. Damage caused by modification
or repair by a non-authorized service centre
and use of non-original spare parts.
Other damage due to conditions beyond the
supplier’s control such as fire, rain, war and
other force majeure events.
How to claim parts or repair under warranty:
To have your product serviced under
warranty, you must contact the dealer from
whom the product was purchased.
You will need to produce this warranty
booklet completed and stamped by your
dealer on the date of purchase.
Alternatively, you will need the original sales
invoice or other proof of ownership and date
of purchase.
The supplier is liable only to repair or replace
defective parts of products and the supplier
is not responsible for indirect losses or
damage arising from the use of the product.
Transportation costs for servicing are not
covered by the warranty.
A service repair or replacement cannot
exceed the value of the product under
warranty; in no event shall the supplier be
responsible or liable for special, incidential,
consequential or indirect damage.
Steljes Calliope Product Manual EM.indd 18 25/01/2016 11:50

Steljes Audio . Calliope User Guide 19
Steljes Calliope TV Sound Bar
2 x 2.75 Inch Mid-High Ferrite Magnet Drivers
2 x 2.75 Inch Bass Ferrite Driver
2 x Passive Bass Radiators
Analogue 3.5mm Stereo Jack In
HDMI In x 2, HDMI Out (ARC) x 1
Bluetooth aptX A2DP
Wall Mount Kit
60W Power Output
3 DSP Settings
Class D Amplifiers
Dimensions: 89 x 850 x 80mm (H x W x D)
Power Input AC 230-240V 50Hz
servIce & support
Please contact your local authorised dealer or reseller.
Email: [email protected]
All information contained in this guide herein may change without notice
and is provided on an “AS IS” basis, without warranties of any kind. Steljes
Audio reserves the right to change specifications without notice. Images and
Photos are for illustration only and actual product may vary. E&OE.
specIfIcatIons
Steljes Calliope Product Manual EM.indd 19 25/01/2016 11:50

www.steljesaudio.co.uk
Steljes Calliope Product Manual EM.indd 20 25/01/2016 11:50
