stellar labs SEA14 User manual
Coffee Machine Page 1
AUTHENTIC ESPRESSO AND CAPPUCCINO
Coffee Maker
Instruction Manual
Model No. SEA14
Please read this instruction
manual carefully before use
and save for later reference.
Unpack your Stellar Coffee
Maker carefully and remove
packing pieces.
Coffee Machine
Page 2
2
345
6
7
8
1. Cup
warming
plate
2. Control knob
3. Steam switch
4. OFF switch position
5. Power & heat switch position
6. Power & heat ON indicator light
7. Pump switch position
8. Pump ON indicator light
9. Vari-steam control -
Clockwise MIN
Anti-clockwise MAX
10. Water tank and base control valve (SEA14WT)
11. Steam tube (SEA14ST)
12. Bayonet housing for filter and pod handle
13. Filter handle (SEA14FH)
14. Drip tray cover (SEA14DT)
15. Drip tray (SEA14DT)
16. Float indicator (SEA14DT)
17. Power cable and plug
18. Measuring spoon (SEA14MS)
19. Coffee tamper (SEA14T)
20. Coffee outlets
21. Flow control spacer
22. Coffee container (SEA14CC)
23. Pod handle, ESE Pod system (SEA14PH)
Identifying the parts
(With Part Numbers for
customer replaceable items)
1
29
10
Base control valve
11
12
13
14
15
16
17
18
19
20
21
TWO ESPRESSO
COFFEE CUPS
(SEA14CC)
MAX COFFEE
LEVEL
22
23
Coffee Machine Page 3
Before rst use
Before first use or after long storage the
coffee maker should be flushed through.
• Site the coffee maker on a level stable
surface - the rubber feet should all fully
contact the surface to ensure stability.
• Slide the water tank
10
upwards and
remove. Fill to the MAX level shown
on the casing with cold water. Replace
water tank, ensuring the valve at base is
properly seated.
• Lock-in the filter handle
13
by twisting it
anti-clockwise into the
bayonet housing
12
.
• Turn the steam control
9
clockwise to
MIN.
• Set the control knob
2
to OFF setting
4
.
• Plug the power cable
17
into your socket
(check your supply is compatible with the
Rating Information - page 8).
• Turn the control knob
2
to power &
heat setting
5
. The water in the boiler
will start to heat.
• Place a heat proof jug under the steam
tube
11
.
• Rotate steam control knob
9
anti-
clockwise to MAX.
• Wait a few minutes for the water to
boil, then turn control knob
2
to pump
switch position
7
- water will flow from
the steam tube
11
.
• After cleaning return the control knob
2
to power and heat ON setting
5
, and steam control knob
9
clockwise
to MIN.
• Place the heat proof jug under the filter
handle
13
.
• Turn the control knob
2
to pump switch
position
7
and water will flow from the
filter handle
13
.
• Return the control knob
2
to power and
heat ON setting
5
.
How to use
Making coffee
The cup warming plate
1
will become
warm as the coffee maker heats - stand the
clean, dry cups on this plate before brewing.
Using Ground Coffee
• Fill the water tank
10
to the MAX mark.
• Start heating the water by turning the
control knob
2
to power and heat
switch position
5
. The warning light
6
indicates that the thermostat is
controlling the temperature of the water.
• Add ground coffee to the coffee
container
22
using the measuring spoon
18
and tamp down using the tamper
19
, following the MAX level mark.
The strength of the Espresso depends
upon how tightly the ground coffee is
compacted in the coffee container. If it
takes more than just a few minutes for
the coffee brew to flow into the cups,
then the ground coffee has either been
ground too finely, or has been compacted
too tightly in the filter.
• Load the coffee container
22
into the
filter handle
13
. Lock-in the filter handle
13
by twisting it anti-clockwise into the
bayonet housing
12
.
• Place a cup on the centre of the drip tray
cover
14
.
Before first use (Continued)
Coffee Machine
Page 4
• When the pump ON indicator light
8
is GREEN the temperature is correct for
Espresso - turn the control knob
2
to
pump switch position
7
, and after a
short time Espresso will pour from the
coffee outlets
15
into the cup: stop the
pouring by turning the control knob
2
to power & heat switch position
5
, and
remove the cup. Repeat if more than 1
cup is desired.
• Having made your Espresso, gradually
loosen the filter handle
13
by carefully
turning it clockwise. Remove the coffee
container
22
and dispose of the contents.
Wash through with cold water before
returning to the filter handle
13
.
NOTE
•
A ‘fail-safe’ mechanism prevents boiling
dry when the water tank is empty - just
unplug the machine, remove the water
tank and refill
.
Using Coffee Pods
Your coffee maker can make Espresso
using 44mm Easy Serving Espresso (ESE)
pods, available from all good multiple
stores. These provide an exact dose of
correctly ground coffee, pre-weighed and
pressed between two layers of filtering
paper. The method of use is very similar to
that for ground coffee, so the instructions
are summarised below, with only the
differences described in detail.
• Fill the Water Tank
10
to the MAX level.
• Remove the ESE pod from its external
wrapping and place in the receptacle in
the centre of the pod handle
23
.
• Lock-in the pod handle
23
to the bayonet
housing, as described in detail under “
Before first use”.
Espresso (Continued)
• Place a cup on the centre of the
Drip Tray
14
.
• Follow the rest of the instructions for
Using ground coffee, except the pod
handle
23
is used instead of the filter
handle
13
.
Milk Frothing
For Cappuccino or latte
• Turn the control knob
2
to steam
switch position
3
: note that the pump
indicator light
8
will be OFF, confirming
that the machine is heating for steam.
(It is normal for a small spurt of steam to
escape during initial heating)
.
• Place an empty heat-resistant jug under
the steam tube
11
and turn the steam
control
9
anti-clockwise (MAX). A
little water, followed by a strong jet of
steam will be emitted from the steam
tube
11
. Turn the steam control knob
9
clockwise (MIN) and dispose of contents.
• Place a heat-proof jug containing milk to
be frothed under the steam tube
11
.
• CAUTION: TAKE PRECAUTIONS TO
AVOID SCALDING FROM HOT WATER
AND STEAM DISCHARGED.
• Immerse the steam tube
11
in the jug of
milk close to the bottom and slowly turn
the steam control knob
9
anti-clockwise until the desired volume of
froth is achieved by varying the postion
of the steam tube
11
in the cup. (Ensure
that the pump ON indicator light
8
is
ON when frothing the milk).
• Return the steam control knob clockwise
(MIN).
Coffee Machine Page 5
Steam tube
11
• Hold the black rubber sleeve on the
steam tube and turn clockwise which will
unscrew the complete lower part of the
steam tube.
• Wash this assembly under running water.
• Reassemble by gently screwing back on
anti-clockwise.
Water tank
10
• Periodically remove, clean the inside
with a cloth or sponge, rinse and replace.
Check that the water control valve in the
base of the water tank
10
is operating
properly - water should flow smoothy
when the central plunger of the valve is
pushed upwards.
Periodic de-scaling
To ensure the lasting quality of your
espresso maker it is important to regularly
de-scale the system. It is suggested to run
this procedure every 2 months for hard
water areas and up to 6 months for soft
water areas:
1. Mix 1 x tablet of Stellar descaling tablets
(SSDT) with 1Ltr of water, or Mix 125ml
of de-scaler (Please use a crystal based
product, that is suitable for aluminium
thermo blocks) and 1 litre of fresh water
into the empty water tank
10
. (or follow
instructions of your de-scaling product)
2. Rotate the control knob
2
to setting
5
power & heat position. Allow to heat for
3 minutes.
Making further shots of Espresso
• If you are making more Espresso directly
after frothing milk, any superheated
water in the system must be expelled as it
could spoil the brew.
• Put an empty jug under the filter handle
13
and turn the control knob
2
to pump
switch position
7
.
• When residue water is fully expelled you
are ready to make your Espresso.
Cleaning
• The coffee maker should be regularly
cleaned.
• Before cleaning the coffee maker ensure
that it is disconnected from the electrical
supply, and the whole machine is cool.
• Never immerse the whole machine in
water.
Drip tray
15
• The tray should be emptied whenever
necessary - the float indicator
16
rises
to denote that the tray is full. The tray
and drip tray cover
14
should regularly
be removed and washed in warm soapy
water.
Handles
13
&
23
and coffee container
22
• Check that the fine holes in the coffee
container
22
are not clogged: a small
brush can be used to clear any remaining
grounds, and the handle can then be
rinsed under a cold tap. If the small hole
in the flow control spacer
21
is clogged
it may be cleaned with a pin. Then check
that the rim of the filter handle and
the underside of the top flange of the
filter are clean and will seat perfectly,
reassemble the coffee container
22
into
the filter handle
13
, and rinse.
Coffee Machine
Page 6
2. Check there is sufficient water in the
water tank
10
and it is seated properly.
3. If this is not effective repeat the
“de-scaling” instructions.
C.Coffee overowing from the Filter
bayonet connection.
1. Too much ground coffee may have been
placed into the filter basket, preventing
proper tightening of the bayonet
connection. When the machine has
cooled remove the grounds, refill to the
MAX mark on the inside of the filter and
remake the Espresso.
2. Coffee grounds residue may have
collected on the top ring of the filter
13
or the bayonet housing
12
. Clean with a
wooden cocktail stick.
3. If this is not effective repeat the
“de-scaling” instructions.
D.Coffee is dispensed slowly or not
at all.
1. Check there is sufficient water in the
water tank
10
and it is seated properly.
2. Allow the machine to cool, and unplug
from mains. Repeat the instructions
given previously for - Regular cleaning of
filter handle and filter, Steam tube, and
water tank (page 5).
3. If this is not effective repeat the
“de-scaling” instructions..
E. Coffee is watery and cold.
1. The coffee may have been ground too
coarsely - try a finer ground coffee and
tamp down as instructed in ‘Making
coffee - Espresso’ directions.
If any of the problems persist please
return to Stellar at the address given in
the Warranty section
3. Rotate the control knob
2
to setting
7
to start the pump and let 1/3 of the water
run through the machine. Then rotate
the control knob
2
back to setting
5
to
stop the pump and rest for 10 minutes.
4. Place a suitable container under the
steam tube
11
, rotate the control knob
2
to setting
3
steam switch, and
rotate the Vari-steam control
9
to max.
Let another 1/3 of the water run through
the machine, Return the control knob
2
to setting
5
and leave to rest for a
further 10 minutes
5. Rotate the control knob
2
to setting
7
to start the pump and let the remaining
water run through the machine. Then
rotate the control knob
2
back to
setting
4
to switch off the machine.
6. Rinse out the water tank and fill with
fresh water and repeat the above
procedures. This will thoroughly clean
through the system, ensuring your
espresso maker will last the test of time.
Troubleshooting
A.The coffee maker does not supply
hot water.
1. Check there is sufficient water in the
water tank
10
and it is seated properly.
2. There may be an air-lock in the water
system. Repeat the ‘Before first use’
instructions.
3. If this is not effective repeat the
“de-scaling” instructions.
B.No steam.
1. When the machine is unplugged and
cool, remove and clean the steam tube
11
.
Periodic de-scaling (Continued)
Coffee Machine Page 7
Cautions
Please read these Caution notes before
first use and keep them for reference by
future users.
• Hot steam and boiling water can cause
burns: protect your hands/face when
when the coffee maker is in operation.
• Do not immerse the coffee maker, cable
or plug in water - risk of electric shock.
• Not suitable for use by children or infirm
people: take extra care using the coffee
maker when children are present.
• Ensure the power supply corresponds
with the appliance rating, as stated in
this manual.
• Plug into the power socket before
switching on the appliance. After use,
switch off, and then unplug.
• Do not let the cable hang over edge of
the table or worktop, or let it contact hot
surfaces.
• Place the coffee maker on a flat and level
surface, and do not place it on or near
other heat sources such as an electric
cooker.
• Condensation can collect under the
base of the machine - protect precious
surfaces.
• Always unplug from the power socket
and allow the machine to cool before
cleaning.
• The coffee maker should only be used for
its stated purpose in accordance with the
instruction booklet.
• Do not use the coffee maker outdoors or
in a humid environment.
• Do not use the coffee maker near a wall,
cupboard or soft furnishings, or where
escaping steam could cause damage.
• Extreme caution should always be taken
when moving an appliance containing
hot liquids.
• Do not leave the coffee maker
unattended during use.
• If the unit develops a fault, or the cable
is damaged, please contact Stellar
Customer Services for advice. Do not
attempt to repair the appliance yourself.
• The unit is designed for Domestic Use
only.
Coffee Machine
Page 8
The Stellar Guarantee covers the product to be free of
defects in materials and workmanship for a period of TWO
YEARS from the date of original retail purchase. During this
period, Stellar will, at our option, repair or replace defective
parts of the product, or replace the product, providing the
Use, Care and Safety Advice has been followed.
Stellar 2 Year Domestic Electrical Guarantee
YEAR
GUARANTEE
DOMESTIC
ELECTRICAL
USE
STELLAR
The Guarantee does not cover damage, defect or failure caused by or resulting from
accidents, external damage, alteration, modification, abuse, misuse or misapplication.
The Guarantee does not cover any damage caused by taking the appliance apart
yourself, or attempting to repair the appliance yourself.
THE PRODUCT IS INTENDED FOR DOMESTIC USE ONLY.
Please keep your Purchase Receipt and contact us directly if you encounter any
problems with your product.
HORWOOD SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT (INCLUDING COLOUR
FADING, SCRATCHES OR ACCUMULATED DIRT) WITHOUT FOLLOWING THE USE,
CARE & SAFETY INSTRUCTIONS.
Note: Due to the introduction of improvements from time to time, the right
is reserved to supply products which differ slightly from those illustrated and
described in this publication.
Errors and Omissions Excepted.
STELLAR CUSTOMER SERVICES, HORWOOD, AVONMOUTH WAY,
BRISTOL, BS11 9HX, GREAT BRITAIN
www.stellarcookware.co.uk
Tel: 0117 940 0000
Specication
Name Model No. Power Supply Wattage
Coffee Maker SEA14 220-240v / 50Hz 800W
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and collection systems or contact
the retailer where the product was purchased. They can take this product for environmental
safe recycling.
FOR DOMESTIC USE ONLY
THIS PRODUCT
MUST BE EARTHED.
Table of contents
