Stenograph LUMINEX User manual

i
2019 Stenograph, L.L.C. All Rights Reserved. i
Luminex Users Guide
Release: August 2019, February 2019, October 2018, August 2018, March 2018, April
2017, September 2016, April 2016, January 2016, November 2015, August 2015.
Copyright 2018, Stenograph, LLC. All Rights Reserved.
Stenograph. Adjustable LCD Screen Assembly for Writing Machine. U.S. patent
7,403,375, filed May 27, 2005, and issued July 22, 2008.
This material is protected by law, including the Copyright Act of 1976 and is not to be
copied, reproduced, modified, sold, stored or transmitted in any form or by any means
(electronic, mechanical, photocopy, recording or otherwise), or used in any other manner,
without the prior written permission of Stenograph.
STENOGRAPH PROPRIETARY: This material constitutes proprietary and trade secret
information of Stenograph and shall not be disclosed to any third party, nor used by the
recipient, except under the terms and conditions of the purchase agreement between the
customer and Stenograph.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes may be made periodically to the information in this publication. Such changes will
be incorporated in any new edition of this manual.
Stenograph is a Pettibone Company.
Luminex, Case CATalyst, CATalyst, EasyLock, Diamante, TrueStroke Technology, élan
Mira, Stentura Fusion, SmartWriter, Stentura, Stenograph logo and Stenograph are
trademarks and registered trademarks of Stenograph.
Windows is a registered trademark of Microsoft Corporation in the United States and other
countries.
SanDisk is a registered trademark of SanDisk Corporation.
The SD logo is a trademark of Toshiba Corporation.
All other trademarks are the property of their respective owners.

ii
2019 Stenograph, L.L.C. All Rights Reserved. ii
Luminex Users Guide
Congratulations
We strongly encourage you to read this User Guide and practice using your writing machine
according to the instructions contained therein. This will allow you to become comfortable and
familiar with it before taking it on a job or into class.
The Luminex is equipped with a full-color high resolution LCD touch screen for viewing steno
or text and to interact with what is displayed.
The Luminex comes with a built-in rechargeable battery. Advanced battery technology
prevents the battery from overcharging so you don’t have to worry about leaving the writer
plugged into an electrical outlet for extended periods of time.
EasyLock™ LMX V2 tripod positioning with a positive-locking mechanism provides smooth
and easy setup. Simply open and set the tripod on the floor and place your machine on it
according to the instructions in this guide. The design of the tripod assures a smooth, even
writing platform for you to enjoy. A tilt-mechanism enables the writer to be tilted 70 degrees
forward and backwards to suit your personal preference.
Weighing in at only 3.5 pounds, the Luminex lightens your load when carrying it from place to
place.
Remember to check the Stenograph® web site, www.stenograph.com, for updates to the
Luminex. The Luminex was designed with you in mind. We are confident you’ll enjoy using it!
STENOGRAPH

iii
2019 Stenograph, L.L.C. All Rights Reserved. iii
Luminex Users Guide
Stenograph believes that the Luminex shorthand machine, when used in compliance with the
enclosed instructions and information, is safe. Certain sources, though controverted, suggest a
relationship between injuries of the hands and forearms with prolonged use of any type of keyboard or
other equipment involving repetitive movements of the hands. At the same time, other sources
indicate that there is no such cause and effect.
The safety and well-being of persons using Stenograph equipment is of paramount concern and
because we recognize that these medical and scientific questions are not definitively resolved,
Stenograph encourages all users of our writers to carefully review the following Work Area Checklist
and to use appropriate work habits. Remember, personalizing your environment so that it is
comfortable for you, promotes a healthy physical and mental work lifestyle.
The following Work Area Checklist is not intended to be all inclusive but a guideline for you to use.
Only you can determine what is best for you. Use the checklist to assess and adjust your work area
to suit your own needs. Personalizing your environment so that it is comfortable for you promotes a
healthy physical and mental work lifestyle.
At Your Luminex
- Use a comfortable chair conducive to correct posture.
- Adjust the height of the shorthand machine appropriately for your body.
- Position the shorthand machine comfortably close to you.
- Place the tripod between your knees. Do not sit “sidesaddle”.
- Minimize the use of the shorthand machine on surfaces other than the tripod stand.
At Your Computer
-Place the monitor screen perpendicular to the window to help avoid glare.
- Adjust or close window coverings.
- Arrange materials such as reference books or a telephone close to you to help avoid excessive
reaching or twisting.
- Clear the area under and around the desk to leave room for your feet and legs.
- Remove sources of distraction around the monitor.
- Keep noise to a minimum.
- See accompanying materials provided by the computer keyboard manufacturer.
Your Body
- Take frequent breaks to stretch or exercise.
- Maintain a straight wrist position.
- Avoid resting your wrists while writing.
- Keep your hands level with your forearms.
- Let your fingers curve naturally.
- Let your forearm go up and down a little when you write, pivoting at the elbow, not at the wrists.
- Pull your steno machine comfortably close to you.
- Keep your feet on the floor or supported by a footrest.
- Support your lower back.
- Assure that your knees are bent at an angle of 90° or more and your thighs at an angle of 90°
or greater in relation to your torso.
- Adjust the chair position and your posture throughout the day.
- If you experience any aching, numbing, or tingling in your arms, wrists, or hand, consult a qualified
health care professional.
The Importance of Working Comfortably and Effectively

iv
2019 Stenograph, L.L.C. All Rights Reserved. iv
Luminex Users Guide TABLE OF CONTENTS
View of the Luminex 1
Chapter 1 Introduction 2
Luminex Feature Details ..................................................................................................... 3
User Guide Overview .......................................................................................................... 4
Chapter 2 Hardware 5
Battery ................................................................................................................................. 6
Charging the Battery ..................................................................................................... 6
Turning the Luminex On and Off ................................................................................... 6
Battery Charging Procedure .......................................................................................... 7
Viewing Battery Charging Procedures .......................................................................... 7
View Battery Voltage Level ........................................................................................... 8
Low Battery Warnings ................................................................................................... 8
Battery Gauge ............................................................................................................... 9
Battery Messages ......................................................................................................... 9
Communication Ports ....................................................................................................... 10
Powering with the USB Cable ...................................................................................... 11
Updating with the USB Cable ...................................................................................... 11
Connect for realtime writing ....................................................................................... 11
Micro USB Cable Communications .............................................................................. 12
USB Virtual Serial Port Communications ..................................................................... 13
Wireless Communication ............................................................................................ 14
Function Sensors ............................................................................................................... 15
Touch Screen ..................................................................................................................... 16
Keyboard Depth and Tension Controls ........................................................................... 17
Reset ................................................................................................................................... 19
Secure Digital (SD) Cards .................................................................................................. 20
Secure SD Care ............................................................................................................ 20
Enable Writing on a SD Card ....................................................................................... 21
Remove or Insert a SD Card ........................................................................................ 21
USB SD Flash Drive Reader ......................................................................................... 21
Status LCD .......................................................................................................................... 23
Tilting Color Touch Screen ............................................................................................... 24
Cleaning the Tilting Screen ......................................................................................... 24
Tripod ................................................................................................................................. 25
Adjusting the Tripod Height ........................................................................................ 26
Tilting the Luminex ...................................................................................................... 26

v
2019 Stenograph, L.L.C. All Rights Reserved. v
Luminex Users Guide TABLE OF CONTENTS
Removing the Tripod ................................................................................................... 26
Routine Maintenance ....................................................................................................... 27
Chapter 3 Writing on the Luminex 29
Accessing Luminex Features ............................................................................................. 30
Writing Menu .................................................................................................................... 31
Writing Jobs ....................................................................................................................... 33
A/An Resolution ................................................................................................................ 35
About ................................................................................................................................. 36
Audio .................................................................................................................................. 37
Audio Hardware Setup ................................................................................................. 37
Audio Options .............................................................................................................. 37
Audio Playback ............................................................................................................ 39
Auto-Conflict Resolution .................................................................................................. 40
Backup SD Card ................................................................................................................. 41
Format the Backup Card .............................................................................................. 41
View Files on the Backup SD Card .............................................................................. 42
Brief It ................................................................................................................................. 43
Managing Briefs .......................................................................................................... 44
Use Brief It .................................................................................................................. 45
Brief It Options ............................................................................................................ 46
Copy Log ............................................................................................................................. 48
Data SD Card ...................................................................................................................... 49
Format a SD Card ......................................................................................................... 49
Manage Data SD Card Space ...................................................................................... 49
Check the Data SD Card Space .................................................................................... 50
Change the Data SD Card ............................................................................................ 50
View and Copy Data SD Card Files .............................................................................. 50
Dictionaries ........................................................................................................................ 52
Load Dictionaries on the Luminex ............................................................................... 52
Using Job Dictionaries ................................................................................................. 53
Electronic Marks ................................................................................................................ 55
J-Defines ............................................................................................................................. 56
Create J-Defines .......................................................................................................... 56
Create J-Defines Using the Power Define ................................................................... 57
Create J-Defines Using Spell Mode ............................................................................. 58
Write All J-Defines to Data SD Card ............................................................................ 59
Clear All J-Defines ....................................................................................................... 60

vi
2019 Stenograph, L.L.C. All Rights Reserved. vi
Luminex Users Guide TABLE OF CONTENTS
Spell Mode ......................................................................................................................... 61
Lower and Upper case letters ..................................................................................... 62
Punctuation and Format Symbols ................................................................................ 63
Numbers ...................................................................................................................... 64
Job Statistics ...................................................................................................................... 65
View Job Statistics ....................................................................................................... 65
Keyboard Settings ............................................................................................................. 67
Keyboard Adjustments ................................................................................................ 67
Individual Key Adjustments ......................................................................................... 69
Keyboard Profiles .............................................................................................................. 71
Load a Keyboard Profile .............................................................................................. 71
New View ........................................................................................................................... 72
Memory .............................................................................................................................. 73
View and Copy Memory Files ...................................................................................... 73
Clear Memory .............................................................................................................. 74
Information .................................................................................................................. 74
Options ............................................................................................................................... 75
Language ..................................................................................................................... 75
Keyboard Layout .......................................................................................................... 76
USB Communication .................................................................................................... 76
Beeper Volume ............................................................................................................ 77
Function Keys (touch sensors) during job ................................................................... 77
Prompt to End Job ........................................................................................................ 78
Clear J-defines when turning on/ending job ............................................................... 78
Display Strokes Per Minute (SPM) Option ................................................................... 79
TrueStroke ................................................................................................................... 79
Reopen ............................................................................................................................... 81
Search ................................................................................................................................. 83
Search for Last Question ............................................................................................. 83
Search for Last Answer ................................................................................................ 83
Search for Last Mark ................................................................................................... 83
Search for Steno Strokes .............................................................................................. 84
Search for Last Untranslate ......................................................................................... 84
Scroll - Using Menus .......................................................................................................... 86
Scroll - Using Touch Screen .............................................................................................. 87
Serial Protocol ................................................................................................................... 89
Steno Test .......................................................................................................................... 90
Status ................................................................................................................................. 91

vii
2019 Stenograph, L.L.C. All Rights Reserved. vii
Luminex Users Guide TABLE OF CONTENTS
Suffix Handling .................................................................................................................. 92
Test Mode .......................................................................................................................... 93
Thumb Drive ...................................................................................................................... 94
Tilting Screen Appearance ............................................................................................... 95
Set Tilting Screen Text Colors ..................................................................................... 95
Select Tilting Screen Font Size ..................................................................................... 96
Set the Tilting Screen Backlight Level ......................................................................... 96
Time and Date ................................................................................................................... 98
Translate Options .............................................................................................................. 99
WiFi Communications ..................................................................................................... 100
To Establish WiFi Communications ........................................................................... 100
To Turn WiFi On or Off .............................................................................................. 102
To Manage Your WiFi Connection ............................................................................. 102
WiFi Options .............................................................................................................. 103
Chapter 4 Troubleshooting 105
Luminex Technical Support ............................................................................................ 110
Appendix A Updating Luminex Software 111
Appendix B Luminex Utilities 113
Stenograph Writer Utility Program ............................................................................... 114

1
2019 Stenograph, L.L.C. All Rights Reserved. 1
Luminex Users Guide View of the Luminex

2
2019 Stenograph, L.L.C. All Rights Reserved. 2
Luminex Users Guide Chapter 1 Introduction
Chapter 1, Introduction, highlights the features of your Luminex, describes typographical conventions
used in this guide and outlines the organization of this guide.
Package Contents:
Your new Luminex comes with the following items:
· Carrying case
· EasyLock™ LMX V2 tripod
· 110/220 AC adapter/charger
· 1 Data SDHC card, (8 GB)
· 1 Backup Micro SDHC card, (8 GB)
· USB SD Flash Drive reader
· Micro USB cable (6 ft.)
· Optical-quality spray cleaner and cleaning cloth
· Stenograph One-Year Commercial Warranty document
· Let Us Help You Get Started insert.

3
2019 Stenograph, L.L.C. All Rights Reserved. 3
Luminex Users Guide Chapter 1 Introduction
Luminex Feature Details
The Luminex provides you with the following features:
· Full-Color, High Resolution LCD Touch Screen which pivots a full 180o.
· Six capacitive touch sensors. The first one on the left turns the Luminex on and off.
· View text, steno notes or text and steno notes simultaneously.
· Realtime ready through USB, virtual serial port and Bluetooth.
· Backup SD card saves steno notes, timestamps and audio.
· Data SD card saves steno notes, timestamps, job dictionary and audio.
· Record and playback audio with optional microphone and headset.
· Adjustable digital clock with month, date, and time.
· Adjust beeper volume.
· Adjust screen brightness and text color and font size.
· Update Luminex software from Internet download via USB.
· Date and timestamp note files.
· Automatically load main and job dictionaries.
· J-Define entries into a job dictionary.
· A/An resolution, Auto-Conflict, Brief It and suffix handling options.
· Search for and display the previous or last Question, Answer, untranslate, StenoMark, or steno
string.
· Scroll forward and backward in a file.
· Keyboard and individual key sensitivity adjustments.
· Reopen an existing file for readback and play audio.

4
2019 Stenograph, L.L.C. All Rights Reserved. 4
Luminex Users Guide Chapter 1 Introduction
User Guide Overview
This Luminex User Guide contains the following chapters with related topics.
Chapter 1: Introduction
Introduction acquaints you to the Luminex features and explains this User Guide.
Chapter 2: Hardware
Hardware explains the various components of the Luminex and how to use them.
Chapter 3: Writing on the Luminex
Writing on the Luminex explains all the software features of the Luminex used for setup before you
begin writing and while writing a job. These includes features such as loading dictionaries, setting
audio options, customizing the tilting screen, searching steno and text and changing the tilting screen
view.
Chapter 4: Troubleshooting
Troubleshooting suggests possible solutions to some common situations that you may encounter
when using the Luminex.
Appendix A: Updating Luminex Software
Updating Luminex Software instructs you how to download available updates for your Luminex from
the Stenograph web site.
Appendix B: Luminex Utilities
Luminex Utilities provides instruction on how to load an RTF/CRE dictionary on the Luminex, convert
Luminex files from Date and Time format to Stentura compatible format, personalize the Luminex
splash screen, retrieve jobs from a Backup SD card and view TrueStroke® data.

5
2019 Stenograph, L.L.C. All Rights Reserved. 5
Luminex Users Guide Chapter 2 Hardware
Chapter 2, Hardware, provides information about the hardware components of your Luminex. This
includes details on battery charging and use; communication ports and setup; function touch sensors
for accessing menus; touch screen, status LCD icons; adjusting the Tilting screen; resetting the
writing machine; and assembling and attaching the tripod.
Luminex Ports
· Data SD port holds your SD Data Card.
· Standard USB port is designed for a thumb drive for copying files.
· Reset button reboots your Luminex.
· Micro USB port holds the micro end of your USB cable for USB communication between writer
and computer and/or as a virtual serial connection to CAT systems that do not support
Stenograph’s USB communications protocol.
· Micro Backup SD port holds your micro Backup SD card.
· Microphone jack when recording audio.
· Headphone jack for monitoring live audio and/or audio playback.
· Power receptacle for charging the Luminex.

6
2019 Stenograph, L.L.C. All Rights Reserved. 6
Luminex Users Guide Chapter 2 Hardware
Battery
The Luminex comes with one main rechargeable battery and an AC adapter/charger. You can operate
your writing machine on battery power or using the AC adapter/charger with the main battery charging.
Although you can use the Luminex with the AC adapter/charger, Stenograph recommends that you
fully charge the battery before first time use.
The main battery, fully charged, operates all the features on the Luminex for approximately 12 hours.
The charging time for the main battery is approximately 5 - 6 hours.
The main battery provides a FailSafe mode if the charged level of the main battery becomes too low
and you are not using the AC adapter/charger or do not have your micro USB cable plugged into a
powered computer. In FailSafe mode, the tilting screen, Bluetooth and WiFi communication turn Off.
Your steno notes and audio continue to be written to the Data and Backup SD cards and, if you are
writing realtime via a USB connection, steno notes are sent to the realtime screen. Steno notes also
continue to be stored in memory. FailSafe mode may last up to 3 hours. The Luminex retains the date,
time and user settings during FailSafe mode. Charging the Battery when the Luminex is powered by
the AC adapter/charger maintains the main battery level. The batteries fully charge in 5 - 6 hours. You
can use your writing machine while the AC adapter/charger charges the battery. The Luminex battery
fully charged operates all features for approximately 12 hours and then will go into FailSafe mode
which may last up to 3 hours.
Charging the Battery
When the Luminex is powered by the AC adapter/charger, the main battery level is maintained. The
batteries fully charge in 5 - 6 hours. You can use your writing machine while the AC adapter/charger
charges the battery. The Luminex battery fully charged operates all features for approximately 12
hours and then will go into FailSafe mode which may last up to 3 hours.
The Luminex battery only charges when needed. Once the batteries are charged, it is not necessary
to keep the writing machine plugged into the AC adapter/charger, however, keeping the writing
machine plugged in does not damage the battery. If you are connected via the micro USB cable to a
computer that is powered On, the Luminex battery can be charged. If you are not going to use your
Luminex for an extended period of time, Stenograph recommends keeping the Luminex plugged into
the AC adapter/charger. If the Luminex is not in use for a long period of time while disconnected from
the AC adapter/charger, it is important to fully charge the battery before use and to check the date and
time setting on the writer.
Use only the AC adapter/charger supplied with your Luminex. The Diamante® AC adapter/charger will
charge the Luminex if your Luminex AC adapter/charger is not available. All other chargers designed
for other Stenograph writing machines do not power the Luminex. Although previous Stenograph
writing machine AC adapter/charger may fit the Luminex, they will not charge the Luminex battery.
Turning the Luminex On and Off
On either side of the Status LCD are three touch sensitive sensors. The far left sensor turns the
Luminex On and Off. If there is no power source to the writer (AC adapter is not plugged in or your

7
2019 Stenograph, L.L.C. All Rights Reserved. 7
Luminex Users Guide Chapter 2 Hardware
Luminex is not connected to your computer via the USB cable) you need to touch the On/Off sensor
for 2 seconds in order to turn the Luminex On. To turn the Luminex off, touch the On/Off sensor until
you hear the beep.
Battery Charging Procedure
To charge your Luminex battery:
1. Plug the AC charger/adapter into a wall outlet.
2. Insert the small plug on the AC adapter/charger cord into the AC adapter/charger socket on the
back of the Luminex.
3. The Luminex turns On. A black dot in the lower right corner of the Status LCD indicates the
Luminex is On. A row of running blocks indicates the battery is charging. If you plug your Luminex
in to charge and only the black dot displays, the batteries are charged. Charging is not necessary
and no charging occurs.
· You can use the Luminex while the battery charges. The running blocks do not display while
writing but the Luminex continues to charge.
· You can also turn off the Luminex while it is charging. The tilting screen turns off but the Luminex
remains On while charging as indicated by the black dot on the Status LCD.
Viewing Battery Charging Procedures
The Tilting screen and the Status LCD display graphic indicators reflect the charging status of the
battery. Use the Battery Voltage Level feature to see specific battery voltage levels, current charging
status and the most recent charging history.
When the AC adapter/charger is connected to the Luminex charging the battery, the title bar on the
tilting screen displays a battery icon with the battery gauge showing running black and yellow stripes.
When the batteries are fully charged, a plug icon replaces the battery charging icon until you
disconnect the AC adapter/charger.
Battery Charging Battery Fully Charged
When the battery is charging, the Status LCD displays black bars in running sequence from left to
right. The black bars are not visible when you are writing, but re-display when you close the job. When
the Luminex is finished charging, the black bars move from each side of the screen to the middle of
the screen in a “clapping” motion.

8
2019 Stenograph, L.L.C. All Rights Reserved. 8
Luminex Users Guide Chapter 2 Hardware
View Battery Voltage Level
The Battery diagnostic screen displays the voltage level and charging status.
To view battery voltage and charging status:
1. Make sure the charger/adapter is not plugged into the Luminex. If you just disconnected the
charger/adapter from the Luminex, turn the Luminex On and wait 10 – 15 minutes to get an
accurate battery voltage reading.
2. From the Opening menu, touch More.
3. Touch Diag and then touch Battery. The battery status screen displays.
Luminex Battery Status Screen
4. Review the following battery information:
· Indicator bar - provides an approximate indication of the battery voltage level. Green indicates the
battery is fully charged; yellow indicates it is charged and red indicates it is low.
· Voltage - the actual voltage amount. A main battery reading of 4.07 volts or higher indicates
normal operating voltage. 3.6 volts or below indicates the battery is very low and the titling
screen will turn off and Failsafe mode will occur if battery is not charged.
· State - displays whether the battery is charging or not charging.
5. When finished, touch OK, Quit. To display the Opening menu, touch More.
Low Battery Warnings
As the main battery becomes progressively low, the battery indicator on the writer's title bar will
change from green to yellow to red indicating a drop in battery voltage. The Luminex displays warnings
messages on the tilting screen and will beep to indicate the battery voltage is getting low. Once the
Luminex switches to FailSafe mode, the battery icon on the Status LCD blinks. When the main battery
becomes low while the Luminex is connected to a computer with the micro USB cable during
realtime, low battery messages continue to display until the battery is depleted but the writer will not

9
2019 Stenograph, L.L.C. All Rights Reserved. 9
Luminex Users Guide Chapter 2 Hardware
beep. The micro USB cable plugged into a powered computer may be able to charge the battery but
may not begin charging immediately if the battery is in a very low voltage state. The battery indicator
on the title bar may reflect that it is charging, but it may not actually be charging if the battery voltage is
extremely low.
Use the Luminex Diagnostic feature to check the specific voltage level of the battery.
Battery Gauge
The battery gauge on the title bar of the Tilting screen provides a general indicator of the battery
voltage level. It changes appearance as the voltage level of the battery changes:
· an electrical plug with a full green gauge indicates the Luminex is plugged into the AC
adapter/charger and the main battery is fully charged.
· a battery with a full green gauge indicates the main battery is fully charged. As the
charge of the battery level drops, the green bar becomes smaller.
· a battery with a partial yellow gauge indicates the battery is low.
· a battery with a short red gauge indicates the battery is almost completely drained. The
battery icon flashes on and off.
· a battery with black and yellow running stripes indicates the Luminex is plugged into the
AC adapter/charger and the batteries are charging.
Battery Messages
The Tilting screen displays two warning messages as the main battery level becomes low:.
· Battery, Danger -- Battery Low.
· Battery, Danger -- Recharge Battery Now.

10
2019 Stenograph, L.L.C. All Rights Reserved. 10
Luminex Users Guide Chapter 2 Hardware
Communication Ports
There are two types of USB ports on your Luminex. The standard USB A (host) port allows you to
insert a thumb drive to copy files from the memory or from the Data SD card. The micro USB-B
(client) port provides connection access for the USB realtime cable between the writing machine and
Case CATalyst and any other CAT system that supports the Stenograph USB protocol. The micro
USB port also allows for a virtual serial connection for other CAT systems. To use the USB cable
connection, it is necessary to install the Luminex USB drivers.
Install the Luminex USB Drivers USB:
The Luminex USB driver must be installed on your computer in order to write realtime with the micro
USB cable, load dictionaries and install updates. The USB driver installation also installs the USB
driver that creates a virtual serial port. If your CAT vendor does not support a USB realtime
connection, the driver allows for serial communication between the Luminex and other CAT software.
See USB Virtual Serial Port Communication for more details.
You can use the USB Realtime and Read communications with USB compatible CAT software such
as Case CATalyst version 4.096 or higher.
Locate the Let Us Help You Get Started insert that came with your Luminex. You can easily download
the Luminex USB drivers and utilities to personalize your Luminex, convert writer files and access the
Luminex User Guide by going to stenograph.com/utilitycd. Depending on your settings, clicking
the link will automatically start the Stenograph Writer Utilities download.
1. At the Do you want to run or save writerutilitysetup.exe... prompt, select to do one of the following:
· To run the Writer Utility Setup, select Run. The Stenograph Utility Setup screen displays.
· To Save the setup file to your hard disk, select Save. If you selected Save, once the exe is
downloaded, do one of the following:
· To run and install the Writer Utility setup, select Run. The Stenograph Utility Setup screen
displays.
· To open the folder where the Writer Utility was installed, click Open folder.
· To display the Download folder contents, click View downloads.
2. Once the writer utility program is downloaded, you can install the Luminex drivers. Turn your
computer On and make sure it is fully booted.
3. Turn your Luminex On.

11
2019 Stenograph, L.L.C. All Rights Reserved. 11
Luminex Users Guide Chapter 2 Hardware
4. Plug the USB cable into your computer’s USB port and the micro end of the USB cable into the
Luminex USB port.
Lum inex Back Port Panel
5. Navigate to the location where you installed the Stenograph Utility files. At the Writer Utilities main
menu, click the Install USB Drivers button and the drivers will begin to install.
6. Once the drivers install, the Stenograph Writer Drivers Setup Complete dialog box displays. Touch
Enter (Finish) to close the wizard.
Powering with the USB Cable
When the Luminex is connected to your computer for realtime via the micro USB cable, the main
battery continues to power the writing machine. In most situations, the USB port can power the
Luminex and may charge the battery when the main battery is not fully charged.
When the main battery becomes low while using the micro USB connection, low battery messages
display on the Luminex, but all features continue to operate. The USB port provides power to run all
the Luminex components except Bluetooth communications. When powered by the micro USB port,
the Luminex tilting screen displays at about half of the Backlight brightness setting.
To use the micro USB cable, you must install the Luminex USB driver on your computer.
Updating with the USB Cable
Software updates for your Luminex, when available, can be easily downloaded from the Stenograph
web site. Once downloaded onto your computer, you can load the software update onto your Luminex
over a USB cable. To update Luminex software, see Appendix A more information about updating the
Luminex.
Connect for realtime writing
To connect your Luminex to your computer for realtime writing, you must have one of the
following:
· a USB cable connection which requires using a micro USB compatible CAT software, such as
Case CATalyst V4.096 or higher. A micro USB cable is included with your Luminex. Check with
your CAT software vendor for compatibility information.
· a virtual serial port connection via the micro USB cable. The virtual serial port connection is
compatible with any CAT software that accepts a serial connection and Stentura protocol.

12
2019 Stenograph, L.L.C. All Rights Reserved. 12
Luminex Users Guide Chapter 2 Hardware
· a Bluetooth wireless kit. Stenograph provides technical support for Luminex Bluetooth wireless
communication when the Bluetooth Wireless Communication kit sold by Stenograph is used.
Technical support for other wireless adapters is not supported.
· a WiFi Network for a WiFi connection between the Luminex and Case CATalyst.
Micro USB Cable Communications
You must be using a USB compatible CAT software and have installed the Luminex USB driver on
your computer.
1. Ensure your Luminex and computer are turned On and are fully booted.
2. Each end of the USB cable has a different connection plug. Insert the micro end of the USB cable
into the USB B (client) micro port on the back of the Luminex and the other end into a USB port on
the computer.
3. Start your CAT software.
4. Set your realtime options. In Case CATalyst V16.04 and higher, select Stenograph Writer USB on
the Translate Realtime tab.
· In Case CATalyst V10 - V16.03, select Diamante - USB or élan - USB.
· In Case CATalyst V4.096 - V9, select élan - USB.
· Please check with your CAT software vendor if you are not using Case CATalyst.
5. Write a few strokes on the Luminex before starting realtime. If you loaded a dictionary onto your
Luminex, the translated steno displays on the tilting screen.
The USB realtime connection allows you to disconnect and reconnect the USB cable and maintain
the realtime connection. For example, if you disconnect from the USB port to report a bench
conference and then reconnect when finished, the USB realtime connection will feed the strokes
written during the bench conference. Please check with your CAT vendor to see if this capability is
available with your CAT software if you are not using Case CATalyst.
6. When you are finished writing realtime using a USB cable, it is important that you complete the
following steps in order. This ensures your computer shuts down properly.
· Touch End on the Luminex to close the file. If the option, Prompt to confirm ending job is active,
touch End again at the prompt.
