Sterling Plumbing ENSEMBLE 76120110 User manual

Features
•Compression molded from Sterling’s exclusive solid
Vikrell
®
material
•1.25 hp pump with air switch and grounding-type
plug-in cord
•Tongue-and-groove ″snap together″design
•Durable high gloss finish
•Three-piece wall set with generous storage shelves
•8 Jets
•Integral apron with removable access panel
•10 year consumer/3 year commercial limited
warranty, pump motor assembly has 1 year limited
warranty
•Lightly pebbled bottom surface for sure footing
•60″(152.4 cm) x 33-1/4″(84.5 cm) x 75-1/4″
(191.1 cm) complete unit rough-in dimensions include
flanges
•60″(152.4 cm) x 32″(81.3 cm) x 74″(188 cm)
complete unit finished dimensions
Codes/Standards Applicable
Specified model meets or exceeds the following:
•ASTM E162
•ASTM E662
•ANSI Z124.1.2
•Underwriters Laboratories (UL)
•HUD, UM Bulletin 73A
•ASTM F462 Slip Resistance
•ASME A112.19.7M
•IAPMO/UPC
32″(81.3 cm) BATH WHIRLPOOL
SYSTEM
76120110
ALSO 76120120, 76220110, 76220120
76120120 76220120
Colors/Finishes
•0: White
•Other: Refer to Price Book for additional colors/finishes
Specified Model
Model Description Colors/Finishes
76120110 32″(81.3 cm) bath whirlpool and tile wall surround, left drain ❑0❑Other_____
76120120 32″(81.3 cm) bath whirlpool and tile wall surround, right drain ❑0❑Other_____
76220110 32″(81.3 cm) bath whirlpool and curved wall surround, left drain ❑0❑Other_____
76220120 32″(81.3 cm) bath whirlpool and curved wall surround, right drain ❑0❑Other_____
ENSEMBLETM
SterlingPlumbing.com
Visit us online for fixture color choices, detailed product information, color photos, installation instructions, care
guides, and warranties. Sterling offers additional lines of plumbing products to complement the Sterling product
you’ve chosen. Sign up for the Sterling monthly e-newsletter which showcases our latest product innovations. You
may also call our Sterling Plumbing Answer Center from within the USA at 1-888-STERLING in addition to
consulting with your local dealer. Sterling. Strong. Professional. Design.
Page 1 of 2
1032217-4-D

Technical Information
Fixture*: basin area top area
Bathing well 42″(106.7 cm) x
20″(50.8 cm)
54″(137.2 cm) x
26″(66 cm)
To overflow water depth capacity
13-3/4″(34.9 cm) 55 gal (208.2 L)
* Approximate measurements for comparison only.
Pump: Hp V Hz A
1-speed 1-1/4 120 60 7
Model door maximum
width
door maximum
height
76120110
76120120
76220110
76220120
57-11/16″
(146.5 cm)
55-1/2″(141 cm)
Required Electrical Service
Dedicated circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI):
Pump/control 120 V, 15 A, 60 Hz
Installation Notes
Install this product according to the installation guide.
Pump is supplied with a grounding type plug-in cord. Locate
the outlet behind the whirlpool, and within 24″(61 cm) of the
pump.
60"
(152.4 cm)
75-1/4"
(191.1 cm)
75-1/4"
(191.1 cm)
1-1/4" (3.2 cm)
33-1/4"
(84.5 cm)
33-1/4"
(84.5 cm)
7622012076120120
3-1/2" (8.9 cm)
22-1/2"
(57.2 cm)
4" (10.2 cm)
30" (76.2 cm)
33-1/4"
(84.5 cm)
Pump Motor
Location 15-1/2"
(39.4 cm)
8-1/2"
(21.6 cm)
8-1/2"
(21.6 cm)
16" (40.6 cm)
14" (35.6 cm)
Recommended
Support Clip
Location (5 total)
60"
(152.4 cm)
18" (45.7 cm)
54"
(137.2 cm)
2"
(5.1 cm)
20" (50.8 cm)
21"
(53.3 cm)
54"
(137.2 cm)
2"
(5.1 cm)
18" (45.7 cm)
20"
(50.8 cm)
21"
(53.3 cm)
8"
(20.3 cm)
1-1/4"
(3.2 cm)
6" (15.2 cm)
(Typical)
2" (5.1 cm) D.
Drain
60" (152.4 cm) Min
60-1/8" (152.7 cm) Max
Overflow Detail
2-7/8" (7.3 cm)
Product Diagram
ENSEMBLETM
ENSEMBLETM 32″(81.3 cm) BATH WHIRLPOOL SYSTEM
Page2of2
1032217-4-D
