Stewart Filmscreen Cabaret Quick start guide

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 1
Inspect :
Inspect the box for obvious damage.
Make sure the product box was delivered
in proper condition and all the fragile
labels were honored. If the box looks to
be in bad shape; straps are broken,
corners caved in, or there are obvious
bends or intrusions in the cardboard
packing material, please indicate the
damage clearly on the Bill of Lading
before signing and accepting shipment
or refusing. Please inspect the product
within 48 hours of receipt. If damage is
observed please call your dealer or
Stewart Filmscreen Corp immediately.
Leave the product in the package
unless advised to remove it.
Cut :
To insure that the product is safe inside,
do not attempt to rip or pull off the straps.
This will most likely damage the packing
box and/or the product components.
Open :
Remove tape and staples.
Fold the box open and look inside.
Nylon straps are to be cut only.
Confirmation :
Locate both shipping labels to insure that
the correct product was delivered to the
correct person/company/corporation.
Also, the top main label has the product
weight information on it. Be sure to use
proper lifting techniques to avoid injury
to personnel or damage to the box
and product.
01
02
03
04

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 2
Check:
Inside the box are the main Cabaret
unit, the LED light bar (OPTIONAL),
the controls and the owner’s manual.
Unwrap :
Be sure to read this instruction
manual completely before
proceeding.
Gently, remove the protective wrap off
LED lighting if applicable. Insure that
the LED lighting looks in good order.
Removal :
Remove the Cabaret unit from the box.
Be sure to use proper lifting techniques
to avoid injury. Cabaret unit should be
lifted straight up and out of the box.
Avoid turning the unit on end.
Control box :
The Cabaret screen and optional
LED bar are supplied with
independent control systems.
Check your order and verify that the
correct controls were sent to you.
05
07
06
08

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 3
Packing Removal :
Remove the packing material from
the unit by sliding the end packing
and center support packing off.
Remove plastic wrap and stretch
wrap from unit. Do not remove
batten retainers at this time.
Mounting location:
Determine where you want the top
of the projected image to be.
Y= amount of top masking.
X= Y(top masking)+6 5/8”(case height)
Z= amount of space for LED light wash.
If the unit has LED bar, then Z=
6 Inches or more of clearance.
Wall types :
Determine the type of
wall construction.
Mounting Options:
The Cabaret screen is available with
either the standard mounts, close
coupled slide and lock plates, or the
extended mount kit, which cantilevers
the unit out from the wall to clear a flat
panel display, an art work or other
wall décor. If you have the standard
mounts proceed to the next step, for
extended mounts, go directly to page 6.
10
12
09
11

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 4
Mounting hardware :
(Hardware not included)
Determine suitable anchors for your
wall type.
Each anchored screw should support
a minimum of 65lbs (30kgs)
Masonry mount :
The first hole is determined by the
projected image in relationship to the
mounting hole on the Cabaret unit
(reference image 11). After finding the
screw hole location, drill, mount anchor,
and screw the screw in the wall about
90%. Leave space for the keyhole on the
unit to slide over the screw freely.
Drywall mount :
The first hole is determined by the
projected image in relationship to the
mounting hole on the Cabaret unit
(reference image 11).
Find your stud location, and slide
the Cabaret mounting bracket to match
the keyhole to the first mounting hole.
After determining your screw hole
location, drill, mount anchor, and screw
the screw in the wall about 90%,
leave space for the keyhole on the
unit to slide over the screw freely.
13
16
123
14
123
(z) LED Lighting Space
(+/-) In between
Mounts Distance
(x)Top of Image to Hole
15
(z) LED Lighting Space
(+/-) In between
Mounts Distance
(x) Top of Image to Hole
Hit Wood!

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 5
Mounting the unit :
Caution: Now that the front cover is
removed, do not handle the screen
material or batten, only touch the case.
Place the unit on the screw in the first
hole anchor. With the unit attached to
the first anchor, swivel the Cabaret unit
using the spirit levelers as a guide to
find the position of the second hole and
mark the location. Remove the unit off
the wall now, place it away from the
work area so no damage can be done
to the screen material or the case.
Proceed to mount a screw in the second
hole position. Reference images 14-16
for help if needed. Now with the unit in
the desired location tighten both screws
down to secure the Cabaret unit in place.
20
Front valance removal :
Swivel the valance outward on the top
hook rail, and then lift the valance
away from the unit.
Caution: Do not pull on the valance from
the center of the unit to try to release it,
this may cause damage to the unit.
Remove acrylic top piece and protective
paper. To remove the front valance
place your hands at the very ends of the
unit, reach inside the batten cutout with
your hands and pull down to release
the cover.
17
18
Batten packing removal :
With the front valance removed proceed
to remove batten retaining foam blocks.
19

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 6
Attach clip to end of wall plate with
two 1/4-20 hardware provided.
Align the ledger edges of the clip
upward as shown.
B4
Reference image #13
(Hardware not included)
Locate wall studs. The center of the
bracket should be no more than 6 inches
away from the end of the backbone rail.
Two holes of the wall plate must be
mounted to a stud or otherwise suitably
anchored. The other two holes should
be secured to the wall. Mount wall plate
to wall using appropriate hardware.
Placing Cover :
Slide plastic cover over the
plate and snap it into place.
B3
Offset Bracket :
The offset bracket comes in 3 pieces.
The Wall Plate, plastic cover, and clip.
Decide how you are going to wire the
unit. Wiring may optionally run through
the offset bracket into a wall box.
The slot on the wall plate is for optional
wire routing. This slot must be oriented
either up or down.
B1
B2

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 7
Locating the ILC Board :
If you have a Cabaret unit with LED
lighting, look to locate your Integrated
Lighting Control (ILC) board placed
inside the cast aluminum end pice on
the audience right of the Cabaret unit.
IMC and ILC Communication:
If you purchase you lighting kit from
Stewart after the purchasing of the unit,
pay close attention to the next steps.
Caution: Unplug unit power if applicable
before you work on wiring the IMC or ILC.
Do to the fact that the Cabaret Unit has
active lighting on deploy & retract, the
IMC has to interface with the ILC via a
RJ25 (low voltage) cable as seen in the
image on the left and in the next image.
ILC (Intelligent Lighting Control):
Using the diagram on the left, you can
get familiar with the wiring of the ILC
which controls the LED lighting.
21
22
Mounting Unit :
Clip the Cabaret back rail to
the mount.
Secure clip to unit, using the provided
1/4-20 Screws and a 5/32 size Allen key.
B5
LED Option Only
23

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 8
LED lighting :
If you have a light bar, place it on top
of the support brackets inside of the
Cabaret unit. The leads for the LED
strip should be on the audience right
unless otherwise specified.
LED Controls :
The LED lighting can be powered up
only on screen deployment or retraction,
if no LED control component are added
to the system; With the LC (Light Control)
wall switch (WS) or (WR) wireless remote
control, you can fully configure the LED
strip by changing; colors and intensity.
Consult your LED Lighting manual on full
details of operation and settings.
Powering up the lighting :
Using the diagram on the left, wire up
the ILC by first connecting in the LED
lighting bar into the board and than the
transformer into a 110V wall socket.
RJ25 (low voltage) Cable Link :
Connect the IMC board to the ILC board
by using a RJ25 cable. Use Connection
port (#1) on the IMC and port (#1)
on the ILC.
If you purchase the unit with LED lighting
then this connection will be made at the
factory.
24
25
26
27

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 9
Power for Control Board (IMC):
Power diagram on the left allows you
to power up the unit directly.
Using 16ga wire is prefered or
18ga (min) to power up the unit.
Caution: Use the correct voltage for
the unit (110V-220V) depending on
your purchase and your location.
Locating control board :
Locate the control board within
the left side end fitting.
28
Locate controls socket on the right
side of the control board.
Connecting controls for LV will allow
the user to deploy and retract the
screen from a wall mounted switch.
29
31
Controls (IMC): STI
Locate controls socket on the right
side of the control board.
Connecting controls for STI will allow
the user to deploy and retract screen
base on projector output trigger.
STI range is 3-15 V DC (10 ma min)
30

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 10
Controls (IMC): 5 Button
Intelligent Keypad (LV)
Locate CS-bus socket on the lower
right side of the control board.
Connect controls through the CS-bus
port using a RJ25 (low voltage) cable.
With this option, you can control the
screen functions remotely through
an on-board receiver.
Controls (IMC): IR and RF
Locate CS-bus socket on the lower
right side of the control board.
Connecting controls through CS-bus
for both the infrared or radio frequency
control units. With this option, you can
control the screen functions either
through infrared or wirelessly.
33
Front valance reattachment:
Carefully align the top edge on the
hooks located at the center and ends
of the case. Verify that the top of the
valance is flush with the top of the
end caps and aligned left to right.
34
32
Powering up the unit :
a. Plug the cord into the wall outlet.
b. For Lutron motor units reference
Lutron manual for installation guidelines
before you power up the unit.
c. With the (IMC) powered directly test
for power and motor functions.
With the control system wired,
proceed to test and make sure the
controls are wired correctly and
working properly.

Installation Instructions
Cabaret Electriscreen: Owner’s Manual 11
Screen deployment :
Using your screen control system,
deploy the screen.
Verify that the unit is in working order.
ENJOY!
Thank you for your purchase.
Reference the manual for warranty
and maintenance information.
Placing acrylic :
After replacing the front valance, place
the acrylic on top of the case.
36
37
38
Firmly press on the bottom of the
valance near the ends to snap
valance back into place.
Caution: Do not push on the valance
from the center of the unit to try to
attach it, this may cause damage
to the screen.
35

Stewart Filmscreen Corp
Motor Limit Adjustments
Motor Options:
Locating the motor limit switch: Caution: Warranty Note:
Warning:
Inside the left bottom of the Cabaret unit one can locate the motor limit switches. First determine which motor option is installed in the unit. Start by locating the end of the motor on the left. Remove the unit’s front Valance for better access, if necessary. Reference images #17-19. The extension and retraction limit switches have The screen is fully retracted when the batten is flush with the bottom of the case. Do not attempt adjustments with the retraction (UP) limit switch that will further retract the screen. Incorrect adjustment of the switch will cause severe screen damage. Please consult the factory if you have any questions. been preset at the factory. In general, we advise you to avoid readjusting these switches. Lutron Motor Note: For full details on modifying settings, motor installation and operation, consult your Lutron motor manual. Improper adjustment of the limit switches can cause irreparable damage to the screen itself, resulting in voiding the factory warranty.
MOTOR LIMIT SWITCH ACCESS POINT

Decrease screen extension (roll up).
To decrease the screen extension: Lower the screen until it is about halfway down and stop.
Locate the white extension (down) limit switch on the left side of the unit. Use a small screwdriver or a 5/32” hex wrench to turn the switch in a clockwise direction.
Activate the screen in the down direction until it reaches the newly reduced stop position. Repeat this procedure until the desired stop position is reached.
(1/2)
123
Original
6” ~15cm
Motor Limit Adjustments SOMFY
Stewart Filmscreen Corp
Note: One complete turn of the switch will make approximately a 3/4” change in the screen’s stop position.
In some cases, to enable proper alignment of the displayed image on the screen, you may need to adjust the extension of the screen. If adjustment to the extension is necessary, carefully follow these instructions.
You can increase the extension of the screen up to 3” past the factory preset stop, or you can decrease the extension by 4-6” from factory preset stop.
Increase screen extension (drop).
Use a small screwdriver or a 5/32” hex wrench to turn the switch in a counterclockwise direction. If the power is still on, the screen will drop incrementally as the switch is turned.
To increase the screen’s fully extended (screen down) position: Lower the screen to its current stop position. Locate the white (down) limit switch on the left side.
Original Original Original
3”~7.5cm
3”~7.5cm
6” ~15cm
123
CAUTION: Do not make a clockwise or shortening adjusment when
the screen is deployed. Always move the screen away from the down limit position if you plan to make an adjusment to shorten the deployment of the screen. If you make this adjusment with the screen in the down position it is very likely that you will strip the limit.
Power
ON
DO NOT ATTEMPT TO MODIFY THE SCREEN EXTENTION BEYOND RECOMMENDED AMOUNT!
STOP

To increase / decrease the screen extension: Use the ( ) to lower the screen and the ( ) to raise the screen, to the desired position.
Press and hold ( ) for 5 seconds, the LED will flash for 2 seconds then go dark, indicating the current position has been set.
Reattach the unit’s valance, reference image # 27-29 if needed.
456
Motor Limit Adjustments LUTRON
Stewart Filmscreen Corp
In some cases, to enable proper alignment of the displayed image on the screen, you may need to adjust the extension of the screen. If adjustment to the extension is necessary, carefully follow these instructions.
You can increase the extension of the screen up to 3” past the factory preset stop, or you can decrease the extension by 4-6” from factory preset stop.
Increase screen extension (drop) & Decrease screen extension (roll up).
Push the ( ) button and the LED in the center will turn on steady, indicating the motor is in “Set Limit Mode”.
To increase the screen’s fully extended (screen down) position: Lower the screen to its current stop position. Locate the down ( ) limit switch on the left side.
Original Original
Original
3”~7.5cm
6” ~15cm
3”~7.5cm
6” ~15cm
123
CAUTION: Do not operate the motor when any of the following occurs:
The unit emits any smoke, heat, abnormal noise or odor. The unit is damaged in some way, such as water damage.
If any of these situations occur, call a qualified service person.
DO NOT ATTEMPT TO MODIFY THE SCREEN EXTENSION BEYOND RECOMMENDED AMOUNT!

LIMITED ONE YEAR WARRANTY
Stewart’s sole obligation under this warranty shall be to repair or to replace (at Stewart’s sole discretion)
the defective part of the merchandise. This warranty expressly does not cover any costs of removal, in-
stallation, framing, or other costs incident to replacing the screen or returning it to Stewart. Returns for
service should be made to your Stewart dealer. If it is necessary for the dealer to return the screen or part
to Stewart, transportation (freight) expenses to and from Stewart are payable by the purchaser. Stewart is
not responsible for damage in shipment. To protect yourself against damage or loss in transit, insure the
product and prepay all transportation expenses.
This warranty is in lieu of all other warranties, expressed or implied, including warranties as to tness
for use and merchantability. Any implied warranties of tness for use, or merchantability, that may be
mandated by statue or rule of law are limited to the one (1) year warranty period. This warranty gives
you specic legal rights, and you may also have other rights which vary from state-to-state. In no event
will Stewart be liable for sums in excess of the purchase price of the product. No liability is assumed by
Stewart for expenses or damages resulting from interruption in operation of equipment, or for incidental,
direct, or consequential damages of any nature.
IMPORTANT: This warranty shall not be valid and Stewart shall not be bound by this warranty if the prod-
uct is not installed and maintained in accordance with Stewart’s written instructions.
©2012 Stewart Filmscreen Corporation
STEWART FILMSCREEN CORPORATION (Stewart) warrants its CabaretTM products to the original
purchaser only, to be free from defects in materials and workmanship for a period of one (1) year from
the date of purchase by the original purchaser or eighteen (18) months from date of
manu-facture, as dened in the serial number, provided they are properly operated and maintained
according to Stewart instructions and are not damaged due to improper handling or
treatment after shipment from the factory. This warranty does not apply to equipment showing
evidence of misuse, abuse, or accidental damage, including neglect caused by improper installation (i.e.
proximity to hot lights, exposure to extreme heat or cold, exposure to excessive humidity, etc.). No
Stewart services are available for this product.
Stewart Filmscreen Corporation shall not be liable for any and all consequential damage(s)
occasioned by the breach of any written or implied warranty pertaining to the sale of CabaretTM by
Stewart Filmscreen product in excess of the purchase price of the product sold.
In the event that there is adefect in materials or workmanship of a Cabaret product, youmay
contactour CustomerService Departmentat 1161WSepulveda Blvd,Torrance, California
90502-2797 (310-784-5300) Toll free (800-762-4999).
Printed in USA. Rev. 10/16/2012
15

www.stewartfilmscreen.com
1-800-762-4999 Fax [phone]
