Stiga 915333 User manual

RIDING ROTARY LAWN MOWER
SAMOJÍZDNÁ SEKAČKA
AUFSITZ-SICHELMÄHER
HAVETRAKTOR MED ROTERENDE KNIVE
TRACTOR CORTACÉSPED GIRATORIO
KETASNIIDUKIGA MURUTRAKTOR
PUUTARHATRAKTORI PYÖRIVÄLLÄ LEIKKUUYKSIKÖLLÄ
TONDEUSE À GAZON AUTOPORTÉE ROTATIVE
TRAKTORČIĆ S OKRETNOM REZNOM GLAVOM
TRATTORINO CON UNITÀ DI TAGLIO ROTATIVA
VEJAPJOVĖ SU ROTACINIU PJOVIMO AGREGATU
MINI TRAKTORS AR ROTĒJOŠU PĻAUŠANAS AGREGĀTU
RIJDENDE ROTERENDE GRASMAAIER
PLENTRAKTOR MED ROTORKLIPPER
SAMOBIEŻNA ROTACYJNA KOSIARKA TRAWNIKOWA
INSTRUCTION MANUAL........................... EN
INSTRUKTIONSMANUAL .......................... CS
GEBRAUCHSANWEISUNG....................... DE
INSTRUKTIONSMANUAL .......................... DA
USO Y MANTENIMIENTO...........................ES
KASUTUSJUHEND .....................................ET
KÄYTTÖOPAS .............................................. FI
MANUEL D’UTILISATION........................... FR
PRIRUČNIK ZA UPORABU ........................HR
MANUALE DI ISTRUZIONI ........................... IT
VARTOJIMO INSTRUKCIJA ........................ LT
OPERATORA ROKASGRÅMATA................ LV
GEBRUIKERSHANDLEIDINGNL ............... NL
BRUKSANVISNING - VEDLIKEHOLD........NO
INSTRUKCJE OBSŁUGI..............................PL
171506091/0 09/2016
ZERO TURN MOWER series
Type 915333

Ariens Company
655 West Ryan Street
Brillion, Wisconsin
54110-1072 USA
Telephone
[phone]
Facsimile
[phone]
EC DECLARATION OF CONFORMITY ISSUED BY THE MANUFACTURER – ES PROHLÁŠENÍ O
SHODĚ, VYDANÉ VÝROBCEM – VOM HERSTELLER HERAUSGEGEBENE EG-
KONFORMITÄTSERKLÄRUNG – OVERENSSTEMMELSESCERTIFIKAT FOR MODELLER, UDSTEDT
AF FABRIKANTEN – DECLARACIÓN DE CONFORMIDAD CE EMITIDA POR EL FABRICANTE – TOOTJA
VÄLJASTATUD EC-VASTAVUSDEKLARATSIOON – VALMISTAJAN ANTAMA EY-
VAATIMUSTENMUKAISUUSVAKUUTUS – DÉCLARATION DE CONFORMITÉ CE ÉMISE PAR LE
FABRICANT – EZ IZJAVA O SUKLADNOSTI KOJU DAJE PROIZVOĐAČ– DICHIARAZIONE DI
CONFORMITÀ CE DEL PRODOTTO RILA SCIATA DAL PRODUTTORE – EK GAMINTOJO ATITIKTIES
DEKLARACIJA – EK ATBILSTĪBAS DEKLARĀCIJA, KURU IZDOD RAŽOTĀJS – EG-
CONFORMITEITSVERKLARING, UITGEGEVEN DOOR DE FABRIKANT – EF-SAMSVARSERKLÆRING
FRA PRODUSENTEN – DEKLARACJA ZGODNOŒCI Z PRZEPISAMI EC WYDANA PRZEZ
PRODUCENTA – CERTIFICADO DE CONFORMIDADE DO MODELO EMITIDO PELO FABRICANTE –
СОСТАВЛЕННОЕ ПРОИЗВОДИТЕЛЕМ ЗАЯВЛЕНИЕ ОСООТВЕТСТВИИ СТАНДАРТАМ ИНОРМАМ
ЕС – ES-IZJAVA O SKLADNOSTI, KI JO JE IZDAL PROIZVAJALEC – ES VYHLÁSENIE O ZHODE,
VYDANÉ VÝROBCOM – EG-DEKLARATIONEN OM ÖVERENSSTÄMMELSE UTFÄRDAD
AV TILLVERKAREN – ÜRETİCİTARAFINDAN DÜZENLENEN EC UYGUNLUK BEYANI
We the undersigned, ARIENS COMPANY, certify that: My, nížepodepsaní, ARIENS COMPANY, prohlašujeme, že: Der Unterzeichnete,
ARIENS COMPANY, bescheinigt, dass: Undertegnede, ARIENS COMPANY, attesterer, at: Nosotros, los abajo firmantes, ARIENS
COMPANY, certificamos que: Meie, allakirjutanud, ETTEVÕTE ARIENS, kinnitame, et: Allekirjoittanut, ARIENS COMPANY, vakuuttaa,
että: Nous, soussignés ARIENS COMPANY, certifions que: Mi, dolje potpisani, ARIENS COMPANY, potvrđujemo da: La sottoscritta
società ARIENS COMPANY certifica che: Mes, žemiau pasirašiusieji, „ARIENS“ kompanija, patvirtiname, jog: Mēs, zemāk
parakstījušies, ARIENS COMPANY, apliecinām, ka: Wij, de ondergetekenden, ARIENS COMPANY, verklaren dat: Undertegnede,
ARIENS COMPANY, bekrefter at: My, niżej podpisani, ARIENS COMPANY, oświadczamy, że: Nós, abaixo assinados, certificamos em
nome da ARIENS COMPANY, que: Мы (фирма ARIENS), нижеподписавшиеся, настоящим заявляем, что: Spodaj podpisani
ARIENS COMPANY potrjujemo, da je: My, spoločnosťARIENS COMPANY vyhlasujeme, že: Undertecknad, ARIENS COMPANY,
intygar att: Biz altta imzasıbulunan, ARIENS COMPANY olarak tasdik ederiz ki:
Type: Typ: Typ: Type:
Tipo: Tüüp: Tyyppi:
Type: Tipo: Type: Tip:
Type: Tips: Typ: Tipas:
Tipo: Тип: Tip: Typ:
Typ: Tip:
Riding Rotary Lawn Mower – Samojízdná Sekačka – Aufsitz-Sichelmäher – Havetraktor med roterende
knive – Tractor cortacésped giratorio – Rootor-murutraktor – Puutarhatraktori Pyörivällä Leikkuuyksiköllä –
Tondeuse à gazon autoportée rotative – Samohodna rotaciona kosilica za travu – Trattorino con unità di taglio
rotativa – Savaeigėžoliapjovė – Braucošais rotējošais zāles pļāvējs – Rijdende roterende grasmaaier –
Plentraktor med rotorklipper – Samobieżna rotacyjna kosiarka trawnikowa – Tractor cortador de relva –
езда Косилка роторная – Sedežna vrtljiva kosilnica – Jazdecké rotačná kosačka na trávu –
Sittrotorgräsklippare – Döner biçme makinesi sürme
Trade Name: Obchodní název: Handelsbezeichnung: Firmanavn: Nombre comercial:
Kaubamärk: Kauppanimi: Appellation commerciale: Trgovački naziv: Nome commerciale:
Prekės pavadinimas: Komerciālais nosaukums: Handelsnaam: Handelsnavn: Nazwa
handlowa: Nome da Marca: Название фирмы: Trgovsko ime: Názov výrobku:
Handelsbeteckning: Ticaret Unvan:
Stiga
Model, Serial Number: Model, výrobní číslo: Modell, Seriennummer: Model, Serienummer : Modelo,
Nº de Serie:
Mudel, Seerianumber: Malli, sarjanumero: Modèle, numéro de série: Model, Serijski
broj: Modello, Numero di serie
: Modelis, Serijos numeris: Modelis, Sērijas numurs : Model,
Volgnummer
: Modell, serienummer : Model, numer seryjny: Modelo, Número de Série : Модель,
серийный номер: Model, Serijska številka: Model, výrobné číslo: Modell, serienummer
: Model,
Seri Numarası:
915333,
915333000101+
Cutting Width: Pracovní záběr : Schnittbreite : Klippebredde : Anchura de corte : Lõikelaius:
Leikkuuleveys : Largeur de coupe: Širina reza: Pjovimo plotis: Larghezza : Griešanas
platums: Maaibreedte : Atbilst: Klippebredde : Szerokość cięcia : Largura de corte : Ширина
скашивания : Širna košnje: Šírka kosenia : Klippbredd : Kesme Genişliği :
915333: 106.7 cm
Conforms to: Odpovídá normě: mit den Anforderungen der folgenden Richtlinien übereinstimmt: Er i overensstemmelse med:
Cumple con: Vastab: Täyttää seuraavat vaatimukset: Est conforme à: U sukladnosti s: È conforme a: Atitinka: Voldoet aan: Er i
samsvar med: Jest zgodny z: De acordo com: Соответствует: v skladu z: Je v zhode s: Överensstämmer med: Uygundur:
2006/42/EC, 2014/30/EU, 2012/46/EU
2000/14/EC amended by 2005/88/EC Conformity Assessment Annex VI. 2000/14/EC ve znění 2005/88/ES o posuzování shody
příloha VI. 2000/14/EC geändert durch 2005/88/EG Konformitätsbewertung Anhang VI. 2000/14/EC ændret ved 2005/88/EF
Overensstemmelsesvurdering bilag VI. 2000/14/EC modificada por 2005/88/CE evaluación de la conformidad del anexo VI.
2000/14/EÜ, mida on muudetud 2005/88/EÜ vastavuse hindamise VI lisale. 2000/14/EY muutettuna 2005/88/EY
vaatimustenmukaisuuden arviointi Liite VI. 2000/14/CE modifiée par 2005/88/CE évaluation de la conformité aux annexes VI.
2000/14/EZ dopunjeno s 2005/88/EZ procjena sukladnosti, Dodatak VI. 2000/14/EC modificata dalla 2005/88/CE Valutazione
Conformità, Allegato VI. 2000/14/EB, 2005/88/EB direktyvos atitikimo vertinimo VI priedo pataisos nuostatas. 2000/14/EK, grozīts
ar 2005/88/EK, Atbilstības novērtēšanas pielikums VI. 2000/14/EG gewijzigd bij 2005/88/EG conformiteitsbeoordeling bijlage VI.
2000/14/EC endret ved 2005/88/EC konformitetsvurdering anneks VI. 2000/14/EC zmieniona przez 2005/88/WE oceny zgodności
załączniku VI. 2000/14/EC alterada pela 2005/88/CE Avaliação da Conformidade anexo VI. 2000/14/EC amended by 2005/88/EC
Conformity Assessment Annex VI. 2000/14/EC v znení 2005/88/ES o posudzovaní zhody prílohe VI. direktivo 2000/14/ES
dopolnjeno z aneksom VI za ocenitev skladnosti direktive 2005/88/ES. 2000/14/EC ändrat genom 2005/88/EG
Överensstämmelseutvärdering Bilaga VI. 2000/14/EC 2005/88/EC Uygunluk Değerlendirme Ek VI ile değiştirilen.
EN ISO 5395-1: 2013, EN ISO 5395-3: 2013
EN ISO 14982: 2009
04688800C • 10/16

Notified Body – Pověřená osoba – Benachrichtigte Körperschaft – Bemyndiget organ – Organismo notificado –
Teavitatud asutus – Entité notifiée – Organisme notifié – Obaviješteno tijelo – Organismo notificato –
Registruota instancija –Pieteiktāiestāde – Aangemelde instantie – Teknisk kontrollorgan – Organ
zaświadczający – Organismo Certificador – Уполномоченным органом – Priglašeni organ – Notifikovaný
Orgán – Anmält organ – OnaylanmışKuruluş
SNCH
11, Route de
Luxembourg
L-5230
Sandweiler
Representative Measured Sound Power Level (Lwa) –
Representativní hodnota změřené hladiny akustického výkonu
(Lwa) – Repräsentativer gemessener Geräuschpegel (Lwa) –
Näitlik mõõdetud helivõimsuse tase (Lwa) – Repræsentativt, målt
støjeffektniveau (Lwa) – Nivel de potencia acústica
representativo medido (Lwa) – Tyypillinen mitattu äänitehotaso
(Lwa) – Niveau de puissance acoustique représentatif mesuré
(Lwa) – Reprezentativna izmjerena razina snage zvuka (Lwa) –
Livello di potenza sonora rappresentativo rilevato (Lwa) –
Reprezentatīvais izmērītais skaņas jaudas līmenis (Lwa) –
Būdingas išmatuotas garso galios lygis (Lwa) – Representatief
gemeten geluidsniveau (Lwa) – Representativt målt lydeffektnivå
(Lwa) – Zmierzony reprezentatywny poziom mocy akustycznej
(Lwa) – Nível de Potência de Som Medido Representativo (Lwa)
– Репрезентативный измеренный уровень звуковой
мощности (Lwa) – Tipična izmerjena raven zvočne moči (Lwa) –
Charakteristická zmeraná hladina akustického výkonu (Lwa) –
Representativ uppmätt ljudnivå (Lwa) – Örnek ÖlçülmüşSes Güç
Seviyesi (Lwa)
Guaranteed Sound Power Level (Lwa) – Zaručovaná hodnota
hladiny akustického výkonu
(Lwa) – Garantierter Geräuschpegel
(Lwa) – Garanteret støjeffektniveau (Lwa) – Nivel de potencia
acústica garantizado
(Lwa) – Tagatud mõõdetud helivõimsuse tase
(Lwa)
– Taattu äänitehotaso (Lwa) – Niveau de puissance acous-
tique garanti
(Lwa) – Zajamčena razina snage zvuka (Lwa) – Livello
di potenza sonora garantito
(Lwa) – Garantuotas garso galios
lygis (Lwa) – Garantētais skaņas jaudas līmenis (Lwa) –
Gega-
randeerd geluidsniveau
(Lwa) – Garantert lydeffektnivå (Lwa) –
Gwarantowany reprezentatywny poziom mocy akustycznej (Lwa)
– Nível de Potência de Som Medido Garantido
(Lwa) –
Гарантированный уровень звуковой мощности (Lwa) – Zajam-
čena raven zvočne moči (Lwa) –
Zaručená hladina akustického
výkonu
(Lwa) – Garanterad uppmätt ljudnivå (Lwa) – Garanti
EdilmişSes Güç Seviyesi (Lwa)
915333: 99 dB(A) 915333: 100 dB(A)
Engine Power (Kw @ RPM): Výkon motoru při regulovaných otáčkách (Kw při ot./min):
Motorleistung (kW bei U/Min): Motoreffekt (Kw @ RPM): Potencia del motor (Kw a RPM): Mootori
võimsus (Kw @ RPM): Enimmäisteho (Kw @ RPM): Puissance moteur (Kw au régime max.):
Snaga motora (kW pri o/min): Potenza max. del motore (Kw a giri/min.): Variklio galia (Kw @ RPM):
Dzinēja jauda (Kw pie apgriezieniem minūtē): Motor Vermogen (Kw @ RPM): Motoreffekt (Kw @
RPM): Moc silnika (Kw przy obr./min): Potência (Kw @ RPM): Мощность двигателя (кВт при
об/мин): Močmotorja (kW pri vrt./min.): Výkon motora (Kw @ RPM) (Kw / ot./min.): Motoreffekt (Kw
@ varvtal): Motor Gücü (Kw @ RPM):
915333: 10.8 @ 2600
Fred J. Moreaux:
Director Product Conformance & Warranty (Keeper of Technical
File) / Správce shody výrobku a záruky (správce technické
dokumentace) / Director Product Conformance & Warranty
(Archivar der technischen Akte) / Direktør for
produktoverholdelse & garanti (indehaver af teknisk fil)/ Director
de conformidad de los productos y de garantía (Conservador de
los archivos técnicos) / Tootevastavuse ja garantii juht (tehniliste
dokumentide valdaja) / Tuotteen vaatimustenmukaisuudesta
vastaava johtaja (teknisen tiedoston haltija) / Responsable de la
conformité des produits et de la garantie (dépositaire de la fiche
technique) / Direktor za sukladnost proizvoda i jamstvo (zadužen za
čuvanje tehničke arhive) / Responsabile di conformità del prodotto
e garanzia (depositario del fascicolo tecnico) / Tiesioginis
gaminio atitikimas ir garantija (Techninės bylos turėtojas) /
Produktu atbilstības un garantijas direktors (tehniskās lietas
glabātājs) / Directeur technische produktstandardisatie &
garantie (Houder van het technische bestand) / Ansvarlig for
produktsamsvar (innehaver av teknisk fil) / Dyrektor ds.
zgodności produktów i gwarancji (przechowujący dokumentację
techniczną) / Director de Conformidade de Produto & Garantia
(Encarregado do Ficheiro Técnico) / Директор по гарантии на
изделия иих соответствию стандартам (Хранитель
технического файла) / Direktor za skladnost in garancijo
izdelka (skrbnik tehnične dokumentacije) / Vedúci pre zhodu a
záruku výrobku (udržiavateľsúboru technickej dokumentácie) /
Chef för produktöverensstämmelse och garanti (innehavare av
tekniska data) / Ürün Uygunluk ve Garanti Müdürü (Teknik
Dosya Saklayıcısı)
Ariens Company
Brillion, WI 54110-1072 USA
Signature – Podpis – Unterschrift
– Underskrift Firma – Allkiri –
Allekirjoitus – Signature – Potpis –
Firma – Parašas – Paraksts –
Handtekening – Signatur –
Podpis – Assinatura – Подпись –
Podpis – Namnteckning – Imza
10/16
Date – Datum – Datum –
Dato – Fecha – Kuupäev –
Päivämäärä – Date – Data –
Datum – Data – Datums –
Datum – Dato – Data – Data
– дата – Datum –Dátum –
Datum – Tarih
Darren Spencer:
Authorized to Compile the Technical File / Oprávněný vytvořit
technickou dokumentaci / Zur Anlage der technischen Akte
ermächtigt / Autoriseret til at kompilere den tekniske fil /
Autorizado para compilar los archivos técnicos / Volitatud
tehnilisi dokumente koostama / Valtuutettu laatimaan teknisen
tiedoston / Autorisé à remplir la fiche technique / Ovlaštena
osoba za pripremu tehničke arhive / Autorizzato alla
compilazione del fascicolo tecnico / Įgaliotas sudaryti techninį
failą / Pilnvarots sastādīt tehnisko lietu / Geautoriseerd om het
technische bestand samen te stellen / Autorisert til å produsere
den tekniske filen / Uprawniony do przygotowania dokumentacji
technicznej / Autorizado a Compilar o Ficheiro Técnico /
Уполномочен на составление технического файла /
Pooblaščenec za pripravo tehnične dokumentacije / Oprávnený
na zostavenie súboru technickej dokumentácie / Auktoriserad att
kompilera den tekniska filen / Teknik DosyayıDerlemeye Yetkili
Ariens Company
Great Haseley
Oxford
OX44 7PF UK
Signature – Podpis – Unterschrift
– Underskrift Firma – Allkiri –
Allekirjoitus – Signature – Potpis –
Firma – Parašas – Paraksts –
Handtekening – Signatur –
Podpis – Assinatura – Подпись –
Podpis – Namnteckning – Imza
10/16
Date – Datum – Datum –
Dato – Fecha – Kuupäev –
Päivämäärä – Date – Data –
Datum – Data – Datums –
Datum – Dato – Data – Data
– дата – Datum – Dátum –
Datum – Tarih
04688800C • 10/16

EN - 2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Assembly . . . . . . . . . . . . . . . . . . . . . . . 11
Controls and Features. . . . . . . . . . . . . 13
Operation . . . . . . . . . . . . . . . . . . . . . . . 14
Maintenance Schedule . . . . . . . . . . . . 19
Service and Adjustments . . . . . . . . . . 21
Storage . . . . . . . . . . . . . . . . . . . . . . . . . 29
Troubleshooting. . . . . . . . . . . . . . . . . . 30
Accessories . . . . . . . . . . . . . . . . . . . . . 31
Specifications. . . . . . . . . . . . . . . . . . . . 32
Original Instructions.
THE MANUAL
Before operation of unit, carefully and
completely read your manuals. The contents
will provide you with an understanding of
safety instructions and controls during normal
operation and maintenance.
All reference to left, right, front, or rear are
given from operator seated in operation
position and facing the direction of forward
travel.
ENGINE MANUAL
The engine on this unit is covered by a
separate manual specific to the engine. This
manual is included in the literature package
that shipped with the unit. Refer to this
manual for engine service recommendations.
If the engine manual is not available, contact
the engine manufacturer for a replacement
manual.
DISCLAIMER
Stiga reserves the right to discontinue,
change, and improve its products at any time
without notice or obligation to the purchaser.
The descriptions and specifications contained
in this manual were in effect at printing.
Equipment described within this manual may
be optional. Some illustrations may not be
applicable to your unit.
SAFETY ALERTS
The safety alert symbol is used in decals and
with this manual. Understand the safety
message. It contains important information
about personal safety.
TABLE OF CONTENTS
INTRODUCTION
SAFETY
WARNING: This cutting machine
is capable of amputating hands
and feet and throwing objects.
Failure to observe the safety
instructions in the manuals and on
decals could result in serious
injury or death.
Slopes are a major factor related
to loss-of-control and tip-over
accidents. Operation on all slopes
requires extra caution.
Tragic accidents can occur if the
operator is not alert to the
presence of children. Never
assume that children will remain
where you last saw them.
Gasoline is extremely flammable
and the vapors are explosive,
handle with care.
Disengage attachment, stop unit
and engine, remove key, engage
parking brake, and allow moving
parts to stop before leaving
operator’s position.
Look for these symbols to
point out important safety
precautions. They mean:
• Attention!
• Personal Safety Is
Involved!
• Become Alert!
• Obey The Message!
WARNING: POTENTIALLY
HAZARDOUS SITUATION! If not
avoided, COULD RESULT in
death or serious injury.
DANGER: IMMINENTLY
HAZARDOUS SITUATION! If not
avoided, WILL RESULT in death
or serious injury.

EN - 3
NOTATIONS
NOTICE: General reference information for
proper operation and maintenance practices.
IMPORTANT: Specific procedures or
information required to prevent damage to
unit or attachment.
SAFETY DECALS AND
LOCATIONS
ALWAYS replace missing or damaged Safety
Decals. Refer to Figure 1 for safety decal
locations.
CAUTION: POTENTIALLY
HAZARDOUS SITUATION! If not
avoided, MAY RESULT in minor
or moderate injury. It may also be
used to alert against unsafe
practices.
P
07800403
07800401
KEEP HANDS and FEET AWAY
02988100
2
7
4
6
1
3
5
2
Figure 1

EN - 4
1. DANGER!
Discharge Hazard -
NEVER operate unit
without discharge chute in
operating position. Thrown
objects can cause injury or
damage.
Do not operate mower
unless all guards are in
operating position or
bagger is attached.
2. DANGER!
Discharge Hazard - NEVER
direct discharge toward
people, pets or property.
Thrown objects can cause
injury or damage.
Dismemberment Hazard -
NEVER stick hands or feet
under deck or shielded
areas.
Shut off engine, remove key,
and read manual before
servicing or making
adjustments to unit.
Keep children and others
away from unit while unit is
in operation.
Keep feet and hands away
from all rotating or moving
parts.
DO NOT step or stand in
this area.
3. DANGER!
DANGER!
Read and understand the
operator’s manual before
operating unit.
3.1 Amputation Hazard
To avoid amputation hazard
do not put hands near
rotating blades.
To avoid amputation hazard
do not put hands near
moving belts.
Keep hands away from all
rotating or moving parts.
Keep all guards and shields
in place.
3.2 Discharge Hazard
Discharge Hazard - NEVER
direct discharge toward
people, pets or property.
Thrown objects can cause
injury or damage.
Keep children and others
away from unit while unit is
in operation.
Do not operate mower
unless all guards are in
operating position or bagger
is attached.

EN - 5
3.3 Tipping Hazard
Avoid tipping hazard.
DO NOT operate on slopes
over 15°.
DO NOT operate on slopes
over 15°.
3.4 Service Hazard
Before servicing unit do the
following:
Read owners manual before
servicing or making
adjustments to unit.
Set parking brake.
Remove key and disconnect
spark plug before servicing
or making adjustments to
unit.
3.5 Bystander Hazard
DO NOT operate the unit in
the presence of bystanders.
Do not carry passengers.
15
15
P
Look behind when operating
the unit in reverse.
3.6 Loss of Traction Hazard
If loss of traction is
experienced do the
following:
Disengage PTO.
Proceed off slope slowly.
Do not try to turn or speed
up.
4. DANGER!
To avoid dismemberment
hazard do not put hands
near moving belts.
Keep hands away from all
rotating or moving parts.
5. DANGER!
DANGER!

EN - 6
Safety Rules
The following safety instructions are based
on ISO 5395 in effect at the time of
production.
ALWAYS Keep hands and
feet away from discharge
chute.
Dismemberment Hazard -
NEVER put hands or feet
beneath guards and or
shields.
6. DANGER!
DO NOT touch parts which
are hot from operation.
ALWAYS allow parts to cool.
7. CAUTION!
No smoking.
IMPORTANT: DO NOT
overfill.
Fill fuel tank to below bottom
of filler neck.
WARNING: Overfilling may cause
severe damage to evaporative
system!
• Never fill fuel tank when engine is
running, hot or unit is indoors. Never
overfill fuel tank.
• Replace fuel cap securely and clean
up spilled fuel.
Training
Read, understand, and follow all instructions
on the machine and in the manual(s) before
starting.
Be sure the area is clear of bystanders and
pets before operating. Stop machine if
anyone enters the area.
Improper use of power equipment can cause
serious permanent injury or death to the
operator or a bystander.
Understand:
• How to operate all controls
• The functions of all controls
• How to STOP in an emergency
• Braking and steering characteristics
• Turning radius and clearances
If the operator or the mechanic cannot read
the manual, it is the owner’s responsibility to
explain it to them.
ALWAYS train any inexperienced operators
and require them to read and understand all
manuals and decals.
Only allow responsible adults, who are
familiar with the instructions, to operate this
machine.
Only the operator can prevent and is
responsible for accidents or injuries
occurring to themselves, other people or
property.
Operator Age
DO NOT allow children under the age of 18
to operate any outdoor power equipment.
Local regulations may restrict the age of the
operator.
Data indicates operators age 60 years and
above are involved in a large percentage of
riding mower-related injuries.
These operators should evaluate their ability
to operate the riding mower safely enough to
protect themselves and others from serious
injury.
Children
Tragic accidents can occur if the operator is
not alert to the presence of children.
Children are often attracted to the machine
and the mowing activity. NEVER assume
that children will remain where you last saw
them.
Be alert and turn machine off if a child enters
the area.
Before and while backing, look behind and
down for small children.
NEVER carry children, even with the
blade(s) shut off. They may fall off and be
seriously injured or interfere with safe
machine operation. Children who have been
given rides in the past may suddenly appear
in the mowing area for another ride and be
run over or backed over by the machine.

EN - 7
NEVER allow children to operate the
machine.
Use extreme care when approaching blind
corners, shrubs, trees or other objects that
may block your view of a child.
Keep children out of the mowing area and in
the watchful care of a responsible adult
other than the operator.
Personal Protection
DO NOT wear loose clothing or jewelry and
tie back hair that may get caught in rotating
parts.
Wear adequate outer garments.
NEVER wear open sandals or canvas shoes
during operation. Wear adequate safety
gear, protective gloves and footwear.
Wear proper footwear to improve footing on
slippery surfaces.
ALWAYS wear eye and ear protection when
operating machine.
Before Operating
Keep all nuts and bolts tight to be sure the
equipment is in safe working condition.
Maintain the machine to be in compliance
with the maintenance schedule.
Clean grass and debris from unit, especially
from around muffler and engine, to help
prevent fires.
Check parking brake operation frequently.
Adjust and service as required.
Inspect unit before each use for missing or
damaged decals and shields, correctly
operating safety interlock system, and
deterioration of grass catchers. Replace or
repair as needed.
Ensure Safety Interlock System is
functioning properly. DO NOT operate unit if
safety interlock is damaged or disabled.
Start and operate unit only when seated in
operator’s position. Steering control levers
must be in neutral, PTO disengaged and
parking brake set when starting engine.
NEVER interfere with the intended function
of a safety device or reduce the protection
provided by a safety device. Check their
proper operation regularly.
Keep machine free of grass, leaves or other
debris build-up. Clean up oil or fuel spillage
and remove any fuel-soaked debris.
Operation
Be sure the area is clear of bystanders
before operating. Stop machine if anyone
enters the area.
NEVER operate machine in a closed or
poorly-ventilated area.
ALWAYS maintain unit in safe operating
condition. Damaged or worn out muffler can
cause fire or explosion.
This product is equipped with an internal
combustion type engine. DO NOT use unit
on or near any unimproved, forest-covered
or brush-covered land unless exhaust
system is equipped with a spark arrester
meeting applicable local, state or federal
laws. A spark arrester, if it is used, must be
maintained in effective working order by
operator.
DO NOT operate machine while feeling
tired, ill or under the influence of alcohol or
other drugs.
DO NOT put hands or feet near rotating
parts or under the machine. Keep clear of
the discharge opening at all times.
DO NOT touch parts which are hot. Allow
parts to cool.
DO NOT operate machine without the entire
grass catcher, discharge guard or other
safety devices in place and working.
ALWAYS keep hands and feet away from all
pinch points.
Avoid slippery surfaces. ALWAYS be sure of
your footing.
NEVER carry passengers.
NEVER direct discharged material toward
anyone. Avoid discharging material against
a wall or obstruction. Material may ricochet
back toward the operator. Stop the blade(s)
when crossing gravel surfaces.
NEVER engage PTO when attachment,
including mower blades, is not in use.
ALWAYS turn off power to attachment when
not in active use such as traveling or
crossing driveways.
ALWAYS disengage PTO, stop unit and
engine, remove key, engage parking brake
and allow moving parts to stop before
leaving operator’s position.
NEVER engage PTO while raising the
attachment, including mower blades, or
when attachment is in the raised position.
Keep safety devices or guards in place and
functioning properly. NEVER modify or
remove safety devices.

EN - 8
DO NOT mow in reverse unless absolutely
necessary. ALWAYS look down and behind
before and while backing.
Stop engine before removing grass catcher
or unclogging chute.
Slow down before turning.
If you strike a foreign object, stop and
inspect the machine. Repair, if necessary,
before restarting.
NEVER leave a running machine
unattended. ALWAYS turn off blade(s), set
parking brake, stop engine and remove key
before dismounting.
Disengage blade(s) when not mowing. Shut
off engine and wait for all parts to come to a
complete stop before cleaning the machine,
removing the grass catcher, or unclogging
the discharge guard.
Know the weight of loads. Limit loads to
those you can safely control and the unit can
safely handle.
Operating Conditions
Lightning can cause severe injury or death.
If lightning is seen or thunder is heard in the
area, do not operate the machine; seek
shelter.
ALWAYS check overhead and side
clearances carefully before operation.
Watch for traffic when operating near or
crossing roadways.
Clear the area of objects such as rocks,
wire, toys, etc., which could be thrown by the
blades.
Check for weak spots on docks, ramps or
floors. Avoid uneven work areas and rough
terrain. Stay alert for hidden hazards or
traffic.
Use care when approaching blind corners,
shrubs, trees or other objects that may
obscure vision.
Dust, smoke, fog, etc. can reduce vision and
cause an accident.
Operate machine only in daylight or good
artificial light.
Slope Operation
Slopes are a major factor related to loss of
control and tip-over accidents, which can
result in severe injury or death. Operation on
all slopes requires extra caution. If you
cannot back up the slope or if you feel
uneasy on it, DO NOT mow it.
DO NOT operate on slopes of more than
15°.
Mow up and down slopes, not across.
ALWAYS keep the machine in gear when
going down slopes. DO NOT shift to neutral
and coast downhill.
Watch for holes, ruts, bumps, rocks, or other
hidden objects. Uneven terrain could
overturn the machine. Tall grass can hide
obstacles.
DO NOT mow on moist or wet grass. Tires
may lose traction causing a loss of control.
Use extra care while operating machine with
grass catchers or other attachments; they
can affect the stability of the machine. DO
NOT use on steep slopes.
Keep all movements on the slope slow and
gradual. DO NOT make sudden changes in
speed or direction, which could cause the
machine to roll over.
Avoid starting, stopping, or turning on a
slope. If the tires lose traction, disengage
the blade(s) and proceed slowly straight
down the slope.
Operation on slopes may lead to loss of
steering control. When operating on slopes
be prepared to react to an emergency
situation:
• Return steering levers to neutral position.
• Immediately set parking brake.
• Turn off PTO and engine.
DO NOT try to stabilize the machine by
putting your foot on the ground.
DO NOT park on slopes unless necessary.
When parking on slope ALWAYS chock or
block wheels. ALWAYS set parking brake.
Choose a low ground speed so you will not
have to stop or shift while on a slope.
DO NOT mow near drop-offs, ditches, or
embankments. The machine could suddenly
roll over if a wheel goes over the edge or if
the edge caves in.
DO NOT bypass transmission or allow
transmission to free-wheel when on a slope.
Fuel
To avoid personal injury or property damage,
use extreme care in handling gasoline.
Gasoline is extremely flammable and the
vapors are explosive.

EN - 9
Ethanol blends must not exceed E10. Higher
ethanol content may cause your
machine to run hotter and damage your
engine.
Replace fuel cap securely and clean up
spilled fuel before starting engine.
Extinguish all cigarettes, cigars, pipes and
other sources of ignition.
Use only an approved gasoline container.
NEVER store the machine or fuel container
where there is an open flame, spark or pilot
light such as on a water or space heater or
other appliances.
NEVER fill containers inside a vehicle or on
a truck or trailer bed with a plastic liner.
ALWAYS place containers on the ground
away from your vehicle before filling.
NEVER fuel the machine indoors.
NEVER remove gas cap or add fuel with the
engine running. Allow engine to cool before
fueling.
Fuel is highly flammable and its vapors are
explosive. Handle with care. Use only an
approved gasoline container with an
appropriately-sized dispensing spout.
NO smoking, NO sparks, NO flames.
Remove gas-powered equipment from the
trailer and refuel it on the ground. If this is
not possible, then refuel such equipment
with a portable container, rather than from a
gasoline dispenser nozzle.
Keep the nozzle in contact with the rim of
the fuel tank or container opening at all
times until the fueling is complete. DO NOT
use a nozzle lock-open device.
NEVER overfill fuel tank. Replace gas cap
and tighten securely.
If fuel is spilled on clothing, change clothing
immediately.
Towing
Follow the manufacturer’s recommendations
for weight limits for towed equipment and
towing on slopes.
NEVER allow children or others in or on
towed equipment.
Tow only with a machine that has a hitch
designed for towing. DO NOT attach towed
equipment except at the hitch point.
On slopes, the weight of the towed
equipment may cause loss of traction and
loss of control.
Travel slowly and allow extra distance to
stop.
Accessories
Follow the manufacturer’s recommendation
for wheel weights or counterweights
Check the discharge guard frequently and
replace with the manufacturer’s
recommended parts, when necessary.
Use only Stiga-recommended attachments
that are appropriate to your use and can be
used safely in your application.
Batteries
Avoid electric shock. Objects contacting
both battery terminals at the same time may
result in injury and unit damage. DO NOT
reverse battery connections.
Reverse connections may result in sparks
which can cause serious injury. ALWAYS
connect positive (+) lead of charger to
positive (+) terminal, and negative (-) lead to
negative (-) terminal.
ALWAYS disconnect negative (-) cable
FIRST and positive (+) cable SECOND.
ALWAYS connect positive (+) cable FIRST,
and negative (-) cable SECOND.
Explosive gases from battery can cause
death or serious injury. Poisonous battery
fluid contains sulfuric acid and its contact
with skin, eyes or clothing can cause severe
chemical burns.
No flames, No sparks, No smoking near
battery.
ALWAYS wear safety glasses and protective
gear near battery. Use insulated tools.
ALWAYS keep batteries out of reach of
children.
Battery posts, terminals and related
accessories contain lead and lead
compounds, chemicals known to the state of
California to cause cancer and reproductive
harm. Wash hands after handling.
Service
The use of non-genuine replacement parts
or accessories could adversely affect
machine operation and safety.
Do not change engine governor setting or
overspeed the engine.
Maintain or replace safety and instruction
labels as necessary.
Keep unit free of debris. Clean up oil or fuel
spills.

EN - 10
ALWAYS block wheels and know all jack
stands are strong and secure and will hold
weight of unit during maintenance.
Release any pneumatic or hydraulic
pressure from components slowly.
NEVER attempt to make any adjustments to
unit while engine is running (except where
specifically recommended). Stop engine,
remove key and spark plug wire and wait for
all moving parts to stop before servicing or
cleaning.
Lower cutting deck unless a positive
mechanical lock is used.
Allow engine to cool before servicing.
Moving parts can cut or amputate fingers or
a hand. On multiblade mowers, rotation of
one blade will cause all blades to rotate.
NEVER weld or straighten mower blades.
NEVER make adjustments or repairs with
the engine running.
Mower blades are sharp. Wrap the blade or
wear gloves, and use extra caution when
servicing them.
ALWAYS keep body and hands away from
pin holes or nozzles which eject hydraulic
fluid under pressure.
Transporting Unit
Use extra care when loading or unloading
the machine into a trailer or truck.
Secure unit chassis to transport vehicle.
NEVER secure from rods or linkages that
could be damaged.
DO NOT transport machine while engine is
running.
ALWAYS turn off power to attachment and
shut off fuel when transporting unit.
Storage
NEVER store unit with fuel in fuel tank inside
a building where any ignition sources are
present.
Keep machine free of grass, leaves or other
debris build-up. Clean up oil or fuel spillage
and remove any fuel-soaked debris. Allow
machine to cool before storing.
For extended storage, close fuel shut off
valve and clean unit thoroughly. See engine
manual for proper storage.
Insuring Your Lawnmower
Check the insurance on your lawnmower.
Contact your insurance company.
You ought to have fully comprehensive
insurance for traffic, fire, damage and theft.

EN - 11
Tools Required
• Adjustable wrenches
• Petroleum jelly or dielectric grease
Unpack Unit
Remove unit and all other components from
the shipping container. Engage transmission
bypass lever. See Moving Unit Manually on
page 18. Push unit from container onto a
level surface. Disengage transmission
bypass lever.
Connect Battery
See Install Factory-Installed Battery on
page 26 and perform steps 4 and 6 in the
installation section.
Place Unit in Operating Position
(Figure 2)
NOTE: The unit is shipped with the seat
positioned as far forward as possible and in
service position.
1. Remove steering lever hardware from
bottom hole of the steering lever.
2. Rotate steering lever forward to align
bottom hole with hole in pivot arm and
reinstall hardware.
NOTE: Do not tighten hardware before
reviewing Adjusting Steering Levers on
page 27. If no adjustment is desired, tighten
hardware.
3. Push steering levers aside and tip seat
into operating position.
4. Adjust the seat as needed. See Seat
Adjustment on page 15.
Check Engine Oil Level
Refer to Engine Manual.
Check Tire Pressure
See Specifications on page 32.
ASSEMBLY
WARNING: AVOID INJURY.
Read and understand the entire
Safety section before
proceeding.
CAUTION: Avoid injury!
Explosive separation of tire and
rim parts is possible when they
are serviced incorrectly:
• Do not attempt to mount a tire
without the proper equipment
and experience to perform the
job.
• Do not inflate the tires above
the recommended pressure.
• Do not stand in front or over
the tire assembly when
inflating. Use a clip-on chuck
and extension hose long
enough to allow you to stand to
one side.
Figure 2
1. Steering Lever
2. Steering Lever Hardware
3. Steering Pivot Arm
1
2
3

EN - 12
Level Mower Deck
See Leveling and Adjusting Pitch of Mower
Deck on page 22.
Fill Fuel Tank
Fill fuel tank. DO NOT OVERFILL! See Filling
Fuel Tank on page 17.
Check Safety Interlock System
See Safety Interlock System on page 14.
Check Function of all Controls
See Operation on page 14.
WARNING: Safety interlock
failure and improper operation of
unit can result in death or serious
injury. Check system before each
use to make sure it is functioning
properly.

EN - 13
1. Ignition Switch
2. PTO Switch
3. Seat
4. Fuel Level
5. Steering Levers
6. Fuel Tank
7. Mower Lift Pedal
8. Mower Deck
9. Discharge Chute
10. Parking Brake Lever
11. Throttle Lever
12. Choke
13. Seat Adjustment Lever
14. Height of Cut Selector Lever
15. Washout Port
CONTROLS AND FEATURES
3
10
7
9
5
4
14
2
1
6
8
13
15
11 12
Figure 3

EN - 14
CONTROLS AND FEATURES
See Figure 3 for all controls and features
locations.
Safety Interlock System
Perform the following tests to ensure the
safety interlock system is working properly. If
the unit does not perform as stated contact
your Stiga dealer for repairs.
Ignition Switch
Operate ignition switch
with a removable key.
Ignition switch has three
positions: Stop (1),
Run (2), Start (3). See
Starting and Shutting Off
Engine on page 17 for
detailed instructions on
how to start engine.
Throttle
Fast (1) – Increases engine
speed.
Slow (2) – Decreases engine
speed.
Choke
Pull choke control out to start a
cold engine.
Push choke control in when
engine is warm.
Parking Brake Lever
Engages (2) and
disengages (1) parking
brake.
Power Take-Off (PTO) Switch
Engages (2)
and
disengages
(1) mower
blades.
OPERATION
WARNING: AVOID INJURY.
Read and understand the entire
Safety section before proceeding.
WARNING: Safety interlock failure
and improper operation of unit can
result in death or serious injury.
Check system before each use to
make sure it is functioning
properly.
Test Steering Lever PTO Parking Brake Engine
1 Neutral Position Off Engaged Starts
2 Neutral Position On Engaged Doesn’t Start
3 Neutral Position Off Disengaged Doesn’t Start
4*+ Out of Neutral Position Off Disengaged Shuts Off
5*+ Neutral Position On Engaged Shuts Off
* Test with engine running. + Operator lifts off seat.
C
1
2
1
2
1
2

EN - 15
Steering Levers
• Reverse (1) – Pull both steering levers
backward.
• Forward (2) – Push both steering
levers forward.
• Left (3) – Pull left steering lever back
or push right steering lever forward or
a combination of both.
• Right (4) – Pull right steering lever
back or push left steering lever
forward or a combination of both.
NOTE: To stop, return both steering levers to
neutral.
NOTE: The steering levers must be in the
neutral position to start the engine.
NOTE: The parking brake must be
disengaged prior to moving the steering
levers from the neutral position.
Height of Cut
(Figure 4)
1. Press the mower lift pedal to raise the
deck.
2. Position height of cut selector lever at
the desired setting in the height of cut
bracket.
3. Release mower lift pedal.
Seat Adjustment
(Figure 5)
Push lever back and slide seat forward or
backward to the desired position. Release
lever to lock seat in position.
Washout Port
(Figure 6)
NOTICE: Wash the underside of the mower
after each use to prevent grass buildup and
improve mulch action and clipping dispersal.
12
34
Figure 4
1. Mower Lift Pedal
2. Height of Cut Selector Lever
3. Height of Cut Bracket
231
WARNING: A broken or
missing deck port can result in
exposure to harmful thrown
objects or blade contact.
Replace broken or missing
deck port before using unit.
NEVER put your hands or feet
under the mower or through
openings in the mower.
Figure 5

EN - 16
1. Park the unit on a level surface, within
reach of hose and in a location where
the dispersal of wet grass clippings is
acceptable.
2. Disengage the PTO switch, shut off the
engine, remove key, engage parking
brake and allow unit to cool for at least
30 minutes.
IMPORTANT: Do not wash the unit with water
when the unit is warm from operation. Water
can seep into bearings and cause damage.
3. Attach the hose coupling to a standard
garden hose connected to a water
supply.
4. Pull back the lock collar of the hose
coupling and push the coupling onto the
deck port until the coupling it tightly in
place. Release the lock collar to lock the
coupling to the deck port.
NOTICE: Apply petroleum jelly to washout
fitting O-ring to allow the coupling to slide on
easier and to protect the O-ring.
NOTICE: The coupling contains a valve that
will not allow water flow unless coupling is
attached to washout fitting. Water supply
should be turned off before attaching coupling
to the fitting.
5. Lower deck to lowest cutting height.
6. Turn the water supply on high.
NOTICE: If water leaks excessively from
hose coupling onto top of deck, coupling may
not be fully seated onto washout port. Turn off
water supply and repeat steps 4 through 6.
Use firm pressure while installing coupling
onto washout port.
7. From the operators seat, start the
engine and engage the PTO. Allow unit
to run as needed - typically
2 to 3 minutes.
NOTICE: Water spraying from discharge
chute should change from green to clear
when deck is clean.
8. Disengage the PTO, turn off engine,
remove key and wait for all moving parts
to stop.
9. Turn the water supply off and remove
coupling from the washout fitting.
NOTICE: If the mower deck is not clean after
one washing, soak it and let stand for
30 minutes. Then repeat process.
10. After cleaning the mower deck, run the
unit again for 2 to 3 minutes to remove
access water.
Fuel Level
Slot in seat plate shows the fuel
level in the tank. Refill when
level reaches bottom of slot.
Figure 6
1. Deck Port
2. Hose Coupling
3. Lock Collar
4. Mower Deck
5. Standard Garden Hose
1
3
5
4
2
WARNING: When using the deck
wash system, NEVER engage the
deck from any position other than
the operator’s seat.
DO NOT engage deck in the
presence of ANY bystander.

EN - 17
FILLING FUEL TANK
IMPORTANT: DO NOT OVERFILL!
To add fuel to the fuel tank:
1. Clean fuel cap and surrounding area to
prevent dust, dirt, and debris from
entering fuel tank.
2. Remove fuel cap.
IMPORTANT: Use lead-free petrol only. DO
NOT mix petrol with oil. Petrol is perishable
and should not remain in the tank for more
than 30 days. The use of ecological fuels, i.e.
alkylate petrol, is possible and the
composition of this petrol is less harmful to
people and the environment. No negative
effects linked to the use of this petrol have
been reported, but always consult the
instructions and data provided by the
producer of the alkylate-based petrol. Empty
the fuel tank completely before storing
machine for a prolonged period (e.g. over the
winter).
3. Fill fuel tank to the bottom of filler neck.
See Specifications on page 32 for fuel
tank capacity.
IMPORTANT: DO NOT OVERFILL! This
equipment and/or its engine may include
evaporative emissions control system
components that will only function properly
when the fuel tank has been filled to the
recommended level. Overfilling may cause
permanent damage to evaporative emissions
control system components. Filling to the
recommended level ensures a vapor gap
required to allow for fuel expansion. Pay
close attention while filling the fuel tank to
ensure that the recommended fuel level
inside the tank is not exceeded. Use a
portable gasoline container with an
appropriately sized dispensing spout when
filling the tank. Do not use a funnel or other
device that obstructs the view of the tank
filling process.
4. Replace fuel cap and tighten.
5. ALWAYS clean up spilled fuel.
STOPPING IN AN EMERGENCY
1. Return steering levers to neutral position.
2. Immediately set parking brake.
3. Turn off PTO and engine.
NOTE: This unit is equipped with the return to
neutral function. The control arms will
automatically return gradually to neutral when
released from the forward position.
STARTING AND SHUTTING OFF
ENGINE
Starting the Engine
NOTICE: Disengage the PTO, engage the
parking brake, and place the steering levers
in neutral prior to starting the engine.
1. If the engine is cold, apply choke. If the
engine is warm or hot, do not use choke.
See on page 14.
IMPORTANT: DO NOT operate starter for
more than 10 seconds per minute as damage
can occur.
2. Turn ignition key to start position and
release once the engine has started.
3. Let the engine warm up several seconds
to several minutes depending on outside
temperature.
Stopping the Engine
1. Stop unit.
2. Disengage PTO.
3. Set throttle lever to slow.
4. Turn ignition switch to off position and
remove key.
5. Set parking brake.
OPERATING MOWER
1. Start engine.
2. Set throttle lever to fast.
IMPORTANT: Never engage PTO if mower is
plugged with grass or other material.
3. Engage PTO to start mower blades. It
will take 2 – 3 seconds for the blades to
engage.
NOTE: The parking brake must be
disengaged prior to moving the steering
levers from the neutral lockout position.
4. Release parking brake.
5. Use steering levers to move the unit.
6. Disengage PTO to stop mower blades.
TRANSPORTING UNIT
ALWAYS shut off engine, set parking brake,
remove key, and properly remove fuel when
transporting unit on a truck or trailer. Tie unit
down securely. Do not tie down by linkages,
guards, cables or other parts that may be
damaged.
WARNING: Operating unit on
slopes may lead to loss of
steering control. When operating
on slopes be prepared to react to
an emergency situation.

EN - 18
FOR BEST PERFORMANCE
Cut grass when it is dry.
Keep mower blades sharp.
Keep mower deck properly leveled.
Do not set height of cut too low. For very tall
grass, mow twice.
Do not travel too fast.
Mow with the engine set at full throttle.
When mulching, only remove one-third of
grass length per cutting.
Discharge clippings into areas already cut.
Vary cutting pattern with each mowing.
Do not allow grass or debris to collect inside
of mower deck. Clean after each use.
MOVING UNIT MANUALLY
(Figure 7)
Pull the bypass lever out and lock it in place,
and then release the parking brake to push
the unit by hand.
Push the bypass lever in to drive the unit
normally.
NOTICE: There are two bypass levers (one
on each side of the unit).
WARNING: DO NOT disengage
or bypass transmission and coast
downhill.
Figure 7
1. Bypass lever pulled out to push the unit
by hand.
2. Bypass lever pushed in to drive the
unit.
2
1
