STKR FUL PRO LIGHT TELESCOPING 12679 User manual

IPX6
WATERPROOF
704-508-1031 | [email protected] | STKRconcepts.com
QUESTIONS? Before returning to your retailer, call our customer service department at
704-508-1031, 8 a.m. - 5 p.m. ET, Monday - Friday or email us at inf[email protected]
INSTRUCTIONS COMPONENTS
POWER/MODE BUTTON
Press to turn ON
Press to change mode:
1. Spotlight
2. Flood Light
3. Spotlight + Flood Light
4. Red Flood Light
5. Flashing Red Flood Light
6. Flashing Flood Light
7. O
After 5 seconds of no mode change, next
button press is OFF
CHANGE BRIGHTNESS
Press & HOLD to increase/decrease brightness
Light blinks to indicate minimum or maximum
brightness level.
MEMORY RECALL
FLi-PRO Telescoping Light remembers the last
used light mode. After 5 seconds of no mode
change, next Power Button press is OFF. When
pressed again the light will recall last used light
mode.
WIRELESS REMOTE
Wireless remote works up to 15’(4.5m) from
ashlight head
Independently control light modes and
brightness
When not in use magnetically attach remote to
base of tripod
Hooks
Tripod Mount
(1/4”-20 UNC)
Rod Leveler
Ball Joint
Tensioner
Wireless
Remote
Storage
Flip-out Leg Extension/
Earth Spike
WIRELESS REMOTE
FLi-PRO FLASHLIGHT TELESCOPING ROD
TRIPOD
Wireless Remote
Magnet
Magnet
Spotlight
Flood Light
Power Button/
Battery Level
Indicator
USB-C Port
Extendable from 2’3” to 8’(2.4m)
FLi-PRO Flashlight
Holder
Tripod Connector
Extension
Rod
Flood Light
Dimmer
Brighter
Spotlight
Finger placement
(Wireless Remote Orientation)
Red Flood Light
Model # 12679

LIGHTING STRIKE HAZARD WARNING
DO NOT USE during a thunderstorm. Before a thunderstorm approaches ensure the
FLi-PRO Telescoping Light is stored safely. If you are caught outside during a thunder-
storm DO NOT STAND NEAR the FLi-PRO Telescoping Light. STAY A SAFE DISTANCE AWAY
from the FLi-PRO Telescoping Light as it can act as a lighting rod. Use all lightning safety
measures. Not following thunderstorm/lighting precautions can result in serious injury
or death.
Model # 12679
1 Year warranty
Troutman, NC | 704-508-1031 | [e-mail] | STKRconcepts.com
REPLACEABLE BATTERY
Over time battery degradation may occur. To replace a worn out cell follow these steps:
1) Unscrew handle 2) Carefully unplug battery 3) Replace 21700 Lithium-ion recharge-
able battery with JST connector (to match original battery capacity use 4000mAh,
available on our website.) 4) Plug battery connector into terminal 5) Screw handle back
on.
PATENT PENDING
CHARGING
1) Remove USB-C port cover 2) Plug the USB-C cable into the USB-C port 3) plug the
other end of the cable into a USB wall charger*, USB car charger*, or any other USB
charging device* (e.g. computer). *Not included. *Charger output of up to 3A is
recommended. Charger output should NOT exceed 3.6A to prevent battery damage.
- - Battery Level Indicator lights blink while charging then solid glow when fully charged.
**Please recharge a stored unit every four months to maintain optimum performance of the
lithium-ion batteries and maximize charging levels. Battery excl. from warranty.
LED SAFETY WARNING
This product contains high intensity LED devices.To prevent permanent eye damage, do
not stare into the light beam at close range.
PACKAGE CONTENTS
[1] FLi-PRO Flashlight
[1] Telescoping Rod
[1] Tripod
[1] Wireless Remote
[1] USB-A to USB-C Cable
[1] Carrying Bag
SPECIFICATIONS
LIGHT
1200 Total Max True-Lumens
Flood Light: 900 Lumens (Daylight White) or Red Light
Spotlight: 400 Lumens (Daylight White)
RUNTIME
Spotlight: 4.5 hours (100% brightness)
Flood Light: 1.5 hours (100% brightness)
Spotlight + Flood Light: 1 hour (100% brightness)
BATTERY
21700 Rechargeable Lithium-ion
Capacity: 4000mAh
OTHER
IPX6 Waterproof Rating
Total Weight: 1.9lb (0.86Kg) [battery incl.]
Store Magnetic
Wireless Remote
Here
BATTERY LEVEL INDICATOR
Power button battery level indicator LEDs turn on for 5 seconds when light is turned on
or off.
100-60% Green
59-25% Yellow
24-10% Red
9-0% Flashing Red
