Stonegate FP10-27-11-50 Installation and operating instructions

ELECTRIC FIREPLACE HEATER
ASSEMBLYAND OPERATION MANUAL


IMPORTANT SAFETY INSTRUCTIONS

CAUTION / ATTENTION -- DO NOT PLUG THE HEATER INTO ANY
POWER OUTLET OR OPERATE BEFORE READING ALL
INSTRUCTIONS!
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
When using electrical appliances, basic precautions should always be followed to reduce the
risk of fire, electric shock, and injury to persons, including the following:
1. Read all instructions before using this fireplace. Failure to follow these important safety
instructions may cause fire, electric shock or damage. Following proper safety and
operating instructions is the responsibility of the owner.
2. WARNING: This fireplace heater is hot when in use. To avoid bums, do not let bare skin
touch hot surfaces. The grill directly in front of the heater outlet becomes hot during
heater operation.
3. CAUTION – High Temperature. Keep any combustible materials, such as furniture,
pillows, bedding, papers, clothes, curtains and other furnishings at least 10 feet away
from the front, sides and rear of the heater.
4. Extreme caution is necessary when any heater is used by or near children or those with
disabilities.
5. Do not operate the heater unattended or while sleeping. Stay alert and monitor operation
at all times.

6. Always unplug fireplace when not in use.
7. Do not operate any fireplace heater with a damaged cord or plug, or if the heater has
malfunctioned, or if the fireplace has been dropped or damaged in any manner. Take
fireplace to authorized service facility for examination, electrical or mechanical
adjustment or repair.
8. Check your heater cord and plug connections. A loose fitting outlet can cause the plug
to overheat and/or cause a fire. Be sure plug fits tight in the outlet. Check frequently
during use to make sure plug and outlet are not hot. If so, discontinue using heater
immediately and have outlet replaced by a qualified electrician. CAUTION: Heaters
draw more current than small appliances, overheating of the outlet may occur even if it
has not occurred with the other appliances.
9. Under no circumstance should this electric fireplace be modified. Parts having to be
removed for servicing must be replaced by a certified repair center prior to operating this
electric fireplace again.
10. Do not use outdoors or anywhere that it can get wet.
11. This fireplace is not intended for use in bathrooms, laundry areas and similar indoor
locations. Never use this appliance near a bathtub or in the vicinity of water.
12. Do not place or operate the fireplace insert directly on carpet or a similar surface, which
may restrict air circulation beneath the unit. The fireplace insert must be installed in the
mantle before use.
13. To prevent a possible fire, do not block air intake or exhaust in any manner. Do not use on
soft surfaces, like a bed, where openings may become blocked.
14. Do not run cord under carpeting, furniture or appliances. Do not cover cord with
carpeting, throw rugs, runners, or the like. Arrange cord away from traffic area and
where it will not be tripped over.
15. To disconnect fireplace, turn all controls to off, then remove plug from outlet.
16. Grounding – this heater is for use on 120 volts. The cord has a plug with three blades
for proper grounding. DO NOT attempt to modify the plug in any way or use adaptors
to defeat the purpose of the grounding feature. Plug ONLY into a receptacle that accepts
three-blade plugs. CAUTION: To Prevent Electric Shock Match Wide Blade of Plug to
Wide Slot of Outlet, Fully Inserted.
17. When this appliance is installed, it must be electrically grounded in accordance with local
codes with the current CSA C22.1 Canadian local codes for USA installation. Follow
local codes and National Electrical Code, ANSI/NFPA NO. 70 and Canadian Code, CZ
22.2 No. 0.
18. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this
may cause an electric shock or fire, or damage the heater.
19. WARNING: This appliance gets hot and it contains internal parts that could arc or spark.
Do not use it in areas where gasoline, paint, or flammable liquids are used or stored or
where the unit will be exposed to flammable vapors. This fireplace should not be used
as a drying rack for clothing. Do not hang Christmas stocking or any decoration on the
fireplace heater or mantle. Do not use near propane tanks.
20. Do not modify this fireplace. Use it only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock or injury to persons.

21. WARNING: NEVER USE WITH AN EXTENSION CORD OR RE-LOCATABLE
POWER STRIP. An extension cord may overheat and cause a risk of fire.
22. Do not burn wood or other materials in this fireplace.
23. Do not strike fireplace glass.
24. If the heater unit has been dropped or damaged, do not operate unless fully checked out
by a certified repair center.
25. Always use a certified electrician should new circuits or outlets be required.
26. Always use properly grounded, fused and polarized outlets.
27. Always use ground fault protection where required by electrical code.
28. WARNING – Always disconnect the unit from the power supply before performing any
cleaning, light bulb replacement, maintenance or relocation of the electric fireplace.
29. When transporting or storing the fireplace and cord, keep in a dry place, free from
excessive vibration and store so as to avoid damage.
NOTE: Procedures and techniques that are considered important enough to emphasize.
CAUTION: Procedures and techniques, which, if not carefully followed, will result in
damage to the equipment or personal property or may cause personal injury.
CAUTION: TO RESET TEMPERATURE LIMITING CONTROL DISCONNECT POWER
USING PLUG CAP OR MAIN SWITCH FOR 5MIN.
CAUTION: TO PREVENT ELECTRIC SHOCK MATCH WIDE BLADE OF PLUG TO
WIDE SLOT, FULLY INSERT
WARNING: Procedures and techniques, which, if not carefully followed, will expose the
user to the risk of serious injury, illness or death.
WARNING:
This heater and parts become hot when in use. Be sure to maintain a personal distance and
keep any combustible material at least ten feet away from the heater. The area directly
around and under the heater must be clear and free of any obstructions.
DO NOT ALLOW CHILDREN TO OPERATE. KEEP CHILDREN AND PETS
AWAY FROM HEATER AND CONTROLS.
CHOOSING LOCATION FOR YOUR FIREPLACE:
When choosing a location for your Electric Fireplace ensure that the general safety
instructions are followed. For best results, install out of direct sunlight.
NOTE: A complete electric fireplace heater may consist of two parts, the wooden mantle
and the fireplace heater insert. DO NOT use the fireplace heater insert without first
installing it in the wooden mantle. Unpack the fireplace heater and mantle. Remove all
packing materials

Assembly Instructions
PartsList: HardwareList:
PartsDiagram:



A
I
F
E
B
C
D
G
JK
M
LO
P
N
HH
I
P
P
P
Q Cam Lock Screws 62pcs
R Cam Lock Nut 62pcs
S Self-Tapping
Screws 24pcs
T
Mounting Screws 5pcs
U
L Shape Bracket 2pcs
A Top Panel 1pc
B Middle Panel 1pc
C Base Panel 1pc
D Upper Back Panel 1pc
E Upper Front Panel 1pc
F Right Inner Panel 1pc
G Left Inner Panel 1pc
H Front Shelves 2pcs
I Small Back Panel 2pcs
J Right Back Panel 1pc
K Left Back Panel 1pc
L Right Large Inner Panel 1pc
M Left Large Inner Panel 1pc
N Right Front Panel 1pc
O Left Front Panel 1pc
P Side Shelves 4pcs
Top Panel
MiddlePanel
BasePanel
Small
BackPanels
LeftInnerPanel
Ri
g
htInnerPanel
RightBackPanel
RightLargeInnerPanel LeftLargeInnerPanel
Left Back Panel
RightFrontPanel
L
eft

Front

Panel

U
pp
erBackPanel
UpperFrontPanel
FrontShelfFrontShelf
SideShelvesSideShelves

**RECOMMEND 2 PEOPLE FOR ASSEMBLY!
Step 1: Attach 8pcs Cam Lock Screws (Q) under the Top Panel (A).
Attach 4pcs Cam Lock Screws (Q) to the Middle Panel (B).
Attach 12pcs Cam Lock Screws (Q) to the Base Panel (C).
Attach 3pcs Cam Lock Screws (Q) to the Right Inner Panel (F).
Attach 3pcs Cam Lock Screws (Q) to the Left Inner Panel (G).
Attach 6pcs Cam Lock Screws (Q) to the Right Back Panel (J).
Attach 6pcs Cam Lock Screws (Q) to the Left Back Panel (K).
Attach 4pcs Cam Lock Screws (Q) to the Right Large Inner Panel (L).
Attach 4pcs Cam Lock Screws (Q) to the Left Large Inner Panel (M).
Attach 6pcs Cam Lock Screws (Q) to the Right Front Panel (N).
Attach 6pcs Cam Lock Screws (Q) to the Left Front Panel (O).
See Figure 1.
A
B
CG
F
JLNKM
O
Figure 1
Q

Step 2: Insert the 2 pcs Cam Lock Nuts (R) into the Upper Front Panel (E) making sure the +
is facing out and the arrow is pointing up. Attach the Upper Front Panel (E) to the Right Inner
Panel (F) and the Left Inner Panel (G). Turn the Cam Lock Nuts (R) clockwise with a Phillips
Head Screwdriver (not included) until the arrow is pointing down. See Figure 2.
E
G
F
Figure 2
Step 3: Insert 4 pcs Cam Lock Nuts (R) into Right Inner Panel (F) and the Left Inner Panel
(G). Insert Cam Lock Screws in the Middle Panel (B) into the Right Inner Panel (F) and the
Left Inner Panel (G) and tighten the 4 Cam Lock Nuts (R). See Figure 3.
E
G
F
B
Figure3
Q
R
Q
R

Step 4: Attach the Left & Right Front Shelves (H) to the Right Inner Panel (F) and to the Left
Inner Panel (G) using 4pcs Cam Lock Nuts (R). Note: Cam Lock Nuts should be placed on
the underneath side of the shelves. See Figure 4.
G
F
B
H
Figure4
Step 5: Attach the Right Large Inner Panel (L) to the Right Back Panel (J) using 2 Cam Lock
Nuts (R). Attach the Left Large Inner Panel (M) to the Left Back Panel (K) using 2 Cam
Lock Nuts (R). See Figure 5.
L
K
M
J
Figure5
R
Q
R

Step 6: Attach 2pcs Side Shelves (P) to the Right Back Panel (J) using 4pcs Cam Lock Nuts
(R). Attach 2pcs Side Shelves (P) to the Left Back Panel (K) Using 4pcs Cam Lock Nuts (R).
Note: The Cam Lock Nuts should be inserted on the underside of the shelves. See Figure 6.
L
K
M
J
P
P
P
P
Figure6
Step 7: Attach the Right Front Panel (N) to the Right Large Inner Panel (L) and the 2pcs
Shelves (P) using 6pcs Cam Lock Nuts (R). Note: The Cam Lock Nuts should be inserted on
the underside of the shelves. Attach the Left Front Panel (O) to the Left Large Inner Panel (M)
and the 2 pcs Shelves (P) using 6pcs Cam Lock Nuts (R). See Figure 7.
L
K
M
J
P
P
O
N
Figure 7
R
Q
R
Pre‐attachedCamLock
Screws(Q)ontheback
sidesoftheFrontPanels.

Step 8: Attach the Right Large Inner Panel (L) to the Top Panel (B) and to the Right Front
Shelf (H) using 4pcs Cam Lock Nuts (R). Attach the Left Large Inner Panel (M) to the Top
Panel (B) and to the Left Front Shelf (H) using 4pcs Cam Lock Nuts (R). Note: The Cam
Lock Nuts should be on the underside of the Panels and Shelves. See Figure 8.
G
F
B
H
H
L
K
J
P
P
O
N
Figure8
Step 9: Lay the Assembled unit on its backside to make it easier to attach the Base (C). Attach
the assembled unit to the Base Panel (C) using 12pc Cam Lock Nuts (R). Make sure all of the
Cam Lock Nut (R) holes line up with all of the Cam Lock Screws (Q) on the Base Panel (C).
See Figure 9.
G
F
B
H
H
L
K
J
P
P
O
N
C
Figure9
R
Q
R
Q

Step 10: Attach the Small Back Panels (I) to the Right Inner Panel (F) & the Right Large
Inner Panel (L) and then to the Left Inner Panel (G) & the Left Large Inner Panel (M) on the
back side of the cabinet using 12pcs Self-Tapping Screws (S). See Figure 10.
F
BK
J
P
P
O
N
C
II
Figure10
Step 11: Attach the Top Panel (A) to the Cabinet using 4 Cam Lock Nuts (R). Note: Cam
Lock Nuts will be inside the shelf area. See Figure 11.
FB
K
J
P
P
O
N
C
II
A
Figure 11
BACKVIEW
BACKVIEW
R
S

Step 12: Attach the Upper Back Panel (D) with 12pcs Self-Tapping Screws (S).
See Figure 12.
FP
P
O
N
C
II
A
D
Figure12
Step 13: Place the Electric Fireplace Heater Insert through the back of mantle with the Front of
the heater facing the opening in the mantle. See Figure 13.

FP
P
O
NC
II
A
Figure13
BACKVIEW
BACKVIEW
S

Step 14: Once the insert is in place, attach the Top of the insert to the back of the Upper Front
Panel (E) using 3pcs Mounting Screws (T). Also attach the insert to the Base Panel (C) using 2pcs
L-Shape Brackets (U) and 2pcs Mounting screws (T). See Figure 14.
P
P
O
N
II
A
Figure14
ASSEMBLY COMPLETE
BACKVIEW

After reading through the following instructions completely, confirm all controls on fireplace
heater are in the OFF position. Plug the fireplace into a 15AMP/120Volt outlet. Once the
fireplace insert has been properly connected to a grounded, electrical outlet, it is ready to operate.
Operating Instructions
The controls are located behind the grill below the front glass and can be accessed by pulling grill
from the top. Pull forward and down.
O/I: Press this button for main power and flame effect. The indicator light will turn on.
1250W: For heat function - Press this switch while the O/I switch is in the ON position. The
indicator light will turn on.
Temperature Control: To adjust the temperature to your individual requirements, turn the
temperature control dial to the right (clock-wise) to increase the desired temperature and to the left
for lower temperature. This temperature control dial can only be used while the O/I switch and
1250W switch are in the ON position.
Note: When the O/I switch is turned off, the heater functions will stop even though the switches
may be in the ON position.
Maintenance
WARNING: Disconnect power before attempting any maintenance or cleaning to reduce the
risk of fire or electric shock.
Cleaning
Before cleaning any parts of the fireplace make sure to first turn off the controls and then unplug
the unit from power source.
CAUTION: Wait until the unit has completely cooled before attempting any cleaning.
Cleaning glass door: Remove dust with clean dry cloth. Remove fingerprints and other marks
from glass door by using a clean damp cloth. Do not use abrasive cleaners or spray liquids on
glass door surfaces.
Metal and metal painted parts should be cleaned with clean damp cloth only. Do not use abrasive
cleaners or spray liquids on this surface.

RISK OF FIRE:
Do not exceed the recommended bulb wattage. Do not use with an extension cord or power strip.
Replacing the Light Bulb
Step 1: Unplug the fireplace heater.
Step 2: Remove the 12 screws on the back of fireplace insert and open the back cover. There are 2
larger screws and 10 smaller screws.
Step 3: You will find 1 X 40W Type B-10 bulbs under log-set bed.
Step 4: Loosen and remove the old bulb and replace with a new bulb.
Step 5: Close the back cover. Secure the 2 larger screws into the top left corner hole and bottom
right corner holes as shown in the diagram. Secure the 10 smaller screws into the remaining holes.
Make sure the screws are in the correct holes and have been tightened.
Step 6: Plug in the unit and resume use.
