Napoleon NEFE42-1715BW User manual

W415-1532 / A / 03.04.16
EN
FR
PG
15
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
1.45A
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone [phone] • Fax [phone] • www.napoleonfireplaces.com • [email protected]
SAFETY INFORMATION
!WARNING
If the information in these instructions are
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
$10.00
CERTIFIED UNDER CANADIANAND AMERICAN NATIONAL STANDARDS: CSA C22.2 No-46 / UL 2021
NEFE42-1715BW
ELECTRIC FIREPLACE MEDIA CONSOLE

EN
W415-1532 / A / 03.04.16
2
NOTE: Changes, other than editorial, are denoted by a vertical line in the margin.
TABLE OF CONTENTS
1.0 GENERAL INFORMATION 2
2.0 OVERVIEW 2
2.1 MEDIA CONSOLE COMPONENTS LIST 2
2.2 HARDWARE LIST 3
3.0 ASSEMBLY 4
3.1 APPLIANCE INSTALLATION 8
3.2 CARE AND MAINTENANCE 10
4.0 WARRANTY 11
5.0 NOTES 12
1.0 GENERAL INFORMATION
This media console is approved for use with electric appliances only. It is not approved for use as a stand alone
product or in conjunction with any other appliance.
2.0 OVERVIEW
A
G
F
H
D
B
G
J
I
E
C
G
G
K
O
M
P
N
L
REFERENCE DESCRIPTION
QTY
A
BASE
RIGHT BOTTOM REAR PANEL
LEFT BOTTOM REAR PANEL
GLASS SHELVES
PART # 1
1
1
1
1
1
4
1
LEFT INNER PANEL
LEFT DOOR
RIGHT DOOR
MIDDLE SHELF PANEL
TOP GLASS
1
1
1
1
1
1
RIGHT INNER PANEL
B
C
D
E
F
G
H
I
J
K
L
M
N
O
W035-0413
W475-1181
W475-1180
W590-0024
W475-1175
W475-1176
W225-0365
W225-0364
W590-0023
W370-0049
1
W300-0223
W475-1183
TOP SUPPORT PANEL
TOP PANEL
W475-1177
HARDWARE KIT
LEFT OUTER PANEL
W475-1178
W715-1065
TOP TRIM
W475-1182 TOP REAR PANEL
P
Q
1
1
RIGHT OUTER PANEL
W475-1179
2.1 MEDIA CONSOLE COMPONENTS LIST

EN
W415-1532 / A / 03.04.16
3
REF.NO DESCRIPTION QUANTITY
1 FLAT HEAD SCREW (3mm X 16mm) 13
2
FLAT HEAD SCREW (3mm X 25mm) 10
3
FLAT HEAD BOLT (6.35 mm X25) 21
4
FLAT HEAD BOLT (6.35 mm X12) 20
5
SHELF PIN WITH PLASTIC (
5mm X 16mm) 16
6
WOOD DOWEL (8mm X 30mm) 4
7
LED LIGHT 2
8
HINGES 4
9
ALLEN KEY 1
10
TOUCH-UP PEN 1
11
LONG BRACKET ( 68mm X 20mm X 25mm ) 1
1
37
6
4
2
9
11
10
8
12
12
FLAT HEAD SCREW ( 4mm X 16mm ) WHITE
8
5
2.2 HARDWARE LIST

EN
W415-1532 / A / 03.04.16
4
3.0 ASSEMBLY
X4
A
H
I
NOTE: Install media console on a level surface. Loosely secure bolts until
Step 4, then tighten. This ensures the media console is straight and level.
1
2

EN
W415-1532 / A / 03.04.16
5
K
M
O
N
X11
X8
J
F
X4
3
4

EN
W415-1532 / A / 03.04.16
6
X10
P
F
N
J
X12
X6
X8
3mm X 25mm
3mm X 16mm
5
6

EN
W415-1532 / A / 03.04.16
7
G
G
B
G
G
E
X16
LED X 1
X4
SCREWS X 2
(3mm X 16mm)
LED X 1
SCREWS X 2
(3mm X 16mm)
X8
4mm X 16mm
7

EN
W415-1532 / A / 03.04.16
8
APPLIANCE
3.1 APPLIANCE INSTALLATION
!
WARNING
DO NOT SLIDE APPLIANCE; MEDIA CONSOLE OR OTHER PAINTED
SURFACES MAY SCRATCH.
8
The bottom of the appliance has rivets which can scratch the painted surface of the media
console; have two people lift the appliance up and insert into the opening of the media
console.
APPLIANCE
Appliance secure bracket installation location.

EN
W415-1532 / A / 03.04.16
9
9
Secure bottom part of bracket using screw from step 9.
10
Remove screw from top centre of back of appliance. Do not discard.

EN
W415-1532 / A / 03.04.16
10
3.2 CARE AND MAINTENANCE
Clean media console with a non-abrasive cloth. Clean as often as necessary.
!
WARNING
DO NOT USE ABRASIVE OR CHEMICAL CLEANERS;
DISCOLOURING OR DAMAGE TO FINISH MAY RESULT.
NOTE: Excessive sun exposure may cause discolouring or fading of media console finish.
3mm X 16mm
SCREW
Secure top of bracket using screw from hardware kit.
11
